Development and Operation of Expressive Speech Synthesis System

Ryo Terashima (LINE / Voice Team / Machine Learning Engineer)
Kosuke Futamata (LINE / Voice Team / Machine Learning Engineer)

https://tech-verse.me/ja/sessions/55
https://tech-verse.me/en/sessions/55
https://tech-verse.me/ko/sessions/55

Transcript

1. Development and Operation of Expressive Speech Synthesis System Kosuke Futamata / LINE Ryo Terashima / LINE
2. Agenda - Introduction - Emotional TTS from Neutral Data - TTS System for Product
3. Agenda - Introduction - What is “TTS” ? - Our TTS System “Coharis” - Emotional TTS from Neutral Data - TTS System for Product
4. What is “TTS” ? to Speech Text Hello
5. What is “TTS” ? Acoustic model Vocoder ありがとう Text processing Acoustic features [ a- ri^ ga- to- o- ] Linguistic features
6. Agenda - Introduction - What is “TTS” ? - Our TTS System “Coharis” - Emotional TTS from Neutral Data - TTS System for Product
7. COntrollable, High-quAlity, and expRessIve TTS
8. Acoustic model Vocoder ありがとう Text processing Neutral Conversation Narration Happy Sad Angry Expressive Focus on Emotion Expressive TTS System Coharis
9. Audiobook Narration Telephone Answering Use cases of Coharis
10. Agenda - Introduction - Emotional TTS from Neutral Data - TTS System for Product
11. Problems in building emotional TTS Recording required Emotional Data Acting skills needed Burden on Speakers Only neutral data Low Resource Data
12. Emotional TTS using neutral data Emotional TTS Speech database (A) with emotional data Speech database (B) with only neutral data
13. Emotional TTS using neutral data Emotional TTS Speech database (A) with emotional data Emotional TTS! Speech database (B) with pseudo emotional data Emotion transfer
14. Emotional TTS using neutral data Data augmentation via pitch-shifting Data augmentation via voice conversion
15. Data augmentation via voice conversion Neutral Happiness Sadness Source speaker Neutral Target speaker Target speaker (VC) VC model training Neutral Happiness Sadness
16. Data augmentation via voice conversion Neutral Happiness Sadness Neutral Happiness Sadness VC Style: Source speaker Identity: Target speaker Generation of pseudo-emotional data using VC Source speaker Neutral Target speaker Target speaker (VC)
17. Data augmentation via pitch-shifting Generate data for various pitches -3 semitone +12 semitone Original Pitch-shift -3 to +12 semitones ・ ・ ・ ・ ・ ・
18. MS-TTS VC-TTS VC-TTS-PS Performance evaluations Source Target n Neutral n Happiness n Sadness n Neutral Target n Neutral n Neutral n Happiness n Sadness Target Multi-speaker Single-speaker with VC Single-speaker with PS&VC n Neutral n Neutral n Happiness n Sadness via VC w/ PS via VC
19. Performance evaluations Performance on Naturalness 2.85 3.88 4.20 2.74 4.00 4.00 1 2 3 4 5 MS-TTS VC-TTS VC-TTS-PS Happiness Sadness
20. Performance evaluations 2.48 3.33 3.82 2.72 3.63 3.67 1 2 3 4 MS-TTS VC-TTS VC-TTS-PS Happiness Sadness Performance on Emotional Similarity
21. Performance evaluations 4.20 4.08 4.00 3.96 1 2 3 4 5 VC-TTS-PS VC-TTS-PS (40%) Naturalness Experiments with less than half of the recorded speech data of the target speaker 3.82 3.87 3.67 3.63 1 2 3 4 VC-TTS-PS VC-TTS-PS (40%) Emotional Similarity Happiness Sadness
22. n We proposed a cross-speaker emotion style transfer method that combines PS-based and VC-based data augmentation. n Our method improved the performance of emotional TTS. In particular, the experiments showed that our method significantly enhanced the naturalness and emotional similarity of speech with a happiness style. Audio samples https://ryojerky.github.io/demo_vc-tts-ps/ Summary
23. Agenda - Introduction - Emotional TTS from Neutral Data - TTS System for Product
24. About the architecture of Coharis TTS system for product ⎯ How Coharis works ⎯ Introduce microservice architecture on Coharis ⎯ Benefits and difficulties after rebuilding Controllable, High-quAlity, and expRessIve TTS
25. TTS flow with monolithic architecture Phrase break prediction Accent prediction Grapheme-to-phoneme Text segmentation / normalization Mix up linguistic features Acoustic model Vocoder Coharis server Raw text Raw speech “こんにちは” For TTS For text processing
