1. Animations & Gestures with React Native Raul Gomez, Ferran Negre @rgommezz, @ferrannprannp
2. Agenda • Everything is split into modules. We’ll cover 5 modules in total. • Theory + hands on exercises per module • Solutions attached for reference • We’ll use expo
3. Module 1 Introduction to Animation
7. translateX: 0 translateX: 500 progress: 0% progress: 100% translateX: 250 progress: 50% translateX = progress * 500 translateX = 0.0 * 500 = 0 translateX = 0.5 * 500 = 250 translateX = 1.0 * 500 = 500 To define a basic computed animation, we define duration, initial position and final position. The computer takes care of animating it.
8. Why animations are important • Animation has a special role in interface design, as one of the most important tools of successful interaction. • It can be said that without animation, there cannot be interaction • Users have high expectations of the UI they use, specially nowadays where the high quality content is everywhere.
9. Functional animation Build meaningful transitions
10. Functional animation Provide visual feedback
11. Functional animation Help the user get started
12. Delightful animation To reward the user
13. Delightful animation To entertain users
14. Animate with purpose • Don’t distract the user from successfully completing what they intended to do. • The best animations are those that seem natural • If you disable animations, the flow should feel broken. If it is not, this might mean your animations are superfluous
16. Module 2 Animated API
17. Animated API • Has been designed to make it very easy to concisely express a wide variety of interesting animation and interaction patterns in a very performant way. • Animated values bypass the usual render method, so they get updated even though there is no state change. • Animated exports four animatable component types: View, Text, Image and ScrollView.
18. Static Drivers • There are 3 different animation types, also known as static drivers: timing, spring, decay • Each type provides a particular animation curve that controls how your values animate from their initial to the final value.
20. Easing on timing animations
22. Steps to perform animation • 1. Create animated value: const translateX = new Animated.Value(0); • 2. Bind the value to the Animated View (inside Render) <Animated.View style={{ transform: [{ translateX }] }} /> • 3. Run the animation with the static driver Animated.timing(translateX, { toValue: 50, duration: 1000 }).start();
23. Exercise 1 Move a box from left to right using Animated timing, when the component mounts. Extra: use some elastic curve
24. Interpolation
25. const progress = new Animated.Value(0); const scale = progress.interpolate({ inputRange: [0, 0.2, 0.4, 0.7, 1], outputRange: [1, 1.3, 2, 1.5, 1.2], });
26. Interpolating to strings • Can interpolate to strings, provided that the string contains at least one number or is a color. • Numbers in the string are parsed and interpolated, then wrapped back in string again. • For rotation, we can use degrees or radians, i.e “360deg” or “1rad”
27. Exercise 2 • Move a box from left to right • It should change opacity from 1 to 0, • It should rotate from 0 to 90 degrees when it reaches half and from 90 to 360 degrees when it reaches the end • The animation should loop over 4 times. Loop time can be 4000ms • Don’t press the button for now!
28. Using the native driver • Rather than calling into JS every frame to update an animation, declare the animation configuration in JS and execute in UI thread on native. • As a consequence, JS thread can be blocked without affecting the animation. • Just add useNativeDriver: true to the animation config when starting it. Animated.timing(this.progress, { toValue: 1, duration: 1000, useNativeDriver: true // Add this line }).start();
29. Native driver in depth
30. requestAnimationFrame The bridge JS Native Value Interpolation Update prop Update Native View
31. requestAnimationFrame The bridge JS Native Value Interpolation Update prop Update Native View Every frame
32. Update Native View The bridge JS Native Execute Calculate intermediate values useNativeDriver: true (Serialize instructions) Deserialize Instructions
33. Update Native View The bridge JS Native Execute Calculate intermediate values useNativeDriver: true (Serialize instructions) Deserialize Instructions Every frame
34. Native driver caveats • You can only animate non-layout properties • Things like transform and opacity will work, but flexbox and position properties will not • That’s why we were using transformX for moving the box horizontally. • Still without using native driver, animating transformX is more efficient than animating left, because with the former, the layout doesn’t have to be recalculated every frame
35. Exercise 2 • Add useNativeDriver: true to the animation config. • Press the button to block the JS thread while the animation runs. • Set useNativeDriver to false and press the button again. Observe the difference
36. Listening to value updates • It is useful sometimes to know what the value is at a given point in time • You can’t access the value synchronously through a public API this.progress.addListener(({ value }) => { // Do something with the value! });
37. Exercise 3 ! • Use interpolation to transition between colours in the Spanish flag. • Show a text to display the current animated value in a text component. • Show an Alert when the animation finishes.
