  1. By Thijs Feryn Build, provision & deploy in the Cloud

    with Packer, Ansible & Terraform
  2. I’m so sick of Cloud!

  3. Automation

  4. Many platforms

  5. None
  6. None
  7. ✓ Less lock-in ✓ Faster deployments ✓ Better scalability ✓

    Better reproducibility ✓ Less human error ✓ Lower cost ✓ Operational stability Goals
  8. Hi, I’m Thijs

  9. I’m @ThijsFeryn on Twitter

  10. I’m an Evangelist At

  11. I’m an Evangelist At

  12. None
  13. None
  14. ✓ Alicloud ECS ✓ Amazon EC2 ✓ Azure ✓ CloudStack

    ✓ DigitalOcean ✓ Docker ✓ File ✓ Google Cloud ✓ Hyper-V ✓ LXC ✓ LXD ✓ Null ✓ 1&1 ✓ OpenStack ✓ Oracle OCI ✓ Parallels ✓ ProfitBricks ✓ QEMU ✓ Triton ✓ VirtualBox ✓ VMware ✓ Custom Packer builders
  15. None
  16. { "builders": [ { "type": "amazon-ebs", "access_key": "", "secret_key": "",

    "region": "eu-west-2", "instance_type": "t2.micro", "ssh_username": "admin", "associate_public_ip_address": true, "subnet_id": “subnet-11d3d56a", "source_ami": "ami-e1e8f085", "ami_name": "thijsferyn_{{isotime \"2006_01_02__03_04_05\"}}" } ], "provisioners": [ { "type": "shell", "inline": ["apt-get update","apt-get install -y nginx"] } ] }
  17. $ packer build packer.json

  18. $ aws ec2 describe-images --owners=self --query "Images[*]. {ID:ImageId,Name:Name,Status:State}" --output=table +--------------+-----------------------------------+-------------+

    | ID | Name | Status | +--------------+-----------------------------------+-------------+ | ami-82ccd6e6| thijsferyn_2018_01_31__02_26_27 | available | +--------------+-----------------------------------+-------------+
  19. None
  20. Configuration management system

  21. None
  22. ✓ Written in Python ✓ Agentless ✓ Standalone ✓ SSH-based

    ✓ Runs playbook (yml files) ✓ Groups playbook in roles ✓ Install software ✓ Configure your server Ansible
  23. --- - hosts: all vars: code_folders: - "web" become: true

    tasks: - name: update apt cache apt: update_cache=yes cache_valid_time=86400 - name: install required packages apt: name={{ item }} state=present with_items: - vim - curl - nginx - php7.0-fpm - rsync - name: create /var/www/html/ folder file: path: /var/www/html/ state: directory mode: 0755 owner: www-data playbook.yml
  24. - name: create /var/www/html/ folder file: path: /var/www/html/ state: directory

    mode: 0755 owner: www-data - name: Copy code synchronize: src: ../{{ item }} dest: /var/www/html delete: yes recursive: yes group: no owner: no perms: no with_items: "{{code_folders}}" - name: Chown code to www-data file: path: /var/www/html/{{ item }} group: www-data owner: www-data mode: u=rwx,g=r,o=r recurse: yes playbook.yml
  25. Organize your playbooks

  26. . !"" files # $"" db.sql !"" host_vars # $""

    default.yml !"" group_vars # $"" all.yml !"" inventory !"" playbook.yml !"" roles # $"" my-role # !"" defaults # # $"" main.yml # !"" handlers # # $"" main.yml # !"" meta # # $"" main.yml # !"" tasks # # $"" main.yml # !"" templates # # $"" template.j2 # $"" vars # $"" vars.yml !"" tasks # !"" task1.yml # !"" task2.yml $"" templates $"" template.j2
  27. --- - hosts: all tasks: - include_tasks: task1.yml - include_tasks:

    task2.yml roles: - my-role
  28. { "builders": [ { "type": "openstack", "identity_endpoint": "https://osp.combell.com:5000/v3", "tenant_name": "18324-1",

