LaCasa: Lightweight Affinity and Object Capabilities in Scala

Transcript

1. LaCasa:
   Lightweight Affinity and Object
   Capabilities in Scala
   1
   Philipp Haller1 and Alex Loiko2*
   OOPSLA 2016
   Amsterdam, Netherlands
   November 2nd, 2016
   1 KTH Royal Institute of Technology, Sweden
   2 Google Stockholm, Sweden
   * Work done while at KTH


   View Slide

2. Context: Concurrent
   Programming in Scala
   • Scala = “Scalable Language”
   • cf. Guy Steele. Growing a Language. OOPSLA ’98 keynote
   • Concurrency models as libraries
   • Flexible extension and adaptation
   • Reuse of compilers, debuggers, and IDEs
   2


   View Slide

3. Context: Concurrent
   Programming in Scala
   • Scala = “Scalable Language”
   • cf. Guy Steele. Growing a Language. OOPSLA ’98 keynote
   • Concurrency models as libraries
   • Flexible extension and adaptation
   • Reuse of compilers, debuggers, and IDEs
   2
   Do not have to guess the answer to the question:
   Which concurrency model is going to “win”?


   View Slide

4. Background
   • Authored or co-authored:
   • Scala Actors (2006)
   • Scala Joins (2008)
   • Scala futures (2012)
   • FlowPools (2012)
   • Scala Async (2013)
   • Contributions to Akka, Akka.js projects at Typesafe
   3
   Haller and Sommers
   Artima Press, 2012


   View Slide

5. Background
   • Authored or co-authored:
   • Scala Actors (2006)
   • Scala Joins (2008)
   • Scala futures (2012)
   • FlowPools (2012)
   • Scala Async (2013)
   • Contributions to Akka, Akka.js projects at Typesafe
   3
   Haller and Sommers
   Artima Press, 2012
   Production use
   at Twitter, The Guardian
   and others


   View Slide

6. Background
   • Authored or co-authored:
   • Scala Actors (2006)
   • Scala Joins (2008)
   • Scala futures (2012)
   • FlowPools (2012)
   • Scala Async (2013)
   • Contributions to Akka, Akka.js projects at Typesafe
   3
   Haller and Sommers
   Artima Press, 2012
   Production use
   at Twitter, The Guardian
   and others
   Production use at
   LinkedIn, The Huffington Post
   and others


   View Slide

7. Background
   • Authored or co-authored:
   • Scala Actors (2006)
   • Scala Joins (2008)
   • Scala futures (2012)
   • FlowPools (2012)
   • Scala Async (2013)
   • Contributions to Akka, Akka.js projects at Typesafe
   3
   Haller and Sommers
   Artima Press, 2012
   Production use
   at Twitter, The Guardian
   and others
   Production use
   at Morgan Stanley,
   Gawker and others
   Production use at
   LinkedIn, The Huffington Post
   and others


   View Slide

8. Background
   • Authored or co-authored:
   • Scala Actors (2006)
   • Scala Joins (2008)
   • Scala futures (2012)
   • FlowPools (2012)
   • Scala Async (2013)
   • Contributions to Akka, Akka.js projects at Typesafe
   3
   Haller and Sommers
   Artima Press, 2012
   Production use
   at Twitter, The Guardian
   and others
   Production use
   at Morgan Stanley,
   Gawker and others
   Production use at
   LinkedIn, The Huffington Post
   and others
   The programming-models-as-libraries
   approach has been successful in Scala!


   View Slide

9. Problem
   • Problem:
   Scala cannot ensure concurrency safety for
   library-based concurrency abstractions
   • This also applies to Java, C++, and most other
   widely-used programming languages
   4


   View Slide

10. Goal
    5


    View Slide

11. Goal
    Static prevention of data races
    5


    View Slide

12. Goal
    Static prevention of data races
    • using a lightweight type system
    5


    View Slide

13. Goal
    Static prevention of data races
    • using a lightweight type system
    • that minimizes the effort to reuse existing code
    5


    View Slide

14. Goal
    Static prevention of data races
    • using a lightweight type system
    • that minimizes the effort to reuse existing code
    Focus:
    5


    View Slide

15. Goal
    Static prevention of data races
    • using a lightweight type system
    • that minimizes the effort to reuse existing code
    Focus:
    • Existing, full-featured languages like Scala
    5


    View Slide

16. Goal
    Static prevention of data races
    • using a lightweight type system
    • that minimizes the effort to reuse existing code
    Focus:
    • Existing, full-featured languages like Scala
    5
    In contrast to new
    language designs like Rust


