A Reactive 3D Game Engine in Scala

Most modern 3D game engines are written close to the metal in C++ to achieve smooth performance and stunning. Managed languages and runtimes are usually avoided for this task since they incur garbage collection lags and other performance penalties.

We decided to put this conventional wisdom to test with an experiment - we used an Rx-style reactive programming framework enriched with reactive collections and isolates in unison with a high-level OpenGL framework to build a modern 3D engine.

Game engines are traditionally written in low-level imperative style to achieve optimal performance. Such code can be hard to understand and maintain - the uprising reactive programming is much more natural for writing games, since game engines are in essence discrete event simulations. However, reactive programming comes with performance penalties that we overcome using Scala Specialization, inlining and efficient reactive data containers. Similarly, the OpenGL API exposes a plethora of low-level routines unfit for large scale development - a more structured approach to graphics programming with higher level programming abstractions is desired, but yields a higher performance cost. Through the use of Scala Macros we eliminate these inefficiencies while in the same time retaining the advantages of a structured graphics programming framework.

Result? A high-throughput reactive 3D real-time game engine achieving smooth 60FPS on modern hardware with high polygon counts, texture blending, GPU-based object instancing, and effects like ambient occlusion, shadow mapping and image filtering.

Transcript

1. 1
   A Reactive 3D Game Engine in Scala
   Aleksandar Prokopec
   @_axel22_


   View Slide

2. 2
   What’s a game engine?


   View Slide

3. 3
   Simulation


   View Slide

4. 4
   Real-time simulation


   View Slide

5. 5
   15 ms
   Real-time simulation


   View Slide

6. 6
   Demo first!
   http://youtu.be/pRCzSRhifLs


   View Slide

7. 7
   Input Simulator
   Interaction
   Renderer


   View Slide

8. Reactive Collections
   http://reactive-collections.com
   8


   View Slide

9. 9
   Reactive values


   View Slide

10. Reactive[T]
    10


    View Slide

11. val ticks: Reactive[Long]
    11
    ticks 1
    1
    2
    2
    3
    3
    4
    4
    60
    60
    61
    61


    View Slide

12. ticks onEvent { x =>
    log.debug(s”tick no.$x”)
    }
    12
    1 2 3 4 60 61
    tick no.1
    tick no.2
    tick no.3
    tick no.4
    tick no.60
    tick no.61
    ...


    View Slide

13. ticks foreach { x =>
    log.debug(s”tick no.$x”)
    }
    13
    1 2 3 4 60 61


    View Slide

14. 14
    for (x <- ticks) {
    log.debug(s”tick no.$x”)
    }


    View Slide

15. 15
    Reactive combinators


    View Slide

16. for (x <- ticks) yield {
    x / 60
    }
    16


    View Slide

17. val seconds: Reactive[Long] =
    for (x <- ticks) yield {
    x / 60
    }
    17


    View Slide

18. 60
    61
    val seconds: Reactive[Long] =
    for (x <- ticks) yield {
    x / 60
    }
    18
    ticks 1
    1
    2
    2
    3
    3 60 61
    seconds
    0 0 0 1 1
    ticks
    seconds
    0
    0
    0
    1
    1


    View Slide

19. val days: Reactive[Long] =
    seconds.map(_ / 86400)
    19


    View Slide

20. val days: Reactive[Long] =
    seconds.map(_ / 86400)
    val secondsToday =
    20


    View Slide

21. val days: Reactive[Long] =
    seconds.map(_ / 86400)
    val secondsToday =
    (seconds zip days) {
    (s, d) =>
    s – d * 86400
    }
    21


    View Slide

22. val days: Reactive[Long] =
    seconds.map(_ / 86400)
    val secondsToday =
    (seconds zip days) {
    _ – _ * 86400
    }
    22
    seconds days
    secondsToday


    View Slide

23. val angle =
    secondsInDay.map(angleFunc)
    23


    View Slide

24. val angle =
    secondsInDay.map(angleFunc)
    val light =
    secondsInDay.map(lightFunc)
    24