    "username": "18324", "password": "", "image_name": "MyBuild-{{isotime \"2006-01-02 03:04:05\"}}", "source_image": "1b9fe43e-4cf2-4986-b7f2-51f5706b120b", "ssh_username": "debian", "domain_name" : "default", "flavor": "m1.medium", "networks": ["a1175c54-cb12-436d-ac7b-d327499dc39b"], "floating_ip_pool" : "public" } ], "provisioners": [ { "type": "ansible", "playbook_file": "./ansible/playbook.yml" } ] }
  29. "image_name": "MyBuild-{{isotime \"2006-01-02 03:04:05\"}}", "source_image": "1b9fe43e-4cf2-4986-b7f2-51f5706b120b", "ssh_username": "debian", "domain_name" :

    "default", "flavor": "m1.medium", "networks": ["a1175c54-cb12-436d-ac7b-d327499dc39b"], "floating_ip_pool" : "public" } ], "provisioners": [ { "type": "ansible", "playbook_file": "./ansible/playbook.yml" } ], "post-processors": [ { "type": "manifest", "output": "manifest.json" } ] }
  30. { "builds": [ { "name": "amazon-ebs", "builder_type": "amazon-ebs", "build_time": 1517408990,

    "files": null, "artifact_id": "eu-west-2:ami-82ccd6e6", "packer_run_uuid": "ba98283c-08ca-a9fc-ab10-e49502ce4ab6" }, { "name": "openstack", "builder_type": "openstack", "build_time": 1509053610, "files": null, "artifact_id": "ef90ad1c-ed64-4ae0-8283-e446e95c33e6", "packer_run_uuid": "b6000539-f3e6-85dd-2733-9fb3ae443e9f" } ], "last_run_uuid": "b6000539-f3e6-85dd-2733-9fb3ae443e9f" }
  31. None
  32. Deploy the VM image

  33. Orchestration

  34. ✓ Launch virtual network ✓ Boot up webservers ✓ Configure

    firewalls ✓ Assign loadbalancers ✓ Create DNS-records ✓ Assign SSH keys ✓ Create autoscaling group Orchestration
  35. ✓ CloudFormation (AWS) ✓ Heat (OpenStack) ✓ Resource manager (Azure)

    Vendor-specific orchestration tools
  36. None
  37. ✓ Infrastructure As Code ✓ Plan, graph, execute ✓ State

    management ✓ Multiple providers ✓ Incremental changes ✓ Interacts with Cloud vendor APIs Terraform
  38. ✓ Alicloud ✓ Archive ✓ Arukas ✓ AWS ✓ Bitbucket

    ✓ CenturyLinkCloud ✓ Chef ✓ Circonus ✓ Cloudflare ✓ CloudStack ✓ Cobbler ✓ Consul ✓ Datadog ✓ DigitalOcean ✓ DNS ✓ DNSMadeEasy ✓ DNSimple ✓ Docker ✓ Dyn ✓ External ✓ Fastly ✓ GitHub ✓ Gitlab ✓ Google Cloud ✓ Grafana ✓ Heroku ✓ HTTP ✓ Icinga2 ✓ Ignition ✓ InfluxDB ✓ Kubernetes ✓ Librato ✓ Local ✓ Logentries ✓ LogicMonitor ✓ Mailgun ✓ Microsoft Azure ✓ Microsoft Azure (Legacy ASM) ✓ MySQL ✓ New Relic ✓ Nomad ✓ NS1 ✓ 1&1 ✓ Oracle Public Cloud ✓ OpenStack ✓ OpsGenie ✓ OVH ✓ Packet ✓ PagerDuty ✓ PostgreSQL ✓ PowerDNS ✓ ProfitBricks ✓ RabbitMQ ✓ Rancher ✓ Random ✓ Rundeck ✓ Scaleway ✓ SoftLayer ✓ StatusCake ✓ Spotinst ✓ Template ✓ Terraform ✓ Terraform Enterprise ✓ TLS ✓ Triton ✓ UltraDNS ✓ Vault ✓ VMware vCloud Director ✓ VMware vSphere Terraform providers
  39. main.tf