    View Slide

17. Isn’t it a Solved Problem?
    6


    View Slide

18. Isn’t it a Solved Problem?
    • A lot of progress in type systems for safe concurrency
    (linear and affine types, static capabilities, uniqueness
    types, ownership types, region inference, etc.)
    6


    View Slide

19. Isn’t it a Solved Problem?
    • A lot of progress in type systems for safe concurrency
    (linear and affine types, static capabilities, uniqueness
    types, ownership types, region inference, etc.)
    • Challenges:
    6


    View Slide

20. Isn’t it a Solved Problem?
    • A lot of progress in type systems for safe concurrency
    (linear and affine types, static capabilities, uniqueness
    types, ownership types, region inference, etc.)
    • Challenges:
    • Sound integration with advanced type system
    features
    6


    View Slide

21. Isn’t it a Solved Problem?
    • A lot of progress in type systems for safe concurrency
    (linear and affine types, static capabilities, uniqueness
    types, ownership types, region inference, etc.)
    • Challenges:
    • Sound integration with advanced type system
    features
    6
    Example: local type
    inference


    View Slide

22. Isn’t it a Solved Problem?
    • A lot of progress in type systems for safe concurrency
    (linear and affine types, static capabilities, uniqueness
    types, ownership types, region inference, etc.)
    • Challenges:
    • Sound integration with advanced type system
    features
    • Adoption on large scale
    6
    Example: local type
    inference


    View Slide

23. Isn’t it a Solved Problem?
    • A lot of progress in type systems for safe concurrency
    (linear and affine types, static capabilities, uniqueness
    types, ownership types, region inference, etc.)
    • Challenges:
    • Sound integration with advanced type system
    features
    • Adoption on large scale
    • Key: reuse of existing code
    6
    Example: local type
    inference


    View Slide

24. Example
    data
    7


    View Slide

25. Example
    data
    apply filter
    7


    View Slide

26. Example
    data
    apply filter
    7


    View Slide

27. Example
    data
    apply filter
    Image processing pipeline:
    filter 1 filter 2
    7


    View Slide

28. Example
    data
    apply filter
    Image processing pipeline:
    filter 1 filter 2
    7
    Pipeline stages
    run concurrently


    View Slide

29. Example: Implementation
    8


    View Slide

30. Example: Implementation
    • Assumptions:
    • Main memory expensive (image data large)
    8


    View Slide

31. Example: Implementation
    • Assumptions:
    • Main memory expensive (image data large)
    • Approach for high performance:
    • In-place update of image buffers
    • Pass mutable buffers by-reference
    8


    View Slide

32. Example: Problem
    Easy to produce data races:
    1. Stage 1 sends a reference to a buffer to stage 2
    2. Following the send, both stages have a reference
    to the same buffer
    3. Stages can concurrently access the buffer
    9


    View Slide

33. Preventing Data Races
    10


    View Slide

34. Preventing Data Races
    • Approach: safe transfer of ownership
    • Sending stage loses ownership
    • Type system prevents sender from accessing
    transferred objects
    10


    View Slide

35. Preventing Data Races
    • Approach: safe transfer of ownership
    • Sending stage loses ownership
    • Type system prevents sender from accessing
    transferred objects
    • Advantages:
    • No run-time overhead
    • Errors caught at compile time
    10


    View Slide

36. Ownership Transfer in Scala
    11


    View Slide

37. Ownership Transfer in Scala
    • Enter LaCasa: Affine references for Scala
    11


    View Slide

38. Ownership Transfer in Scala
    • Enter LaCasa: Affine references for Scala
    • “Transferable” references
    11


    View Slide

39. Ownership Transfer in Scala
    • Enter LaCasa: Affine references for Scala
    • “Transferable” references
    • At most one owner per transferable reference
    11


    View Slide

40. Ownership Transfer in Scala
    • Enter LaCasa: Affine references for Scala
    • “Transferable” references
    • At most one owner per transferable reference
    • LaCasa combines two concepts:
    11


    View Slide

41. Ownership Transfer in Scala
    • Enter LaCasa: Affine references for Scala
    • “Transferable” references
    • At most one owner per transferable reference
    • LaCasa combines two concepts:
    • Access permissions
    11


    View Slide

42. Ownership Transfer in Scala
    • Enter LaCasa: Affine references for Scala
    • “Transferable” references
    • At most one owner per transferable reference
    • LaCasa combines two concepts:
    • Access permissions
    • Encapsulated boxes
    11


    View Slide

43. Access Permissions
    12


    View Slide

44. Access Permissions
    • Permissions control access to transferable objects
    12


    View Slide

45. Access Permissions
    • Permissions control access to transferable objects
    CanAccess { type C }
    12


    View Slide

46. Access Permissions
    • Permissions control access to transferable objects
    • Type member C uniquely identifies box
    CanAccess { type C }
    12


