Speed up Rails, Speed up your code

Transcript

1. Hello!!!

2. Welcome!

3. None

4. Thanks!!!

5. YOU PARTY ME!

6. As Loooonnnngg As Possible

7. None

8. Aaron Patterson @tenderlove

9. None
10. None

11. Ruby Core Rails Core

12. This is my first time to give a talk.

13. Twitter: tenderlove GitHub: tenderlove Instagram: tenderlove Yo: tenderlove

14. ಠ_ಠ ಠ_ಠ Separation Of Concerns

15. OMG! INTERNET! POINTS

16. Revert Commits Count Too!

17. More mistakes == more points!!!!

18. Short Stack Engineer

19. None
20. None

21. Dad-Joke Programmer

22. Gorbachev Puff Puff Thunderhorse

23. SEA-TAC Airport YouTube

24. None
25. None

26. Last Year

27. Hawker Centers

28. None
29. None

30. I love food!

31. Earth (top)

32. Radius at Latitude R = radius of earth! a =

    equatorial radius! b = polar radius! l = geodetic latitude

33. Seattle Singapore Latitude 47.6097° N 1.3667° N Radius 6,373 km

    6,357 km
34. None
35. None

36. WE MISS YOU,! JIM!

37. Durian Fruit!!!

38. None
39. None
40. None
41. None

42. Node.JS

43. Closer to the METAL

44. None

45. Speed up Rails,! Speed up your Code

46. Rails.inspect

47. THIS IS NOT MAGENTA

48. Performance! Tradeoffs

49. Speed vs! Memory

50. Time vs! Space

51. VS

52. Space! isn’t free.

53. Time! isn’t free.

54. Nothing! is free.

55. VS

56. Find a better algorithm.

57. Mystical Unicorn

58. Making Tradeoffs

59. RAM is cheap. (for web developers) SORRY HEROKU!

60. SPEED at the! cost of RAM.

61. Time and space are related.

62. Performance Tools

63. Raw Performance

64. benchmark/ips

65. benchmark Benchmark.bm do |x| x.report('some test') { N.times { some_test

    } } end How big? STD LIB

66. Output user system total real some test 0.000000 0.000000 0.000000

    ( 0.000098)

67. benchmark/ips require 'benchmark/ips' require 'set' ! list = ('a'..'zzzz').to_a set

    = Set.new list ! Benchmark.ips do |x| x.report("set access") { set.include? "foo" } ! x.report("ary access") { list.include? "foo" } end G EM

68. Output Calculating ------------------------------------- set access 68622 i/100ms ary access 395

    i/100ms ------------------------------------------------- set access 3047175.3 (±12.7%) i/s - 14959596 in 5.018692s ary access 3899.2 (±7.1%) i/s - 19750 in 5.096118s IPS

69. Set Include: 3047175.3 / sec

70. Array Include: 3899.2 / sec

71. IPS: Higher Is Better

72. Output Calculating ------------------------------------- set access 68622 i/100ms ary access 395

    i/100ms ------------------------------------------------- set access 3047175.3 (±12.7%) i/s - 14959596 in 5.018692s ary access 3899.2 (±7.1%) i/s - 19750 in 5.096118s STDDEV

73. benchmark N = 100000 ! list = ('a'..'zzz').to_a hash =

    list.each_with_object({}) { |x,h| h[x] = true } set = Set.new list ! Benchmark.bm do |x| x.report("set access") { N.times { set.include? "foo" } } ! x.report("hash access") { N.times { hash.include? "foo" } } end STD LIB

74. Output user system total real set access 0.030000 0.000000 0.030000

    ( 0.030044) hash access 0.030000 0.000000 0.030000 ( 0.032125) Set Is Faster? benchm ark

75. benchmark/ips list = ('a'..'zzz').to_a hash = list.each_with_object({}) { |x,h| h[x]

    = true } set = Set.new list ! Benchmark.ips do |x| x.report("set access") { set.include? "foo" } x.report("hash access") { hash.include? "foo" } end G EM

76. Output Calculating ------------------------------------- set access 73910 i/100ms hash access 73845

    i/100ms ------------------------------------------------- set access 3081455.6 (±7.6%) i/s - 15299370 in 4.999343s hash access 3772358.3 (±7.2%) i/s - 18756630 in 5.004747s benchm ark/ips

