Jetpack Compose: UI toolkit for Android and Desktop apps

Jetpack Compose, the new UI toolkit by Google, has been in dev and alpha stage for more than a year and it is now in beta. Throught several live examples, let’s see how you can bring high quality UI to your Android application and how functional programming helped achieving such as thing. We will go even further and I’ll introduce Jetpack Compose for Desktop application where components from your Android app can be reused to keep the same quality of design design accross the platforms.

Transcript

1. Jetpack Compose:
   UI toolkit for Android
   and Desktop apps
   Julien Salvi - Android GDE | Lead Android Engineer @ Aircall
   DevFest Nantes 2021
   @JulienSalvi


   View Slide

2. Jetpack Compose
   introduction
   A declarative UI toolkit


   View Slide

3. - Me about Jetpack Compose
   Wow c’est trop stylé!


   View Slide

4. What’s Jetpack Compose?
   Jetpack Compose is a declarative UI framework
   made by Google. Stable since Aug. 2021.
   It is composed of a compiler, a runtime and a
   bunch of core UI libraries.
   Made with Kotlin.
   Nice interoperability with View UI framework.


   View Slide

5. Jetpack Compose
   Jetpack Compose
   1.0.0 🥳
   Jetpack Compose
   1.0.0-alpha-01
   2020
   Compose
   0.1.0-dev-01
   Compose Web
   preview
   2019 2021 2022
   Jetpack Compose
   1.0.0-beta-01
   Compose Desktop
   dev-01
   Compose Desktop
   and Web
   alpha


   View Slide

6. Jetpack Compose
   From XML/View to Compose
   XML layout Activity / Fragment / View




   setContentView(...)
   inflate(...)
   findViewById(...)


   View Slide

7. Jetpack Compose
   From XML/View to Compose
   XML layout Activity / Fragment / View




   setContentView(...)
   inflate(...)
   findViewById(...)
   title.text = ...
   desc.isVisible = ...
   group += View()
   a = MyAdapter()


   View Slide

8. Jetpack Compose
   From XML/View to Compose
   XML layout Activity / Fragment / View




   setContentView(...)
   inflate(...)
   findViewById(...)
   title.text = ...
   desc.isVisible = ...
   group += View()
   a = MyAdapter()
   STATE


   View Slide

9. Jetpack Compose
   From XML/View to Compose
   XML layout Activity / Fragment / View




   setContentView(...)
   inflate(...)
   findViewById(...)
   title.text = ...
   desc.isVisible = ...
   group += View()
   a = MyAdapter()
   STATE


   View Slide

10. Jetpack Compose
    From XML/View to Compose
    XML layout Activity / Fragment / View




    setContentView(...)
    inflate(...)
    findViewById(...)
    title.text = ...
    desc.isVisible = ...
    group += View()
    a = MyAdapter()
    STATE
    STATE
    STATE
    STATE
    STATE


    View Slide

11. Jetpack Compose
    From XML/View to Compose
    XML layout Activity / Fragment / View




    setContentView(...)
    inflate(...)
    findViewById(...)
    title.text = ...
    desc.isVisible = ...
    group += View()
    a = MyAdapter()
    STATE
    STATE
    STATE
    STATE
    STATE
    ⚠
    💥
    ⚠
    💥
    ⚠
    💥
    ⚠
    💥
    ⚠
    💥


    View Slide

12. Jetpack Compose
    From XML/View to Compose
    UI
    State
    UI 2
    State 2
    ?


    View Slide

13. Jetpack Compose
    Let’s explore the foundation of Compose:
    ● How Compose transforms a state to a UI component
    by demystifying the declarative paradigm
    ● How to make UI components: Composable
    ● What Compose has to offer as a UI Toolkit to build top
    notch apps on Android


    View Slide

14. Declarative UI
    ●
    Every Composable is a function
    annotated with @Composable
    ●
    You can split your UI into a set of
    tiny reusable components
    ●
    Produce and render components
    @Composable
    fun IngredientList(ingredients: List) {
    Column(modifier = modifier
    .fillMaxWidth()
    .wrapContentHeight()
    ) {
    Text(text = "Ingrédients")
    LazyRow {
    items(ingredients) { ing ->
    IngredientItem(ingredient = ing)
    }
    }
    }
    }


    View Slide

15. Declarative UI
    ●
    Basic conditions to show or hide
    UI components
    @Composable
    fun TwoPanel() {
    val threshold = density.run { 400.dp.toPx() }
    BoxWithConstraints {
    if (maxWidth.value > threshold) {
    TwoColumnsLayout()
    } else {
    HomeScreen()
    }
    }
    }


