Building SDKs with clean architecture

Ever had to create one or more SDKs to expose your company’s services to other apps? We went through this process at babylon and we’re here to share the experience.

In this talk we’ll try to demonstrate how we went from a business decision of allowing the use of babylon services by 3rd party apps, to actually making this happen.

We’ll share some of the challenges and phases we went through to get there and how that impacted our code base.

Transcript

1. Building SDKs with clean
   architecture
   babylon Londroid April 2018
   Joao Alves and Sakis Kaliakoudas


   View Slide

2. Babylon Services


   View Slide

3. ● Partner agreement to ship
   babylon services as SDKs
   ● 2 months to ship initial
   versions
   ● 5 months for them to
   integrate
   ● 3 months of going through
   a multi phase QA
   Lift off


   View Slide

4. ● Initial discussion
   ● Many parallel streams
   ● Usually 2 developers
   per SDK
   ● At most 4 teams
   working in parallel in
   different SDKs
   Planning


   View Slide

5. How many SDKs?


   View Slide

6. Babylon SDKs
   Appointments
   SDK
   Authentication
   SDK
   Consultation
   SDK
   User SDK NHS GP SDK Maps SDK
   Clinical
   Records SDK
   Payment SDK
   AI Chatbot
   SDK
   Monitor SDK
   Notifications
   SDK
   Common SDK
   Wrapper


   View Slide

7. What did the code look like?


   View Slide

8. Views Presenters Interactors
   Gateways/
   Repositories
   Retrofit
   Services
   Clean architecture layers


   View Slide

9. Views Presenters Interactors
   Gateways/
   Repositories
   Retrofit
   Services
   What to ship?


   View Slide

10. View related Domain
    Views Presenters Interactors
    Gateways/
    Repositories
    Retrofit
    Services
    What to ship?


    View Slide

11. Views Presenters Interactors
    Gateways/
    Repositories
    Retrofit
    Services
    Legacy


    View Slide

12. Views Presenters Interactors
    Gateways/
    Repositories
    Retrofit
    Services
    MVP


    View Slide

13. Views Presenters Interactors
    Gateways/
    Repositories
    Retrofit
    Services
    MVP + Clean


    View Slide

14. Moving stuff around
    App
    Gateways/
    Repositories
    Interactors Entities
    SDK 1
    SDK 2
    SDK N
    App
    Non-SDK
    Interactors
    Non-SDK
    Gateways
    SDK
    Gateways
    Entities


    View Slide

15. Moving stuff around
    App
    Gateways/
    Repositories
    Interactors Entities
    App
    Non-SDK
    Interactors
    Non-SDK
    Gateways
    SDK
    Gateways
    Entities
    SDK 1
    SDK 2
    SDK N


    View Slide

16. Moving stuff around
    App
    Gateways/
    Repositories
    Interactors Entities
    App
    Non-SDK
    Interactors
    Non-SDK
    Gateways
    SDK
    Gateways
    Entities
    SDK 1
    SDK 2
    SDK N


    View Slide

17. Gateways and entities sharing
    SDK
    Gateways
    Entities
    SDK 1
    SDK 2
    SDK N


    View Slide

18. Splitting it up
    Gateways 1
    Gateways 2
    Gateways N
    Entities
    SDK 1
    SDK 2
    SDK N


    View Slide

19. class DoSomethingInteractor{
    private Gateway gateway;
    @Inject
    public DoSomethingInteractor(Gateway gateway){
    this.gateway = gateway;
    }
    Disposable execute(Request request, Callback callback){
    ...
    }
    }
    But what does it look like


    View Slide

20. interface Callback{
    void onSuccess(Result result);
    void onError(Exception exception);
    }
    class Request {
    String someField1;
    String someField2;
    }
    class Result {
    String someField3;
    String someField4;
    }
    But what does it look like


    View Slide

21. class DoSomethingInteractor{
    private Gateway gateway;
    @Inject
    public DoSomethingInteractor(Gateway gateway){
    this.gateway = gateway;
    }
    Disposable execute(Request request, Callback callback){
    ...
    }
    }
    But what does it look like


    View Slide

22. Client
    Clinical
    Records
    SDK
    Wrapping the interactors
    ClinicalRecordsApi clinicalRecordsApi = ClinicalRecordsSdk.getApiInstance();
    clinicalRecordsApi.doSomething(request, callback);
    Client requests an instance of the API