77. IPS Graph 0 1000000 2000000 3000000 4000000 Iterations / Sec

    Set access Hash Access

78. Blackbox Testing

79. Cache Impls cache1 = Cache1.new cache2 = Cache2.new ! cache1["x"]

    = Object.new cache2["x"] = Object.new ! Benchmark.ips do |x| x.report("cache1") { cache1["x"] } x.report("cache2") { cache2["x"] } end

80. Collect Reports reports = [10, 100, 1000, 100_000].map do |i|

    cache1 = Cache1.new cache2 = Cache2.new ! (i - 1).times { |z| cache2[z.to_s] = cache1[z.to_s] = Object.new } ! cache1["x"] = Object.new cache2["x"] = Object.new ! report = Benchmark.ips do |x| x.report("cache1") { cache1["x"] } x.report("cache2") { cache2["x"] } end [i, report] end Report

81. Compile Data header = nil rows = reports.map { |i,report|

    header ||= [nil] + report.map(&:label) ["#{i} elements"] + report.map { |r| (1 / r.ips) * 10_000 } } puts header.join ',' rows.each { |r| puts r.join ',' } Seconds Per Iteration Seconds for 10k iters

82. Runtime Graph Time for 10,000 iterations (seconds) 0.01 0.1 1

    10 100 Cache Size 10 elements 100 elements 1000 elements 100000 elements Cache 1 Cache 2

83. Cache Implementation class Cache1 def initialize @cache = {} end

    def [] k; @cache[k]; end def []= k,v; @cache[k] = v; end end ! class Cache2 def initialize @cache = [] end def [] k; x, = @cache.assoc(k); x; end def []= k,v; @cache << [k, v]; end end Constant Linear

84. Real World Example: Routes

85. Number Of Routes class MyTest routes = ActionDispatch::Routing::RouteSet.new routes.draw {

    resources(:articles) } end ! article = Article.new.tap(&:save!) ! Benchmark.ips do |x| x.report("link_to") { test.link_to "zomg", article } end

86. Add 10 routes class MyTest routes = ActionDispatch::Routing::RouteSet.new routes.draw {

    resources(:articles) 10.times do |num| resources num.to_s.to_sym end } end

87. Add 100 routes class MyTest routes = ActionDispatch::Routing::RouteSet.new routes.draw {

    resources(:articles) 100.times do |num| resources num.to_s.to_sym end } end

88. Add 1000 routes class MyTest routes = ActionDispatch::Routing::RouteSet.new routes.draw {

    resources(:articles) 1000.times do |num| resources num.to_s.to_sym end } end

89. Sec / 100k calls 9.5 9.7 9.9 10.1 10.3 1

    2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 link_to

90. Size of URL class MyTest routes = ActionDispatch::Routing::RouteSet.new link =

    'a' ! routes.draw { get "/#{link}/:id", :as => :article, :controller => :articles, :action => :show } end ! test = MyTest.new article = Article.new.tap(&:save!) ! puts "Model Instance" Benchmark.ips do |x| x.report("link_to") { test.link_to "zomg", article } end

91. Length of 1 class MyTest routes = ActionDispatch::Routing::RouteSet.new link =

    1.times.map(&:to_s).join '/' ! routes.draw { get "/#{link}/:id", :as => :article, :controller => :articles, :action => :show } end

92. Length of 10 class MyTest routes = ActionDispatch::Routing::RouteSet.new link =

    10.times.map(&:to_s).join '/' ! routes.draw { get "/#{link}/:id", :as => :article, :controller => :articles, :action => :show } end

93. Length of 100 class MyTest routes = ActionDispatch::Routing::RouteSet.new link =

    100.times.map(&:to_s).join '/' ! routes.draw { get "/#{link}/:id", :as => :article, :controller => :articles, :action => :show } end

94. Sec / 100k calls 9 10.5 12 13.5 15 1

    2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 link_to

95. Where is time spent?

96. stackprof https://github.com/tmm1/stackprof

97. Profiling url_for require 'stackprof' StackProf.run(mode: :cpu, out: 'url_for.dump') do 5000.times

    { test.url_for article } end

98. View Results $ stackprof url_for.dump --text

99. ================================== Mode: cpu(1000) Samples: 218 (0.00% miss rate) GC: 27

