Anko to Jetpack Compose, LINE Sticker Maker's Technical Debt Resolution

Po-Hao Chen (Po) (LINE Fukuoka / Development C Team / Android Developer)

https://tech-verse.me/ja/sessions/16
https://tech-verse.me/en/sessions/16
https://tech-verse.me/ko/sessions/16

Transcript

1. View Slide

2. Takeaway of This Session
   - Why the migration is inevitable
   - Migration plan plays a big role to protect user experience
   - Our learning when migrating from Anko to Jetpack Compose


   View Slide

3. Agenda
   - About LINE Sticker Maker
   - Tech Stack and Debt
   - Migration Plan
   - Obstacles and Resolution
   - Release Strategy


   View Slide

4. About Me
   Po-Hao Chen (Po)
   - Android Engineer at LINE Fukuoka
   - Project
   - LINE Wallet
   - LINE Sticker Maker


   View Slide

5. LINE Sticker Maker
   - Creating LINE Stickers on
   smartphone with simple edit flow
   - Create for scratch, existing image or
   LINE Avatar
   - Various image editing tools
   - Concluding the flow of creating sticker
   to requesting for sale all on one
   device/app


   View Slide

6. LINE Sticker Maker History
   2021.05
   Rebranding to LINE
   Sticker Maker
   2018.10
   Image Auto
   Trimming Feature
   with OpenCV
   2021.12
   LINE Avatar
   Sticker Creation
   2018.11
   Sticker Campaign
   Frame Feature
   2017.06
   Service Launched
   as LINE Creators
   Studio


   View Slide

7. Tech Stack
   - Kotlin
   - Anko Layout
   - RxJava
   - Coroutine
   - Realm
   - Retrofit
   - OkHttp
   - Hilt


   View Slide

8. Tech Stack
   - Kotlin;
   - Anko Layout
   - RxJava
   - Coroutine
   - Realm
   - Retrofit
   - OkHttp
   - Hilt
   !!


   View Slide

9. What is Anko Layout
   A fast and type-safe way to write dynamic Android layouts with KotlinaDSL, by JetBrains


   View Slide

10. Anko Layout
    linearLayout {
    }


    View Slide

11. Anko Layout
    linearLayout {
    id = R.id.container
    gravity = Gravity.CENTER
    backgroundColor = R.color.background
    }


    View Slide

12. Anko Layout
    linearLayout {
    id = R.id.container
    gravity = Gravity.CENTER
    backgroundColor = R.color.background
    themedTextView(R.style.CommonButtonStyle) {
    textResource = R.string.common_done
    }
    }


    View Slide

13. Anko Layout
    linearLayout {
    id = R.id.container
    gravity = Gravity.CENTER
    backgroundColor = R.color.background
    themedTextView(R.style.CommonButtonStyle) {
    textResource = R.string.common_done
    onClick {
    actionA()
    }
    }
    }


    View Slide

14. Anko Layout
    linearLayout {
    id = R.id.container
    gravity = Gravity.CENTER
    backgroundColor = R.color.background
    themedTextView(R.style.CommonButtonStyle) {
    textResource = R.string.common_done
    onClick {
    if (isFirstVisit) {
    actionA()
    } else {
    actionB()
    }
    }
    }
    }


    View Slide

15. Write UI with Anko
    - Fast Performance


    View Slide

16. - Presentation Logic in UI code
    - Fast Performance
    Write UI with Anko


    View Slide

17. - Presentation Logic in UI code
    - More Flexible than XML
    - Fast Performance
    Write UI with Anko


    View Slide

18. However, in 2019…


    View Slide

19. The Team Decided to Keep Using it


    View Slide

20. The Team Decided to Keep Using it
    2 Years Later…


    View Slide

21. The Team Decided to Keep Using it
    2 Years Later…
    The Technical Debt


    View Slide

22. The Technical Debt
    As we decided to continue to self-maintain Anko Layout
    - Anko Layout is lack of UI Preview feature


    View Slide

23. The Technical Debt
    As we decided to continue to self-maintain Anko Layout
    - diff Anko-Layout Android-Support-Library
    - Anko Layout is lack of UI Preview feature


