Create GitHub bots with PHP & Symfony

Bots are a great way to link tools together and enhance the developers/users experiences across companies and projects.

As engineers, we use GitHub every day and this tool take a huge part in our workflow, and someday we probably need to be able to automatically perform actions when something happens on GitHub.

In this talk, we're gonna learn how to make our own bots to interact with GitHub, by using both GitHub web hooks and GitHub API in PHP, and we'll see how some packages/bundles could help us in Symfony.

Demo bot source code: http://bit.ly/oss-enthusiast-bot

Transcript

1. Sylvain Mauduit @swop Senior Software Engineer, Etsy GitHub bot with Symfony
2. GitHub bot | Definition A GitHub bot is a web app which is going to react to events happening on GitHub by performing some action on its side and/or will trigger other behaviours on GitHub
3. GitHub bot | Workflow Event Something happens on GitHub GITHUB Triggers a Web Hook call GitHub will call your server GITHUB Web hook request handling Process the event CUSTOM APP (BOT) Use GitHub API as an output CUSTOM APP (BOT)
4. GitHub bot | Today’s menu 1. Connect GitHub to our app via GitHub web hooks 2. Communicate with GitHub via the GitHub API
5. Use web hooks to connect our app to GitHub Image source: pexels.com
6. Each GitHub activity will trigger an event. Comment on commit on deployment on fork comment on issue/PR labelling an issue when open a PR on push … You can request a web hook call on all/some events GitHub | Events
11. X-GitHub-Event
 Event type
 commit_comment
 deployment
 fork
 issue_comment
 pull_request, push … Web hook payload | Headers
12. X-Hub-Signature
 Signed web hook payload (using a shared secret)
 sha1=5b97ee25c90585f5b809e87d5be7bd942e3c7a28 Web hook payload | Headers
13. X-GitHub-Delivery
 Unique ID for the web hook call
 72d3162e-cc78-11e3-81ab-4c9367dc0958 Web hook payload | Headers
14. User-Agent
 Prefixed User Agent
 GitHub-Hookshot/{hash} Web hook payload | Headers
15. JSON
 (or form-urlencoded) representation of the event and its context Web hook payload | Body (POST)
16. Web hook payload | Example POST /webhook HTTP/1.1 Host: my_awesome_bot.com User-Agent: GitHub-Hookshot/044aadd Content-Type: application/json X-GitHub-Event: issues X-Github-Delivery: 72d3162e-cc78-11e3-81ab-4c9367dc0958 X-Hub-Signature: sha1=5b97ee25c90585f5b809e87d5be7bd942e3c7a28
17. Web hook payload | Example { "action": "opened", "issue": { "url": "https://api.github.com/repos/octocat/Hello-World/issues/1347", "number": 1347, ... }, "repository" : { "id": 1296269, "full_name": "octocat/Hello-World", ... }, "sender": { "login": "octocat", "id": 1, ... } }
18. Web hook | Security Whitelist GitHub IPs Check web hook request signature
19. Web hook | Security Recreate the signature and compare it Using the same secret CUSTOM APP Sign the web hook call Using the secret GITHUB REQUEST X-Hub-Signature sha1=5b97ee25c9… Secret
 my_secret https://developer.github.com/webhooks/securing/
20. Web hook | Security <?php $signature = $request->headers->get('X-Hub-Signature'); $explodeResult = explode('=', $signature, 2); if (2 !== count($explodeResult)) { return false; // Invalid signature header } list($algorithm, $hash) = $explodeResult; $payload = $request->getContent(); $payloadHash = hash_hmac($algorithm, $payload, 'my_secret'); if ($hash !== $payloadHash) { return false; // Invalid signature (wrong secret or altered payload) }
21. Communicate with GitHub via the GitHub API Image source: pexels.com
22. https://developer.github.com/v3/ GitHub API | Docs
23. KnpLabs/php-github-api GitHub API | PHP client
