Caching the uncacheable with Varnish - PHP UG FFM 19

This talk is about caching personalized data using Varnish. It was presented at the PHP UG FFM in Frankfurt.

See https://feryn.eu/speaking/caching-uncacheable-varnish-phpugffm19/ for more information

Transcript

1. CACHING THE UNCACHEABLE
   BY THIJS FERYN
   WITH VARNISH


   View Slide

2. Slow websites
   SUCK


   View Slide

3. WEB PERFORMANCE IS AN
   ESSENTIAL PART OF THE
   USER EXPERIENCE


   View Slide

4. SLOW ~ DOWN


   View Slide

5. View Slide

6. View Slide

7. View Slide

8. THROWING
   SERVERS
   AT THE PROBLEM


   View Slide

9. MO' MONEY
   MO' SERVERS
   MO' PROBLEMS


   View Slide

10. IDENTIFY SLOWEST PARTS


    View Slide

11. OPTIMIZE


    View Slide

12. AFTER A WHILE YOU HIT THE LIMITS


    View Slide

13. CACHE


    View Slide

14. HI, I'M THIJS


    View Slide

15. I'M AN
    EVANGELIST
    AT


    View Slide

16. View Slide

17. View Slide

18. 4,800,000 WEBSITES
    19% OF THE TOP 10K WEBSITES


    View Slide

19. View Slide

20. I'M @THIJSFERYN


    View Slide

21. View Slide

22. View Slide

23. NORMALLY
    USER SERVER


    View Slide

24. WITH REVERSE CACHING PROXY
    USER PROXY SERVER


    View Slide

25. View Slide

26. View Slide

27. CONTROLLING THE CACHE WITH HTTP
    Expires: Sat, 09 Sep 2017 14:30:00 GMT
    Cache-control: public, max-age=3600, s-maxage=86400
    Cache-control: private, no-cache, no-store
    Vary: Accept-Language


    View Slide

28. STATE


    View Slide

29. STATE
    ~
    USER SPECIFIC DATA
    COOKIES
    AUTH
    HEADERS


    View Slide

30. FOR YOUR EYES ONLY
    NOT CACHED


    View Slide

31. VARNISH CONFIGURATION LANGUAGE


    View Slide

32. vcl 4.1;
    sub vcl_recv {
    if (req.http.Cookie) {
    set req.http.Cookie = ";" + req.http.Cookie;
    set req.http.Cookie = regsuball(req.http.Cookie, "; +", ";");
    set req.http.Cookie = regsuball(req.http.Cookie,
    ";(SESS[a-z0-9]+|SSESS[a-z0-9]+|NO_CACHE)=", "; \1=");
    set req.http.Cookie = regsuball(req.http.Cookie, ";[^ ][^;]*", "");
    set req.http.Cookie = regsuball(req.http.Cookie, "^[; ]+|[; ]+$", "");
    if (req.http.Cookie == "") {
    unset req.http.Cookie;
    }
    else {
    return (pass);
    }
    }
    }
    Only
    keep certain
    cookies


    View Slide

33. sub vcl_recv {
    if (req.http.Cookie) {
    set req.http.Cookie = ";" + req.http.Cookie;
    set req.http.Cookie = regsuball(req.http.Cookie, "; +", ";");
    set req.http.Cookie = regsuball(req.http.Cookie, ";(language)=", "; \1=");
    set req.http.Cookie = regsuball(req.http.Cookie, ";[^ ][^;]*", "");
    set req.http.Cookie = regsuball(req.http.Cookie, "^[; ]+|[; ]+$", "");
    if (req.http.cookie ~ "^\s*$") {
    unset req.http.cookie;
    return(pass);
    }
    return(hash);
    }
    }
    sub vcl_hash {
    hash_data(regsub( req.http.Cookie, "^.*language=([^;]*);*.*$", "\1" ));
    }
    Cookie
    cache
    variation


    View Slide

34. vcl 4.1;
    import cookieplus;
    sub vcl_recv {
    cookieplus.keep("language");
    cookieplus.write();
    }
    sub vcl_hash {
    hash_data(cookieplus.get("language"));
    }
    VMOD_COOKIE


    View Slide

35. CONTAINS
    USER
    INFORMATION


    View Slide

36. NO CACHE


    View Slide

37. PLACEHOLDERS


    View Slide

38. SEPARATE
    HTTP REQUEST


    View Slide

39. AJAX


    View Slide

40. ✓CLIENT-SIDE
    ✓COMMON KNOWLEDGE
    ✓PARALLEL PROCESSING
    ✓GRACEFUL
    DEGRADATION
    -PROCESSED BY THE
    BROWSER
    -EXTRA ROUNDTRIPS
    -SOMEWHAT SLOWER
    AJAX


    View Slide

41. EDGE-SIDE INCLUDES ESI


    View Slide

42.