    View Slide

24. The Technical Debt
    As we decided to continue to self-maintain Anko Layout
    - diff Anko-Layout Android-Support-Library
    - Bottleneck for introducing new-comers
    - Anko Layout is lack of UI Preview feature


    View Slide

25. To Jetpack Compose
    The Declarative UI Framework for Android
    - Migration was considered soon after
    the deprecation of Anko Layout
    - Jetpack Compose stable-release in
    July 2021
    - The Team proceed to migrate in
    March 2022


    View Slide

26. Migration is Inevitable


    View Slide

27. Migration is Inevitable
    Migration
    Started for
    Developer Needs


    View Slide

28. Migration is Inevitable
    What if…?
    Migration
    Started for
    Developer Needs
    User get
    Affected "
    Migration Side Effect


    View Slide

29. Migration is Inevitable
    What if…?
    User get
    Affected "
    Migration Side Effect
    ❌
    Migration
    Started for
    Developer Needs
    Developer Experience x User Experience


    View Slide

30. Developer Experience x User Experience
    Migration is Inevitable
    What if…?
    User get
    Affected "
    Migration Side Effect
    ❌
    Migration
    Started for
    Developer Needs
    A Proper Migration Plan is Important


    View Slide

31. Strategy for Continuous Migration
    Let the Migration
    Begins


    View Slide

32. Migration Goal
    Keep in mind what the most important goal is
    For Maintainability
    Replace
    Anko


    View Slide

33. Migration Goal
    Keep in mind what the most important goal is
    Refactor
    Legacy Code
    For Maintainability
    1st Priority
    Replace
    Anko
    UI
    Performance
    Keep minimal Avoid over-tuning


    View Slide

34. Migration Goal
    Keep in mind what the most important goal is
    Refactor
    Legacy Code
    For Maintainability
    1st Priority
    Replace
    Anko
    UI
    Performance
    Keep minimal Avoid over-tuning
    Keep in Sync, Aiming for the Same Goal


    View Slide

35. Migration Plan
    Release Remove Improve
    Implement


    View Slide

36. Migration Plan
    Refactor and
    recreate the same
    UI in Compose
    After QA, enable
    Compose in release
    build
    Release Remove Improve
    Implement
    Remove Anko
    completely
    Replace
    Fragment-based
    structure


    View Slide

37. Migration Plan
    Current Phase
    Refactor and
    recreate the same
    UI in Compose
    After QA, enable
    Compose in release
    build
    Release Remove Improve
    Implement


    View Slide

38. LINE Sticker Maker Code Structure
    Feature-based Multi-Module
    - Features are independent from
    each other
    :app
    :feature:a :feature:b :feature:c
    :core


    View Slide

39. LINE Sticker Maker Code Structure
    Feature-based Multi-Module
    - Features are independent from
    each other
    - Create a `common-ui` module with
    no other dependency for common
    UI components
    :app
    :feature:a :feature:b :feature:c
    :core :common-ui


    View Slide

40. Obstacles for Migration
    - Mixing Layer between data and UI in older features
    - Massive Usage of Custom Android View
    - Fragment Based Navigation


    View Slide

41. Yes or No Fragments?


    View Slide

42. Keep Most of the Fragments
    For now
    - Migrate to Navigation Compose at one go is risky
    - Speedy iteration of screen-based migration and quality assurance
    - Have the Screen Composable ready for future improvement


    View Slide

43. Mixing of Layers


    View Slide

44. - Presentation Logic in UI code
    - More Flexible than XML
    - Fast Performance
    Write UI with Anko


    View Slide

45. - Presentation Logic in UI code
    - More Flexible than XML
    - Fast Performance
    Write UI with Anko


    View Slide

46. Current Situation
    UI
    Anko
    Data Provider
    Data Provider
    .
    .
    .


    View Slide

47. Refactor for Clean Architecture
    Data Layer
    UI Layer
    UI Elements
    StateHolder/ViewModel
    App Data
    UI State (Processed Data) UI Event