    View Slide

47. Access Permissions
    • Permissions control access to transferable objects
    • Type member C uniquely identifies box
    CanAccess { type C }
    Box[T] { type C }
    12


    View Slide

48. Matching Boxes and
    Permissions
    • Type members match permissions and boxes
    • Via path-dependent types
    • Example:
    def method[T](box: Box[T])
    (implicit p: CanAccess { type C = box.C }): Unit
    13


    View Slide

49. Matching Boxes and
    Permissions
    • Type members match permissions and boxes
    • Via path-dependent types
    • Example:
    def method[T](box: Box[T])
    (implicit p: CanAccess { type C = box.C }): Unit
    13


    View Slide

50. Creating Boxes and
    Permissions
    14


    View Slide

51. Creating Boxes and
    Permissions
    class Message {
    var arr: Array[Int] = _
    }
    14


    View Slide

52. Creating Boxes and
    Permissions
    mkBox[Message] { packed =>
    }
    class Message {
    var arr: Array[Int] = _
    }
    14


    View Slide

53. Creating Boxes and
    Permissions
    mkBox[Message] { packed =>
    }
    class Message {
    var arr: Array[Int] = _
    }
    14
    LaCasa
    library


    View Slide

54. Creating Boxes and
    Permissions
    mkBox[Message] { packed =>
    }
    class Message {
    var arr: Array[Int] = _
    }
    14


    View Slide

55. Creating Boxes and
    Permissions
    mkBox[Message] { packed =>
    }
    class Message {
    var arr: Array[Int] = _
    }
    sealed trait Packed[+T] {
    val box: Box[T]
    val access: CanAccess { type C = box.C }
    }
    14


    View Slide

56. Creating Boxes and
    Permissions
    mkBox[Message] { packed =>
    }
    class Message {
    var arr: Array[Int] = _
    }
    14


    View Slide

57. Creating Boxes and
    Permissions
    mkBox[Message] { packed =>
    }
    class Message {
    var arr: Array[Int] = _
    }
    implicit val access = packed.access
    val box = packed.box
    …
    14


    View Slide

58. Accessing Boxes
    • Boxes are encapsulated
    • Boxes must be opened for access
    15


    View Slide

59. Accessing Boxes
    • Boxes are encapsulated
    • Boxes must be opened for access
    mkBox[Message] { packed =>
    implicit val access = packed.access
    val box = packed.box
    box open { msg =>
    msg.arr = Array(1, 2, 3, 4)
    }
    }
    15


    View Slide

60. Accessing Boxes
    • Boxes are encapsulated
    • Boxes must be opened for access
    mkBox[Message] { packed =>
    implicit val access = packed.access
    val box = packed.box
    box open { msg =>
    msg.arr = Array(1, 2, 3, 4)
    }
    }
    Requires implicit
    access permission
    15


    View Slide

61. Accessing Boxes
    • Boxes are encapsulated
    • Boxes must be opened for access
    mkBox[Message] { packed =>
    implicit val access = packed.access
    val box = packed.box
    box open { msg =>
    msg.arr = Array(1, 2, 3, 4)
    }
    }
    15


    View Slide

62. Consuming Permissions
    Example: transfering a box from one actor to
    another consumes its access permission
    16


    View Slide

63. Consuming Permissions
    Example: transfering a box from one actor to
    another consumes its access permission
    mkBox[Message] { packed =>
    implicit val access = packed.access
    val box = packed.box
    …
    someActor.send(box)
    // illegal to access `box` here!
    }
    16


    View Slide

64. Consuming Permissions
    Example: transfering a box from one actor to
    another consumes its access permission
    mkBox[Message] { packed =>
    implicit val access = packed.access
    val box = packed.box
    …
    someActor.send(box)
    // illegal to access `box` here!
    }
    16
    How to
    enforce this?


