  1. © 2016 Mesosphere, Inc. All Rights Reserved. 1
    Apache Myriad
    (incubating)
    ApacheCon NA, May 2016
    Mohit Soni Adam Bordelon
    mohit@ me@

    View Slide

  2. © 2016 Mesosphere, Inc. All Rights Reserved. 2
    AGENDA
    • Why Myriad ?
    • What is Myriad ?
    • Scheduling Modes
    • Demo !
    Apache Mesos, Hadoop, and Myriad logos are trademarks of the Apache Software Foundation

    View Slide

  3. © 2016 Mesosphere, Inc. All Rights Reserved. 3
    WHY MYRIAD ?
    Mesos
    Agent Agent Agent
    Agent Agent Agent
    YARN
    NM NM NM
    NM NM NM
    Isolated clusters

    View Slide

  4. © 2016 Mesosphere, Inc. All Rights Reserved. 4
    UTILIZATION FLUCTUATES
    Server sprawl; Excess capacity

    View Slide

  5. © 2016 Mesosphere, Inc. All Rights Reserved. 5
    WHY MYRIAD ?
    Mesos
    Agent Agent Agent
    Agent Agent Agent
    YARN
    NM NM NM
    NM NM NM
    Isolated clusters

    View Slide

  6. © 2016 Mesosphere, Inc. All Rights Reserved. 6
    BREAKING SILOS
    Mesos
    Agent
    YARN
    Agent Agent
    Agent Agent Agent
    Agent Agent Agent
    Agent Agent Agent

    View Slide

  7. © 2016 Mesosphere, Inc. All Rights Reserved. 7
    THE PROBLEM WITH RESOURCE SILOS
    ● Overprovision to handle maximum capacity
    ● No elasticity to handle spikes/drops in load
    ● Hadoop and non-Hadoop services cannot co-locate
    ○ If they do, they need strong isolation
    ● Even test/prod Hadoop clusters don’t co-locate
    ○ Makes it difficult to share the data layer

    View Slide

  8. © 2016 Mesosphere, Inc. All Rights Reserved. 8
    AGENDA
    • Why Myriad ?
    • What is Myriad ?
    • Coarse vs Fine grained scheduling
    • Demo !

    View Slide

  9. © 2016 Mesosphere, Inc. All Rights Reserved. 9
    WHAT IS MYRIAD ?
    ● A framework that delegates resources between Apache
    Mesos and Apache YARN
    ○ Implements both Mesos Scheduler interface
    and YARN scheduler interface
    ○ Takes Mesos resource offers and launches/grows NMs
    ○ Can kill/shrink NMs to give resources back to Mesos
    ● With Myriad, Mesos is your datacenter’s kernel,
    and YARN is a managed service running on top of it

    View Slide

  10. © 2016 Mesosphere, Inc. All Rights Reserved. 10
    MYRIAD ARCHITECTURE
    YARN RM
    Mesos Scheduler
    Web Server

    View Slide

  11. © 2016 Mesosphere, Inc. All Rights Reserved. 11
    MYRIAD ARCHITECTURE
    Myriad/RM
    ZK
    Agent
    NM
    HDFS
    A
    B
    C
    Agent
    NM
    HDFS
    B
    C1
    C2
    Agent
    NM
    HDFS
    A
    B
    C3
    Mesos

    View Slide

  12. © 2016 Mesosphere, Inc. All Rights Reserved. 12
    AGENDA
    • Why Myriad ?
    • What is Myriad ?
    • Scheduling Modes
    • Demo !

    View Slide

  13. © 2016 Mesosphere, Inc. All Rights Reserved. 13
    SCHEDULING MODES
    ● Coarse-grained
    ● Fine-grained

    View Slide

  14. © 2016 Mesosphere, Inc. All Rights Reserved. 14
    COARSE GRAINED
    Myriad/RM
    Agent Agent
    Mesos
    Myriad API
    /api/flexup
    {“profile”: “medium”,
    “instances”: 1}
    HDFS HDFS

    View Slide

  15. © 2016 Mesosphere, Inc. All Rights Reserved. 15
    COARSE GRAINED
    Myriad/RM
    Agent Agent
    Mesos
    Myriad API
    /api/flexup
    {“profile”: “medium”,
    “instances”: 1}
    Offer
    HDFS HDFS

    View Slide

  16. © 2016 Mesosphere, Inc. All Rights Reserved. 16
    COARSE GRAINED
    Myriad/RM
    Agent Agent
    Mesos
    HDFS HDFS
    Executor NM

    View Slide

  17. © 2016 Mesosphere, Inc. All Rights Reserved. 17
    COARSE GRAINED
    Myriad/RM
    Agent Agent
    Mesos
    HDFS HDFS
    Executor NM
    Resources allocated for
    future YARN containers

    View Slide

  18. © 2016 Mesosphere, Inc. All Rights Reserved. 18
    FINE GRAINED
    Myriad/RM
    Agent Agent
    Mesos
    HDFS HDFS
    Executor NM
    Resources allocated for
    future YARN containers
    Myriad API
    /api/flexup
    {“profile”: “zero”,
    “instances”: 1}