    (12.39%) ================================== TOTAL (pct) SAMPLES (pct) FRAME 149 (68.3%) 57 (26.1%) ActionDispatch::Routing::RouteSet#url_for 183 (83.9%) 19 (8.7%) ActionDispatch::::UrlHelper#call 18 (8.3%) 18 (8.3%) #<Module:0x007fb2f4ea3db0>.build_host_url 14 (6.4%) 13 (6.0%) ActionDispatch::UrlHelper#handle_positional_args 68 (31.2%) 12 (5.5%) ActionDispatch::Journey::Formatter#generate 66 (30.3%) 12 (5.5%) ActionDispatch::Formatter#visit_CAT 10 (4.6%) 10 (4.6%) ActionDispatch::Utils::UriEncoder#escape 56 (25.7%) 7 (3.2%) block in ActionDispatch::Formatter#generate 13 (6.0%) 5 (2.3%) ActionDispatch#extract_parameterized_parts

100. GC.stat()

101. Total allocations GC.stat(:total_allocated_object)

102. Measure Allocations Person.find id before = GC.stat(:total_allocated_object) N.times { Person.find

     id } after = GC.stat(:total_allocated_object) puts (after - before) / N W arm up Benchmark Objects / Call Count O bjs C ount O bjs

103. Real World Example: Views

104. Request Benchmark task :allocated_objects do app = Ko1TestApp::Application.instance app.app do_test_task(app)

     env = rackenv "/books/new" do_test_task(app, env.dup) before = GC.stat :total_allocated_object TEST_CNT.times { do_test_task(app, env.dup) } after = GC.stat :total_allocated_object puts (after - before) / TEST_CNT end "/books/new"

105. Request Benchmark task :allocated_objects do app = Ko1TestApp::Application.instance app.app do_test_task(app)

     env = rackenv "/books/new" do_test_task(app, env.dup) before = GC.stat :total_allocated_object TEST_CNT.times { do_test_task(app, env.dup) } after = GC.stat :total_allocated_object puts (after - before) / TEST_CNT end

106. Request Benchmark task :allocated_objects do app = Ko1TestApp::Application.instance app.app do_test_task(app)

     env = rackenv "/books/new" do_test_task(app, env.dup) before = GC.stat :total_allocated_object TEST_CNT.times { do_test_task(app, env.dup) } after = GC.stat :total_allocated_object puts (after - before) / TEST_CNT end

107. Test Results Object Allocations Per Request 2000 2150 2300 2450

     2600 4-0-stable 4-1-stable master 2000

108. HOW TO LIE WITH GRAPHS

109. Test Results Object Allocations Per Request 0 650 1300 1950

     2600 4-0-stable 4-1-stable master

110. ~19% reduction since 4-0-stable

111. ~14% reduction since 4-1-stable

112. allocation_tracer https://github.com/ko1/allocation_tracer

113. Example ObjectSpace::AllocationTracer.trace do 1000.times { ["foo", {}] } end !

     ObjectSpace::AllocationTracer.allocated_count_table

114. Output {:T_NONE=>0, :T_OBJECT=>0, :T_CLASS=>0, :T_MODULE=>0, :T_FLOAT=>0, :T_STRING=>1000, :T_REGEXP=>0, :T_ARRAY=>1000, :T_HASH=>1000,

     :T_ZOMBIE=>0}

115. Speeding up ActiveRecord

116. ~3 Years of work

117. How! ActiveRecord! works.

118. ActiveRecord::Relation Post.find(10) ARel::SQL::Node Database ActiveRecord::Base SELECT * FROM …

119. Part 1

120. Bind Parameter Introduction

121. Post.find(1) Post.find(3) Post.find(5) SELECT * FROM posts WHERE id =

     1 SELECT * FROM posts WHERE id = 3 SELECT * FROM posts WHERE id = 5

122. Post.find(1) Post.find(3) Post.find(5) SELECT * FROM posts WHERE id =

     ? [id, 1] SELECT * FROM posts WHERE id = ? [id, 3] SELECT * FROM posts WHERE id = ? [id, 5]

