Running YARN alongside Mesos - MesosCon 2014

Almost anyone considering using Mesos in their datacenter, will come across a very interesting challenge, which is of running Mesos alongside YARN. Mesos and YARN are both resource managers, each with a unique architecture, protocol and ecosystem around them. Today, running these two alongside statically partitions the datacenter, something that both managers are designed to avoid, when they are the only resource manager in control. The slidedeck presents a novel solution that will allow Mesos and YARN to co-exist and share resources, without partitioning the datacenter.

mohit

August 21, 2014
Tweet

More Decks by mohit

Other Decks in Programming

Transcript

  1. M e s o s
    Running YARN alongside
    Mohit Soni
    ebay inc
    Renan DelValle
    SUNY Binghamton

    View Slide

  2. •  Cluster  manager
    •  Two  Level  Scheduler
    •  Supports  service  and  analy9cal  jobs
    About Mesos
    Mesos
    Node   Node   Node   Node
    Marathon   MPI   Spark   Aurora

    View Slide

  3. •  Resource  Nego9ator
    •  Single  level  scheduler
    •  Supports  different  types  of  analy9cal  jobs
    About YARN

    View Slide

  4. •  Independent  resource  managers  sta9cally  par99ons  datacenter
    •  Mesos  supports  long  running  services  and  analy9cs  workloads
    •  YARN  ecosystem  is  currently  around  analy9cs/data  processing

    Goal
    Share  resources  between  YARN  and  Mesos,  with  Mesos  being  the  resource  manager
    for  the  data  center.

    Solu'on  Characteris'cs
    •  Non-­‐intrusive,  avoids  modifying  Mesos  or  YARN  protocols
    •  Easy  future  upgrades
    •  Easier  cer9fica9on  path
    •  Use  YARN’s  scheduling  data,  for  providing  &  rescinding  resources  to  YARN
    Problem Statement

    View Slide

  5. YARN  Architecture  Overview
    Resource
    Manager
    YARN
    Node
    Node
    Manager
    YARN
    Node
    Node
    Manager
    YARN
    AppMaster   Container   Container
    Container

    View Slide

  6. How it works
    Resource
    Manager
    YARN
    Framework
    +
    Master
    Mesos
    Node
    Mesos
    Slave
    Mesos
    Control  Plane

    View Slide

  7. How it works
    Resource
    Manager
    YARN
    Framework
    +
    Master
    Mesos
    Node
    Mesos
    Slave
    Mesos
    Node
    Manager
    YARN
    Control  Plane
    2.5  CPU
    2.5  GB
    Launch
    NodeManager

    View Slide

  8. How it works
    Resource
    Manager
    YARN
    Framework
    +
    Master
    Mesos
    Node
    Mesos
    Slave
    Mesos
    Node
    Manager
    YARN
    Control  Plane
    2.5  CPU
    2.5  GB
    2.0  CPU
    2.0  GB

    View Slide

  9. How it works
    Resource
    Manager
    YARN
    Framework
    +
    Master
    Mesos
    Node
    C1
    C2
    Mesos
    Slave
    Mesos
    Node
    Manager
    YARN
    Control  Plane
    Launch  containers

    View Slide

  10. How it works
    cgroups  hierarchy
    /sys/fs/cgroup/cpu/mesos
    /
    /C1
    /C2
    Resource
    Manager
    YARN
    Framework
    +
    Master
    Mesos
    Node
    C1
    C2
    Mesos
    Slave
    Mesos
    Node
    Manager
    YARN
    Control  Plane
    /hadoop-­‐yarn

    View Slide

  11. Scenario 1: Handling Traffic Spikes
    Resource
    Manager
    YARN
    Framework
    +
    Master
    Mesos
    Hadoop  cluster  Node  1
    Control  Plane
    Hadoop  cluster  Node  2
    8  CPU
    8  GB
    8.5  CPU  /  8.5  GB   8.5  CPU  /  8.5  GB
    Traffic  spike  for
    ebay.com/sch
    Node
    Manager
    YARN
    Node
    Manager
    YARN
    8  CPU
    8  GB
    Slave
    Mesos
    Slave
    Mesos

    View Slide

  12. Scenario 1: Handling Traffic Spikes
    Resource
    Manager
    YARN
    Framework
    +
    Master
    Mesos
    Hadoop  cluster  Node  1
    Control  Plane
    Hadoop  cluster  Node  2
    8.5  CPU  /  8.5  GB   8.5  CPU  /  8.5  GB
    Traffic  spike  for
    ebay.com/sch
    6  CPU
    6  GB
    Node
    Manager
    YARN
    Slave
    Mesos
    Slave
    Mesos
    Resize  NodeManager
    6  CPU
    6  GB
    Node
    Manager
    YARN