    View Slide

25. 25
    https://www.youtube.com/watch?v=5g7DvNEs6K8&feature=youtu.be
    Preview


    View Slide

26. 26
    val rotate =
    keys
    a ↓
    shift ↓ a ↑ shift ↑
    pgup ↓ pgup ↑
    keys


    View Slide

27. 27
    val rotate =
    keys.filter(_ == PAGEUP)
    a ↓
    shift ↓ a ↑ shift ↑
    pgup ↓ pgup ↑
    keys
    pgup ↓ pgup ↑
    filter


    View Slide

28. 28
    val rotate =
    keys.filter(_ == PAGEUP)
    .map(_.down)
    a ↓
    shift ↓ a ↑ shift ↑
    pgup ↓ pgup ↑
    keys
    pgup ↓ pgup ↑
    filter
    true false
    map


    View Slide

29. 29
    if (rotate()) viewAngle += 1
    true false
    map


    View Slide

30. 30
    Signals


    View Slide

31. 31
    Reactives are
    discrete


    View Slide

32. 32
    Signals are
    continuous


    View Slide

33. 33
    trait Signal[T]
    extends Reactive[T] {
    def apply(): T
    }


    View Slide

34. 34
    val rotate =
    keys.filter(_ == PAGEUP)
    .map(_.down)
    .signal(false)
    true false
    map
    signal


    View Slide

35. 35
    val rotate: Signal[Boolean] =
    keys.filter(_ == PAGEUP)
    .map(_.down)
    .signal(false)
    true false
    map
    signal


    View Slide

36. 36
    val rotate: Signal[Boolean]
    val ticks: Reactive[Long]
    ticks


    View Slide

37. 37
    val rotate: Signal[Boolean]
    val ticks: Reactive[Long]
    ticks
    rotate


    View Slide

38. 38
    val rotate: Signal[Boolean]
    val ticks: Reactive[Long]
    val viewAngle: Signal[Double] =
    ticks
    rotate
    viewAngle


    View Slide

39. 39
    List(1, 2, 3).scanLeft(0)(_ + _)


    View Slide

40. 40
    List(1, 2, 3).scanLeft(0)(_ + _)
    → List(0, 1, 3, 6)


    View Slide

41. 41
    def scanLeft[S](z: S)(f: (S, T) => S)
    : List[S]


    View Slide

42. 42
    def scanLeft[S](z: S)(f: (S, T) => S)
    : List[S]
    def scanPast[S](z: S)(f: (S, T) => S)
    : Signal[S]


    View Slide

43. 43
    val rotate: Signal[Boolean]
    val ticks: Reactive[Long]
    val viewAngle: Signal[Double] =
    ticks.scanPast(0.0)
    ticks
    rotate
    viewAngle


    View Slide

44. 44
    val rotate: Signal[Boolean]
    val ticks: Reactive[Long]
    val viewAngle: Signal[Double] =
    ticks.scanPast(0.0) {
    (a, _) =>
    if (rotate()) a + 1 else a
    }
    ticks
    rotate
    viewAngle


    View Slide

45. 45
    http://youtu.be/blG95W5uWQ8
    Preview


    View Slide

46. 46
    val velocity =
    ticks.scanPast(0.0) {
    (v, _) =>
    }
    val viewAngle =


    View Slide

47. 47
    val velocity =
    ticks.scanPast(0.0) {
    (v, _) =>
    if (rotate()) v + 1
    }
    val viewAngle =


    View Slide

48. 48
    val velocity =
    ticks.scanPast(0.0) {
    (v, _) =>
    if (rotate()) v + 1
    else v – 0.5
    }
    val viewAngle =


    View Slide

49. 49
    val velocity =
    ticks.scanPast(0.0) {
    (v, _) =>
    if (rotate()) v + 1
    else v – 0.5
    }
    val viewAngle =
    velocity.scanPast(0.0)(_ + _)