123. Separate static and dynamic content

124. Theory

125. ActiveRecord::Relation Post.find(10) ARel::SQL::Node Database ActiveRecord::Base SELECT * FROM … Cacheable

126. Part 2

127. Code Decoupling

128. def add_constraints(scope) tables = construct_tables ! chain.each_with_index do |reflection, i|

     table, foreign_table = tables.shift, tables.first ! if reflection.source_macro == :has_and_belongs_to_many join_table = tables.shift ! scope = scope.joins(join( join_table, table[reflection.association_primary_key]. eq(join_table[reflection.association_foreign_key]) )) ! table, foreign_table = join_table, tables.first end ! if reflection.source_macro == :belongs_to if reflection.options[:polymorphic] key = reflection.association_primary_key(klass) else key = reflection.association_primary_key end ! foreign_key = reflection.foreign_key else key = reflection.foreign_key foreign_key = reflection.active_record_primary_key end ! if reflection == chain.last bind_val = bind scope, table.table_name, key.to_s, owner[foreign_key] scope = scope.where(table[key].eq(bind_val)) ! if reflection.type value = owner.class.base_class.name bind_val = bind scope, table.table_name, reflection.type.to_s, value scope = scope.where(table[reflection.type].eq(bind_val)) end else constraint = table[key].eq(foreign_table[foreign_key]) ! if reflection.type type = chain[i + 1].klass.base_class.name constraint = constraint.and(table[reflection.type].eq(type)) end ! scope = scope.joins(join(foreign_table, constraint)) end ! # Exclude the scope of the association itself, because that # was already merged in the #scope method. (scope_chain[i] - [self.reflection.scope]).each do |scope_chain_item| item = eval_scope(reflection.klass, scope_chain_item) ! scope.includes! item.includes_values scope.where_values += item.where_values end end ! scope end

129. One Method to Rule Them All, And In Legacy Code

     Bind Them.

130. rm habtm R ails 4.1

131. habtm.is_a?(hm:t) #=> true

132. commit 88c009377851912c60fd16ec4bfab3001ac2cf9f Author: Aaron Patterson <aaron.patterson@gmail.com> Date: Wed Oct 2

     15:53:56 2013 -0700 ! remove HABTM special cases from associations classes ! diff --git a/activerecord/lib/active_record/associations/association_scope.rb b/activerecord/lib/ active_record/associations/association_scope.rb index 8027acf..d862a5f 100644 --- a/activerecord/lib/active_record/associations/association_scope.rb +++ b/activerecord/lib/active_record/associations/association_scope.rb @@ -44,18 +44,6 @@ module ActiveRecord chain.each_with_index do |reflection, i| table, foreign_table = tables.shift, tables.first - if reflection.source_macro == :has_and_belongs_to_many - join_table = tables.shift - - scope = scope.joins(join( - join_table, - table[reflection.association_primary_key]. - eq(join_table[reflection.association_foreign_key]) - )) - - table, foreign_table = join_table, tables.first - end - if reflection.source_macro == :belongs_to if reflection.options[:polymorphic] key = reflection.association_primary_key(self.klass) diff --git a/activerecord/lib/active_record/associations/join_dependency.rb b/activerecord/lib/ active_record/associations/join_dependency.rb index 5aa17e5..fa212f3 100644 --- a/activerecord/lib/active_record/associations/join_dependency.rb +++ b/activerecord/lib/active_record/associations/join_dependency.rb @@ -216,7 +216,7 @@ module ActiveRecord else association = join_part.instantiate(row) unless row[join_part.aliased_primary_key].nil? case macro - when :has_many, :has_and_belongs_to_many + when :has_many other = record.association(join_part.reflection.name) other.loaded! other.target.push(association) if association diff --git a/activerecord/lib/active_record/associations/join_dependency/join_association.rb b/ activerecord/lib/active_record/associations/join_dependency/join_association.rb

133. Part 3

134. Introduce a cache

135. Cache Code Example cache = ActiveRecord::StatementCache.new do |params| Person.where(name: params.bind).limit(1)

     end ! cache.execute ["Aaron"] cache.execute ["Ebi"] AR::Relation Execute

136. Binds Cache Object Internals #<ActiveRecord::StatementCache:0x007fb8522a09b0 @bind_map= #<BindMap:0x007fb8522a2490 @bind_values= [[#<SQLite3Column:0x007fb852384f98>, #<Substitute:0x007fb8522c35a0>]],

     @indexes=[0]>, @query_builder= #<Query:0x007fb8522a09d8 @sql= "SELECT \"people\".* FROM \"people\" WHERE \"people\".\"name\" = ? LIMIT 1">> C om piled SQ L

137. Update Internals, Cache Relation Objects

138. Things That Use Relations ❤ Post.find() ❤ Post.find_by_* ❤ has_many

     ❤ has_many :through ❤ has_and_belongs_to_many ❤ belongs_to All Cacheable

139. Example Implementation

140. Person.find(id) s = find_by_statement_cache.synchronize { find_by_statement_cache[key] ||= StatementCache.create(connection) { |params|

     where(primary_key => params.bind).limit(1) } } record = s.execute([id], self, connection).first R elation! (static) Parameter! (dynamic)