    View Slide

48. Current Situation
    UI
    Anko
    Data Provider
    Data Provider
    .
    .
    .


    View Slide

49. Refactor Result
    UI
    Anko
    Data Provider
    Data Provider
    .
    .
    . ViewModel
    UI Implementation


    View Slide

50. .uiState
    Isolated Ui Data
    class SampleViewModel() {
    val uiState: StateFlow
    }


    View Slide

51. Isolated Ui Data
    class SampleScreenFragment : Fragment() {
    override fun onCreateView(): View =
    SampleScreenUi().createView(AnkoContext.create(requireContext(), this))
    .also {
    viewLifecycleOwner.lifecycleScope.launch {
    sampleViewModel
    .uiState
    .flowWithLifecycle(lifecycle, Lifecycle.State.STARTED)
    .collect {
    // update UI
    }
    }
    }
    }


    View Slide

52. Next Step: Migrate to Compose
    UI
    Anko
    ViewModel
    Compose
    Swap UI Implementation


    View Slide

53. Feature Flag in UI Layer
    UI
    Anko
    Compose
    ViewModel FeatureFlag


    View Slide

54. Same Data, Different UI Implementation
    class SampleScreenFragment : Fragment() {
    override fun onCreateView(): View =
    SampleScreenUi().createView(AnkoContext.create(requireContext(), this))
    .also {
    viewLifecycleOwner.lifecycleScope.launch {
    sampleViewModel
    .uiState
    .flowWithLifecycle(lifecycle, Lifecycle.State.STARTED)
    .collect {
    // update UI
    }
    }
    }
    }


    View Slide

55. Same Data, Different UI Implementation
    class SampleScreenFragment : Fragment() {
    override fun onCreateView(): View = if (FeatureFlag.FEATURE_SAMPLE_USE_COMPOSE) {
    } else {
    SampleScreenUi().createView(AnkoContext.create(requireContext(), this))
    }
    }


    View Slide

56. Same Data, Different UI Implementation
    class SampleScreenFragment : Fragment() {
    override fun onCreateView(): View = if (FeatureFlag.FEATURE_SAMPLE_USE_COMPOSE) {
    // Compose View Creation
    ComposeView(requireContext()).apply {
    // ...
    }
    }
    } else {
    // Anko View Creation
    SampleScreenUi().createView(AnkoContext.create(requireContext(), this))
    }
    }


    View Slide

57. Same Data, Different UI Implementation
    class SampleScreenFragment : Fragment() {
    override fun onCreateView(): View = if (FeatureFlag.FEATURE_SAMPLE_USE_COMPOSE) {
    // Compose View Creation
    ComposeView(requireContext()).apply {
    // ...
    setContent {
    val uiState by sampleViewModel
    .uiState
    .collectAsLifecycleAwareState(SampleViewModel.UiState())
    }
    }
    } else {
    // Anko View Creation
    SampleScreenUi().createView(AnkoContext.create(requireContext(), this))
    }
    }


    View Slide

58. AS IS
    Activity
    Fragment
    AnkoView
    Fragment Fragment
    AnkoView AnkoView


    View Slide

59. TO BE
    Activity
    Fragment
    AnkoView
    Fragment Fragment
    AnkoView AnkoView
    ComposeView ComposeView ComposeView
    FeatureFlag
    FeatureFlag FeatureFlag


    View Slide

60. - With Clear Layering, switching UI at
    runtime become possible
    - Allow Developers to easily validate
    implementation
    - Simplify QA process without several
    build configs
    Runtime UI switching


    View Slide

61. Custom AndroidViews


    View Slide

62. Custom Android Views
    - Utilized Interoperability API for fast migration
    - Large amount of custom Android Views are used (for image editing)


    View Slide

63. Custom Android Views
    @Composable
    private fun TrimmingComposable(
    bitmap: Bitmap,
    baseMatrix: Matrix,
    modifier: Modifier = Modifier
    ) {
    }


    View Slide

64. Custom Android Views
    @Composable
    private fun TrimmingComposable(
    bitmap: Bitmap,
    baseMatrix: Matrix,
    modifier: Modifier = Modifier
    ) {
    AndroidView(
    modifier = modifier,
    factory = {
    TrimmingView(context)
    },
    update = { view ->
    view.bitmap = bitmap
    view.baseMatrix = baseMatrix
    }
    )
    }