26. TTS flow with monolithic architecture Phrase break prediction Accent prediction Grapheme-to-phoneme Text segmentation / normalization Mix up linguistic features Acoustic model Vocoder Coharis server Raw text Raw speech “こんにちは” Raw text with acoustic parameters is given through REST
27. TTS flow with monolithic architecture Phrase break prediction Accent prediction Grapheme-to-phoneme Text segmentation / normalization Mix up linguistic features Acoustic model Vocoder Coharis server Raw text Raw speech “こんにちは” Split and normalize sentences e.g., 10:00 am → 午前10時
28. TTS flow with monolithic architecture Phrase break prediction Accent prediction Grapheme-to-phoneme Text segmentation / normalization Mix up linguistic features Acoustic model Vocoder Coharis server Raw text Raw speech “こんにちは” Convert raw text into appropriate pronunciation e.g., 午前10時 → ゴゼンジュージ
29. TTS flow with monolithic architecture Phrase break prediction Accent prediction Grapheme-to-phoneme Text segmentation / normalization Mix up linguistic features Acoustic model Vocoder Coharis server Raw text Raw speech “こんにちは” Predict appropriate pause positions e.g., あのねあそこにね → あのね / あそこにね
30. TTS flow with monolithic architecture Phrase break prediction Accent prediction Grapheme-to-phoneme Text segmentation / normalization Mix up linguistic features Acoustic model Vocoder Coharis server Raw text Raw speech “こんにちは” Predict appropriate accents e.g., 音声 → オ_H / ン_L / セ_L / ー_L
31. TTS flow with monolithic architecture Phrase break prediction Accent prediction Grapheme-to-phoneme Text segmentation / normalization Mix up linguistic features Acoustic model Vocoder Coharis server Raw text Raw speech “こんにちは” Align and mix up all linguistic features for TTS
32. TTS flow with monolithic architecture Phrase break prediction Accent prediction Grapheme-to-phoneme Text segmentation / normalization Mix up linguistic features Acoustic model Vocoder Coharis server Raw text Raw speech “こんにちは” Convert linguistic features into acoustic features
33. TTS flow with monolithic architecture Phrase break prediction Accent prediction Grapheme-to-phoneme Text segmentation / normalization Mix up linguistic features Acoustic model Vocoder Coharis server Raw text Raw speech “こんにちは” Convert acoustic features into speech
34. Problems in monolithic architecture Difficult to update part of modules quickly Tightly coupled Can not deploy each service independently Scalability Takes much time to build and deploy Slow development
35. Why microservice in our case? Increase the number of App specific APIs Fast development Required to utilize GPU resources efficiently since the number of available GPUs is limited Let ML engineer focus only on developing ML modules (Not Server/Infrastructure) Less time to update models and dictionaries compared with monolithic architecture Scale up each module independently
36. Coharis with microservice architecture BACKEND MICROSERVICE PROXY API SERVICE APP SERVICE CLIENTS Preprocessing G2P Phrase break Accent (TTS components) PROXY SERVICE CLOVA VOICE AUDIOBOOK APP1 APP2 CLOVA SERVICE AUDIOBOOK SERVICE APP SERVICE 1 APP SERVICE 2
37. Scale up each modules independently BACKEND MICROSERVICE PROXY API SERVICE APP SERVICE CLIENTS Preprocessing G2P Phrase break Accent (TTS components) PROXY SERVICE CLOVA VOICE AUDIOBOOK APP1 APP2 CLOVA SERVICE AUDIOBOOK SERVICE APP SERVICE 1 APP SERVICE 2 We can scale up only high GPU usage modules independently
38. Increase the number of App specific APIs BACKEND MICROSERVICE PROXY API SERVICE APP API SERVICE CLIENTS Preprocessing G2P Phrase break Accent (TTS components) PROXY SERVICE CLOVA VOICE AUDIOBOOK APP1 APP2 CLOVA SERVICE AUDIOBOOK SERVICE APP SERVICE 1 APP SERVICE 2 Aggregate data coming from each backend service to offer App specific API