141. WHAT DO THESE EVEN MEAN??? Ways to call `Post.find` ❤

     Post.find(1) ❤ Post.find([1]) ❤ Post.find([[1]]) ❤ Post.find({1 => 1}) ❤ Post.find(post) ❤ Post.find(1) { … } ❤ scoping { Post.find(1) } Cachea wtf

142. Rejection Code def find(*ids) # We don't have cache keys

     for this stuff yet return super unless ids.length == 1 return super if block_given? || primary_key.nil? || default_scopes.any? || columns_hash.include?(inheritance_column) || ids.first.kind_of?(Array)

143. Performance of ActiveRecord

144. Post.find() Post.find_by_name()

145. `Post.find` Calls Per Second over Time Calls Per Second (higher

     is better) 0 4000 8000 12000 16000 2-3-stable 3-0-stable 3-1-stable 3-2-stable 4-0-stable 4-1-stable master adequaterecord SQLite3 MySQL2 MySQL PostgreSQL

146. `Post.find_by_name` Calls Per Second over Time Calls Per Second (higher

     is better) 0 3500 7000 10500 14000 2-3-stable 3-0-stable 3-1-stable 3-2-stable 4-0-stable 4-1-stable master adequaterecord SQLite3 MySQL2 MySQL PostgreSQL

147. Calls Per Second (MySQL) Calls Per Second (higher is better)

     0 2000 4000 6000 8000 2-3-stable 3-0-stable 3-1-stable 3-2-stable 4-0-stable 4-1-stable master adequaterecord find by id find by name

148. % Faster than 4-1-stable 0.00% 45.00% 90.00% 135.00% 180.00% SQLite3

     MySQL2 MySQL PostgreSQL find by id find by name

149. % Faster than 2-3-stable 0.00% 35.00% 70.00% 105.00% 140.00% SQLite3

     MySQL PostgreSQL find by id find by name

150. Objects Allocated Per Call (find by id) Objects Allocated (lower

     is better) 0 75 150 225 300 2-3-stable 3-0-stable 3-1-stable 3-2-stable 4-0-stable 4-1-stable master adequate SQLite3 MySQL2 MySQL PostgreSQL

151. Object Allocated Per Call (find by name) Objects Allocated (lower

     is better) 0 75 150 225 300 2-3-stable 3-0-stable 3-1-stable 3-2-stable 4-0-stable 4-1-stable master adequate SQLite3 MySQL2 MySQL PostgreSQL

152. 70% Fewer Objects Compared to 4-1-stable

153. 55% Fewer Objects Compared to 2-3-stable

154. belongs_to

155. belongs_to calls per second Calls Per Second (higher is better)

     0 3000 6000 9000 12000 2-3-stable 3-0-stable 3-1-stable 3-2-stable 4-0-stable 4-1-stable master adequaterecord SQLite3 MySQL MySQL2 PostgreSQL

156. belongs_to Percent Faster 0.00% 45.00% 90.00% 135.00% 180.00% SQLite3 MySQL

     MySQL2 PostgreSQL 2-3-stable 4-1-stable

157. has_many has_many :through

158. `has_many` Call Speed Over Time Calls Per Second (higher is

     better) 0 2750 5500 8250 11000 2-3-stable 3-0-stable 4-1-stable master adequaterecord SQlite3 MySQL MySQL2 PostgreSQL

159. `hm:t` Call Speed Over Time Calls Per Second (higher is

     better) 0 3000 6000 9000 12000 2-3-stable 3-0-stable 4-1-stable master adequaterecord SQLite3 MySQL MySQL2 PostgreSQL

160. Percent Faster than 2-3-stable 0% 25% 50% 75% 100% SQLite3

     MySQL PostgreSQL has_many hm:t

161. Percent Faster than 4-1-stable 0% 65% 130% 195% 260% SQLite3

     MySQL MySQL2 PostgreSQL has_many hm:t

162. has_many :through growth

163. Growth Test class A < ActiveRecord::Base has_many :bs has_many :cs,

     :through => :bs end ! class B < ActiveRecord::Base belongs_to :a has_many :cs end ! class C < ActiveRecord::Base belongs_to :b end

164. Growth Test class A < ActiveRecord::Base has_many :bs has_many :cs,

     :through => :bs has_many :ds, :through => :cs end ! class B < ActiveRecord::Base belongs_to :a has_many :cs end ! class C < ActiveRecord::Base belongs_to :b has_many :ds end ! class D < ActiveRecord::Base belongs_to :b end as we add more,! what’s the speed?

