ScalaBlitz

Optimizing the parallel collection operations.

Transcript

1. ScalaBlitz
   Efficient Collections Framework


   View Slide

2. What’s a Blitz?


   View Slide

3. Blitz-chess is a style of
   rapid chess play.


   View Slide

4. Blitz-chess is a style of
   rapid chess play.


   View Slide

5. Knights have horses.


   View Slide

6. Horses run fast.


   View Slide

7. def mean(xs: Array[Float]): Float =
   xs.par.reduce(_ + _) / xs.length


   View Slide

8. View Slide

9. View Slide

10. With Lists, operations
    can only be executed
    from left to right


    View Slide

11. 1 2 4 8


    View Slide

12. 1 2 4 8
    Not your typical list.


    View Slide

13. Bon app.


    View Slide

14. View Slide

15. View Slide

16. View Slide

17. View Slide

18. Apparently not enough


    View Slide

19. View Slide

20. No amount of
    documentation is
    apparently enough


    View Slide

21. View Slide

22. The reduceLeft
    guarantees operations are
    executed from left to right


    View Slide

23. Parallel and sequential
    collections sharing operations


    View Slide

24. There are several
    problems here


    View Slide

25. How we see users


    View Slide

26. How users
    see the docs


    View Slide

27. Bending the truth.


    View Slide

28. And sometimes we
    were just slow


    View Slide

29. So, we have a new API now
    def findDoe(names: Array[String]): Option[String] =
    {
    names.toPar.find(_.endsWith(“Doe”))
    }


    View Slide

30. Wait, you renamed a
    method?
    def findDoe(names: Array[String]): Option[String] =
    {
    names.toPar.find(_.endsWith(“Doe”))
    }


    View Slide

31. Yeah, par already exists.
    But, toPar is different.
    def findDoe(names: Array[String]): Option[String] =
    {
    names.toPar.find(_.endsWith(“Doe”))
    }


    View Slide

32. def findDoe(names: Array[String]): Option[String] = {
    names.toPar.find(_.endsWith(“Doe”))
    }
    implicit class ParOps[Repr](val r: Repr) extends AnyVal {
    def toPar = new Par(r)
    }


    View Slide

33. def findDoe(names: Array[String]): Option[String] = {
    ParOps(names).toPar.find(_.endsWith(“Doe”))
    }
    implicit class ParOps[Repr](val r: Repr) extends AnyVal {
    def toPar = new Par(r)
    }


    View Slide

34. def findDoe(names: Array[String]): Option[String] = {
    ParOps(names).toPar.find(_.endsWith(“Doe”))
    }
    implicit class ParOps[Repr](val r: Repr) extends AnyVal {
    def toPar = new Par(r)
    }
    class Par[Repr](r: Repr)


    View Slide

35. def findDoe(names: Array[String]): Option[String] = {
    (new Par(names)).find(_.endsWith(“Doe”))
    }
    implicit class ParOps[Repr](val r: Repr) extends AnyVal {
    def toPar = new Par(r)
    }
    class Par[Repr](r: Repr)


    View Slide

36. def findDoe(names: Array[String]): Option[String] = {
    (new Par(names)).find(_.endsWith(“Doe”))
    }
    class Par[Repr](r: Repr)
    But, Par[Repr] does not
    have the find method!


    View Slide

37. True, but Par[Array[String]]
    does have a find method.
    def findDoe(names: Array[String]): Option[String] = {
    (new Par(names)).find(_.endsWith(“Doe”))
    }
    class Par[Repr](r: Repr)


    View Slide

38. def findDoe(names: Array[String]): Option[String] = {
    (new Par(names)).find(_.endsWith(“Doe”))
    }
    class Par[Repr](r: Repr)
    implicit class ParArrayOps[T](pa: Par[Array[T]]) {
    ...
    def find(p: T => Boolean): Option[T]
    ...
    }


    View Slide

39. More flexible!


    View Slide

40. More flexible!
    ● does not have to implement methods that
    make no sense in parallel


    View Slide

41. More flexible!
    ● does not have to implement methods that
    make no sense in parallel
    ● slow conversions explicit


    View Slide

42. No standard library collections were
    hurt doing this.
    No standard library collections were
    hurt doing this.