    View Slide

  13. Scenario 1: Handling Traffic Spikes
    Resource
    Manager
    YARN
    Framework
    +
    Master
    Mesos
    Hadoop  cluster  Node  1
    Control  Plane
    Hadoop  cluster  Node  2
    8.5  CPU  /  8.5  GB   8.5  CPU  /  8.5  GB
    Service
    sch
    2  CPU
    2  GB
    Traffic  spike  for
    ebay.com/sch
    Service
    sch
    2  CPU
    2  GB
    6  CPU
    6  GB
    Node
    Manager
    YARN
    Slave
    Mesos
    Slave
    Mesos
    Deploy  sch
    6  CPU
    6  GB
    Node
    Manager
    YARN

    View Slide

  14. Scenario 1: Handling Traffic Spikes
    Resource
    Manager
    YARN
    Framework
    +
    Master
    Mesos
    Hadoop  cluster  Node  1
    Control  Plane
    Hadoop  cluster  Node  2
    8.5  CPU  /  8.5  GB   8.5  CPU  /  8.5  GB
    Service
    sch
    2  CPU
    2  GB
    ebay.com/sch
    survives
    Service
    sch
    2  CPU
    2  GB
    6  CPU
    6  GB
    Node
    Manager
    YARN
    Slave
    Mesos
    Slave
    Mesos
    6  CPU
    6  GB
    Node
    Manager
    YARN

    View Slide

  15. Scenario 1: Handling Traffic Spikes
    Resource
    Manager
    YARN
    Framework
    +
    Master
    Mesos
    Hadoop  cluster  Node  1
    Control  Plane
    Hadoop  cluster  Node  2
    8  CPU
    8  GB
    8.5  CPU  /  8.5  GB   8.5  CPU  /  8.5  GB
    Node
    Manager
    YARN
    Node
    Manager
    YARN
    8  CPU
    8  GB
    Slave
    Mesos
    Slave
    Mesos
    Restore  cluster

    View Slide

  16. YARN Pending Improvements
    •  Restar9ng  NodeManager,  kills  child  containers
    (YARN-­‐1336)
    •  Restar9ng  AppMaster,  kills  child  containers  across
    all  nodes  (YARN-­‐1489)
    •  NodeManager’s  pending  support  for  cgroups
    memory  subsystem
    •  Geeng  richer  scheduling  informa9on  from
    ResourceManager

    View Slide

  17. •  One  unified  cluster  per  datacenter
    •  YARN  and  Mesos  tasks  co-­‐exist  on  Nodes
    •  Provision  resources  on  demand.
    Future Vision
    Resource
    Manager
    YARN
    Framework
    +
    master
    Mesos
    Control  Plane
    Node   Node   Node   Node   Node   Node

    View Slide

  18. Scenario 2: Scaling YARN
    Resource
    Manager
    YARN
    Framework
    +
    master
    Mesos
    Node  1
    Control  Plane
    Node  2
    Service  X
    8  CPU  /  8  GB   8  CPU  /  8  GB
    2  CPU
    2  GB
    Service  Y
    6  CPU
    6  GB
    Service  X
    2  CPU
    2  GB
    4  CPU
    4  GB
    Node
    Manager
    YARN
    Slave
    Mesos
    Slave
    Mesos

    View Slide

  19. Scenario 2: Scaling YARN
    Resource
    Manager
    YARN
    Framework
    +
    master
    Mesos
    Node  1
    Control  Plane
    Node  2
    Service  X
    8  CPU  /  8  GB   8  CPU  /  8  GB
    2  CPU
    2  GB
    Service  X
    2  CPU
    2  GB
    4  CPU
    4  GB
    Node
    Manager
    YARN
    M R
    A
    User  Job
    Slave
    Mesos
    Slave
    Mesos
    Service  Y
    6  CPU
    6  GB

    View Slide

  20. Scenario 2: Scaling YARN
    Resource
    Manager
    YARN
    Framework
    +
    master
    Mesos
    Node  1
    Control  Plane
    Node  2
    Service  X
    8  CPU  /  8  GB   8  CPU  /  8  GB
    2  CPU
    2  GB
    Service  Y
    6  CPU
    6  GB
    Service  X
    2  CPU
    2  GB
    4  CPU
    4  GB
    Node
    Manager
    YARN
    M R
    User  Job
    A
    Slave
    Mesos
    Slave
    Mesos

    View Slide

  21. Scenario 2: Scaling YARN
    Resource
    Manager
    YARN
    Framework
    +
    master
    Mesos
    Node  1
    Control  Plane
    Node  2
    Service  X
    8  CPU  /  8  GB   8  CPU  /  8  GB
    2  CPU
    2  GB
    Service  Y
    6  CPU
    6  GB
    Service  X
    2  CPU
    2  GB
    4  CPU
    4  GB
    Node
    Manager
    YARN
    M R
    User  Job
    A
    Detects  starva9on
    Slave
    Mesos
    Slave
    Mesos

    View Slide

  22. Scenario 2: Scaling YARN
    Resource
    Manager
    YARN
    Framework
    +
    master
    Mesos
    Node  1
    Control  Plane
    Node  2
    Service  X
    8  CPU  /  8  GB   8  CPU  /  8  GB
    2  CPU
    2  GB
    Service  X
    2  CPU
    2  GB
    4  CPU
    4  GB
    Node
    Manager
    YARN
    M R
    User  Job
    A
    Slave
    Mesos
    Slave
    Mesos
    Preempt  Y