    View Slide

43. ESI
    ✓ PLACEHOLDER
    ✓ PARSED BY VARNISH
    ✓ OUTPUT IS A COMPOSITION OF BLOCKS
    ✓ STATE PER BLOCK
    ✓ TTL PER BLOCK


    View Slide

44. sub vcl_recv {
    set req.http.Surrogate-Capability = "key=ESI/1.0";
    }
    sub vcl_backend_response {
    if (beresp.http.Surrogate-Control ~ "ESI/1.0") {
    unset beresp.http.Surrogate-Control;
    set beresp.do_esi = true;
    }
    }


    View Slide

45. ✓SERVER-SIDE
    ✓STANDARDIZED
    ✓PROCESSED ON THE
    “EDGE”, NOT IN THE
    BROWSER
    ✓GENERALLY FASTER
    -SEQUENTIAL*
    -ONE FAILS, ALL FAIL
    -LIMITED
    IMPLEMENTATION IN
    VARNISH
    -NOT THAT COMMON
    ESI PARALLEL IN
    ENTERPRISE


    View Slide

46. NON-CACHEABLE ROUTES WILL STILL BE A
    TARGET FOR LOAD/LATENCY


    View Slide

47. NOT JUST A CACHE
    NOT JUST "TAKE IT OR LEAVE IT"


    View Slide

48. AN HTTP
    LOGIC BOX


    View Slide

49. DECISION MAKING AT THE EDGE


    View Slide

50. vcl 4.1;
    import cookieplus;
    import redis;
    import synthbackend;
    sub vcl_init
    {
    new db = redis.db(
    location="redis:6379",
    type=master,
    connection_timeout=500,
    shared_connections=false,
    max_connections=1);
    }
    sub vcl_recv
    {
    set req.http.X-Login = "false";
    set req.http.x-session = cookieplus.get("PHPSESSID","guest");
    if(req.http.x-session != "guest") {
    db.command("EXISTS");
    db.push("sf_s"+cookieplus.get("PHPSESSID"));
    db.execute();
    if(db.get_integer_reply() == 1) {
    set req.http.X-Login = "true";
    }
    }
    }
    SYNTHETIC HTTP


    View Slide

51. sub vcl_backend_fetch
    {
    if(bereq.url == "/session") {
    if(bereq.http.X-Login != "true") {
    set bereq.backend = synthbackend.from_string("{}");
    return(fetch);
    }
    db.command("EVAL");
    db.push({"
    local session = redis.call('GET', KEYS[1])
    if session == nil then
    return '{}'
    end
    local result = string.gsub(session, '[%c]', '')
    local username = string.gsub(result,'.+Userusername\";s:[0-9]+:\"([^\"]+)\";.+','%1')
    if username == nil then
    return '{}'
    end
    return '{"username":"'.. username ..'"}'
    "});
    db.push(1);
    db.push("sf_s"+cookieplus.get("PHPSESSID"));
    db.execute();
    set bereq.backend = synthbackend.from_string(db.get_string_reply());
    }
    }
    sub vcl_backend_response
    {
    if(bereq.url == "/session") {
    set beresp.http.Content-Type = "application/json; charset=utf-8";
    set beresp.ttl = 3600s;
    set beresp.http.vary = "x-session";
    }
    }
    REDIS LUA
    CODE


    View Slide

52. USER
    GET /session
    Cookie: PHPSESSID=7er3hjKal8u235c87u6ih0vz8Y
    HTTP/1.1 200 OK
    Content-Length: 31
    Content-Type: application/json; charset=utf-8
    X-Varnish: 163854 196622
    Age: 27
    {"username":"thijs"}
    VARNISH


    View Slide

53. WHAT DO YOU DO WITH IT?
    ✓ AJAX CALL
    ✓ LOAD VIA ESI AND PROCESS VIA LOCAL JAVASCRIPT
    ✓ EDGESTASH


    View Slide

54. {{ EDGESTASH }}
    VARNISH
    MODULE FOR MUSTACHE
    PROCESSING ON THE
    EDGE


    View Slide

55. vcl 4.1;
    import edgestash;
    backend default
    {
    .host = "1.1.1.1";
    .port = "80";
    }
    sub vcl_backend_response {
    if (bereq.url == "/session") {
    edgestash.index_json();
    } else if (bereq.url == "/") {
    edgestash.parse_response();
    }
    }
    sub vcl_deliver {
    if (req.url == "/" && edgestash.is_edgestash()) {
    edgestash.add_json_url("/session");
    edgestash.execute();
    }
    }
    EDGESTASH