38. Exercise 4 • Animate a button to emphasise active state, by scaling it up and down. The pressed state should scale it down 10% Hint: use onPressIn and onPressOut
39. Recap • We can think of the progress of an animation from 0 to 1 (or any arbitrary range of numbers) • We can derive other values from the progress value with linear interpolation • Those values can be assigned to style properties on Animated Views • When the progress value updates, the interpolated values update and the views that are bound to those update • We can drive updates to the progress value using functions such as Animated.timing
40. Value Interpolation Views View Image Text ScrollView etc… Driver Event driver Static driver Number @notbrent
41. Value Views View Image Text ScrollView etc… subscribe to value updates value Driver Event driver Static driver Interpolation Number @notbrent
42. Value Interpolation Number Views View Image Text ScrollView etc… subscribe to value updates value set value Driver Event driver Static driver Interpolation @notbrent
43. Value Interpolation Number value Views View Image Text ScrollView etc… Driver Event driver Static driver value subscribe to Value updates subscribe to Interpolated value updates @notbrent
44. Value Interpolation Number value Views View Image Text ScrollView etc… value subscribe to Value updates subscribe to Interpolated value updates set value Driver Event driver Static driver @notbrent
45. Module 3 Event drivers
46. Event drivers • Interactions • Scrolling • Swiping (next module) • Dragging (next module) • etc
47. Scrolling is powerful…
48. ScrollView super powers https://codeburst.io/horizontal-scroll-animations-in-react-native-18dac6e9c720 - horizontal - pagingEnabled - rotateX, rotateY, scale
49. Real life patterns
50. Scrolling for today • onScroll • scrollEventThrottle • event.nativeEvent.contentOffset.y
51. Collapse all the things! Exercise 5
52. Collapsible header
53. Collapsible header
54. Collapsible header • We need to define several interpolation for: • Toolbar —> opacity • Image —> translate • Title —> translate • Several elements with absolute position • zIndex and elevation
55. Make things to disappear Exercise 6
56. Floating Action Button
57. Floating Action Button • We need to listen for scroll events • Animate translation: Outside and inside the screen • A bit of manual work: Save offset (Y) and compare it to the listened value to know if we scroll up or down
58. Floating Action Button
59. Module 4 Interactions
60. Touchable <TouchableHighlight /> <TouchableOpacity /> <TouchableWithoutFeedback /> <TouchableNativeFeedback />
61. JS Responder System @kzzzf
62. Async fate @kzzzf
63. Pan Responder
64. Pan Responder It holds an InteractionManager handle to block long-running JS events from interrupting active gestures gestureState = { dx, dy, vx, vy, ... }
65. Native gesture recognisers • ScrollView uses a native gesture recogniser instead of a JS based. • A Switch component is another example or native gesture recogniser where you can swipe or touch to flip the state • Drawer, NavigatorIOS, ViewPager…
66. Problems 1. Gesture recognition logic is distributed between threads that run in parallel. 2. No API for defining interactions between native gesture recognisers, like a Drawer and a View Pager 3. Touch events recognised by JS responder system can’t be connected with Views that animate on the native thread
67. react-native-gesture-handler
68. <TapGestureHandler /> <LongPressGestureHandler /> <NativeViewGestureHandler /> <PanGestureHandler /> BEGAN ACTIVE FAILED CANCELLED END UNDETERMINED STATES onHandlerStateChange onGestureEvent HANDLERS
69. Components • RN-gesture handler also offers some components that are built using those low level Gesture Recognisers • One of them is the <Swipeable /> component, which comes in handy in many use cases
70. Native driver compliant <PanGestureHandler onGestureEvent={Animated.event( [ { nativeEvent: { translationX: this.translateX, }, }, ], { useNativeDriver: true }, )} onHandlerStateChange={this.onHandlerStateChange} >
71. Exercise 7 Gmail swappable rows!
72. Exercise 8 Instagram story widget interaction!
73. Module 5 react-native-reanimated
74. react-native-reanimated
76. Key points • Reimplementation of Animated Module from scratch • It provides a more comprehensive, low level abstraction • Great flexibility for gesture based animations • Everything runs on the native thread by default!
77. More resources • https://github.com/kmagiera/react-native-reanimated/ tree/master/Example • https://blog.callstack.io/reanimating-your-react-native- experience-d1377d51118a
79. Feedback https://goo.gl/Uss11W
80. Thank you! :) @rgommezz @ferrannp