  40. variable "ami" { type = "string" default = "ami-e1e8f085" #Stock

    Debian Stretch } resource "aws_instance" "web" { ami = "${var.ami}" instance_type = "t2.micro" security_groups = ["Web"] tags { Name = "web" } } data "aws_route53_zone" "web" { name = "aws.combell.com." } resource "aws_route53_record" "web" { zone_id = "${data.aws_route53_zone.web.zone_id}" name = "thijsferyn-web.${data.aws_route53_zone.web.name}" type = "A" ttl = "60" records = ["${aws_instance.web.public_ip}"] } output "public_ip" { value = "${aws_instance.web.public_ip}" } output "hostname" { value = "${aws_route53_record.web.name}" }
  41. $ terraform init

  42. $ terraform init Initializing provider plugins... - Checking for available

    provider plugins on https://releases.hashicorp.com... - Downloading plugin for provider "aws" (1.8.0)... The following providers do not have any version constraints in configuration, so the latest version was installed. To prevent automatic upgrades to new major versions that may contain breaking changes, it is recommended to add version = "..." constraints to the corresponding provider blocks in configuration, with the constraint strings suggested below. * provider.aws: version = "~> 1.8" Terraform has been successfully initialized!
  43. $ terraform plan

  44. An execution plan has been generated and is shown below.

    Resource actions are indicated with the following symbols: + create Terraform will perform the following actions: + aws_instance.web id: <computed> ami: "ami-e1e8f085" associate_public_ip_address: <computed> availability_zone: <computed> ebs_block_device.#: <computed> ephemeral_block_device.#: <computed> instance_state: <computed> instance_type: "t2.micro" ipv6_address_count: <computed> ipv6_addresses.#: <computed> key_name: <computed> network_interface.#: <computed> network_interface_id: <computed> placement_group: <computed> primary_network_interface_id: <computed> private_dns: <computed> private_ip: <computed> public_dns: <computed> public_ip: <computed> root_block_device.#: <computed> security_groups.#: "1" security_groups.2661672386: "Web" source_dest_check: "true" subnet_id: <computed> tags.%: "1" tags.Name: "web" tenancy: <computed> volume_tags.%: <computed> vpc_security_group_ids.#: <computed>
  45. + aws_route53_record.web id: <computed> fqdn: <computed> name: "thijsferyn-web.aws.combell.com" records.#: <computed>

    ttl: "60" type: "A" zone_id: "Z3K2HG3W48B0MR" Plan: 2 to add, 0 to change, 0 to destroy.
  46. $ terraform apply

  47. $ terraform plan -out=bla $ terraform apply bla

  48. None
  49. $ terraform output hostname = thijsferyn-web.aws.combell.com public_ip = 35.178.38.182

  50. $ terraform output -json { "hostname": { "sensitive": false, "type":

    "string", "value": "thijsferyn-web.aws.combell.com" }, "public_ip": { "sensitive": false, "type": "string", "value": "35.178.38.182" } }
  51. $ terraform show

  52. $ terraform show aws_instance.web: id = i-0333e97ea6bdbc5ae ami = ami-e1e8f085

    associate_public_ip_address = true availability_zone = eu-west-2a disable_api_termination = false ebs_block_device.# = 0 ebs_optimized = false ephemeral_block_device.# = 0 iam_instance_profile = instance_state = running instance_type = t2.micro ipv6_addresses.# = 0 key_name = monitoring = false network_interface.# = 0 network_interface_id = eni-c62e7193 placement_group = primary_network_interface_id = eni-c62e7193 private_dns = ip-172-31-19-7.eu-west-2.compute.internal
  53. network_interface_id = eni-c62e7193 placement_group = primary_network_interface_id = eni-c62e7193 private_dns =

    ip-172-31-19-7.eu-west-2.compute.internal private_ip = 172.31.19.7 public_dns = ec2-35-178-38-182.eu-west-2.compute.amazonaws.com public_ip = 35.178.38.182 root_block_device.# = 1 root_block_device.0.delete_on_termination = true root_block_device.0.iops = 100 root_block_device.0.volume_id = vol-0b9364527ec09549e root_block_device.0.volume_size = 8 root_block_device.0.volume_type = gp2 security_groups.# = 1 security_groups.763657905 = Web source_dest_check = true subnet_id = subnet-11d3d56a tags.% = 1 tags.Name = web tenancy = default volume_tags.% = 0 vpc_security_group_ids.# = 0
  54. aws_route53_record.web: id = Z3K2HG3W48B0MR_thijsferyn-web.aws.combell.com._A fqdn = thijsferyn-web.aws.combell.com health_check_id = name

