Distributed Tracing: WebExpo 2018

Transcript

2. stella cotton | @practice_cactus
3. stella cotton | @practice_cactus What is distributed tracing?
4. stella cotton | @practice_cactus
 Tracing requests
 across
 distributed system
 boundaries
5. stella cotton | @practice_cactus

 A Simple Use Case
6. stella cotton | @practice_cactus User Orders Items Authentication Monolithic Web Process Web Request
7. stella cotton | @practice_cactus User Orders Items Web Request Auth Process Ecommerce Process New app Ruby app
8. stella cotton | @practice_cactus Web Request Auth Process Ecommerce Process Original Ruby app Orders Recommendations Billing Python????
9. stella cotton | @practice_cactus

 Microservices! (j/k)
10. stella cotton | @practice_cactus

 Services (Micro or otherwise)
11. stella cotton | @practice_cactus Web Request Auth Process Ecommerce Process Orders Recommendations Billing
12. stella cotton | @practice_cactus Why do we need distributed tracing?
13. stella cotton | @practice_cactus

 Internal services
 look like external APIs
14. stella cotton | @practice_cactus Web Request Auth Process Ecommerce Process Orders Recommendations Billing Why is this slow ???? Blame data science???
15. stella cotton | @practice_cactus
 “You can’t tell a
 coherent macro story
 about your application
 by monitoring
 individual processes” Ben Seligman
16. stella cotton | @practice_cactus

 People are bad guessers
17. stella cotton | @practice_cactus

 How do you tell the story?
18. stella cotton | @practice_cactus

 Distributed Tracing!
19. stella cotton | @practice_cactus
 “Distributed tracing
 commoditizes
 knowledge” - Adrian Cole
20. stella cotton | @practice_cactus What’s Stopping You?
21. stella cotton | @practice_cactus

 Outside Your
 Language’s
 Wheelhouse
22. stella cotton | @practice_cactus

 Domain Specific
 Vocabulary
23. stella cotton | @practice_cactus

 Fractured Ecosystem
24. stella cotton | @practice_cactus Theory -> Practice
25. stella cotton | @practice_cactus The Basics
26. stella cotton | @practice_cactus

 Black Box Tracing
27. stella cotton | @practice_cactus

 Black Box Tracing
28. stella cotton | @practice_cactus

 Why might this not
 work for you?
29. stella cotton | @practice_cactus • Need lots of data • Delayed results • Can’t guarantee causality
30. stella cotton | @practice_cactus def my_cool_system
 service_1
 service_2
 end

 def service_1
 Rails.logger "Service 1"
 execute_async_job
 end

 def execute_async_job
 Rails.logger "Async Job"
 end def service_2
 Rails.logger "Service 2"
 end
01-01-2001 01:01:01 Service 1 01-01-2001 01:01:02 Async Job 01-01-2001 01:01:03 Service 2
 Aggregated Log
31. stella cotton | @practice_cactus def my_cool_system
 service_1
 service_2
 end

 def service_1
 Rails.logger "Service 1"
 execute_async_job
 end

 def execute_async_job
 sleep 15 Rails.logger "Async Job"
 end def service_2
 Rails.logger "Service 2"
 end
01-01-2001 01:01:01 Service 1 01-01-2001 01:01:02 Service 2 01-01-2001 01:01:17 Async Job
 Aggregated Log Latency Simulate
 latency
32. stella cotton | @practice_cactus

 White Box Tracing
33. stella cotton | @practice_cactus

 Metadata Propagation
34. stella cotton | @practice_cactus

 Realtime Analysis
35. stella cotton | @practice_cactus History Lesson
36. stella cotton | @practice_cactus

 Dapper
37. stella cotton | @practice_cactus

 Zipkin
38. stella cotton | @practice_cactus

 “Distributed Tracing”
39. stella cotton | @practice_cactus


 “So, you want to trace your distributed system?
 Key design insights from years of practical experience” Raja R. Sambasivan, Rodrigo Fonseca, Ilari Shafer, Gregory R. Ganger http://www.pdl.cmu.edu/PDL-FTP/SelfStar/CMU-PDL-14-102.pdf
40. stella cotton | @practice_cactus Tracing
 Your Applications
41. stella cotton | @practice_cactus • Tracer • Transport • Collector • Storage • UI Main Components:
42. stella cotton | @practice_cactus Tracing Requests
43. stella cotton | @practice_cactus

 Tracer:
 Lives inside your apps, does the tracing
44. stella cotton | @practice_cactus

 Trace:
 The story of a request’s journey
 through your system
45. stella cotton | @practice_cactus Web Request Auth Process Ecommerce Process Orders Recommendations Billing A trace
 tells
 this whole
 story
46. stella cotton | @practice_cactus

