In this session, I will talk about entertaining examples of architectural disasters in software projects. We will see how excellent ideas can turn into nightmares, how one can slowly but thoroughly introduce incredible complexity, and how a merge between organizational and technical failures can grind productivity to a halt. Names and irrelevant details have been changed to protect the somewhat innocent, but everything is based on actual things I had to experience – and sometimes helped create – in the real world.

Afd6dc452bc20f8f06612d4792bb8be3?s=128

Stefan Tilkov

April 25, 2014
Tweet

Transcript

  1. Stefan Tilkov | @stilkov | innoQ Architecture War Stories CRAFT

    Budapest 04/25/2014
  2. Ground Rules No offense – just lessons learned Most systems

    are in production Still, many {managers | users | admins} are happy
  3. Less can be more

  4. Context Customer care, accounting & billing Large-scale big-bang replacement effort

    > 150 developers > 20 architects/framework devs Java, Swing, CORBA, Oracle Custom persistence framework
  5. Server Client DB

  6. Server Identity Map 1 7 3 9 Tx 1 Tx2

    Transaction Map 1 9 1 2 -
  7. Client DB Server

  8. Server Server Object Warehouse Object Warehouse

  9. Global synchronization? 2 PC? Cache notifications? Events? Transaction locality? Client

    Affinity?
  10. Server Server Object Warehouse Object Warehouse

  11. Server Server Cache Cache DB Cache

  12. Lessons learned Don’t cache the cache In distributed systems, application

    state is your enemy If it’s “sophisticated”, you probably shouldn’t be doing it Development ≠ production
  13. Data Complications

  14. Context Insurance system Maintenance 1000 person months/year Smalltalk, COBOL, C,

    IMS, DB2 Homegrown COBOL OO system
  15. Client (Smalltalk) Broker Gateway Transaction Manager Server (COBOL)

  16. Online Transactions Online DB Access Layer Interface DB Batch External

    Module External Module External Module Tables Foreign Keys Indexes OR/M Events Deltas Blobs
  17. Migration

  18. None
  19. Lessons learned Data should be free of code dependencies The

    longer you store it, the simpler it needs to be Beware of smelly blobs
  20. Evaluating Yourself to Death

  21. Context Strategic health care platform Architecture team 20+10 people Build

    foundation for 800+ person year effort
  22. Vendor Selection Collect and agree on requirements Week 0 Conduct

    market research Week 8 Send out RFP to selected vendors Week 10 Evaluate responses, create shortlist, start PoC Week 14 Evaluate PoC results, recommend vendor X Week 20 Accept your CEO picked vendor Y Week 26
  23. Vendor Selection Collect and agree on requirements Week 0 Conduct

    market research Week 8 Send out RFP to selected vendors Week 10 Evaluate responses, create shortlist, start PoC Week 14 Evaluate PoC results, recommend vendor X Week 20 Shutdown company Week 26
  24. Lessons learned Just do it Better ask for forgiveness than

    permission
  25. Your system WILL be dynamic

  26. Context Large-scale insurance system Model-driven development > 100 developers 2

    Releases/year
  27. Modeling Business Concept 0 3 6 4 5 2 1

    Technical Concept Implementation Module Test Integration Test Rollout Vision What if you miss your slot? Modeling
  28. Policy Holder Clause - id - value - dueDate -

    name - address - status - text - validity - taxClass * * regionCode Model Name New Name (Meaning) Description Release Introduced taxClass regionCode … 10.3 …
  29. Lessons learned Centralized responsibility hurts Faced with too much rigidity,

    a way around the rules will be found Just because you’re used to it doesn’t mean it’s acceptable
  30. Formalism and Common Sense as Orthogonal Concepts

  31. Context Telecommunications OSS platform Support new devices without code changes

    > 100 developers > 3 countries
  32. Warning ((Meta) meta) models) are a perfect means to waste

    time, on a highly inspiring intellectual level, without any results for years Highly complex methodology, tool support, agreement processes Consultants with exclusive pricing strategies
  33. Upload «servlet» DB Model XML XML XML XML XML Transformation

    «slsb» .pl .sh Schema .sql Interface .idl Call «ant task» Quartz Transformer «servlet» Objects «entity» Generic CRUD UI Access «slsb»
  34. Lessons learned If it makes you want to scratch your

    eyes out, you might not want to do it Sometimes constraints need to be fought Beware all things “meta”
  35. The Perils of Being Smart

  36. Context Complex enterprise-wide SOA effort Custom-built “lightweight” middleware

  37. Consumer/Provider Middleware Lib Transport Abstraction Messaging API Business Logic Configuration

    Service Registry Service
  38. Consumer/Provider Middleware Lib Transport Abstraction Messaging API Business Logic XML

    Obj Consumer/Provider Middleware Lib Transport Abstraction Messaging API Business Logic Message XML
  39. “The Product” Consumer/Provider Middleware Lib Transport Abstraction Messaging API Business

    Logic XML Obj OO Mapper Obj XML Transport Abstraction HTTP CORBA JMS Object API
  40. None
  41. “The Product” Transport Abstraction OO Mapper Obj XML Object API

    Messaging API Interceptor Interceptor SOAP Message Header Body XML Message XML Obj null SOAP Message Header Body XML
  42. Lessons learned Fight the madness Tunneling is the root of

    all evil Don’t be too smart
  43. Non-extensible Extensibility

  44. Context E-Commerce (retail) provider Global customer base Catalog/CMS/Shop/Fulfillment Multi-tenant Highly

    customizable
  45. Large customers (“strategic”) Small customers (“long tail”) Specific General High

    Low (Acceptable) Cost Customization (Need) The Solution
  46. Lessons learned Don’t be all things to all people Sometimes

    specific code is preferable Saying “no” might help
  47. Summary

  48. Never-ending supply of {war stories | catastrophes | disasters} seems

    guaranteed
  49. Advice:

  50. 1. Give Feedback

  51. 2. Reflect

  52. 3. Iterate

  53. Q&A Stefan Tilkov, @stilkov stefan.tilkov@innoq.com Phone: +49 170 471 2625