    = thijsferyn-web.aws.combell.com records.# = 1 records.1088376871 = 35.178.38.182 set_identifier = ttl = 60 type = A zone_id = Z3K2HG3W48B0MR data.aws_route53_zone.web: id = Z3K2HG3W48B0MR caller_reference = F7596F57-9ADE-9B0D-8F53-53DF42E03DB3 comment = name = aws.combell.com. private_zone = false resource_record_set_count = 3 zone_id = Z3K2HG3W48B0MR Outputs: hostname = thijsferyn-web.aws.combell.com public_ip = 35.178.38.182
  55. State

  56. terraform.tfstate terraform.tfstate.backup

  57. ✓ Artifactory ✓ Azurerm ✓ Consul ✓ Etcd ✓ Gcs

    ✓ HTTP ✓ Manta ✓ S3 ✓ Swift ✓ Terraform Enterprise Remote state
  58. Changes

  59. $ terraform plan -var 'ami=ami-20ccd644'

  60. ~ update in-place -/+ destroy and then create replacement Terraform

    will perform the following actions: -/+ aws_instance.web (new resource required) id: "i-0333e97ea6bdbc5ae" => <computed> (forces new resource) ami: "ami-e1e8f085" => "ami-20ccd644" (forces new resource) associate_public_ip_address: "true" => <computed> availability_zone: "eu-west-2a" => <computed> ebs_block_device.#: "0" => <computed> ephemeral_block_device.#: "0" => <computed> instance_state: "running" => <computed> instance_type: "t2.micro" => "t2.micro" ipv6_address_count: "" => <computed> ipv6_addresses.#: "0" => <computed> key_name: "" => <computed> network_interface.#: "0" => <computed> network_interface_id: "eni-c62e7193" => <computed> placement_group: "" => <computed> primary_network_interface_id: "eni-c62e7193" => <computed> private_dns: "ip-172-31-19-7.eu-west-2.compute.internal" => <computed> private_ip: "172.31.19.7" => <computed>
  61. key_name: "" => <computed> network_interface.#: "0" => <computed> network_interface_id: "eni-c62e7193"

    => <computed> placement_group: "" => <computed> primary_network_interface_id: "eni-c62e7193" => <computed> private_dns: "ip-172-31-19-7.eu-west-2.compute.internal" => <computed> private_ip: "172.31.19.7" => <computed> public_dns: "ec2-35-178-38-182.eu- west-2.compute.amazonaws.com" => <computed> public_ip: "35.178.38.182" => <computed> root_block_device.#: "1" => <computed> security_groups.#: "1" => "1" security_groups.763657905: "Web" => "Web" source_dest_check: "true" => "true" subnet_id: "subnet-11d3d56a" => <computed> tags.%: "1" => "1" tags.Name: "web" => "web" tenancy: "default" => <computed> volume_tags.%: "0" => <computed> vpc_security_group_ids.#: "0" => <computed> ~ aws_route53_record.web records.#: "" => <computed> Plan: 1 to add, 1 to change, 1 to destroy.
  62. $ terraform apply -var 'ami=ami-20ccd644'

  63. Downtime

  64. High availability plan

  65. Workspace 1 Workspace 2 Internet Entry point BLUE GREEN

  66. $ terraform init $ terraform workspace new wsp1 $ terraform

    workspace new wsp2 $ terraform workspace select wsp1 $ terraform plan $ terraform apply $ terraform workspace select wsp2 $ terraform plan $ terraform apply
  67. variable "ami" { type = "string" default = "ami-e1e8f085" #Stock