 Span:
 Each chapter in that story
47. stella cotton | @practice_cactus Web Request Auth Ecommerce Orders Recommendations Billing A span
48. stella cotton | @practice_cactus Web Request Auth Ecommerce Orders Recommendations Billing Trace id 123 Trace id 123 Trace id 123 Trace id 123 Trace id 123
49. stella cotton | @practice_cactus Web Request Auth Ecommerce Orders Recommendations Billing Trace id 123 Parent id nil Span id 1
50. stella cotton | @practice_cactus Web Request Auth Ecommerce Orders Recommendations Billing Trace id 123 Parent id nil Span id 1 Trace id 123 Parent id 1 Span id 2
51. stella cotton | @practice_cactus Web Request Auth Ecommerce Orders Recommendations Billing Trace id 123 Parent id nil Span id 1 Trace id 123 Parent id 1 Span id 2 Trace id 123 Parent id 2 Span id 3
52. stella cotton | @practice_cactus

 A Trace is many
 Parent - Child Relationships
53. stella cotton | @practice_cactus

 Directed Acyclic Graph
54. stella cotton | @practice_cactus Web Request Auth Ecommerce Orders Recommendations Billing Trace id 123 Parent id nil Span id 1 Trace id 123 Parent id 1 Span id 2 Trace id 123 Parent id 2 Span id 3
55. stella cotton | @practice_cactus

 Annotations:
 Gives us richer insights into our spans
56. stella cotton | @practice_cactus
 Client Start 01:01:01
 Server Receive 01:01:02
 Server Send 01:01:03
 Client Receive 01:01:04
57. stella cotton | @practice_cactus Web Request Auth Ecommerce Orders Recommendations Billing Trace id 123 Parent id nil Span id 1 Trace id 123 Parent id 1 Span id 2 Trace id 123 Parent id 2 Span id 3
58. stella cotton | @practice_cactus Auth Ecommerce Server Receive Client
 Send Trace id 123 Parent id 1 Span id 2
59. stella cotton | @practice_cactus Auth Ecommerce Server
 Send Server Receive Client
 Send
60. stella cotton | @practice_cactus Auth Ecommerce Server
 Send Server Receive Client
 Send Client
 Receive
61. stella cotton | @practice_cactus

 Transporting the Data
62. stella cotton | @practice_cactus Web Request Auth Ecommerce Orders Recommendations Billing Trace id 123 Parent id nil Span id 1 Collector Storage Transport
63. stella cotton | @practice_cactus Propagates ids in band
64. stella cotton | @practice_cactus Reports out of band
65. stella cotton | @practice_cactus

 Viewing the Data
66. stella cotton | @practice_cactus Web Request Auth Ecommerce Orders Recommendations Billing
67. stella cotton | @practice_cactus http://opentracing.io/documentation/
68. stella cotton | @practice_cactus
69. stella cotton | @practice_cactus All happening
 inside the
 “resource
 allocation
 & provisioning”
70. stella cotton | @practice_cactus Parallel
 execution Blocking
 execution
71. stella cotton | @practice_cactus A wide bar can indicate a
 slow application
72. stella cotton | @practice_cactus A widening
 gap here
 could indicate queueing
73. stella cotton | @practice_cactus Tracing Incoming Requests
74. stella cotton | @practice_cactus

 Middleware!
75. stella cotton | @practice_cactus def call(env)
 trace do
 @app.call(env)
 end
 end def trace(env, &block) # tracing code end Trace some stuff
76. stella cotton | @practice_cactus def call(env)
 trace do
 @app.call(env)
 end
 end def trace(env, &block)
 span = Span.new("authentication", generate_span_id)
 span.record(SERVER_RECV)
 status, headers, body = yield
 ensure
 span.record(SERVER_SEND)
 end https://github.com/openzipkin/zipkin-ruby/blob/master/lib/zipkin-tracer/rack/zipkin-tracer.rb Execute the app Received a request Sending back
 to the client Non-pseudocode version:
77. stella cotton | @practice_cactus # config/initializers/tracing.rb
 Rails.application.config.middleware.use TracingRackMiddleware, {
 # some configuration
 } Use our middleware!
78. stella cotton | @practice_cactus # config/initializers/tracing.rb
 Rails.application.config.middleware.use TracingRackMiddleware, {
 service_name: "SERVICE_DOMAIN_NAME",
 service_port: 443,
 sample_rate: ENV.fetch("ZIPKIN_SAMPLE_RATE", 0.1).to_f,
 json_api_host: ENV["ZIPKIN_HOST"]
 }
 Sample a portion of requests
79. stella cotton | @practice_cactus Tracing Outgoing Requests
80. stella cotton | @practice_cactus