165. Time Taken to Call hm:t 100k times Seconds Taken (lower

     is better) 0 40 80 120 160 Nuber of hm:t associations 0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 y = 0.5783x + 5.9815 R² = 0.9971 y = 7.448x + 16.506 R² = 0.9974 4-1-stable adequate AWWWWW YEAH, CONSTANT TIME!

166. TL;DR: ~100% faster

167. TL;DR: 9001% better

168. Challenges

169. Trade Memory For Speed

170. Total Cache Size = count(find_by_*) * Size

171. Raw Relations

172. Example Controller class PeopleController def index @people = Person.where(name: params[:name]).to_a

     end end

173. Can we cache it?

174. Experimental Branch Person.where(name: params[:name]).to_a Iterations Per Second (higher is better)

     0 2000 4000 6000 8000 where(:name) Master Experimental Branch

175. ~30% faster

176. Key Calculation def cached_query if [joins_values, having_values, group_values, order_values, select_values,

     ].any?(&:any?) return yield end ! if limit_value || offset_value || distinct_value || from_value || lock_value return yield end ! if where_values.length != bind_values.length return yield end ! key = if bind_values.any? "bv_#{bind_values.map { |bv| bv.first.name }.join}" else :find_all_stuff end ! connection = @klass.connection cache = @klass.find_by_statement_cache ! s = cache[key] || cache.synchronize { cache[key] ||= begin bvs = bind_values.map { |bv| bv = bv.dup bv[1] = StatementCache::Substitute.new bv } StatementCache.create_with_binds(connection, arel, bvs) end } s.execute bind_values.map(&:last), @klass, connection end Key Calculation Query Execution

177. Over 11 variables impact the key

178. This code only handles two types of queries

179. One more experiment

180. Finder Comparison Benchmark.ips do |x| x.report('Person.where') { Person.where(name: 'Aaron').first }

     x.report('Person.find_by') { Person.find_by_name('Aaron') } end

181. Finder Comparison Calls Per Second 0 3500 7000 10500 14000

     Finder .where() .find_by_name

182. find_by_name is 3x faster

183. Finder Comparison Benchmark.ips do |x| x.report('Person.where') { Person.where(name: 'Aaron').first }

     x.report('Person.find_by') { Person.find_by_name('Aaron') } end New AR::Relation Allocation

184. Should we cache all relations?

185. I’m not sure.

186. I want a new API.

187. New API class Person < ActiveRecord::Base cached_query(:find_all_by_name) do |name| where(name:

     name) end end ! Person.find_all_by_name("foo") Person.find_all_by_name("bar")

188. Cache Key is Easy

189. Relation API maintained

190. Speeding up Helpers

191. Object Allocation Reduction

192. Profiling Request / Response

193. Test Code task :view_stack do app = Ko1TestApp::Application.instance app.app !

     env = rackenv "/books/new" do_test_task(app, env.dup) require 'stackprof' puts "#" * 90 StackProf.run(mode: :cpu, out: 'req-res.dump') do 1800.times { do_test_task(app, env.dup) } end end

194. Test Code task :view_stack do app = Ko1TestApp::Application.instance app.app !

     env = rackenv "/books/new" do_test_task(app, env.dup) require 'stackprof' puts "#" * 90 StackProf.run(mode: :cpu, out: 'req-res.dump') do 1800.times { do_test_task(app, env.dup) } end end

195. Test Code task :view_stack do app = Ko1TestApp::Application.instance app.app !

     env = rackenv "/books/new" do_test_task(app, env.dup) require 'stackprof' puts "#" * 90 StackProf.run(mode: :cpu, out: 'req-res.dump') do 1800.times { do_test_task(app, env.dup) } end end