    View Slide

56. EDGESTASH
    {"username":"Thijs"}
    {{ username }}
    Thijs


    View Slide

57. MORE FLEXIBILITY


    View Slide

58. Surrogate-Control: edgestash="EDGESTASH/2.1"
    Link: ; rel=edgestash


    View Slide

59. vcl 4.1;
    import edgestash;
    import std;
    backend default
    {
    .host = "1.1.1.1";
    }
    sub vcl_recv
    {
    set req.http.Surrogate-Capability={"edgestash="EDGESTASH/2.1""};
    }
    sub vcl_backend_response
    {
    if(beresp.http.Link) {
    std.collect(beresp.http.Link,",");
    }
    if(beresp.http.Link ~ "<([^>]+)>; rel=edgestash") {
    set beresp.http.x-edgestash-json-urls = regsuball(beresp.http.Link,"(?(?=<[^>]+>; rel=edgestash)<([^>]+)>;
    rel=edgestash|<([^>]+)>; rel=[a-z]+, )","\1");
    }
    if(beresp.http.Surrogate-Control) {
    std.collect(beresp.http.Surrogate-Control);
    }
    if(beresp.http.Surrogate-Control ~ {".*="EDGESTASH/2\.[0-9]+".*"}) {
    edgestash.parse_response();
    }
    }
    EDGESTASH


    View Slide

60. sub vcl_deliver
    {
    if(edgestash.is_edgestash() && resp.http.x-edgestash-json-urls) {
    edgestash.add_json_url_csv(resp.http.x-edgestash-json-urls);
    edgestash.execute();
    }
    unset resp.http.Link;
    unset resp.http.x-edgestash-json-urls;
    unset resp.http.surrogate-control;
    }
    EDGESTASH


    View Slide

61. View Slide

62. COMPOSER REQUIRE THIJSFERYN/EDGESTASH-TWIG-BUNDLE


    View Slide

63. {{ edgestash('username','/session') }}
    {{ username | edgestash('username','/session') }}


    View Slide

64.
    {% if isEdgestash() %}
    //Edgestash-supported logic
    {% else %}
    //Regular Twig logic
    {% endif %}



    View Slide

65. {{ edgestash('#username', '/session') }}
    Welcome {{ edgestash('username') }}
    {{ edgestash('/username') }}
    {{ edgestash('^username') }}
    Welcome guest
    {{ edgestash('/username') }


    View Slide

66.
    {{ edgestash('#.', '/users') }}
    {{ edgestash('username') }}
    {{ edgestash('/.') }}



    View Slide

67. View Slide

68. FROM $0.20/H + 14 DAYS FREE TRIAL


    View Slide

69. MORE EDGE DECISION MAKING


    View Slide

70. import deviceatlas;
    sub vcl_recv {
    set req.http.MobilePhone = "no";
    if (deviceatlas.lookup_int(req.http.User-Agent, "isMobilePhone")) {
    set req.http.MobilePhone = "yes";
    }
    }
    Device
    detection


    View Slide

71. vcl 4.0;
    import mmdb;
    backend default { .host = "192.0.2.11"; .port = "8080"; }
    # create a database object
    sub vcl_init {
    new geodb = mmdb.init("/path/to/db");
    }
    sub vcl_recv {
    # retrieve the name of the request's origin
    set req.http.Country-Name = geodb.country_name(client.ip);
    # if the country doesn't come from Germany or Belgium, deny access
    if (req.http.Country-Name != "Germany" ||
    req.http.Country-Name != "Belgium") {
    return (synth(403, "Sorry, only available in Germany and Belgium"));
    }
    }
    Geo
    blocking


    View Slide

72. vcl 4.0;
    import http;
    backend default {
    .host = "origin";
    .port = "80";
    }
    sub vcl_recv {
    set req.http.X-prefetch = http.varnish_url("/");
    }
    sub vcl_backend_response {
    if (beresp.http.Link ~ "<.+>.*(prefetch|next)") {
    set bereq.http.X-link = regsub(beresp.http.Link, "^.*<([^>]*)>.*$", "\1");
    set bereq.http.X-prefetch = regsub(bereq.http.X-prefetch, "/$", bereq.http.X-link);
    http.init(0);
    http.req_copy_headers(0);
    http.req_set_url(0, bereq.http.X-prefetch);
    http.req_send_and_finish(0);
    }
    }
    Pre-fetching


    View Slide

73. View Slide

74. View Slide

75. HTTPS://FERYN.EU
    HTTPS://TWITTER.COM/THIJSFERYN
    HTTPS://INSTAGRAM.COM/THIJSFERYN


    View Slide