    View Slide

  19. © 2016 Mesosphere, Inc. All Rights Reserved. 19
    FINE GRAINED
    Myriad/RM
    Agent Agent
    Mesos
    HDFS HDFS
    Executor NM
    Resources allocated for
    future YARN containers
    Myriad API
    /api/flexup
    {“profile”: “zero”,
    “instances”: 1}
    Executor NM
    No upfront resource
    allocation

    View Slide

  20. © 2016 Mesosphere, Inc. All Rights Reserved. 20
    SCHEDULING YARN TASKS
    Myriad/RM
    Agent Agent
    Mesos
    HDFS HDFS
    Executor NM
    YARN App
    Executor NM

    View Slide

  21. © 2016 Mesosphere, Inc. All Rights Reserved. 21
    COARSE GRAINED
    Myriad/RM
    Agent Agent
    Mesos
    HDFS HDFS
    Executor NM
    YARN App
    Executor NM
    C3
    C1 C2
    Containers
    launched
    using
    previously
    allocated
    resources

    View Slide

  22. © 2016 Mesosphere, Inc. All Rights Reserved. 22
    FINE GRAINED
    Myriad/RM
    Agent Agent
    Mesos
    HDFS HDFS
    Executor NM
    YARN App
    Executor NM
    C3
    C1 C2 Offer

    View Slide

  23. © 2016 Mesosphere, Inc. All Rights Reserved. 23
    FINE GRAINED
    Myriad/RM
    Agent Agent
    Mesos
    HDFS HDFS
    Executor NM
    YARN App
    Executor NM
    C3
    C1 C2
    C4 C5
    Containers
    launched when
    resources from
    this agent are
    offered to Myriad

    View Slide

  24. © 2016 Mesosphere, Inc. All Rights Reserved. 24
    TASKS COMPLETE
    Myriad/RM
    Agent Agent
    Mesos
    HDFS HDFS
    Executor NM Executor NM
    C3
    C4

    View Slide

  25. © 2016 Mesosphere, Inc. All Rights Reserved. 25
    TASKS COMPLETE
    Myriad/RM
    Agent Agent
    Mesos
    HDFS HDFS
    Executor NM Executor NM
    C3
    C4
    Freed resources remain
    allocated for future use
    Freed resources
    reclaimed by Mesos

    View Slide

  26. © 2016 Mesosphere, Inc. All Rights Reserved. 26
    ALL TASKS COMPLETE
    Myriad/RM
    Agent Agent
    Mesos
    HDFS HDFS
    Executor NM Executor NM
    Freed resources remain
    allocated for future use
    Freed resources
    reclaimed by Mesos

    View Slide

  27. © 2016 Mesosphere, Inc. All Rights Reserved. 27
    AGENDA
    • Why Myriad ?
    • What is Myriad ?
    • Scheduling Modes
    • Demo !

    View Slide

  28. © 2016 Mesosphere, Inc. All Rights Reserved. 28
    APACHE MESOS LOVES MYRIAD
    ● Support Hadoop2: Run any YARN app, e.g. Hive, Pig
    ● Sharing: Remove static partitioning, resource silos
    ○ Borrow YARN resources when Tier-1 services spike
    ○ Backfill unused capacity with best-effort Hadoop jobs
    ● Portable: Works with unmodified Mesos distro

    View Slide

  29. © 2016 Mesosphere, Inc. All Rights Reserved. 29
    APACHE HADOOP LOVES MYRIAD
    ● Elastic scaling: NM count and capacity
    ● Fault-tolerant: Maintain RM/NM capacity
    ● Cluster utilization: colocated services, shared resources
    ● Isolation: Cpu, memory, disk, network, gpus, etc.
    ● Multitenancy: many Hadoop clusters on one Mesos cluster
    ● Portable: Works with any modern Hadoop2 distro

    View Slide

  30. © 2016 Mesosphere, Inc. All Rights Reserved. 30
    FEATURES IN MYRIAD 0.1 (DEC 2015)
    ● Scale up/down NM capacity via REST API
    ● Remote Distribution of RM/NM binaries
    ● RM failure/discovery using Marathon/Mesos-DNS
    ● Myriad HA, Task reconciliation
    ● Job history server, Timeline server
    ● UX: REST API and WebUI

    View Slide

  31. © 2016 Mesosphere, Inc. All Rights Reserved. 31
    FEATURES IN MYRIAD 0.2 (~MAY 2016)
    ● Improved Fine-Grained Scaling
    ● CGroups fixes
    ● Dockerized NM
    ● Support for Mesosphere DC/OS

    View Slide

  32. © 2016 Mesosphere, Inc. All Rights Reserved. 32
    UPCOMING FEATURES
    ● Improved multitenancy
    ● Revocable resources, reservations
    ● Security integration
    ● Autoscaling policies (data locality, node drain)
    ● Docker networking, IP-per-container, etc.
    ● Queuing theory scheduling

    View Slide

  33. © 2016 Mesosphere, Inc. All Rights Reserved. 33
    RESOURCES
    ● http://myriad.incubator.apache.org
    [email protected]
    ● https://github.com/apache/incubator-myriad
    ● https://issues.apache.org/jira/browse/MYRIAD