    Debian Stretch } resource "aws_instance" "web" { ami = "${var.ami}" instance_type = "t2.micro" security_groups = ["Web"] tags { Name = "web-${terraform.workspace}" } } output "public_ip" { value = "${aws_instance.web.public_ip}" } Remove DNS resource Interpolate workspace info
  68. variable "ip" { type = "string" } data "aws_route53_zone" "web"

    { name = "aws.combell.com." } resource "aws_route53_record" "web" { zone_id = "${data.aws_route53_zone.web.zone_id}" name = "thijsferyn-web.${data.aws_route53_zone.web.name}" type = "A" ttl = "60" records = ["${var.ip}"] } output "hostname" { value = "${aws_route53_record.web.name}" } Separate Terraform project
  69. $ terraform apply -var 'ip="35.176.171.168"'

  70. Rolling updates

  71. Deployment B Internet Entry point Drain connections and gradually switch

    from deployment A to deployment B Deployment A ROLLING UPDATES
  72. Autoscaling group

  73. resource "aws_vpc" "thijsferyn_terraform" { cidr_block = "10.0.0.0/16" tags { Name

    = "thijsferyn_${terraform.workspace}_terraform" } } resource "aws_subnet" "thijsferyn_terraform_public" { availability_zone = "eu-west-2a" vpc_id = "${aws_vpc.thijsferyn_terraform.id}" cidr_block = "10.0.0.0/24" tags { Name = "thijsferyn_terraform_${terraform.workspace}_public" } } resource "aws_subnet" "thijsferyn_terraform_private" { availability_zone = "eu-west-2a" vpc_id = "${aws_vpc.thijsferyn_terraform.id}" cidr_block = "10.0.1.0/24" tags { Name = "thijsferyn_terraform_${terraform.workspace}_private" } } Virtual network
  74. resource "aws_security_group" "thijsferyn_terraform" { name = "thijsferyn-terraform-${terraform.workspace}" description = "Allow

    HTTP(S) & SSH" vpc_id = "${aws_vpc.thijsferyn_terraform.id}" ingress { from_port = 80 to_port = 80 protocol = "tcp" cidr_blocks = ["0.0.0.0/0"] } ingress { from_port = 443 to_port = 443 protocol = "tcp" cidr_blocks = ["0.0.0.0/0"] } ingress { from_port = 22 to_port = 22 protocol = "tcp" cidr_blocks = ["0.0.0.0/0"] } egress { from_port = 0 to_port = 0 protocol = "-1" cidr_blocks = ["0.0.0.0/0"] } tags { Name = "thijsferyn_terraform-${terraform.workspace}" } } Firewall
  75. data "aws_ami" "thijsferyn_terraform" { most_recent = true filter { name

    = "name" values = ["thijsferyn_*"] } filter { name = "virtualization-type" values = ["hvm"] } owners = ["826481595599"] } resource "aws_launch_configuration" "thijsferyn_terraform" { image_id = "${data.aws_ami.thijsferyn_terraform.id}" instance_type = "t2.micro" security_groups = ["${aws_security_group.thijsferyn_terraform.id}"] lifecycle { create_before_destroy = true } } Prepare VMs
  76. resource "aws_lb" "thijsferyn_terraform" { name = "thijsferyn-terraform-${terraform.workspace}" internal = false

    security_groups = ["${aws_security_group.thijsferyn_terraform.id}"] subnets = ["${aws_subnet.thijsferyn_terraform_public.*.id}","$ {aws_subnet.thijsferyn_terraform_public2.*.id}"] } resource "aws_lb_listener" "thijsferyn_terraform" { load_balancer_arn = "${aws_lb.thijsferyn_terraform.arn}" port = "80" protocol = "HTTP" default_action { target_group_arn = "${aws_lb_target_group.thijsferyn_terraform.arn}" type = "forward" } } resource "aws_lb_target_group" "thijsferyn_terraform" { name = "thijsferyn-terraform-${terraform.workspace}" port = 80 protocol = "HTTP" vpc_id = "${aws_vpc.thijsferyn_terraform.id}" } Load balancing
  77. resource "aws_autoscaling_group" "thijsferyn_terraform" { availability_zones = ["eu-west-2a"] name = "thijsferyn-terraform-${terraform.workspace}-$