    View Slide

65. Custom Android Views
    @Composable
    private fun TrimmingComposable(
    bitmap: Bitmap,
    baseMatrix: Matrix,
    modifier: Modifier = Modifier
    ) {
    AndroidView(
    modifier = modifier,
    factory = {
    TrimmingView(context)
    },
    update = { view ->
    view.bitmap = bitmap
    view.baseMatrix = baseMatrix
    }
    )
    }


    View Slide

66. Custom Android Views
    @Composable
    private fun TrimmingComposable(
    bitmap: Bitmap,
    baseMatrix: Matrix,
    modifier: Modifier = Modifier
    ) {
    AndroidView(
    modifier = modifier,
    factory = {
    TrimmingView(context)
    },
    update = { view ->
    view.bitmap = bitmap
    view.baseMatrix = baseMatrix
    }
    )
    }


    View Slide

67. Custom Android Views
    @Composable
    private fun TrimmingComposable(
    bitmap: Bitmap,
    baseMatrix: Matrix,
    modifier: Modifier = Modifier
    ) {
    AndroidView(
    modifier = modifier,
    factory = {
    TrimmingView(context)
    },
    update = { view ->
    view.bitmap = bitmap
    view.baseMatrix = baseMatrix
    }
    )
    }


    View Slide

68. Custom Android Views
    @Composable
    private fun TrimmingComposable(
    bitmap: Bitmap,
    baseMatrix: Matrix,
    modifier: Modifier = Modifier
    ) {
    AndroidView(
    modifier = modifier,
    factory = {
    TrimmingView(context)
    },
    update = { view ->
    view.bitmap = bitmap
    view.baseMatrix = baseMatrix
    }
    )
    }
    Simple?


    View Slide

69. Custom Android Views
    @Composable
    private fun TrimmingComposable(
    bitmap: Bitmap,
    baseMatrix: Matrix,
    modifier: Modifier = Modifier
    ) {
    AndroidView(
    modifier = modifier,
    factory = {
    TrimmingView(context)
    },
    update = { view ->
    view.bitmap = bitmap
    view.baseMatrix = baseMatrix
    }
    )
    }
    Actually Not So Simple… $


    View Slide

70. View Event Does Not Align With Compose
    class TrimmingView {
    var baseMatrix = Matrix()
    };


    View Slide

71. View Event Does Not Align With Compose
    class TrimmingView {
    var baseMatrix = Matrix()
    };
    private fun loadImageAndBaseMatrixFromViewModel() {
    ui.trimmingView.imageBitmap = editImageViewModel.loadImage()
    ui.trimmingView.baseMatrix = editImageViewModel.baseMatrix
    }


    View Slide

72. View Event Does Not Align With Compose
    class TrimmingView {
    var baseMatrix = Matrix()
    };
    private fun loadImageAndBaseMatrixFromViewModel() {
    ui.trimmingView.imageBitmap = editImageViewModel.loadImage()
    ui.trimmingView.baseMatrix = editImageViewModel.baseMatrix
    }


    View Slide

73. View Event Does Not Align With Compose
    class TrimmingView {
    var baseMatrix = Matrix()
    };
    private fun loadImageAndBaseMatrixFromViewModel() {
    ui.trimmingView.imageBitmap = editImageViewModel.loadImage()
    ui.trimmingView.baseMatrix = editImageViewModel.baseMatrix
    }


    View Slide

74. View Event Does Not Align With Compose
    @Composable
    private fun TrimmingComposable(
    bitmap: Bitmap,
    baseMatrix: Matrix,
    modifier: Modifier = Modifier
    ) {
    AndroidView(
    modifier = modifier,
    factory = {
    TrimmingView(context)
    },
    update = { view ->
    view.bitmap = bitmap
    view.baseMatrix = baseMatrix
    }
    )
    }