    View Slide

23. Clinical
    Records API
    Client
    Clinical
    Records
    SDK
    Wrapping the interactors
    ClinicalRecordsApi clinicalRecordsApi = ClinicalRecordsSdk.getApiInstance();
    clinicalRecordsApi.doSomething(request, callback);
    The SDK class instantiates the API


    View Slide

24. Clinical
    Records API
    Client
    Clinical
    Records
    SDK
    Wrapping the interactors
    ClinicalRecordsApi clinicalRecordsApi = ClinicalRecordsSdk.getApiInstance();
    clinicalRecordsApi.doSomething(request, callback);
    Returns it to the client


    View Slide

25. Clinical
    Records API
    Interactors
    Interactors
    Interactors
    Gateways
    Interactors
    Entities
    Client
    Clinical
    Records
    SDK
    Wrapping the interactors
    ClinicalRecordsApi clinicalRecordsApi = ClinicalRecordsSdk.getApiInstance();
    clinicalRecordsApi.doSomething(request, callback);
    Client can access all the SDK interactors via the API


    View Slide

26. SDK API Interface
    /**
    * Get list of appointments for the main user and its registered children
    * (if any).
    *
    * @param request the request object that contains the required information
    * to get the user appointments.
    * @param output the callback through which the results are returned.
    *
    * @return an RxJava 2 {@link Disposable} resource to manage this request.
    */
    Disposable getAppointments(GetAppointmentsRequest request, GetAppointmentsOutput output);


    View Slide

27. String patientId = "patientId";
    GetAppointmentsRequest request =
    GetAppointmentsRequest.create(AppointmentType.UPCOMING, patientId);
    babylonAppointmentApi.getAppointments(request, new GetAppointmentsOutput() {
    @Override
    public void onFetchAppointmentsSuccess(List appointments) {
    if (appointments.isEmpty()) {
    getView().showNoAppointments();
    } else {
    getView().showAppointments(appointments);
    }
    }});
    Presenter using the SDK:


    View Slide

28. Dog fooding
    ● Using the SDKs inside our
    Apps
    ● Local development with local
    gradle module dependencies
    ● CI builds the SDKs, publishes
    them, then builds the app
    using artifact dependencies


    View Slide

29. Build and deploy
    Local Maven
    Repo
    Artifactory
    Single Gradle
    Task
    ● ~25 releases in 10 months (excluding hotfixes)
    ● Releases around every 10 days
    a day an hour a minute


    View Slide

30. Security
    ● No sensitive information
    stored locally
    ● Encryption with Android
    keystore
    ● Using Dexguard
    ● Logging based on
    environment
    ● Timber Wrapper


    View Slide

31. Uniquely identifying clients via their public certificate
    Offline:
    ● Get certificate hash
    ● Merge it together with the application id to generate a new hash
    ● Save this hash inside the SDKs
    Runtime:
    ● Calculate the same hash
    ● Match it against the precomputed value


    View Slide

32. Activities in the SDKs?


    View Slide

33. Kotlin?


    View Slide

34. SDK size
    ● Trimming all dependencies
    ● Native libraries
    ● Dexguard


    View Slide

35. Documentation
    ● JavaDoc with CheckStyle
    ● Release notes - from git diff to
    git code owners
    ● Sample App
    ● Wiki page


    View Slide

36. Support
    ● Slack support
    ● Dedicated JIRA board
    ● Daily/Weekly calls


    View Slide

37. Finish line
    ● Improved code quality
    ● Much less legacy code
    ● Modularized project
    ● Loads of knowledge
    ● Much bigger user base


    View Slide

38. What does the code look like now?


    View Slide

39. Lessons learned
    ● Planning + Planning +
    Planning
    ● Don’t create silos - merge
    often
    ● More logging
    ● Version controlled
    documentation


    View Slide

40. ● Problems are bound to
    happen and trust us they
    will happen. And they
    don’t come on their own
    they come in herds.
    ● Work your way through
    them and you’ll eventually
    get to the finish line.
    Don’t Panic


    View Slide

41. Questions?
    Presented by Joao Alves and Sakis Kaliakoudas
    Say hi on Twitter & Medium:
    @jcmsalves & @skaliakoudas
    PS: we’re hiring, come and talk to us to know more


    View Slide

42. Useful links
    ● SDK class example: (https://tinyurl.com/MyBossMadeMeDoThis)
    ● Getting a certificate hash (https://tinyurl.com/tralalatralalo)
    ● Merging a certificate hash with an application id to generate a new hash
    (https://tinyurl.com/we-r-hiringgg)
    ● Calculating the same hash at runtime (https://tinyurl.com/PleaseDontAskQuestions)


    View Slide