    {aws_launch_configuration.thijsferyn_terraform.name}" max_size = 10 min_size = 3 launch_configuration = "${aws_launch_configuration.thijsferyn_terraform.name}" target_group_arns = ["${aws_lb_target_group.thijsferyn_terraform.id}"] health_check_grace_period = 10 health_check_type = "ELB" vpc_zone_identifier = ["${aws_subnet.thijsferyn_terraform_private.id}"] default_cooldown = 60 depends_on = ["aws_launch_configuration.thijsferyn_terraform"] lifecycle { create_before_destroy = true } tag { key = "Name" value = "thijsferyn-terraform-${terraform.workspace}-$ {aws_launch_configuration.thijsferyn_terraform.name}" propagate_at_launch = true } } Autoscaling group
  78. resource "aws_autoscaling_policy" "thijsferyn_terraform_high" { name = "thijsferyn-terraform-${terraform.workspace}-high" scaling_adjustment = 1

    adjustment_type = "ChangeInCapacity" cooldown = 10 autoscaling_group_name = "${aws_autoscaling_group.thijsferyn_terraform.name}" } resource "aws_autoscaling_policy" "thijsferyn_terraform_low" { name = "thijsferyn-terraform-${terraform.workspace}low" scaling_adjustment = -1 adjustment_type = "ChangeInCapacity" cooldown = 10 autoscaling_group_name = "${aws_autoscaling_group.thijsferyn_terraform.name}" } Scale up scale down
  79. resource "aws_cloudwatch_metric_alarm" "thijsferyn_terraform_high" { alarm_name = "thijsferyn-terraform-${terraform.workspace}-high" comparison_operator = "GreaterThanOrEqualToThreshold"

    evaluation_periods = "1" metric_name = "RequestCountPerTarget" namespace = "AWS/ApplicationELB" period = "60" statistic = "Sum" threshold = "20" dimensions { TargetGroup = "${aws_lb_target_group.thijsferyn_terraform.name}" LoadBalancer = "${aws_lb.thijsferyn_terraform.name}" } alarm_description = "More than 20 requests per target causes scaleout" alarm_actions = ["${aws_autoscaling_policy.thijsferyn_terraform_high.arn}"] } High water mark
  80. $ terraform plan $ terraform apply

  81. $ terraform graph | dot -Tpng > graph.png

  82. None
  83. None
  84. ✓ vars.tf ✓ output.tf ✓ secgroup.tf ✓ keypair.tf ✓ compute.tf

    ✓ network.tf ✓ provider.tf Organize Terraform files
  85. Modules

  86. !"" autoscaling # !"" README.MD # !"" main.tf # !""

    outputs.tf # $"" variables.tf !"" dns # !"" README.MD # !"" main.tf # !"" outputs.tf # $"" variables.tf !"" launch # !"" README.MD # !"" main.tf # !"" outputs.tf # $"" variables.tf !"" loadbalancing # !"" README.MD # !"" main.tf # !"" outputs.tf # $"" variables.tf !"" main.tf !"" networking # !"" README.MD # !"" main.tf # !"" outputs.tf # $"" variables.tf
  87. variable "zone_name" { default = "aws.combell.com." } variable "record_name" {

    default = "" } variable "records" { type = "list" } output "dns_endpoint" { value = "${aws_route53_record.thijsferyn_terraform_aws_combell_com.fqdn}" } data "aws_route53_zone" "thijsferyn_terraform_aws_combell_com" { name = "${var.zone_name}" } resource "aws_route53_record" "thijsferyn_terraform_aws_combell_com" { zone_id = "${data.aws_route53_zone.thijsferyn_terraform_aws_combell_com.zone_id}" name = "${var.record_name == "" ? "thijsferyn-terraform${terraform.workspace == "default" ? "" : "-${terraform.workspace}"}": var.record_name}.$ {data.aws_route53_zone.thijsferyn_terraform_aws_combell_com.name}" type = "CNAME" ttl = "60" records = ["${var.records}"] } Variables.tf module input args Output.tf module output Main.tf processing
  88. module "dns" { source = "./dns" record_name = "www" records