    View Slide

75. @Composable
    private fun TrimmingComposable(
    bitmap: Bitmap,
    baseMatrix: Matrix,
    modifier: Modifier = Modifier
    ) {
    AndroidView(
    modifier = modifier,
    factory = {
    TrimmingView(context)
    },
    update = { view ->
    view.bitmap = bitmap
    view.baseMatrix = baseMatrix
    }
    )
    }
    View Event Does Not Align With Compose
    Not Working As Expected… $


    View Slide

76. View Event Does Not Align With Compose
    class TrimmingView {
    var baseMatrix = Matrix()
    override fun onSizeChanged() {
    super.onSizeChanged()
    resetMatrix()
    }
    }


    View Slide

77. Anko
    Create View
    OnSizeChanged Reset Matrix
    Set Bitmap
    Set Base Matrix


    View Slide

78. Anko Compose
    Create View
    Set Bitmap
    Set Base Matrix
    OnSizeChanged Reset Matrix


    View Slide

79. Anko Compose
    Create View
    Set Bitmap
    Set Base Matrix
    OnSizeChanged Reset Matrix
    Create View
    Data Binding
    Create View
    OnSizeChanged Reset Matrix
    Set Bitmap
    Set Base Matrix
    Update Block


    View Slide

80. View Event Does Not Align With Compose
    AndroidView(
    modifier = modifier,
    factory = {
    TrimmingView(context).apply {
    onSizeChangeListener =
    TrimmingView.OnSizeChangeListener {
    trimmingView.baseMatrix = baseMatrix
    }
    }
    },
    update = { view ->
    view.bitmap = bitmap
    }
    )


    View Slide

81. View Event Does Not Align With Compose
    AndroidView(
    modifier = modifier,
    factory = {
    TrimmingView(context).apply {
    onSizeChangeListener =
    TrimmingView.OnSizeChangeListener {
    trimmingView.baseMatrix = baseMatrix
    }
    }
    },
    update = { view ->
    view.bitmap = bitmap
    }
    )
    class TrimmingView {
    override fun onSizeChanged() {
    super.onSizeChanged()
    resetMatrix()
    onSizeChangeListener.onSizeChanged()
    }
    }


    View Slide

82. View Event Does Not Align With Compose
    AndroidView(
    modifier = modifier,
    factory = {
    TrimmingView(context).apply {
    onSizeChangeListener =
    TrimmingView.OnSizeChangeListener {
    trimmingView.baseMatrix = baseMatrix
    }
    }
    },
    update = { view ->
    view.bitmap = bitmap
    }
    )
    class TrimmingView {
    override fun onSizeChanged() {
    super.onSizeChanged()
    resetMatrix()
    onSizeChangeListener.onSizeChanged()
    }
    }
    Create View
    Set Bitmap
    Set Base Matrix
    OnSizeChanged Reset Matrix


    View Slide

83. View Event Does Not Align With Compose
    AndroidView(
    modifier = modifier,
    factory = {
    TrimmingView(context).apply {
    onSizeChangeListener =
    TrimmingView.OnSizeChangeListener {
    trimmingView.baseMatrix = baseMatrix
    }
    }
    },
    update = { view ->
    view.bitmap = bitmap
    }
    )
    class TrimmingView {
    override fun onSizeChanged() {
    super.onSizeChanged()
    resetMatrix()
    onSizeChangeListener.onSizeChanged()
    }
    }
    Create View
    Set Bitmap
    Set Base Matrix
    OnSizeChanged Reset Matrix


    View Slide

84. Android View Internal State Restoration
    @Composable
    fun SampleComposable(
    modifier: Modifier = Modifier,
    ) {
    val stateToPreserved = rememberSaveable {
    }
    }


    View Slide

85. Android View Internal State Restoration
    @Composable
    fun SampleComposable(
    modifier: Modifier = Modifier,
    ) {
    val stateToPreserved = rememberSaveable {
    }
    }
    Will be restored when recreation


    View Slide

86. Android View Internal State Restoration
    class TrimmingView {
    var baseMatrix;=;Matrix();
    };


    View Slide

87. Android View Internal State Restoration
    class TrimmingView {
    var baseMatrix;=;Matrix();
    val transformMatrix = Matrix()
    };