    View Slide

65. Permissions and
    Continuations
    17


    View Slide

66. Permissions and
    Continuations
    • Make implicit permission unavailable in
    continuation of permission-consuming call
    17


    View Slide

67. Permissions and
    Continuations
    • Make implicit permission unavailable in
    continuation of permission-consuming call
    • Scala’s type system is flow-insensitive => use
    continuation passing
    17


    View Slide

68. Permissions and
    Continuations
    • Make implicit permission unavailable in
    continuation of permission-consuming call
    • Scala’s type system is flow-insensitive => use
    continuation passing
    • Restrict continuation to exclude consumed
    permission
    17


    View Slide

69. Continuation-Passing Style
    mkBox[Message] { packed =>
    implicit val access = packed.access
    val box = packed.box
    …
    someActor.send(box) {
    // make `access` unavailable
    …
    }
    }
    18


    View Slide

70. Restricting Continuations
    19


    View Slide

71. Restricting Continuations
    • Continuation disallows capturing variables of
    the type of access
    19


    View Slide

72. Restricting Continuations
    • Continuation disallows capturing variables of
    the type of access
    • Leverage spores [1]
    19
    [1] Miller, Haller, and Odersky. Spores: A type-based foundation for closures
    in the age of concurrency and distribution. ECOOP ’14


    View Slide

73. Restricting Continuations
    • Continuation disallows capturing variables of
    the type of access
    • Leverage spores [1]
    def send(msg: Box[T])
    (cont: NullarySpore[Unit] {
    type Excluded = msg.C
    })
    (implicit p: CanAccess { type C = msg.C }): Nothing
    19
    [1] Miller, Haller, and Odersky. Spores: A type-based foundation for closures
    in the age of concurrency and distribution. ECOOP ’14


    View Slide

74. Restricting Continuations
    • Continuation disallows capturing variables of
    the type of access
    • Leverage spores [1]
    def send(msg: Box[T])
    (cont: NullarySpore[Unit] {
    type Excluded = msg.C
    })
    (implicit p: CanAccess { type C = msg.C }): Nothing
    19
    [1] Miller, Haller, and Odersky. Spores: A type-based foundation for closures
    in the age of concurrency and distribution. ECOOP ’14


    View Slide

75. Restricting Continuations
    • Continuation disallows capturing variables of
    the type of access
    • Leverage spores [1]
    def send(msg: Box[T])
    (cont: NullarySpore[Unit] {
    type Excluded = msg.C
    })
    (implicit p: CanAccess { type C = msg.C }): Nothing
    19
    “May not occur in
    captured types”
    [1] Miller, Haller, and Odersky. Spores: A type-based foundation for closures
    in the age of concurrency and distribution. ECOOP ’14


    View Slide

76. Stack Locality
    20


    View Slide

77. Stack Locality
    • Permissions are restricted to be stack local

    (or “stack confined”)
    20


    View Slide

78. Stack Locality
    • Permissions are restricted to be stack local

    (or “stack confined”)
    • This prevents problematic “indirect capturing”:
    20
    def method[T](box: Box[T])
    (implicit p: CanAccess { type C = box.C }) = {
    val fun = () => p
    someActor.send(box) {
    implicit val forbidden = fun()
    // could still access `box`
    …
    }
    }


    View Slide

79. Stack Locality
    • Permissions are restricted to be stack local

    (or “stack confined”)
    • This prevents problematic “indirect capturing”:
    20
    def method[T](box: Box[T])
    (implicit p: CanAccess { type C = box.C }) = {
    val fun = () => p
    someActor.send(box) {
    implicit val forbidden = fun()
    // could still access `box`
    …
    }
    }
    “error: p stack local”


    View Slide

80. Recall Example
    mkBox[Message] { packed =>
    implicit val access = packed.access
    val box = packed.box
    …
    someActor.send(box) {
    // `access` unavailable
    …
    }
    }
    21


    View Slide

81. Encapsulation
    Problem: not all types safe to transfer!
    22


    View Slide

82. Encapsulation
    Problem: not all types safe to transfer!
    22
    class Message {
    var arr: Array[Int] = _
    def leak(): Unit = {
    SomeObject.fld = arr
    }
    }
    object SomeObject {
    var fld: Array[Int] = _
    }


    View Slide

83. Encapsulation
    • Ensuring absence of data races (“concurrency
    safety”) requires restricting types put into boxes
    • Requirements for “safe” classes:*
    • Methods only access parameters and this
    • Methods only instantiate “safe” classes
    • Types of fields are “safe”
    23
    * simplified


    View Slide

84. Encapsulation
    • Ensuring absence of data races (“concurrency
    safety”) requires restricting types put into boxes
    • Requirements for “safe” classes:*
    • Methods only access parameters and this
    • Methods only instantiate “safe” classes
    • Types of fields are “safe”
    23
    “Safe” = conforms to object capability model [2]
    * simplified
    [2] Mark S. Miller. Robust Composition: Towards a Unified Approach to
    Access Control and Concurrency Control. PhD thesis, 2006


    View Slide

85. Object Capabilities in Scala
    • How common is object-capability safe code in Scala?
    • Empirical study of over 75,000 SLOC of open-source
    Scala code:
    24
    Project Version SLOC GitHub stats
    Scala stdlib 2.11.7 33,107 ✭5,795 257
    Signal/Collect 8.0.6 10,159 ✭123 11
    GeoTrellis 0.10.0-RC2 35,351 ✭400 38
    -engine 3,868
    -raster 22,291
    -spark 9,192