    View Slide

43. More flexible!
    ● does not have to implement methods that
    make no sense in parallel
    ● slow conversions explicit
    ● non-intrusive addition to standard library


    View Slide

44. More flexible!
    ● does not have to implement methods that
    make no sense in parallel
    ● slow conversions explicit
    ● non-intrusive addition to standard library
    ● easy to add new methods and collections


    View Slide

45. More flexible!
    ● does not have to implement methods that
    make no sense in parallel
    ● slow conversions explicit
    ● non-intrusive addition to standard library
    ● easy to add new methods and collections
    ● import switches between implementations


    View Slide

46. def findDoe(names: Seq[String]): Option[String] = {
    names.toPar.find(_.endsWith(“Doe”))
    }


    View Slide

47. def findDoe(names: Seq[String]): Option[String] = {
    names.toPar.find(_.endsWith(“Doe”))
    }


    View Slide

48. But how do I write generic code?
    def findDoe(names: Seq[String]): Option[String] = {
    names.toPar.find(_.endsWith(“Doe”))
    }


    View Slide

49. def findDoe[Repr[_]](names: Par[Repr[String]]) = {
    names.toPar.find(_.endsWith(“Doe”))
    }


    View Slide

50. Par[Repr[String]]does not
    have a find
    def findDoe[Repr[_]](names: Par[Repr[String]]) = {
    names.toPar.find(_.endsWith(“Doe”))
    }


    View Slide

51. def findDoe[Repr[_]: Ops](names: Par[Repr[String]]) = {
    names.toPar.find(_.endsWith(“Doe”))
    }


    View Slide

52. def findDoe[Repr[_]: Ops](names: Par[Repr[String]]) = {
    names.toPar.find(_.endsWith(“Doe”))
    }
    We don’t do this.


    View Slide

53. Make everything as simple as
    possible, but not simpler.


    View Slide

54. def findDoe(names: Reducable[String])= {
    names.find(_.endsWith(“Doe”))
    }


    View Slide

55. def findDoe(names: Reducable[String])= {
    names.find(_.endsWith(“Doe”))
    }
    findDoe(Array(1, 2, 3).toPar)


    View Slide

56. def findDoe(names: Reducable[String])= {
    names.find(_.endsWith(“Doe”))
    }
    findDoe(toReducable(Array(1, 2, 3).toPar))


    View Slide

57. def findDoe(names: Reducable[String])= {
    names.find(_.endsWith(“Doe”))
    }
    findDoe(toReducable(Array(1, 2, 3).toPar))
    def arrayIsReducable[T]: IsReducable[T] = { … }


    View Slide

58. So let’s write a program!


    View Slide

59. View Slide

60. import scala.collection.par._
    val pixels = new Array[Int](wdt * hgt)
    for (idx <- (0 until (wdt * hgt)).toPar) {
    }


    View Slide

61. import scala.collection.par._
    val pixels = new Array[Int](wdt * hgt)
    for (idx <- (0 until (wdt * hgt)).toPar) {
    val x = idx % wdt
    val y = idx / wdt
    }


    View Slide

62. import scala.collection.par._
    val pixels = new Array[Int](wdt * hgt)
    for (idx <- (0 until (wdt * hgt)).toPar) {
    val x = idx % wdt
    val y = idx / wdt
    pixels(idx) = computeColor(x, y)
    }


    View Slide

63. import scala.collection.par._
    val pixels = new Array[Int](wdt * hgt)
    for (idx <- (0 until (wdt * hgt)).toPar) {
    val x = idx % wdt
    val y = idx / wdt
    pixels(idx) = computeColor(x, y)
    }
    Scheduler not found!