    View Slide

50. 50
    http://youtu.be/NMVhirZLWmA
    Preview


    View Slide

51. 51
    Higher-order
    reactive values


    View Slide

52. 52
    (T => S) => (List[S] => List[T])


    View Slide

53. 53
    (T => S) => (List[S] => List[T])
    Reactive[Reactive[S]]


    View Slide

54. 54
    val mids = mouse
    .filter(_.button == MIDDLE)
    mids ↓ ↓ ↓
    ↑ ↑ ↑


    View Slide

55. 55
    val mids = mouse
    .filter(_.button == MIDDLE)
    val up = mids.filter(!_.down)
    val down = mids.filter(_.down)
    mids ↓ ↓ ↓
    up
    down ↓ ↓ ↓
    ↑ ↑ ↑
    ↑ ↑ ↑


    View Slide

56. 56
    val mids = mouse
    .filter(_.button == MIDDLE)
    val up = mids.filter(!_.down)
    val down = mids.filter(_.down)
    val drags = down
    .map(_ => mouse)
    up
    down ↓ ↓ ↓
    ↑ ↑ ↑


    View Slide

57. 57
    val mids = mouse
    .filter(_.button == MIDDLE)
    val up = mids.filter(!_.down)
    val down = mids.filter(_.down)
    val drags = down
    .map(_ => mouse)
    up
    down ↓ ↓ ↓
    ↑ ↑ ↑
    Reactive[Reactive[MouseEvent]]


    View Slide

58. 58
    val mids = mouse
    .filter(_.button == MIDDLE)
    val up = mids.filter(!_.down)
    val down = mids.filter(_.down)
    val drags = down
    .map(_ => mouse)
    up
    down ↓ ↓ ↓
    ↑ ↑ ↑
    drags


    View Slide

59. drags
    up ↑ ↑ ↑
    59
    val mids = mouse
    .filter(_.button == MIDDLE)
    val up = mids.filter(!_.down)
    val down = mids.filter(_.down)
    val drags = down
    .map(_ => mouse.until(up))
    down ↓ ↓ ↓
    mouse.until(up)


    View Slide

60. 60
    val mids = mouse
    .filter(_.button == MIDDLE)
    val up = mids.filter(!_.down)
    val down = mids.filter(_.down)
    val drags = down
    .map(_ => mouse.until(up))
    down ↓ ↓ ↓
    up ↑ ↑ ↑
    drags


    View Slide

61. 61
    val drags = down
    .map(_ => mouse.until(up))
    .map(_.map(_.xy))
    drags
    1, 1
    2, 3
    3, 5
    4, 6
    6, 9
    9, 9


    View Slide

62. 62
    val drags = down
    .map(_ => mouse.until(up))
    .map(_.map(_.xy))
    .map(_.diffPast(_.xy - _.xy))
    drags
    0, 0
    1, 2
    1, 2
    0, 0
    2, 3
    0, 0


    View Slide

63. 63
    val drags = down
    .map(_ => mouse.until(up))
    .map(_.map(_.xy))
    .map(_.diffPast(_.xy - _.xy))
    .concat()
    drags 0, 0 1, 2 1, 2 0, 0 2, 3 0, 0


    View Slide

64. 64
    val drags = down
    .map(_ => mouse.until(up))
    .map(_.map(_.xy))
    .map(_.diffPast(_.xy - _.xy))
    .concat()
    val pos =
    drags.scanPast((0, 0))(_ + _)
    drags 0, 0 1, 2 1, 2 0, 0 2, 3 0, 0
    pos 0, 0 1, 2 2, 4 2, 4 4, 7 4, 7


    View Slide

65. 65
    http://youtu.be/RsMSZ7OH2fo
    Preview
    However, a lot of object
    allocations lead to GC issues.


