Getting Started with Microservices

Understand:
1. Why Microservice ?
2. What is Microservice ?
3. What do we( Developer,Architect, Business..etc) need ?
4. Technology Comparison
5. Microservice Features
6. Spring Boot Features
7. Microservice Communication
8. Testing

Transcript

1. Getting Started With Microservices Pranav Kumar
2. Agenda • Why Microservice ? • What is Microservice ? • What do we( Developer,Architect, Business..etc) need ? • Technology Comparison • Microservice Features • Spring Boot Features • Microservice Communication • Testing • Demo
3. Why ?
4. Problem with Monolithic Architecture ➔ Tightly Coupled ➔ Language dependency ➔ Scalability ➔ Root Cause Analysis ➔ Monitoring ➔ Auditing ➔ Performance Management Integration Layer (Business Logic) Catalog Query Parts Pricing & Availabilit y Quotatio n Order Order Track ORM Database Pricing
5. What ? ➔ Software Architecture Style ➔ Loosely coupled ➔ Language Agnostic ➔ Highly Scalable Catalog ORM Database
6. What ? “Microservices is a way of breaking large software projects into smaller, independent, and loosely coupled modules. Individual modules are responsible for highly defined and discrete tasks and communicate with other modules through simple, universally accessible APIs.”
7. What do we need ?
8. Software/Service • Loosely coupled • Rest Support • Transaction Management • Log Management • Auditing • Scalable • Secure • Statistics We need..
9. Technologies.. Comparison Rest Support Embedded Container Statistics Support Log Management Transaction Management Security DropWizard ✓ ✓ ✓ ✓ ✕ ✓ Spring Boot ✓ ✓ ✓ ✓ ✓ ✓ Apache Karaf ✓ ✓ ✕ ✕ ✓ ✓ Jersey ✓ ✓ ✓ ✓ ✕ ✓ Apache CXF ✓ ✓ ✓ ✓ ✓ ✓
10. Microservice Features
11. Coupling Microservices definitions says that “Microservices is a way of breaking large software projects into smaller, independent, and loosely coupled modules” So, this issue is straightaway solved. Catalog ORM Database Query Parts ORM Database
12. Language Independent Each service can be developed using different programming language Allows you to take advantage of emerging and latest technologies (framework, programming language , programming practice, etc.). Catalog( Spring Boot ) Spring Data NoSql Query Parts( Apache Karaf ) Hibernate RDBMS
13. Scalability Since microservices are very small part of the complete software ecosystem, It is very easy to scale the same. Unlike, the monolithic web application, where if we have to do a scaling, first we have to setup the environment ( apache, tomcat ) and then deploy the war/ear files in that.
14. Scalability with monolithic ... Integration Layer (Business Logic) Catalog Query Parts Pricing & Availabi lity Quotat ion Order Order Track ORM Database Pricing Integration Layer (Business Logic) Catalog Query Parts Pricing & Availabi lity Quotat ion Order Order Track ORM Database
15. Scalability with Microservice Catalog ORM Database Query Parts ORM Database Catalog ORM Database
16. Root Cause Analysis It is always difficult to find the root cause in a Single Large Monolithic system. In microservice, fault isolation would be improved and we can easily identify which service is consuming more memory or cpu and we can scale that service easily and fix the issue ( if any ) later.
17. Spring Boot
18. Logging Strategy Spring Boot provides us the various way to achieve logging ➔ Using Aspect ➔ Using logback ➔ Annotation based logging ( When an exception occurs )
19. @Before("execution(* com.wtc.samplems.controller.*.*(..))") public void logServicebefore(JoinPoint joinPoint) { logger.debug("Completed: " + joinPoint); System.out.println( "Completed: " + joinPoint ); } Annotation ( Handling Exception and log ): @ExceptionHandler(Exception.class) @ResponseStatus(HttpStatus.INTERNAL_SERVER_ERROR) public @ResponseBody JSONObject handleException(Exception e, HttpServletRequest request) { JSONObject jSONObject = new JSONObject(); jSONObject.put(ConstantsUtility.STATUS, ConstantsUtility.FAILED); UtilityLogger.error("Request Processing Failed in Navigation Serv "+e.getMessage()); return jSONObject; } AspectJ:
20. <?xml version="1.0" encoding="UTF-8"?> <configuration> <property scope="context" name="logger.type" value="servicename" /> <!-- <include resource="org/springframework/boot/logging/logback/base.xml" /> --> <include resource="org/springframework/boot/logging/logback/defaults.xml" /> <jmxConfigurator /> <appender name="navigationservices" class="ch.qos.logback.core.rolling.RollingFileAppender"> <Encoding>UTF-8</Encoding> <File>./logs/servive.log</File> <encoder> <pattern>%d ${logger.type} %p %m%n</pattern> </encoder> <rollingPolicy class="ch.qos.logback.core.rolling.FixedWindowRollingPolicy"> <maxIndex>10</maxIndex> <FileNamePattern>./logs/navigationservices.log.%i</FileNamePattern> </rollingPolicy> <triggeringPolicy class="ch.qos.logback.core.rolling.SizeBasedTriggeringPolicy"> <MaxFileSize>1MB</MaxFileSize> </triggeringPolicy> </appender> <appender name="CONSOLE" class="ch.qos.logback.core.ConsoleAppender"> <encoder> <pattern>%d ${logger.type} %p %m%n</pattern> <charset>utf8</charset> </encoder> </appender> <root level="info"> <appender-ref ref="navigationservices" /> </root> </configuration> Logback:
21. Monitoring Spring boot comes with it’s own monitoring tool called “Spring Admin Console” We can monitor various aspects like: ➔ Application health ➔ Memory ➔ JVM ➔ Garbage Collection ➔ Metrics etc.. We can also changelog level without restarting of the application. This would help us in debugging any prod issue Sample UI : https://github.com/codecentric/spring-boot-admin
22. Dashboard with Desktop Notifications
23. View Application Health, Information & Details
24. View Metric Counters
25. Manage Logback logger levels
26. Auditing Auditing would be achieved using AspectJ We can have the information like ➔ Who accessed the URL and from where ➔ How many requests have been successfully served to whom and how many got failed ➔ Which services - How many times - By Whom
27. Performance Management Until now, We are using several tools to perform this task • Jconsole • JvisualVM • Java Mission Control ( Comes with Java 8 ) • Logicmonitor (Paid)
28. Performance Management Every time a new developer/user comes to the environment, we have to educate them to understand each of the tool. Spring Boot gives us a single tool ( Spring Admin Console) to do the performance management as well
29. Transaction Management Spring gives us various ways to manage the transactions, In which two of them are very popular : ➔ Using Aspects ➔ Annotation Based
30. <!-- the transactional advice (what 'happens'; see the <aop:advisor/> bean below) --> <tx:advice id="txAdvice" transaction-manager="txManager"> <!-- the transactional semantics... --> <tx:attributes> <!-- all methods starting with 'get' are read-only --> <tx:method name="get*" read-only="true"/> <!-- other methods use the default transaction settings (see below) --> <tx:method name="*"/> </tx:attributes> </tx:advice> <!-- ensure that the above transactional advice runs for any execution of an operation defined by the FooService interface --> <aop:config> <aop:pointcut id="fooServiceOperation" expression="execution(* x.y.service.FooService.*(..))"/> <aop:advisor advice-ref="txAdvice" pointcut-ref="fooServiceOperation"/> </aop:config> Using Aspect
31. @Transactional public class DefaultFooService implements FooService { Foo getFoo(String fooName); Foo getFoo(String fooName, String barName); . . } <tx:annotation-driven transaction-manager="txManager"/> <bean id="txManager" class="org.springframework.jdbc.datasource.DataSourceTransactionManager"> <!-- (this dependency is defined somewhere else) --> <property name="dataSource" ref="dataSource"/> </bean> Annotation
32. Communication External : Using REST Internal : Using REST
33. Testing - Unit testing - Junit - Integration Testing - Rest Client - Postman
34. Demo
35. ?
36. Thank You! Follow us on www.walkingtree.tech