196. TOTAL (pct) SAMPLES (pct) FRAME 813 (9.5%) 813 (9.5%) ActiveSupport::SafeBuffer#initialize

     699 (8.1%) 350 (4.1%) block in ActiveRecord::Read#read_attribute 486 (5.7%) 298 (3.5%) ActionController::UrlFor#url_options 670 (7.8%) 274 (3.2%) ActionDispatch::Journey::Format#evaluate 773 (9.0%) 253 (2.9%) ActionDispatch#parameterize_args 1172 (13.6%) 220 (2.6%) ActiveRecord::Persistence#instantiate 213 (2.5%) 213 (2.5%) block in SQLite3::Statement#each 208 (2.4%) 208 (2.4%) ActiveSupport::SafeBuffer#html_safe? 204 (2.4%) 204 (2.4%) ActionDispatch::UrlFor#routes_generation? 245 (2.9%) 191 (2.2%) block (2 levels) in Class#class_attribute

197. ActiveSupport::SafeBuffer #initialize

198. Finding Calls require 'active_support/all' ! trace = TracePoint.new(:c_call, :call) {

     |tp| if tp.defined_class == ActiveSupport::SafeBuffer && tp.method_id == :initialize puts "#" * 90 puts tp.binding.eval "caller" end } ! trace.enable "asdfadsf".html_safe ActiveSupport::SafeBuffer.new "omgee" Callstack

199. Output ##################################################################### t1.rb:7:in `eval' t1.rb:7:in `block in <main>' lib/active_support/core_ext/string/output_safety.rb:166:in `initialize'

     lib/active_support/core_ext/string/output_safety.rb:251:in `new' lib/active_support/core_ext/string/output_safety.rb:251:in `html_safe' t1.rb:12:in `<main>' ##################################################################### t1.rb:7:in `eval' t1.rb:7:in `block in <main>' lib/active_support/core_ext/string/output_safety.rb:166:in `initialize' t1.rb:13:in `new' t1.rb:13:in `<main>'

200. In Rails

201. Tag Options def tag_option(key, value, escape) if value.is_a?(Array) value =

     escape ? safe_join(value, " ") : value.join(" ") else value = escape ? ERB::Util.h(value) : value end %(#{key}="#{value}") end

202. HTML Sanitization in Rails

203. ActiveSupport:: SafeBuffer

204. Ordinary String >> x = "foo" => "foo" >> x.class

     => String >> x.html_safe? => false

205. SafeBuffer >> x = "foo" => "foo" >> y =

     x.html_safe => "foo" >> y.class => ActiveSupport::SafeBuffer >> y.html_safe? => true

206. `html_safe` just tags the string.

207. ERB::Utils.h

208. ERB::Utils.h def html_escape(s) s = s.to_s if s.html_safe? s else

     s.gsub(HTML_ESCAPE_REGEXP, HTML_ESCAPE).html_safe end end

209. Creates 2 Strings.

210. Tag Options def tag_option(key, value, escape) if value.is_a?(Array) value =

     escape ? safe_join(value, " ") : value.join(" ") else value = escape ? ERB::Util.h(value) : value end %(#{key}="#{value}") end

211. String -> String -> SafeBuffer -> String

212. String -> String -> String

213. Extract Method def unwrapped_html_escape(s) # :nodoc: s = s.to_s if

     s.html_safe? s else s.gsub(HTML_ESCAPE_REGEXP, HTML_ESCAPE) end end ! def html_escape(s) unwrapped_html_escape(s).html_safe end

214. Update Callers def tag_option(key, value, escape) if value.is_a?(Array) value =

     escape ? safe_join(value, " ") : value.join(" ") else value = escape ? ERB::Util.unwrapped_html_escape(value) : value end %(#{key}="#{value}") end

215. String -> String -> String

216. ~200 Allocations Per Request for /books/new

217. Request Benchmark task :allocation_tracer do app = Ko1TestApp::Application.instance app.app do_test_task(app)

     env = rackenv "/books/new" do_test_task(app, env.dup) ObjectSpace::AllocationTracer.trace do TEST_CNT.times { do_test_task(app, env.dup) } end p ObjectSpace::AllocationTracer.allocated_count_table end "/books/new"

218. Request Benchmark task :allocation_tracer do app = Ko1TestApp::Application.instance app.app do_test_task(app)

     env = rackenv "/books/new" do_test_task(app, env.dup) ObjectSpace::AllocationTracer.trace do TEST_CNT.times { do_test_task(app, env.dup) } end p ObjectSpace::AllocationTracer.allocated_count_table end

219. Request Benchmark task :allocation_tracer do app = Ko1TestApp::Application.instance app.app do_test_task(app)

     env = rackenv "/books/new" do_test_task(app, env.dup) ObjectSpace::AllocationTracer.trace do TEST_CNT.times { do_test_task(app, env.dup) } end p ObjectSpace::AllocationTracer.allocated_count_table end