    View Slide

  23. Scenario 2: Scaling YARN
    Resource
    Manager
    YARN
    Framework
    +
    master
    Mesos
    Node  1
    Control  Plane
    Node  2
    Service  X
    8  CPU  /  8  GB   8  CPU  /  8  GB
    2  CPU
    2  GB
    Service  X
    2  CPU
    2  GB
    4  CPU
    4  GB
    Node
    Manager
    YARN
    M R
    User  Job
    A
    Slave
    Mesos
    Slave
    Mesos
    Launch  NodeManager
    4  CPU
    4  GB
    Node
    Manager
    YARN

    View Slide

  24. Scenario 2: Scaling YARN
    Resource
    Manager
    YARN
    Framework
    +
    master
    Mesos
    Node  1
    Control  Plane
    Node  2
    Service  X
    8  CPU  /  8  GB   8  CPU  /  8  GB
    2  CPU
    2  GB
    Service  X
    2  CPU
    2  GB
    4  CPU
    4  GB
    Node
    Manager
    YARN
    User  Job
    A
    Slave
    Mesos
    Slave
    Mesos
    4  CPU
    4  GB
    Node
    Manager
    YARN
    Schedule  M  and  R
    M
    R

    View Slide

  25. New YARN API (YARN-­‐2408)
    •  Resource  Requests  snapshot  API:
    •  Memory
    •  Virtual  Cores
    •  Locality  constraint
    •  REST  API  with  JSON  &  XML  output
    •  Non-­‐intrusive  –  simply  exposes
    more  informa9on  from  the
    Resource  Manager
    •  Helps  control  plane  decide
    NodeManager  sizing
    !
    96256!
    94!
    !
    application_!
    appattempt_!
    default!
    96256!
    94!
    3!
    !
    !
    1024!
    1!
    /default-rack!
    94!
    true!
    20!
    !
    !
    1024!
    1!
    *!
    94!
    true!
    20!
    !
    !
    1024!
    1!
    master!
    94!
    true!
    20!
    !
    !
    !
    !

    View Slide

  26. Design  scope:
    •  Flex  up  or  down,  ver9cally  or  horizontally?
    •  Determining  NodeManager  profile  for  flex  Up
    –  Small  (2  CPU,  4  GB  RAM),  OR  Large  (8  CPU,  24  GB  RAM)
    •  Choosing  NodeManager(s)  to  flex  down,
    avoiding  ones
    –  which  runs  AppMaster  container
    –  whose  child  containers  are  cri9cal  (ex:  HBase  zone  servers)
    Control Plane (Mesos Framework?)

    View Slide

  27. Thanks!

    View Slide

  28. Sample  Aurora  Job
    #imports
    pre_cleanup  =  Process(...)
    make_cgroups_dir  =  Process(...)

    configure_cgroups  =  Process(name  =  'configure_cgroups’,  cmdline  =  "MY_TASK_ID=`pwd  |  awk  -­‐F'/'  '{  print  $
    (NF-­‐1)  }'`  &&  echo  'hadoop'  |  sudo  -­‐S  sed  -­‐i  \"s@mesos.*/hadoop-­‐yarn@mesos/$MY_TASK_ID/hadoop-­‐yarn@g\"  /usr/
    local/hadoop/etc/hadoop/yarn-­‐site.xml")

    start  =  Process(name  =  'start’,  cmdline  =  "source  %s;  %s  start  nodemanager;  sleep  10;"  %  (BASHRC,
    YARN_DAEMONS))

    monitor  =  Process(name  =  'monitor’,  cmdline  =  "sleep  10;  PID=`cat  /tmp/yarn-­‐hduser-­‐nodemanager.pid`;  echo
    'Monitoring  nodemanager  pid:  '  ${PID};  while  [  -­‐e  /proc/${PID}  ];  do  sleep  1;  done")

    stop  =  Process(name  =  'stop',final  =  True,  cmdline  =  "source  %s;  %s  stop  nodemanager"  %  (BASHRC,
    YARN_DAEMONS))

    template_task  =  Task(
       processes  =  [pre_cleanup,  make_cgroups_dir,  configure_cgroups,  start,  monitor,  stop],
       constraints  =  order(pre_cleanup,  make_cgroups_dir,  configure_cgroups,  start,  monitor)  +  order(stop)
    )

    small_task  =  template_task(name  =  'small_task’,  resources  =  Resources(cpu=1.0,  ram=512*MB,  disk=2048*MB))

    large_task  =  template_task(name  =  'large_task’,  resources  =  Resources(cpu=2.0,  ram=2048*MB,  disk=2048*MB))

    jobs  =  [Service(task  =  large_task,  instances  =  instances,  cluster  =  'devcluster',
           role  =  ROLE,  environment  =  'devel',  name  =  'yarnlarge’)]

    #  Job  config,  for  a  small  task.
    #small_jobs  =  [Service(task  =  small_task,  instances  =  instances,  cluster  =  'devcluster',
           role  =  ROLE,  environment  =  'devel',  name  =  'yarnsmall’)]