 More Middleware!
81. stella cotton | @practice_cactus

 Faraday
82. stella cotton | @practice_cactus
 def call(env)
 trace!(env) do |env|
 @app.call(env)
 end
 end

 def trace!(env, &block)
 # some tracing
 end
 Execute our http client
83. stella cotton | @practice_cactus
 def call(env)
 trace!(env) do |env|
 @app.call(env)
 end
 end

 def trace!(env, &block)
 env = set_headers(env)
 span = Span.new("external_call", 1234)
 span.record(Trace::Annotation::CLIENT_SEND)
 status, headers, body = yield env
 ensure
 span.record(Trace::Annotation::CLIENT_RECV)
 end
 Manipulate the headers Using client instead of server
84. stella cotton | @practice_cactus Each of these
 colors
 represents
 an instrumented
 application
85. stella cotton | @practice_cactus Client Send Client Receive
 def call(env)
 trace!(env) do |env|
 @app.call(env)
 end
 end

 def trace!(env, &block)
 env = set_headers(env)
 span = Span.new("external_call", 1234)
 span.record(Trace::Annotation::CLIENT_SEND)
 status, headers, body = yield env
 ensure
 span.record(Trace::Annotation::CLIENT_RECV)
 end

86. stella cotton | @practice_cactus def self.client
 Faraday.new(url: base_url) do |connection|
 connection.use TracingFaradayMiddleware
 connection.adapter Faraday.default_adapter
 end
 end Add our middleware
87. stella cotton | @practice_cactus Checklist
88. stella cotton | @practice_cactus Buy, Build, or Adopt
89. stella cotton | @practice_cactus

 Buy?
90. stella cotton | @practice_cactus
 Lightstep
 AppOptics…
 and more?
91. stella cotton | @practice_cactus

 Adopt an OSS Solution?
92. stella cotton | @practice_cactus

 Zipkin
 Jaeger
 OpenCensus
93. stella cotton | @practice_cactus

 What about Open Tracing?
94. stella cotton | @practice_cactus

 Standardizes Instrumentation
95. stella cotton | @practice_cactus

 Where is OpenTracing at today?
96. stella cotton | @practice_cactus

 Interoperability is Still Messy
97. stella cotton | @practice_cactus

 “Language Support”
98. stella cotton | @practice_cactus

 Rinse and Repeat
99. stella cotton | @practice_cactus

 Build Your Own?
100. stella cotton | @practice_cactus

 What are other folks doing?
101. stella cotton | @practice_cactus End-to-End Tracing: Adoption and Use Cases Jonathan Mace, Brown University https://cs.brown.edu/~jcmace/papers/mace2017survey.pdf
102. stella cotton | @practice_cactus • 15 using Zipkin • 9 using internal solutions • 1 using other OSS solution • 1 using paid solution
 Jonathan Mace, Brown University https://cs.brown.edu/~jcmace/papers/mace2017survey.pdf
103. stella cotton | @practice_cactus Infra Requirements and Limitations
104. stella cotton | @practice_cactus
 Dependency matrix of:
 - Tracer
 - Transport Layer
 - Collection Layer
 - Storage Layer
105. stella cotton | @practice_cactus

 Installing a Separate Agent
106. stella cotton | @practice_cactus Authentication
107. stella cotton | @practice_cactus

 Missing Authentication & Authorization
108. stella cotton | @practice_cactus

 Client Authorization
109. stella cotton | @practice_cactus

 Basic auth via htpasswd https://www.nginx.com/resources/admin-guide/restricting-access-auth-basic/
110. stella cotton | @practice_cactus

 Browser Authentication
111. stella cotton | @practice_cactus

 bit.ly’s Oauth2 proxy https://github.com/bitly/oauth2_proxy
112. stella cotton | @practice_cactus

 Giving people access
113. stella cotton | @practice_cactus Sensitive Data
114. stella cotton | @practice_cactus

 Custom Instrumentation
115. stella cotton | @practice_cactus

 What happens when data leaks?
116. stella cotton | @practice_cactus Is Everyone On Board?
117. stella cotton | @practice_cactus

 Get it on the Roadmap
118. stella cotton | @practice_cactus

 Open PRs
119. stella cotton | @practice_cactus Should you buy, build or adopt? What are your infrastructure requirements and limitations? How is it authenticated? Do you have sensitive data? What will you do if it leaks? Is everyone on board? Evaluating Distributed Tracing Solutions:
120. stella cotton | @practice_cactus OMG, this is so much information
121. stella cotton | @practice_cactus

 Try out Docker Zipkin
122. stella cotton | @practice_cactus Thank you! Plant Illustrations designed by Natkacheva / Freepik
