How the Web Works: Lecture 3

How the Web Works: Lecture 3

This talk was designed for a class (98-135) taught at Carnegie Mellon University in Spring 2010.

Avatar for Abhinav Sharma

Abhinav Sharma

February 03, 2010
Tweet

More Decks by Abhinav Sharma

Other Decks in Education

Transcript

  1. POST helloworld.com cmd: make me a sandwich User Web Server

    <html> <head> <title> Hello </title> </head> <body> World! </body> </html>
  2. You Idiot! Is that all you can do? User Web

    Server <html> <head> <title> Make Your Own </title> </head> <body> @#$%#^%$&^&$ </body> </html>
  3. Static Pages + Placeholders <html> <head> <title> <?php $title ?>

    </title> </head> <body> <?php $text ?> </body> </html> Computed Results +
  4. GET index.php <html> <head> <title> <?php $title ?> </title> </head>

    <body> <?php $text ?> </body> </html> Interpreter <html> <head> <title> Hello </title> </head> <body> World </body> </html>
  5. GET index.php <html> <head> <title> <?php $title ?> </title> </head>

    <body> <?php $text ?> </body> </html> Return HTML Interpreter <html> <head> <title> Hello </title> </head> <body> World </body> </html>
  6. GET index.php <html> <head> <title> <?php $title ?> </title> </head>

    <body> <?php $text ?> </body> </html> Return HTML Interpreter <html> <head> <title> Hello </title> </head> <body> World </body> </html> Dynamic
  7. Step 1: Take Input Step 2: Compute Results Step 3:

    Put results in template Step 4: Spit out HTML
  8. Step 1: Take Input Step 2: Compute Results Step 3:

    Put results in template Step 4: Spit out HTML
  9. Why PHP? ... so can Perl, Python, Java, Ruby, or

    even C PHP is easy to learn Syntax similar to Java Most popular Lots of (open) code out there - ex. Wordpress.
  10. Hello, World! <html> <head> <title>My Page</title> </head> <body> <?php print

    "Hello, World"; ?> </body> </html> = <html> <head> <title>My Page</title> </head> <body> Hello, World </body> </html>
  11. Syntax Overview Always between <?php and ?> End lines with

    ; Case Sensitive Syntax similar to Java Variables Weakly Typed!
  12. Syntax Overview Always between <?php and ?> End lines with

    ; Case Sensitive Syntax similar to Java Variables Weakly Typed!
  13. Variables Dont need to declare Prefixed with $ No explicit

    type! Assign with = operator No integer / floats Boolean true or false <?php $var = 23; print $var; $var = "Hello"; print $var; $c = 2; print $c/2; $b = true; ?>
  14. Operators + - * / % == < > <=

    >= String Concatenation (.) && || ! XOR <?php $a = 23; $b = 15; print $a + $b; $var = "Hello" . “World”; $c = true; $d = false; $a = $c || $d; ?>
  15. Comments <?php /* Multiline Comment */ $var = 23; print

    $var; // Single Line Comment $var = "Hello"; print $var; ?> C++ / Java Style Comments
  16. String Quoting Strings can be “string” or ‘string’, char not

    special. Single Quotes ‘ ‘ - printed literally Double quotes “ “ - can embed values <?php $lang = “PHP”; $string1 = “I like $lang”; $string2 = ‘I like $lang’; print $string1; print $string2; ?>
  17. String Quoting Strings can be “string” or ‘string’, char not

    special. Single Quotes ‘ ‘ - printed literally Double quotes “ “ - can embed values $string1: I like PHP $string2: I like $lang <?php $lang = “PHP”; $string1 = “I like $lang”; $string2 = ‘I like $lang’; print $string1; print $string2; ?>
  18. Arrays Created with array() ... actually Hash Tables Indices dont

    have to be numbers! Appending with $arr[] Similar to PERL <?php $arr = array(); $arr[32] = 23; // following appends to [33] $arr[] = 24 $arr = array(“foo”=>1, “bar”=>2); print $array[“foo”]; print $array[“bar”]; ?> http://php.net/manual/en/language.types.array.php
  19. $_GET Special Array! Params passed in URL $val = $_GET[‘key’]

    <?php $n1 = $_GET[‘n1’]; $n2 = $_GET[‘n2’]; $sum = $n1 + $n2; print “sum is $sum”; ?>
  20. $_GET Special Array! Params passed in URL $val = $_GET[‘key’]

    <?php $n1 = $_GET[‘n1’]; $n2 = $_GET[‘n2’]; $sum = $n1 + $n2; print “sum is $sum”; ?>
  21. $_POST Similar to $_GET POST parameters $val = $_POST[‘key’] Processing

    Forms <?php $a = 23; $b = 15; print $a + $b; $var = "Hello" . “World”; $c = true; $d = false; $a = $c || $d; ?>
  22. <form method="POST" action="target.php"> <input type="text" name="login" /><br /> <input type="password"

    name="pass" /><br /> <input type="submit" value=”Submit Query”> </form>
  23. If Similar to C++/Java Things that are false: false “”

    0 NULL Everything Else True if ($color == “red”) { print “red”; } else if ($color = “blue”) { print “blue”; } else { print “no color”; }
  24. For Similar to C++/Java | ‘while’ also available | foreach

    favored for ($i = 0; $i < 10; $i++) { print $i; }
  25. Foreach Iterates as key, value pair or just as values

    Similar to Java’s for(int a : arr) $languages = array( ‘best’ => ‘php’, ‘worst’ => ‘brainf*ck’, ‘easy’ => ‘php’ ); // Iterate as key-value pair foreach ($languages as $adj => $lang) { print “The $adj language is $lang”; } // Iterate over values foreach ($languages as $lang) { print “One language is $lang”; }
  26. Functions Keyword function No return types Take/not take arguments Overloading

    function count($i, $max = 10) { while ( $i< $max) { print $i; } } function factorial($n) { if ($n == 0) return 0; return $n * factorial($n-1); }
  27. Cookies Website can store info on user’s computer. ... in

    small files called “Cookies” Set with setcookie() Access with $_COOKIE Happens in HTTP header, before any HTML setcookie ($name, $value, $expire) $new_value = $_COOKIE[$name]; http://php.net/manual/en/function.setcookie.php
  28. Sessions Also store user info. ... on server Across multiple

    pages $_SESSION[‘key’] = ‘val’ Login / Shopping Carts Data can’t be tampered session_start(); if (isset($_SESSION[‘user’])) { print “Welcome Back!”; } else { // Get $name from form $_SESSION[‘user’] = $name; }
  29. Classes Logical group of variables and functions “public” & “private”

    supported Use the class keyword -> to access members
  30. Useful Functions print_r($arr) : Prints arrays, useful in debugging require_once(‘lib.php’)

    : Imports other PHP files header($data) : Sets HTTP headers (Google for more) isset($var) : Checks is variable has a value explode($delimiter, $string) : Splits string to array mail($to, $subject, $message) : Sends email! htmlspecialchars($string) : Preventing XSS Attacks
  31. Announcement Homework 1 isn’t out yet Involves HTML, PHP, MySQL

    I haven’t coded it yet =P Minis are now Extra Credit 2 Minis = 1 Homework Minis can cover for Homeworks
