Intro Five Android Architecture

Introduction to the modification of the Clean Architecture that we use at Five Agency during our Android development

Transcript

1. Intro to Five Architecture 29.09.2016@Five #IzSveSnage tomislav.homan@fiveminutes.eu Or zero to clean…. Tomislav Homan, Five
2. Overview • Earlier fails • General Clean Architecture • Clean Adjusted for Android • Is it better? • No code, just philosophy
3. Software Architecture • “Intellectually graspable” abstraction of a complex system (wiki) • (which helps us plan, design and construct software)
4. Software Architecture • “Intellectually graspable” abstraction of a complex system (wiki) • Multitude of stakeholders • Separation of concerns - one reason to change • Run away from the real world (Android, DB, Internet) • Testability • SRP + Testability + … = Maintainability, Scalability, etc...
5. The olden times - God activity public final class UsersActivity extends ListActivity { @Override protected void onCreate(Bundle savedInstanceState) { super.onCreate(savedInstanceState); //... new ListUsers().execute(); } private final class ListUsers extends AsyncTask<Void, Void, Void> { @Override protected Void doInBackground(Void... voids) { // final SQLiteOpenHelper sqLiteOpenHelper = ... // JsonObjectRequest jsObjRequest = new JsonObjectRequest // (Request.Method.GET, url, null, new Response.Listener<JSONObject>() { // MySingleton.getInstance(this).addToRequestQueue(jsObjRequest); // showData(user); return null; } } }
6. The olden times - God activity public final class UsersActivity extends ListActivity { @Override protected void onCreate(Bundle savedInstanceState) { super.onCreate(savedInstanceState); //... new ListUsers().execute(); } private final class ListUsers extends AsyncTask<Void, Void, Void> { @Override protected Void doInBackground(Void... voids) { // final SQLiteOpenHelper sqLiteOpenHelper = ... // JsonObjectRequest jsObjRequest = new JsonObjectRequest // (Request.Method.GET, url, null, new Response.Listener<JSONObject>() { // MySingleton.getInstance(this).addToRequestQueue(jsObjRequest); // showData(user); return null; } } }
7. The olden times - God activity public final class UsersActivity extends ListActivity { @Override protected void onCreate(Bundle savedInstanceState) { super.onCreate(savedInstanceState); //... new ListUsers().execute(); } private final class ListUsers extends AsyncTask<Void, Void, Void> { @Override protected Void doInBackground(Void... voids) { // final SQLiteOpenHelper sqLiteOpenHelper = ... // JsonObjectRequest jsObjRequest = new JsonObjectRequest // (Request.Method.GET, url, null, new Response.Listener<JSONObject>() { // MySingleton.getInstance(this).addToRequestQueue(jsObjRequest); // showData(user); return null; } } } NOT testable
8. The olden times - God activity public final class UsersActivity extends ListActivity { @Override protected void onCreate(Bundle savedInstanceState) { super.onCreate(savedInstanceState); //... new ListUsers().execute(); } private final class ListUsers extends AsyncTask<Void, Void, Void> { @Override protected Void doInBackground(Void... voids) { // final SQLiteOpenHelper sqLiteOpenHelper = ... // JsonObjectRequest jsObjRequest = new JsonObjectRequest // (Request.Method.GET, url, null, new Response.Listener<JSONObject>() { // MySingleton.getInstance(this).addToRequestQueue(jsObjRequest); // showData(user); return null; } } } NOT testable Stakeholders?
9. The olden times - God activity public final class UsersActivity extends ListActivity { @Override protected void onCreate(Bundle savedInstanceState) { super.onCreate(savedInstanceState); //... new ListUsers().execute(); } private final class ListUsers extends AsyncTask<Void, Void, Void> { @Override protected Void doInBackground(Void... voids) { // final SQLiteOpenHelper sqLiteOpenHelper = ... // JsonObjectRequest jsObjRequest = new JsonObjectRequest // (Request.Method.GET, url, null, new Response.Listener<JSONObject>() { // MySingleton.getInstance(this).addToRequestQueue(jsObjRequest); // showData(user); return null; } } } NOT testable Stakeholders? SRP?