24. Several choice to auth to GitHub API Personal tokens JWT OAuth2 app … Easy way to start (and test the bot): Personal access token https://github.com/settings/tokens/new GitHub API | Authentication
26. GitHub API | Authentication <?php $token = '23c6834b1d353eabf976e524ed489c812ff86a7d'; $cacheDir = sprintf( '%s/github-api-cache', $this->container->getParameter('kernel.cache_dir') ); $client = new Client( new CachedHttpClient( ['cache_dir' => $cacheDir] ) ); $client->authenticate($token, null, Client::AUTH_HTTP_TOKEN);
27. GitHub API | Call the API <?php $client ->issue() ->comments() ->create( 'Octocat', 'Hello-World', 1337, ['body' => 'Hello!'] );
28. Demo Open-Source enthusiast bot Image source: pexels.com github.com/Swop/open-source-enthusiast-bot
29. Tips | Development Ngrok
 https://ngrok.com/
 Expose you dev env to the world KnpLabs/php-github-api
 https://github.com/KnpLabs/php-github-api
 GitHub API client for PHP
30. Tips | Development Swop/github-webhook
 https://github.com/Swop/github-webhook
 GitHub web hook signature validator & payload deserializer Swop/github-webhook-bundle
 https://github.com/Swop/github-webhook-bundle
 Symfony bundle around the above lib + web hook declaration on controllers with annotations
31. Tips | Want to try middleware approach? Swop/github-webhook-middleware
 https://github.com/Swop/github-webhook-middleware
 PSR-15 & PSR-7 middleware Swop/github-webhook-stackphp
 https://github.com/Swop/github-webhook-stackphp
 StackPHP middleware
32. Middleware | With Zend Stratigility use Psr\Http\Message\RequestInterface; use Psr\Http\Message\ResponseInterface; use Swop\GitHubWebHook\Security\SignatureValidator; use Swop\GitHubWebHookMiddleware\GithubWebHook; $app = (new \Zend\Stratigility\MiddlewarePipe()) ->pipe(new GithubWebHook(new SignatureValidator(), 'my_secret')) ->pipe('/webhook', function (RequestInterface $request, ResponseInterface $response) { // The security has been check. // Do some stuff with the web hook... return new \Zend\Diactoros\Response\JsonResponse(['message' => 'OK']); }); $request = \Zend\Diactoros\ServerRequestFactory::fromGlobals(); \Zend\Diactoros\Server::createServerFromRequest($app, $request) ->listen(new \Zend\Stratigility\NoopFinalHandler());
33. How we’re using this
34. Bot | Notificator Main controller Wildcard GitHub event types GitHub Web hook REQUEST github. {event_type} DISPATCH (Eventually) Performs actions or get more info on GitHub (using the API) Check review label Internal hook Check review status on merge Internal hook … Internal hook github. {event_type} Notification Notification Notification Attach resulting notifications to the initial event
35. Bot | Notificator Main controller Wildcard GitHub event types GitHub Web hook REQUEST github. {event_type} DISPATCH Notification Notification Notification SlackOutput Post Slack message MailOutput Send a mail MonologOutput Log the notification GitHubOutput Comment on PR/commit StatsDOutput Increment a metric
 on Graphite Output chain LOOP OVER NOTIFICATIONS
36. Bot | Notificator
37. Going further | Here’s some ideas… Create a GitHub “Integration”
 https://developer.github.com/early-access/integrations/
 • Uses JWT instead of personal tokens • Act on its own instead of behalf a user • Web hooks / permissions are built-in
38. Going further | Here’s some ideas… Register your web hooks from… your bot web page
 Travis CI-like
 • Create a web interface on your app • Use GitHub API to auto-register itself as web hook on the user-selected repos.
39. Going further | Here’s some ideas…
40. You like these toys? Join us! Senior full-stack eng. Senior backend eng. iOS eng. Contact me: smauduit@etsy.com Image source: pexels.com
