Percolator
a2-ito
May 17, 2022
Transcript
35 slides
-
Publication Large-scale Incremental Processing Using Distributed Transactions and Notifications Daniel
Peng and Frank Dabek Proceedings of the 9th USENIX Symposium on Operating Systems Design and Implementation, USENIX (2010) 被引用数: 616 -
参考 • Bigtable(2006) ◦ 被引用数: 7,472 • Chubby(2006) ◦ 被引用数:
1,492 • Megastore(2011) ◦ 被引用数: 981 • Dynamo(2007) ◦ 被引用数: 5,873 • Bitcoin(2008) ◦ 被引用数: 17,326 -
Overview • Googleのインデックス作成システムは、数十ペタバイトのデータを保存し、数千 台のマシンで1日あたり数十億の更新を処理 • ドキュメントのクロール時にWebのインデックスを更新するには、既存のドキュメ ントの大規模なリポジトリを継続的に変換する必要があ ◦ MapReduceやその他のバッチ処理システムは、小さな更新を個別に処理できない •
大規模なデータセットの更新を段階的に処理するシステムであるPercolatorを 構築 ◦ ドキュメントの平均経過時間を 50%削減しつつ1日あたり同じ数のドキュメントを処理 -
Introduction • 元々はインデックス作成タスクに MapReduce が使われていた • インデックス更新において、新しいページだけに MapReduce を実行するのは 不十分
◦ 既存ページと相互にリンクがあるため ◦ リポジトリ全体への処理のため、サイズに比例して遅くなる -
Introduction • Percolator は Incremental processing(逐次処理)専用に構築されている ◦ 多くのデータ処理タスクで既存のソリューションに代替を意図していない • 小さな更新に分解できない計算(ファイルの並べ替えなど)は、MapReduce
の 方がよい • 一貫性が必要なければ Bigtable で十分 • MapReduce や Bigtable に適さない小さな計算は、従来のDBMSでOK -
Introduction • Percolator を利用するアプリケーションは、ライブWeb検索インデックスに含め るためのWebページを準備するもの • インデックスシステムを Incremental processing に変換することで、Webクロー
ル時に個々のドキュメントを処理できる ◦ ドキュメントの平均処理待ち時間が 100分の1に短縮され、検索結果に表示されるドキュメントの 平均経過時間は50%近く減少 -
Design • a Percolator worker • a Bigtable tablet server
• a GFS chunkserver • timestamp oracle • Chubby lock service https://blog.yugabyte.com/implementing-distributed-transactions-the-google-way-percolator-vs-spanner/ -
Design • Percolator への要求 ◦ 大規模に実行される ◦ 非常に低いレイテンシーの要求がない • ロックのクリーンアップに
lazy なアプローチを選択 ◦ 実装が簡単 ◦ トランザクションのコミットが数十秒遅くなるかもしれない ◦ OLTPを実行しているDBMSでは許容できないが、インデックスを構築するバッチシステムでは 許容できる • グローバルデッドロック検出をしない ◦ 競合するトランザクションの待ち時間が長くなるが、数千台にスケール可能 -
Transactions • t2 は t1 の書き込みを参照することはない • t3 は t1/t2
両方の書き込みを参照する • t1 と t2 が同じセルに書き込もうとした場合、どちらかが abort する -
Percolator column • Bigtable 上の Percolator column ◦ c:lock ▪
An uncommitted transaction is writing this cell; contains the location of primary lock ◦ c:write ▪ Commited data present; stores the Bigtable timestamp of the data ◦ c:data ▪ Stores the data itself ◦ c:notify ▪ Hint: observers may need to run ◦ c:ack_O ▪ Observer “O” has run; stores start timestamp of successful last run -
Percolator transaction 1/5 • Joe のアカウントに $2、Bob のアカウントに $10 •
Bob から Joe に $7 送金する -
Percolator transaction 5/5 • コミット 2/2 ◦ Joe の write
レコードを timestamp 8 で更新 -
liveness • 通常の動きではロックはきちんと clean up されるが、ダウンしたワーカによって ロックが保持され続ける場合がある • シンプルな liveness
の仕組みを使用 ◦ ワーカはトークンを Chubby に書き込む(プロセスが終わったらトークンは削除) ◦ 他のワーカは、当該ワーカが生きていることを知る ◦ ロックは wall time があり、期限が切れたら clean up される -
参考 Practice in TiKV • We use batching and preallocating
techniques to increase the timestamp oracle’s throughput, and also we use a Raft group to tolerate node failure, but there are still some disadvantages to allocating timestamps from a single node. • One disadvantage is that the timestamp oracle can’t be scaled to multiple nodes. • There are some potential solutions for this final case, such as Google Spanner’s TrueTime mechanism and HLCs (Hybrid Logical Clocks). https://tikv.org/deep-dive/distributed-transaction/timestamp-oracle/ より抜粋 -
Notifications • トランザクションをトリガ経由で実行する方法も必要 ◦ ユーザはトリガによって実行されるタスクを登録しておく ◦ Percolator は notify 列が書き込まれたら次のタスクを実行する
• 一連のトランザクションではない • オブザーバはランダム分散スキャンを実行 ◦ notify列保存用に別のBigtableローカリティグループを利用 ◦ Chubby を利用して重複しないようにしている -
Document clustering delay • crawl rate(時間あたりのリポジトリ更新割 合)における MapReduce と Percolator
の 比較 ◦ 240台のマシン • 1000倍程度の差がある • テストクラスタでは、40%近辺で性能限界を 迎えた -
The overhead of Percolator operations • Bigtable と Percolator の
r/w 回数を比較 ◦ PercolatorによるACIDトランザクションのオーバヘッドがどのくらいなのか? • Percolator introduces overhead relative to Bigtable, a factor of four overhead on writes due to 4 round trips: ◦ Percolator -> Timestamp Server -> Percolator -> Tentative Write -> Percolator -> Timestamp Server -> Percolator -> Commit -> Percolator -
Transaction rate • TPC-E改良版* を使用して測定 ◦ TPC-E: RDBMSベンチマーク仕様 ◦ インタフェースや定期実行処理の仕様を
Percolator用にカスタマイズ • CPUコア数に対するスループット ◦ ほぼリニアにスケール *TPC benchmark E standard specification version 1.9.0.Tech. rep., Transaction Processing Performance Council, September 2009 -
Recovery of tps • 17:19頃 tablet サーバを kill した際の パフォーマンス(tps)影響
• 障害後、他の tablet が即時に立ち上 がりパフォーマンスは元のレベルまで 戻っている