    View Slide

16. Declarative UI
    ●
    Basic conditions to show or hide
    UI components
    ●
    You can pass parameters to your
    Composable
    ●
    A change in these parameters will
    trigger the re-composition
    @Composable
    fun IngredientList(ingredients: List) {
    Column(modifier = modifier
    .fillMaxWidth()
    .wrapContentHeight()
    ) {
    Text(text = "Ingrédients")
    LazyRow {
    items(ingredients) { ing ->
    IngredientItem(ingredient = ing)
    }
    }
    }
    }


    View Slide

17. Declarative UI
    ●
    ViewModel can handle LiveData
    or StateFlow that can be bound
    and collected a Composable
    ●
    Every time a new state will be
    pushed it will re-compose the UI
    @Composable
    fun RecipeDetailsScreen(recipeId: Int) {
    val vm = hiltViewModel()
    val recipe = vm.recipe.collectAsState().value
    if (recipe.ingredients.isNotEmpty()) {
    IngredientList(
    ingredients = recipe.ingredients
    )
    }
    }


    View Slide

18. Declarative UI
    ●
    Composable are immutable...
    ●
    … but they can be dynamic!
    ●
    You can “remember” internal state
    in order to trigger local changes
    @Composable
    fun StepItem(step: Step) {
    var expand by remember{ mutableStateOf(false) }
    Text(
    text = step.desc,
    modifier =
    Modifier.clickable { expand = !expand },
    style = MaterialTheme.typography.body2,
    color = AppColorsTheme.colors.text,
    maxLines = if (expanded) MAX_VALUE else 3,
    overflow = if (expanded) Clip else Ellipsis
    )
    }


    View Slide

19. The UI Toolkit
    Think in Compose!


    View Slide

20. UI Toolkit
    ●
    Override MaterialTheme to
    define your default Typography,
    Shapes and Colors
    ●
    It has a great support for
    dark/light mode
    ●
    Replaces old XML styles for Views
    @Composable
    fun RecipeekTheme(
    darkTheme: Boolean = isSystemInDarkTheme(),
    content: @Composable () -> Unit
    ) {
    val colors = if (darkTheme) {
    DarkColorPalette
    } else {
    LightColorPalette
    }
    ProvideAppColors(colors) {
    MaterialTheme(
    colors = debugColors(darkTheme),
    typography = Typography,
    shapes = RecipeekShapes,
    content = content
    )
    }
    }


    View Slide

21. UI Toolkit
    ●
    Compose offers a large set of
    atomic components (Button,
    Text, TextField, Image…)
    ●
    As well as container (Box, Row,
    Column…) to organize your UI
    ●
    Multiple Modifier to construct
    your components
    Button(
    onClick = { onNavigateTo(recipe.id) },
    shape = MaterialTheme.shapes.medium,
    contentPadding = PaddingValues(0.dp),
    modifier = Modifier
    .fillMaxWidth()
    .wrapContentHeight()
    .background(
    color = AppColorsTheme.colors.main
    shape = MaterialTheme.shapes.medium
    )
    .padding(8.dp)
    )
    Column(modifier = modifier) {
    Text(
    text = "Préparation",
    style = MaterialTheme.typography.h5,
    color = AppColorsTheme.colors.text,
    )
    Spacer(modifier = Modifier.size(8.dp))
    steps.forEach { step ->
    StepItem(step = step)
    Spacer(modifier = Modifier.size(8.dp))
    }
    }


    View Slide

22. UI Toolkit
    ●
    Modifier allow you to shape your
    UI but also interact with your
    Compose (click, touch events…)
    ●
    When manipulating Modifer, keep
    in mind that the order matters!
    ●
    Use them wisely 🙂
    Text(
    text = "Some text",
    modifier = Modifier
    .fillMaxWidth()
    .padding(32.dp)
    .border(
    width = 4.dp,
    color = red700,
    shape = CutCornerShape(32.dp)
    )
    .graphicsLayer {
    shadowElevation = 8.dp.toPx()
    shape = CutCornerShape(32.dp)
    clip = true
    }
    .background(color = greenLight700)
    .padding(32.dp)
    )


    View Slide

23. UI Toolkit
    ●
    Use the @Preview annotation to
    have a sneak peek of your UI
    @MustBeDocumented
    @Retention(AnnotationRetention.SOURCE)
    @Target(
    AnnotationTarget.FUNCTION
    )
    @Repeatable
    annotation class Preview(
    val name: String = "",
    val group: String = "",
    @IntRange(from = 1) val apiLevel: Int = -1,
    val widthDp: Int = -1,
    val heightDp: Int = -1,
    val locale: String = "",
    @FloatRange(from = 0.01)
    val fontScale: Float = 1f,
    val showSystemUi: Boolean = false,
    val showBackground: Boolean = false,
    val backgroundColor: Long = 0,
    @UiMode val uiMode: Int = 0,
    @Device val device: String = Devices.DEFAULT
    )


