Software Quality Days 2023 - Common Cloud Migration Pain Points and how to overcome them - based on practical Experience

here are different obstacles and challenges which you’re facing when starting almost from scratch with the cloud migration of your application. They are related to architectural aspects: what about the structure, what about the components, which have to be provisioned and hosted in the cloud? Which services of the cloud provider should be used: e.g.: Serverless services or a Kubernetes service?

They are related to technical issues - probably common mistakes: inappropriate deployment rules of workloads, scheduling problems of Kubernetes pods...

They can be referred to financial aspects: what costs arise by hosting the application in the cloud? How can they get monitored, respectivelly estimated?

We'd like to reveal our approaches to overcome those issues, based on practical experience.

Transcript

1. Public
   Common Cloud Migration Pain
   Points and how to overcome them
   based on practical experience
   Patrick Koch


   View Slide

2. Public
   Introduction


   View Slide

3. Patrick Koch | | 24 May 2023 |
   / 3
   Public


   View Slide

4. Patrick Koch | | 24 May 2023 |
   / 4
   Public
   What happened before the cloud?
   Once upon a time ... and it‘s still
   1
   AVL and the legacy software application
   2
   Introduction
   Today’s Agenda
   3
   Omg, what do we need to do?
   Why do we need to migrate to
   the cloud?
   Conclusion
   5
   The pain points
   Of course, we didn‘t avoid making
   mistakes ;)
   4
   Q&A
   6


   View Slide

5. Patrick Koch | | 24 May 2023 |
   / 5
   Public
   AVL List GmbH
   Founded 1948
   More than 11,000 worldwide
   4,000 in Graz (headquarters)
   45 affiliates worldwide
   Export quota of 97%
   AVL List GmbH (“AVL”) is the world’s largest independent company for development,
   simulation and testing in the automotive industry, and in other sectors. Drawing on its
   pioneering spirit, the company provides concepts, solutions and methodologies to shape future
   mobility trends.”


   View Slide

6. Patrick Koch | | 24 May 2023 |
   / 6
   Public
   Evolved to
   platform product
   Container,
   K8s
   Automation
   Framework
   Web
   components
   Started >
   25 years
   ago
   Python support
   REST interface
   2014
   New Generation
   (unmanaged legacy (C++) and
   managed (C#) code).
   Windows®
   application
   (component & full integration in
   internal products)
   2018
   ~ 8200 files
   ~ 2,9 Mio LOC
   Linux components
   (data, Python)
   2022 ...
   “A legacy system is outdated computing
   software and/or hardware that is still in use. ”
   ~ 800 customers
   ~ 23000 users
   The application to migrate in the cloud: AVL CONCERTO


   View Slide

7. Public
   Once upon a time ...
   What happened before
   the cloud?


   View Slide

8. Patrick Koch | | 24 May 2023 |
   / 8
   Public


   View Slide

9. Patrick Koch | | 24 May 2023 |
   / 9
   Public
   Data Processing with the Desktop Application


   View Slide

10. Public
    Why do we need to migrate to the cloud…


    View Slide

11. Patrick Koch | | 24 May 2023 |
    / 11
    Public
    An evolution happens – why even more automation, and more data?
    2021 ..
    Huge testbed for single unit under test (UUT)
    1 Operator per testbed
    Very high costs
    Exchanging of unit is labour-intesive
    One testing unit for multiple UUTs (Battery Cells)
    1 Operator for whole lab
    Costs per UUT are much lower
    UUT exchange works automated
    2021 ..


    View Slide

12. Public
    The Pain Points


    View Slide

13. Patrick Koch | | 24 May 2023 |
    / 13
    Public
    Cloud Migration Strategy
    Pain Point 1


    View Slide

14. Patrick Koch | | 24 May 2023 |
    / 14
    Public
    Cloud Migration Strategy
    Decide for a strategy before starting the
    implementation
    Lift & Shift (Rehost)
    Whole application is taken
    and pushed into container
    not possible / would
    cause to much costs
    Refactoring
    Rebuild


    View Slide

15. Patrick Koch | | 24 May 2023 |
    / 15
    Public
    Pain Point 2
    Starting with a too complex
    implementation


    View Slide

16. Patrick Koch | | 24 May 2023 |
    / 16
    Public
    Lift and shift to container using Azure Kubernetes Service
    Source: https://docs.microsoft.com/de-de/azure/architecture/solution-ideas/articles/migrate-existing-applications-with-aks
    “Easily migrate existing application to container(s) and run within the Azure managed Kubernetes service (AKS)”


    View Slide

17. Patrick Koch | | 24 May 2023 |
    / 17
    Public
    The goal of the first implementation
    Azure Container
    Registry
    Azure Kubernetes
    Service
    Azure Virtual Machine
    Azure File Share
    Container
    1
    2
    3
    4


    View Slide

18. Patrick Koch | | 24 May 2023 |
    / 18
    Public
    The faults
    1. ACR not properly attached with AKS
    2. Missing statements in Workload
    3. Wrong Firewall Settings


    View Slide

19. Patrick Koch | | 24 May 2023 |
    / 19
    Public
    The faults
    1. ACR not properly attached with AKS
    2. Missing statements in Workload
    3. Wrong Firewall Settings
    nodeSelector:
    kubernetes.io/os: windows
    tolerations:
    - key: "kubernetes.io/os"
    operator: "Equal"
    value: "windows"
    effect: "NoSchedule"
    restartPolicy: Never
    backoffLimit: 4


    View Slide

20. Patrick Koch | | 24 May 2023 |
    / 20
    Public
    The faults
    1. ACR not properly attached with AKS
    2. Missing statements in Workload
    3. Wrong Firewall Settings


    View Slide

21. Patrick Koch | | 24 May 2023 |
    / 21
    Public
    Start lightweight: use e.g. a Serverless Service
    Azure Container Instance


    View Slide

22. Patrick Koch | | 24 May 2023 |
    / 22
    Public
    Pain Point 3
    Manual Provisioning


    View Slide

23. Patrick Koch | | 24 May 2023 |
    / 23
    Public
    Manual Provisioning of the resources
    e.g.: Creating a Kubernetes Cluster in Azure
    Can you
    reproduce your
    environment
    after the
    destruction?


    View Slide

24. Patrick Koch | | 24 May 2023 |
    / 24
    Public
    Use Infrastructure as Code Approach
    Terraform
    Configuration File
    Azure Kubernetes
    Service


    View Slide

25. Patrick Koch | | 24 May 2023 |
    / 25
    Public
    Pain Point 4
    Costs


    View Slide

26. Patrick Koch | | 24 May 2023 |
    / 26
    Public


    View Slide

27. Patrick Koch | | 24 May 2023 |
    / 27
    Public
    Estimate the costs using tools


    View Slide

28. Patrick Koch | | 24 May 2023 |
    / 28
    Public
    Automated Resource Provisioning in Azure with ADO
    Pipelines and Terraform
    Terraform Configurations Azure
    Azure DevOps Pipeline


    View Slide

29. Patrick Koch | | 24 May 2023 |
    / 29
    Public
    Data Processing using an automated way in Azure


    View Slide

30. Patrick Koch | | 24 May 2023 |
    / 30
    Public
    Conclusion
    Decide for a Cloud
    Migration Strategy
    Avoid to start with a
    too complex
    implementation – start
    lightweight
    Don‘t do manual
    provisioning – use
    Infrastructure as Code
    approach
    Be aware of the costs,
    monitor them


    View Slide

31. Public
    Thank you!


    View Slide