10. The olden times - God activity public final class UsersActivity extends ListActivity { @Override protected void onCreate(Bundle savedInstanceState) { super.onCreate(savedInstanceState); //... new ListUsers().execute(); } private final class ListUsers extends AsyncTask<Void, Void, Void> { @Override protected Void doInBackground(Void... voids) { // final SQLiteOpenHelper sqLiteOpenHelper = ... // JsonObjectRequest jsObjRequest = new JsonObjectRequest // (Request.Method.GET, url, null, new Response.Listener<JSONObject>() { // MySingleton.getInstance(this).addToRequestQueue(jsObjRequest); // showData(user); return null; } } } NOT testable Stakeholders? SRP? Mixed with Android!
11. The olden times - MVP • Better
12. The olden times - MVP • Better
13. The olden times - MVP • Better
14. The olden times - MVP • Better SRP
15. The olden times - MVP • Better SRP Testable-ish
16. The olden times - MVP • Better SRP Testable-ish Stakeholders?
17. The olden times - MVP • Better SRP Testable-ish Mixed with Android! Stakeholders?
18. The olden times - MVP + Managers • Sorta OK Manager this Manager that
19. The olden times - MVP + Managers • Sorta OK Manager this Manager that SRP - meh ok
20. The olden times - MVP + Managers • Sorta OK Manager this Manager that SRP - meh ok Stakeholders
21. The olden times - MVP + Managers • Sorta OK Manager this Manager that SRP - meh ok Stakeholders Mixed with Android!
22. The olden times - MVP + Managers • Sorta OK Manager this Manager that SRP - meh ok Stakeholders Mixed with Android! Testable-ish Tend to be HUGE!!!
23. The Clean Architecture
24. The Clean Architecture Onion
25. The Clean Architecture Ports and Adapters
26. The Clean Architecture • Dependency rule • Abstraction • Communication between layers
27. Dependency rule
28. Dependency rule
29. Dependency rule
30. Dependency rule
31. Dependency rule
32. Abstraction
33. Abstraction
34. Abstraction
35. All dependencies go to the database Core of the app 3 tier Clean All dependencies go to the business layer Abstraction Business is the core of the app
36. Communication
37. Communication I
38. Communication O
39. Communication I O
40. Communication I O
41. Communication I O
42. Communication I O
43. Communication I O
44. Communication I O
45. Communication I Dependency always pointing inwards O
46. Communication I Communication can go both inwards and outwards O
47. Adjusted for Android
48. Adjusted for Android
49. Entities
50. Entities • AKA Domain Objects, Business Objects • No interaction with the gritty details, no database, no Internet • Simple business logic constrained to itself or its children • Immutable • No persistence methods (stay tuned)
51. Entities Example: News app • Category • Article • Commercial
52. Entities Example: News app with user subscriptions • Category • Article • Commercial • User • Subscription
53. Use Cases
54. Use Cases • AKA Interactors, Business Services • Small piece of business logic acting on one or more entities • Must be able to describe its job by using common language (no details) • Don’t skip use cases
55. Use Cases Example: Transfer money to account use case • Load two accounts • Do some validation • If OK transfer money • Save the changes Note the simple common language
56. Repositories
57. Repositories • Perform CRUD operations on entities • Additionally: filtering, aggregate operations, etc… • Repository is abstract (output port) • Concrete implementation in outer layers (DAO, API, Cache, Combination) • Can handle entity’s whole object tree
58. Presenters
59. Presenters • Always have accompanied view • Gather info and send them to view • Don’t know concrete view implementation (view as output port) • But tied to its lifecycle • User input delegated to presenters • Usually map entities to viewmodels
60. Presenters Example: Screen showing details of an account - abstraction View • onTransactionButtonClicked • onUserItemSelected • setUserListPanelVisible • setGenderBoxEnabled Presenter • doTransaction • selectUser • showUsers • activateGenderView
61. Device
62. Device • Gritty Android stuff • NOT Db, Internet or UI - separate component • Sensors, alarms, notifications, players, etc… • Define wrappers around Android objects in Device component • Define interface that wrapper will be implementing in domain component to serve as an output port
63. Device LocationManager NotificationManager AlarmManager MediaPlayer LocationManagerWrapper NotificationManagerWrapper AlarmManagerWrapper MediaPlayerWrapper Locations Notifications Alarms Player Use case 1 Use case 2 Use case 3 Use case 4 Device Domain
64. DB & API
65. DB & API • Also access to the real world • This time real world are a database and the Internet • Classes such as SQLiteOpenHelper, DbModels, DAOs, Retrofit interfaces and services, API models, JSON parsers… • If you are using database only, DAO can implement a repository • Inner layers use entities, so you should also return entities -> mappers
66. UI
67. UI • Android classes used for interacting with user via display • Fragments, Activities, Adapters, Views, Animations, etc… • Display logic only