    = ["bla.domain.com"] } output "dns_endpoint" { value = "${module.dns.dns_endpoint}" } Root Terraform file
  89. module "networking" { source = "./networking" } module "loadbalancing" {

    source = "./loadbalancing" security_groups = ["${module.networking.security_group_id}"] vpc_id = "${module.networking.vpc_id}" subnets = ["${module.networking.subnet_public1_id}","${module.networking.subnet_public2_id}"] } module "launch" { source = "./launch" instance_type = "t2.small" security_groups = ["${module.networking.security_group_id}"] } module "autoscaling" { source = "./autoscaling" target_group = "${module.loadbalancing.target_group_name}" loadbalancer = "${module.loadbalancing.loadbalancer_name}" min_size = "4" subnets = ["${module.networking.subnet_private1_id}","${module.networking.subnet_private2_id}"] launch_configuration = "${module.launch.launch_configuration_name}" target_group_arn = "${module.loadbalancing.target_group_id}" } module "dns" { source = "./dns" records = ["${module.loadbalancing.dns_name}"] } output "dns_endpoint" { value = "${module.dns.dns_endpoint}" }
  90. https://registry.terraform.io

  91. None
  92. module "consul" { source = "hashicorp/consul/aws" }

  93. $ terraform init

  94. Downloading modules... Initializing provider plugins... - Checking for available provider

    plugins on https://releases.hashicorp.com... - Downloading plugin for provider "aws" (1.9.0)... - Downloading plugin for provider "template" (1.0.0)... The following providers do not have any version constraints in configuration, so the latest version was installed. To prevent automatic upgrades to new major versions that may contain breaking changes, it is recommended to add version = "..." constraints to the corresponding provider blocks in configuration, with the constraint strings suggested below. * provider.aws: version = "~> 1.9" * provider.template: version = "~> 1.0" Terraform has been successfully initialized! You may now begin working with Terraform. Try running "terraform plan" to see any changes that are required for your infrastructure. All Terraform commands should now work. If you ever set or change modules or backend configuration for Terraform, rerun this command to reinitialize your working directory. If you forget, other commands will detect it and remind you to do so if necessary.
  95. module “example" { source = "github.com/hashicorp/example" } module "consul" {

    source = "git::https://hashicorp.com/consul.git" } module "ami" { source = "git::ssh://git@github.com/owner/repo.git" }
  96. Remote state

  97. None
  98. $ consul agent -data-dir=/tmp/consul \ -server -ui -dev

  99. terraform { backend "consul" { address = "127.0.0.1:8500" path =

    "example/terraform_state" } }
  100. $ terraform apply Error locking state: Error acquiring the state

    lock: resource temporarily unavailable Lock Info: ID: d2c36deb-32c0-ecc7-b1f1-10068c2ed93b Path: terraform.tfstate Operation: OperationTypeApply Who: thijsferyn@MacBook-Pro-van-Thijs.local Version: 0.10.7 Created: 2018-02-02 16:03:17.005327423 +0000 UTC Info: Terraform acquires a state lock to protect the state from being written by multiple users at the same time. Please resolve the issue above and try again. For most commands, you can disable locking with the "-lock=false" flag, but this is not recommended.
  101. data "terraform_remote_state" "web" { backend = "consul" config { address

    = "127.0.0.1:8500" path = "thijsferyn/terraform/production" } } data "aws_route53_zone" "web" { name = "aws.combell.com." } resource "aws_route53_record" "web" { zone_id = "${data.aws_route53_zone.web.zone_id}" name = "thijsferyn-web.${data.aws_route53_zone.web.name}" type = "A" ttl = "60" records = ["${data.terraform_remote_state.web.public_ip}"] } output "hostname" { value = "${aws_route53_record.web.name}" }
  102. https://feryn.eu https://twitter.com/ThijsFeryn https://instagram.com/ThijsFeryn