    View Slide

86. Object Capabilities in Scala
    Results of empirical study:
    25
    Project #classes/traits #ocap (%) #dir. insec. (%)
    Scala stdlib 1,505 644 (43%) 212/861 (25%)
    Signal/Collect 236 159 (67%) 60/77 (78%)
    GeoTrellis
    -engine 190 40 (21%) 124/150 (83%)
    -raster 670 233 (35%) 325/437 (74%)
    -spark 326 101 (31%) 167/225 (74%)
    Total 2,927 1,177 (40%) 888/1,750 (51%)


    View Slide

87. Object Capabilities in Scala
    Results of empirical study:
    25
    Project #classes/traits #ocap (%) #dir. insec. (%)
    Scala stdlib 1,505 644 (43%) 212/861 (25%)
    Signal/Collect 236 159 (67%) 60/77 (78%)
    GeoTrellis
    -engine 190 40 (21%) 124/150 (83%)
    -raster 670 233 (35%) 325/437 (74%)
    -spark 326 101 (31%) 167/225 (74%)
    Total 2,927 1,177 (40%) 888/1,750 (51%)


    View Slide

88. Object Capabilities in Scala
    Results of empirical study:
    25
    Project #classes/traits #ocap (%) #dir. insec. (%)
    Scala stdlib 1,505 644 (43%) 212/861 (25%)
    Signal/Collect 236 159 (67%) 60/77 (78%)
    GeoTrellis
    -engine 190 40 (21%) 124/150 (83%)
    -raster 670 233 (35%) 325/437 (74%)
    -spark 326 101 (31%) 167/225 (74%)
    Total 2,927 1,177 (40%) 888/1,750 (51%)
    Paper: immutability increases these percentages!


    View Slide

89. In the Paper
    26


    View Slide

90. In the Paper
    • Implementation:
    • Compiler plugin for Scala 2.11.x and integration with actors
    • Enforcement of continuation-passing style
    • Formalization: object-oriented core languages
    • CLC1: type-based notion of object capabilities
    • CLC2: uniqueness via flow-insensitive permissions
    • CLC3: concurrent extension
    • Soundness proof
    • Isolation theorem for processes with shared heap
    26
    Formal model in Coq


    View Slide

91. Conclusion
    27


    View Slide

92. Conclusion
    • Type-based notion of the object capability discipline
    is possible and benefitial
    27


    View Slide

93. Conclusion
    • Type-based notion of the object capability discipline
    is possible and benefitial
    • Safe ownership transfer is possible for objects
    conforming to the object capability discipline
    27


    View Slide

94. Conclusion
    • Type-based notion of the object capability discipline
    is possible and benefitial
    • Safe ownership transfer is possible for objects
    conforming to the object capability discipline
    • Binary check whether a class is reusable unchanged
    27


    View Slide

95. Conclusion
    • Type-based notion of the object capability discipline
    is possible and benefitial
    • Safe ownership transfer is possible for objects
    conforming to the object capability discipline
    • Binary check whether a class is reusable unchanged
    • Sound integration with advanced type system
    features of Scala
    27


    View Slide

96. Conclusion
    • Type-based notion of the object capability discipline
    is possible and benefitial
    • Safe ownership transfer is possible for objects
    conforming to the object capability discipline
    • Binary check whether a class is reusable unchanged
    • Sound integration with advanced type system
    features of Scala
    • In medium to large open-source Scala projects, 21-67%
    of all classes conform to the object capability discipline
    27


    View Slide

97. Conclusion
    • Type-based notion of the object capability discipline
    is possible and benefitial
    • Safe ownership transfer is possible for objects
    conforming to the object capability discipline
    • Binary check whether a class is reusable unchanged
    • Sound integration with advanced type system
    features of Scala
    • In medium to large open-source Scala projects, 21-67%
    of all classes conform to the object capability discipline
    27
    Open-source implementation:
    https://github.com/phaller/lacasa


    View Slide

98. Conclusion
    • Type-based notion of the object capability discipline
    is possible and benefitial
    • Safe ownership transfer is possible for objects
    conforming to the object capability discipline
    • Binary check whether a class is reusable unchanged
    • Sound integration with advanced type system
    features of Scala
    • In medium to large open-source Scala projects, 21-67%
    of all classes conform to the object capability discipline
    27
    Thank you!
    Open-source implementation:
    https://github.com/phaller/lacasa


    View Slide