220. Allocations Per Request 0 275 550 825 1100 T_STRING T_ARRAY

     T_HASH T_NODE T_DATA OTHER 4-0-stable 4-1-stable master

221. ~19% reduction since 4-0-stable

222. ~14% reduction since 4-1-stable

223. YMMV (Your Mileage May Vary)

224. String Object Reduction

225. Mutable Strings irb(main):007:0> 5.times { irb(main):008:1* p "foo".object_id irb(main):009:1> }

     70344882872020 70344882871920 70344882871840 70344882871720 70344882871540 => 5 irb(main):010:0>

226. Frozen Strings irb(main):010:0> 5.times { irb(main):011:1* p "foo".freeze.object_id irb(main):012:1> }

     70344870307760 70344870307760 70344870307760 70344870307760 70344870307760 => 5

227. ERB Template <% books.each do |book| %> <tr><td> <%= book.name

     %> </tr></td> <% end %>

228. Compiled Template @output_buffer = output_buffer || ActionView::OutputBuffer.new;@output_buffer.safe_append='<h1>Listing books</h1> ! <table>

     <thead> <tr> <th>Name</th> <th colspan="3"></th> </tr> </thead> ! <tbody> '.freeze; @books.each do |book| @output_buffer.safe_append=' <tr> <td>'.freeze;@output_buffer.append=( book.name );@output_buffer.safe_append='</td> <td>'.freeze;@output_buffer.append=( link_to 'Show', book );@output_buffer.safe_append='</ td> </tr> '.freeze; end @output_buffer.safe_append=' </tbody> </table> ! <br>

229. Compiled Template @output_buffer = ActionView::OutputBuffer.new @output_buffer.safe_append=' <tr> <td>' @output_buffer.append=( book.name

     ) HTML Literal

230. Template Literals Can’t Change

231. Add `freeze` @output_buffer = ActionView::OutputBuffer.new @output_buffer.safe_append=' <tr> <td>’.freeze @output_buffer.append=( book.name

     ) HTML Literal

232. Allocations Per Request 0 275 550 825 1100 T_STRING T_ARRAY

     T_HASH T_NODE T_DATA OTHER 4-0-stable 4-1-stable master

233. Speeding up Output

234. WARNING:! Work in Progress

235. Law of Demeter

236. Suggestion of Demeter

237. None

238. Arrested Developer?

239. It’s not about dots, it’s about types.

240. Fewer Types == Faster / Easier code

241. Compiled Template @output_buffer = output_buffer || ActionView::OutputBuffer.new;@output_buffer.safe_append='<h1>Listing books</h1> ! <table>

     <thead> <tr> <th>Name</th> <th colspan="3"></th> </tr> </thead> ! <tbody> '.freeze; @books.each do |book| @output_buffer.safe_append=' <tr> <td>'.freeze;@output_buffer.append=( book.name );@output_buffer.safe_append='</td> <td>'.freeze;@output_buffer.append=( link_to 'Show', book );@output_buffer.safe_append='</ td> </tr> '.freeze; end @output_buffer.safe_append=' </tbody> </table> ! <br>

242. Compiled Template @output_buffer = ActionView::OutputBuffer.new @output_buffer.safe_append=' <tr> <td>'.freeze @output_buffer.append=( book.name

     ) HTML Literal

243. safe_append= class OutputBuffer def safe_append=(value) return self if value.nil? super(value.to_s)

     end end W hy?

244. safe_append= class OutputBuffer def safe_append=(value) super(value.to_s) end end

245. Law of Demeter

246. Defensive Programming

247. superclass def safe_append=(value) (!html_safe? || arg.html_safe?) ? arg : ERB::Utils.h(arg)

     end Only on m utations

248. How can you get the Output Buffer?

249. Who Mutates the OutputBuffer?

250. I think no one.

251. superclass def safe_append=(value) arg.html_safe? ? arg : ERB::Utils.h(arg) end

252. Cache Invariants

253. Eliminate Objects

254. "No code is faster than no code"

255. Limit Types

256. Fewer Types = Less Code

257. Less Code = Faster Code

258. Report Performance Issues

259. Rails 4.2 will be the fastest ever!

260. THANKS!

261. append= def append=(value) (!html_safe? || arg.html_safe?) ? arg : escape(arg)

     end