39. Increase the number of App specific APIs BACKEND MICROSERVICE PROXY API SERVICE APP SERVICE CLIENTS Preprocessing G2P Phrase break Accent (TTS components) PROXY SERVICE CLOVA VOICE AUDIOBOOK APP1 APP2 CLOVA SERVICE AUDIOBOOK SERVICE APP SERVICE 1 APP SERVICE 2 Different Requests and Responses are given. And resource usage for each backend service is different
40. Increase the number of App specific APIs BACKEND MICROSERVICE PROXY API SERVICE APP SERVICE CLIENTS Preprocessing G2P Phrase break Accent (TTS components) PROXY SERVICE CLOVA VOICE AUDIOBOOK APP1 APP2 CLOVA SERVICE AUDIOBOOK SERVICE APP SERVICE 1 APP SERVICE 2 Generate speech from raw text Activated modules
41. Increase the number of App specific APIs BACKEND MICROSERVICE PROXY API SERVICE APP SERVICE CLIENTS Preprocessing G2P Phrase break Accent (TTS components) PROXY SERVICE CLOVA VOICE AUDIOBOOK APP1 APP2 NAVER GATEWAY AUDIOBOOK SERVICE APP SERVICE 1 APP SERVICE 2 Activated modules Generate linguistic features from raw text
42. Increase the number of App specific APIs BACKEND MICROSERVICE PROXY API SERVICE APP SERVICE CLIENTS Preprocessing G2P Phrase break Accent (TTS components) PROXY SERVICE CLOVA VOICE AUDIOBOOK APP1 APP2 CLOVA SERVICE EXTERNAL SERVICE APP SERVICE 1 APP SERVICE 2 Activated modules Generate speech from linguistic features
43. Fast development BACKEND MICROSERVICE PROXY API SERVICE APP SERVICE CLIENTS Preprocessing G2P Phrase break Accent (TTS components) PROXY SERVICE CLOVA VOICE AUDIOBOOK APP1 APP2 CLOVA SERVICE AUDIOBOOK SERVICE APP SERVICE 1 APP SERVICE 2 takes less time to update them since they are independent
44. Techniques to speed up inference time Support adaptive batching Support gPRC protocol Use CPU-based workers to handle the sharp increase in requests Requests coming in short intervals are batched together in the proxy server Each service is connected by gRPC to reduce network delay Support CPU-based TTS workers with GPU-based one
45. Microservice architecture on Coharis Phrase break service Accent service Normalization service Segmentation service Text formatter service Acoustic model service Vocoder service BACKEND SERVICES Proxy service Redis CPU-based workers Model storage gRPC App services REST Cache storage Load pre-trained models Queue TTS jobs
46. API call flow Phrase break service Accent service Normalization service Segmentation service Text formatter service Acoustic model service Vocoder service BACKEND SERVICES Proxy service Redis CPU-based workers Model storage gRPC App services REST Cache storage Load pre-trained models Queue TTS jobs
47. CPU-based TTS workers Phrase break service Accent service Normalization service Segmentation service Text formatter service Acoustic model service Vocoder service BACKEND SERVICES Proxy service Redis CPU-based workers Model storage gRPC App services REST Cache storage Load pre-trained models Queue TTS jobs
48. Model loading and cache mechanism Phrase break service Accent service Normalization service Segmentation service Text formatter service Acoustic model service Vocoder service BACKEND SERVICES Proxy service Redis CPU-based workers Model storage gRPC App services REST Cache storage Load pre-trained models Queue TTS jobs
49. Focus only on developing ML services Phrase break service Accent service Normalization service Segmentation service Text formatter service Acoustic model service Vocoder service BACKEND SERVICES Proxy service Redis CPU based workers Model storage gRPC App services REST Cache storage Load pre-trained models Queue TTS jobs Wrapped by ML serving tool e.g. Triton, Torch-serve, seldon-core
50. Pros and Cons Scalability Release procedure ML engineers can focus on backend services without the effects on other services Only backend services with high load can be scaled up and can use GPU effectively Need to consider the release procedure carefully Effective development Setup local environment for researchers Previous Coharis is still used for research purposes since this is easier to set up J J L L
51. n We introduced TTS system for product ready environment n The new architecture makes ML engineers focus on developing TTS n Renewing architecture results in faster development and easier scaling Summary
52. Thank you!!