    View Slide

88. Android View Internal State Restoration
    class TrimmingView {
    val transformMatrix = Matrix()
    override fun onSaveInstanceState(): Parcelable {
    val parentState: Parcelable? = super.onSaveInstanceState()
    return bundleOf(
    KEY_TRANSFORM_MATRIX to transformMatrix.getValues(),
    KEY_PARENT_STATE to parentState
    )
    }
    override fun onRestoreInstanceState(state: Parcelable?) {
    // …
    val transform = (state as Bundle).getFloatArray(KEY_TRANSFORM_MATRIX)
    transformMatrix.setValues(transform)
    // …
    }
    };


    View Slide

89. Android View Internal State Restoration
    @Composable
    private fun TrimmingComposable(
    bitmap: Bitmap,
    baseMatrix: Matrix,
    modifier: Modifier = Modifier
    ) {
    AndroidView(
    modifier = modifier,
    factory = {
    TrimmingView(context)
    .apply {
    id = R.id.trimming_view
    // …
    }
    },
    update = { view ->
    view.bitmap = bitmap
    view.baseMatrix = baseMatrix
    }
    )
    }


    View Slide

90. What’s happening next?
    Release Strategy and
    Feature Work


    View Slide

91. Developer Experience x User Experience
    Migration is Inevitable
    What if…?
    User get
    Affected "
    Migration Side Effect
    ❌
    Migration
    Started for
    Developer Needs


    View Slide

92. Release Strategy
    - Release feature-by-feature


    View Slide

93. Release Strategy
    - Outage monitoring
    - Release feature-by-feature


    View Slide

94. Release Strategy
    - Outage monitoring
    - Fix issue or Quick rollback with feature flag
    - Release feature-by-feature


    View Slide

95. Future Works
    Remove Anko
    completely
    Replace
    Fragment-based
    structure
    Release Remove Improve
    Implement


    View Slide

96. The Technical Debt
    - diff Anko-Layout Android-Support-Library
    - Bottleneck for introducing new-comers
    - Anko Layout is lack of UI Preview feature


    View Slide

97. The Technical Debt
    - diff Anko-Layout Android-Support-Library
    - Bottleneck for introducing new-comers
    - Anko Layout is lack of UI Preview feature
    - Compose Preview


    View Slide

98. The Technical Debt
    - diff Anko-Layout Android-Support-Library
    - Jetpack Library Support
    - Bottleneck for introducing new-comers
    - Anko Layout is lack of UI Preview feature
    - Compose Preview


    View Slide

99. The Technical Debt
    - diff Anko-Layout Android-Support-Library
    - Jetpack Library Support
    - Bottleneck for introducing new-comers
    - Spotlighted topic in Android community
    - Anko Layout is lack of UI Preview feature
    - Compose Preview


    View Slide

100. Migration is Inevitable
     - Developers are the main beneficiary of the migration, but we should keep
     user in mind
     We should…


     View Slide

101. Migration is Inevitable
     - Plan from the beginning and plan for the worst case
     - Developers are the main beneficiary of the migration, but we should keep
     user in mind
     We should…


     View Slide

102. Migration is Inevitable
     - Plan from the beginning and plan for the worst case
     - Focus on the goal as a team
     - Developers are the main beneficiary of the migration, but we should keep
     user in mind
     We should…


     View Slide

103. Migration is Inevitable


     View Slide

104. Migration is Tough "
     - Tidying up Fragment class with 1000+ lines of code %
     - Facing bug with no previous case study &
     - Trying to understand mysterious legacy code $


     View Slide

105. Migration is Tough "


     View Slide

106. Migration Can Also Be … Fun! '
     - Developers get their hands on the newest technology


     View Slide

107. Migration Can Also Be … Fun! '
     - Knowledge sharing between developers has become more proactive
     - Developers get their hands on the newest technology


     View Slide

108. Migration Can Also Be … Fun! '
     - Knowledge sharing between developers has become more proactive
     - Enjoy the Challenges
     - Developers get their hands on the newest technology


     View Slide

109. Thank you


     View Slide