    View Slide

24. UI Toolkit
    ●
    Use the @Preview annotation to
    have a sneak peek of your UI
    ●
    Customize your Previews by
    showing the system UI or by
    enabling the dark mode
    @Preview(
    showSystemUi = true,
    showBackground = true,
    uiMode = Configuration.UI_MODE_NIGHT_YES
    )
    @Composable
    fun StepPreview() {
    RecipeekTheme {
    val step = Step(
    position = 3,
    desc = "Lorem ipsum dolor sit amet"
    )
    StepItem(step = step)
    }
    }


    View Slide

25. UI Toolkit
    ●
    Use the @Preview annotation to
    have a sneak peek of your UI
    ●
    Customize your Previews by
    showing the system UI or by
    enabling the dark mode
    ●
    Mock your data to see it in
    action!


    View Slide

26. UI Toolkit
    ●
    Support for interoperability with
    the View framework
    ●
    Call Composable in View code
    val myComposeView =
    ComposeView(requireContext()).apply {
    // Dispose the Composition
    // when the view's LifecycleOwner is destroyed
    setViewCompositionStrategy(
    DisposeOnViewTreeLifecycleDestroyed
    )
    setContent {
    // Compose stuff
    MaterialTheme {
    Text("Hello DevFest Nantes!")
    }
    }
    }


    View Slide

27. UI Toolkit
    ●
    Support for interoperability with
    the View framework
    ●
    Call Composable in View code
    ●
    Call View code in Composable
    @Composable
    fun CustomView() {
    // Adds view to Compose
    AndroidView(
    modifier = Modifier.fillMaxSize(),
    factory = { context ->
    // Creates custom view
    CustomView(context).apply {
    // Setup your View here
    }
    },
    update = { view ->
    // Populate your view with new state
    // -> re-compose
    view.setStuff = newStuff()
    }
    )
    }


    View Slide

28. What’s next?
    source: https://developer.android.com/jetpack/compose


    View Slide

29. Jetpack Compose
    Live coding!
    Let’s code a small recipe app 🍱
    ⚠ Architecture in MVC (Model-View-Crado) ⚠


    View Slide

30. Compose Android
    Let’s build a small list/detail app: RECIPEEK
    On the main screen we’ll have a Toolbar, a search
    bar and a list of recipes with some information
    What we’re going to learn:
    - Modifier
    - LazyColumn
    - State
    - Theming
    https://github.com/oleur/recipeek


    View Slide

31. Compose Android
    On the recipe details screen we’ll have a look at
    more Modifiers and how to place Composables
    and add some nice Animations.
    What we’re going to learn:
    - More Modifiers
    - Shapes
    - ConstraintLayout Compose
    - State
    - Animations


    View Slide

32. Compose Desktop
    (Almost the)
    Same but on desktop!


    View Slide

33. Compose Desktop
    Developed and maintained by JetBrains based on
    Jetpack Compose for Android
    Uses Skia for a power rendering
    Desktop extensions for mouse/keyboard events,
    menus, window manipulation...
    AWT and Swing interoperability


    View Slide

34. Compose for Desktop
    Live coding!
    Let’s bring our recipe app to desktop 🍱
    ⚠ Architecture in MVC (Model-View-Crado) ⚠


    View Slide

35. Compose Desktop
    With the desktop version of the app we’ll see
    how to adapt Compose Android code to
    make it work on desktop.
    What we’re going to learn:
    - Desktop Modifiers
    - Theme for Desktop
    - Layouts
    - State
    - Animations
    https://github.com/oleur/Recipeek-desktop


    View Slide

36. Compose Multiplatform
    If you want to maintain only one code base to develop
    your app for Android, Desktop or iOS you might want to
    take a look at Kotlin Multiplatform.
    Some Compose tools are only supported on Android
    (ConstraintLayout, Lifecycle, Coil…)
    Developing for desktop might take a bit longer than
    Android as the library ecosystem is not as rich as
    Android yet.


    View Slide

37. Resources
    Compose for Android
    Official Documentation
    https://developer.android.com/jetpack/compose
    Compose Codelabs
    https://codelabs.developers.google.com/?cat=android
    Code Samples
    https://github.com/android/compose-samples
    Recipeek
    https://github.com/oleur/Recipeek


    View Slide

38. Resources
    Compose Desktop & Web
    Official Documentation
    https://www.jetbrains.com/lp/compose/
    Sources, Samples & Tutorials
    https://github.com/jetbrains/compose-jb
    Recipeek Desktop
    https://github.com/oleur/Recipeek-desktop


    View Slide

39. Resources
    The recipes
    Coming soon or ask me later 😅


    View Slide

40. Merci!
    Julien Salvi - Android GDE | Lead Android Engineer @ Aircall
    DevFest Nantes 2021
    @JulienSalvi
    Have fun with Jetpack Compose!


    View Slide
