1. 2020/10/10 @phalanx
   journal part
   Gaussian Vector: An Efficient Solution for
   Facial Landmark Detection


   View Slide

2. Journal Information
   Title: Gaussian Vector: An Efficient Solution for Facial Landmark Detection
   author: Yilin Xiong, Zijian Zhou, Yuhao Dou, Zhizhong Su (Horizon Robotics)
   arxiv: https://arxiv.org/abs/2010.01318
   submit date: 2020/10/03


   View Slide

3. - Facial landmark detection is a fundamentally step in many face applications
   - face recognition, face tracking, face editing
   - Challenge
   - blur, overlap, occlusion, illumination
   - large head pose variation
   Aggregation via Separation: Boosting Facial Landmark Detector with Semi-Supervised Style Translation, in Proc. of ICCV, 2019
   Facial Landmark Detection


   View Slide

4. Coordinate regression method
   - Fully connected layers predict facial landmark coordinates
   - Performance degradation due to spatial information loss
   Facial landmark detection by deep multi task learning, In European conference on computer vision, Springer (2014) 90-108


   View Slide

5. - Predict heatmap where each pixel predicts the probability that it is landmark
   - By utilizing spatial information, it boost the performance compared with
   coordinate regression method
   Heatmap based method


   View Slide

6. Heatmap based method
   - Stacked Hourglass
   - supervised transformation to remove translation
   - stack multiple hourglass modules to extract multi-scale discriminative feature
   Jing Yang, Oingshan Liu, Kaihua Zhang, “Stacked Hourglass Network for Robust Facial Landmark Localisation”, in Proc. of CVPR, 2017


   View Slide

7. - Wing Loss
   - pay more attention to small and medium range errors
   - switching from L1 loss to modified logarithm function
   Zhen-Hua Feng , et al, “Wing Loss for Robust Facial Landmark Localization with Convolutional Neural Networks”, in Proc. of CVPR, 2018
   Heatmap based method


   View Slide

8. - Adaptive Wing Loss
   - adapt loss curvature to ground truth pixel values
   - it can focus on foreground and hard background pixels
   Xinyao Eang, Liefeng Bo, Fuxin Li, “Adaptive Wing Loss for Robust Face Alignment via Heatmap Regression”, in Proc. of CoRR, 2019
   Heatmap based method


   View Slide

9. Heatmap based method
   - Large output heatmap and complicated postprocess cause heavy burden of
   data transmission and computation in embedded system
   - Foreground-Background imbalance problem
   - Spatial information is not fully used, causing detection error
   - Imperfect face detection result in some of the facial landmarks out of bbox


   View Slide

10. Proposed method
    - Gaussian Vector
    - encode face landmark into vector as supervision
    - accelerates the label preparing and extreme foreground-background problem
    - reduce system complexity including postprocess
    - Band Pooling Module
    - convert hxw output heatmap into hx1 and wx1 vectors as prediction
    - take more spatial information into account yet outputs smaller tensor


    View Slide

11. Gaussian Vector Label
    - calculate Euclidean distance between each pixel and landmark
    - transform the distance vector to vector label
    - σ: standard deviation
    - θ: positive constant to reinforce the distribution peak


    View Slide

12. Band Pooling Module (BPM)
    - consist of horizontal band and vertical band [L, w] and horizontal band [L, h]
    - L: adjustable bandwidth, which controls the receptive field size of vector elements
    - much smaller odd number, chosen from 1 to 7
    - each band slide on the heatmap and average the values
    - converting into vector reduce post-processing complexity: O(N^2) -> O(N)
    - output: [N, C, w/h, 2]
    - C: number of facial landmark
    - Aggregated
    - fusing the vectors generated by different bandwidth
    - use this method for experiments
    - bandwidth: 3 and 5


    View Slide

13. Beyond Box Strategy
    - strategy to predict landmarks located in out of bbox
    - landmark location
    - inside: maximum position of predicted vector is in the middle of the vector
    - outside: maximum is close to one of the endpoints
    - assume predicted vectors obey the distribution when landmark is outside
    - Γ: scale parameter
    - d: distance between s and peak


    View Slide

14. Beyond Box Strategy
    - From the assumption, we can get the revised landmark location


    View Slide

15. Experiments: Datasets
    300W (ICCV’13)
    - benchmark challenge dataset for ICCV 2013
    - training data include LFPW, AFW, HELEN, and IBUG datasets
    - re-annotated with semi-supervised learning
    - 3837 images, utilize 3148 images for train and 689 images for val in many previous works
    - test data is newly collected (300 indoor and 300 outdoor)
    - 68 landmark points


    View Slide

16. Experiments: Datasets
    COFW (Caltech Occluded Faces in the Wild) (ICCV’13)
    - large variations in shape and occlusion
    - train data: 1354 images
    - test data: 507 images
    - 29 landmark points consistent with LFPW


    View Slide

17. Experiments: Datasets
    WFLW (Wider Facial Landmarks in-the-wild) (CVPR’18)
    - include extreme disturbance
    - train data: 7500 images
    - test data: 2500 images
    - 98 landmark points


    View Slide

18. JD-landmark (ICME’19)
    - benchmark challenge dataset in ICME 2019
    - train data: 11393 images
    - val/test data: 2000 images
    - 106 landmark points
    Experiments: Datasets


    View Slide

19. - Normalized Mean Error (NME)
    - average the Euclidean distance between predicted and ground truth landmarks
    - normalized to eliminate the impact caused by the image size inconsistency
    - d: normalization factor
    - Failure Rate (FR)
    - percentage of failure samples whose NME is larger than a threshold
    - Area Under Curve (AUC)
    - calculates the area under the cumulative error distribution (CED) curve
    Experiments: Evaluation Metrics


    View Slide

20. - For face bbox, extend short side to the same as the long
    - enlarge bbox in WFLW and COFW by 25% and 10%
    - crop image and resize to 256x256
    - augmentation
    - random rotate/scale/occlusion, hflip
    - Adam optimizer
    - backbone: ResNet50, HRNet
    - 4x TITAN X GPUs
    Experiments: implementation setup


    View Slide

21. Main Result


    View Slide

22. JD-landmark challenge
    - Single model achieve comparable results to the champion
    - Baidu VIS
    - AutoML for architecture search
    - ensemble model
    - well-designed augmentation


    View Slide

23. - dataset: 300W
    - Table5
    - left: compare heatmap based method and proposed method
    - right: shrink the GT bbox by 10% in each dimension and compare w/wo BBS
    Effectiveness of BPM/BBS


    View Slide

24. - use MobileNetV3 for the limitation of the practical system
    - proposed method saves 26% time of whole process
    Time cost analysis


    View Slide

25. Thank you!
    Question?