68. Modules
69. Modules Domain
70. Modules Device
71. Modules Data
72. Modules UI (app)
73. Modules MVP still here
74. Is it better?
75. Is it better? Manager this Manager that SRP - meh ok Stakeholders Mixed with Android! Testable-ish
76. Is it better? Manager this Manager that
77. Is it better?
78. Is it better?
79. Is it better? Use case 1 Use case 2 Use case 3 ...
80. Is it better? Use case 1 Use case 2 Use case 3 ... Repository
81. Is it better? Use case 1 Use case 2 Use case 3 ... Repository Location Notifications ...
82. Is it better? Use case 1 Use case 2 Use case 3 ... Repository Location Notifications ... UI
83. Is it better? Use case 1 Use case 2 Use case 3 ... Repository Location Notifications ... UI Domain
84. Is it better? Use case 1 Use case 2 Use case 3 ... Repository Location Notifications ... UI Data Domain
85. Is it better? Use case 1 Use case 2 Use case 3 ... Repository Location Notifications ... UI Device Data Domain
86. Is it better? Use case 1 Use case 2 Use case 3 ... Repository Location Notifications ... UI Device Outer world Data Domain
87. Is it better? Use case 1 Use case 2 Use case 3 ... Repository Location Notifications ... UI Device Outer world Data Domain SRP
88. Is it better? Use case 1 Use case 2 Use case 3 ... Repository Location Notifications ... SRP
89. Is it better? Use case 1 Use case 2 Use case 3 ... Repository Location Notifications ... SRP
90. Is it better? Use case 1 Use case 2 Use case 3 ... Repository Location Notifications ... SRP Not mixed with Android!
91. Is it better? Use case 1 Use case 2 Use case 3 ... Repository Location Notifications ... SRP Not mixed with Android!
92. Is it better? Use case 1 Use case 2 Use case 3 ... Repository Location Notifications ... SRP Not mixed with Android!
93. Is it better? Use case 1 Use case 2 Use case 3 ... Repository Location Notifications ... SRP Testable Not mixed with Android!
94. Is it better? Use case 1 Use case 2 Use case 3 ... Repository Location Notifications ... SRP Testable Not mixed with Android!
95. Is it better? Use case 1 Use case 2 Use case 3 ... Repository Location Notifications ... SRP Testable Not mixed with Android! UI designer cares about this
96. Is it better? Use case 1 Use case 2 Use case 3 ... Repository Location Notifications ... SRP Testable Not mixed with Android! UI designer cares about this UX designer cares about this
97. Is it better? Use case 1 Use case 2 Use case 3 ... Repository Location Notifications ... SRP Testable Not mixed with Android! UI designer cares about this UX designer cares about this BA, QA, PM care about this
98. Is it better? Use case 1 Use case 2 Use case 3 ... Repository Location Notifications ... SRP Testable Not mixed with Android! UI designer cares about this UX designer cares about this BA, QA, PM care about this Nobody cares about this
99. Is it better? Use case 1 Use case 2 Use case 3 ... Repository Location Notifications ... SRP Testable Not mixed with Android! UI designer cares about this UX designer cares about this BA, QA, PM care about this Backend guys care about this Nobody cares about this
100. Is it better? Use case 1 Use case 2 Use case 3 ... Repository Location Notifications ... SRP Testable Not mixed with Android! Stakeholders are satisfied