    View Slide

66. 66
    Reactive mutators


    View Slide

67. 67
    class Matrix {
    def apply(x: Int, y: Int): Double
    def update(x: Int, y: Int, v: Double)
    }


    View Slide

68. 68
    val screenMat: Signal[Matrix] =
    (projMat zip viewMat)(_ * _)
    val invScreenMat =
    screenMat.map(_.inverse)


    View Slide

69. 69
    Reactive[immutable.Matrix[T]]


    View Slide

70. 70
    val screenMat: Signal[Matrix] =
    (projMat zip viewMat)(_ * _)
    val invScreenMat =
    screenMat.map(_.inverse)
    (4*4*8 + 16 + 16)*4*100 = 64 kb/s


    View Slide

71. 71
    val screenMat = Mutable(new Matrix)
    (projMat, viewMat).mutate(screenMat) {
    (p, v) => screenMat().assignMul(p, v)
    }
    val invScreenMat = Mutable(new Matrix)
    screenMat.mutate(invScreenMat) {
    m => invScreenMat().assignInv(m)
    }


    View Slide

72. 72
    Reactive collections


    View Slide

73. 73
    http://youtu.be/ebbrAHNsexc
    Preview
    How do we model that a
    character is selected?


    View Slide

74. 74
    val selected: Reactive[Set[Character]]


    View Slide

75. 75
    val selected: ReactSet[Character]


    View Slide

76. 76
    trait ReactSet[T]
    extends ReactContainer[T] {
    def apply(x: T): Boolean
    }


    View Slide

77. 77
    trait ReactContainer[T] {
    def inserts: Reactive[T]
    def removes: Reactive[T]
    }


    View Slide

78. 78
    A reactive collection
    is a pair
    of reactive values


    View Slide

79. 79
    val selected =
    new ReactHashSet[Character]


    View Slide

80. View Slide

81. 81
    val selected =
    new ReactHashSet[Character]
    val decorations = selected
    .map(c => (c, decoFor(c)))


    View Slide

82. View Slide

83. 83
    class ReactContainer[T] { self =>
    def inserts: Reactive[T]
    def removes: Reactive[T]
    def map[S](f: T => S) =
    new ReactContainer[S] {
    def inserts: Reactive[T] =
    self.inserts.map(f)
    def removes: Reactive[T] =
    self.removes.map(f)
    }
    }


    View Slide

84. 84
    val selected =
    new ReactHashSet[Character]
    val decorations = selected
    .map(c => (c, decoFor(c)))
    .to[ReactHashMap]


    View Slide

85. 85
    val selected =
    new ReactHashSet[Character]
    val decorations = selected
    .map(c => (c, decoFor(c)))
    .to[ReactHashMap]


    View Slide

86. 86
    val selected =
    new ReactHashSet[Character]
    val decorations = selected
    .map(c => (c, decoFor(c)))
    .to[ReactHashMap]


    View Slide

87. 87
    val selected =
    new ReactHashSet[Character]
    val decorations = selected
    .map(c => (c, decoFor(c)))
    .to[ReactHashMap]


    View Slide

88. 88
    val selected =
    new ReactHashSet[Character]
    val decorations = selected
    .map(c => (c, decoFor(c)))
    .react.to[ReactHashMap]


    View Slide

89. 89
    val selected =
    new ReactHashSet[Character]
    val decorations = selected
    .map(c => (c, decoFor(c)))
    .react.to[ReactHashMap]


    View Slide

90. 90
    val selected =
    new ReactHashSet[Character]
    val decorations = selected
    .map(c => (c, decoFor(c)))
    .react.to[ReactHashMap]


    View Slide

91. 91
    val selected =
    new ReactHashSet[Character]
    val decorations = selected
    .map(c => (c, decoFor(c)))
    .react.to[ReactHashMap]


    View Slide

92. 92
    • reactive mutators
    • reactive collections
    • @specialized
    • Scala Macros
    • shipping computations to the GPU


    View Slide

93. 93
    http://storm-enroute.com/macrogl/
    MacroGL


    View Slide

94. 94
    https://www.youtube.com/watch?v=UHCeXdxkx70
    GC Preview


    View Slide

95. 95
    Is Scala Ready?


    View Slide

96. 96
    YES!


    View Slide

97. 97
    Thank you!


    View Slide