    View Slide

64. import scala.collection.par._
    import Scheduler.Implicits.global
    val pixels = new Array[Int](wdt * hgt)
    for (idx <- (0 until (wdt * hgt)).toPar) {
    val x = idx % wdt
    val y = idx / wdt
    pixels(idx) = computeColor(x, y)
    }


    View Slide

65. import scala.collection.par._
    import Scheduler.Implicits.global
    val pixels = new Array[Int](wdt * hgt)
    for (idx <- (0 until (wdt * hgt)).toPar) {
    val x = idx % wdt
    val y = idx / wdt
    pixels(idx) = computeColor(x, y)
    }


    View Slide

66. New parallel collections
    33% faster!
    Now
    103 ms
    Previously
    148 ms


    View Slide

67. Workstealing tree scheduler
    rocks!


    View Slide

68. Workstealing tree scheduler
    rocks!
    But, are there other interesting


    View Slide

69. Fine-grained uniform
    workloads are on the opposite
    side of the spectrum.


    View Slide

70. def mean(xs: Array[Float]): Float = {
    val sum = xs.toPar.fold(0)(_ + _)
    sum / xs.length
    }


    View Slide

71. def mean(xs: Array[Float]): Float = {
    val sum = xs.toPar.fold(0)(_ + _)
    sum / xs.length
    }
    Now
    15 ms
    Previously
    565 ms


    View Slide

72. But how?


    View Slide

73. def fold[T](a: Iterable[T])(z:T)(op: (T, T) => T) = {
    var it = a.iterator
    var acc = z
    while (it.hasNext) {
    acc = op(acc, it.next)
    }
    acc
    }


    View Slide

74. def fold[T](a: Iterable[T])(z:T)(op: (T, T) => T) = {
    var it = a.iterator
    var acc = z
    while (it.hasNext) {
    acc = box(op(acc, it.next))
    }
    acc
    }


    View Slide

75. def fold[T](a: Iterable[T])(z:T)(op: (T, T) => T) = {
    var it = a.iterator
    var acc = z
    while (it.hasNext) {
    acc = box(op(acc, it.next))
    }
    acc
    }
    Generic methods cause boxing of primitives


    View Slide

76. def mean(xs: Array[Float]): Float = {
    val sum = xs.toPar.fold(0)(_ + _)
    sum / xs.length
    }


    View Slide

77. def mean(xs: Array[Float]): Float = {
    val sum = xs.toPar.fold(0)(_ + _)
    sum / xs.length
    }
    Generic methods hurt performance
    What can we do instead?


    View Slide

78. def mean(xs: Array[Float]): Float = {
    val sum = xs.toPar.fold(0)(_ + _)
    sum / xs.length
    }
    Generic methods hurt performance
    What can we do instead?
    Inline method body!


    View Slide

79. def mean(xs: Array[Float]): Float = {
    val sum = {
    var it = xs.iterator
    var acc = 0
    while (it.hasNext) {
    acc = acc + it.next
    }
    acc
    }
    sum / xs.length
    }


    View Slide

80. def mean(xs: Array[Float]): Float = {
    val sum = {
    var it = xs.iterator
    var acc = 0
    while (it.hasNext) {
    acc = acc + it.next
    }
    acc
    }
    sum / xs.length
    }
    Specific type
    No boxing!
    No memory allocation!


    View Slide

81. def mean(xs: Array[Float]): Float = {
    val sum = {
    var it = xs.iterator
    var acc = 0
    while (it.hasNext) {
    acc = acc + it.next
    }
    acc
    }
    sum / xs.length
    }
    Specific type
    No boxing!
    No memory allocation!
    2X speedup
    565 ms → 281 ms


    View Slide

82. def mean(xs: Array[Float]): Float = {
    val sum = {
    var it = xs.iterator
    var acc = 0
    while (it.hasNext) {
    acc = acc + it.next
    }
    acc
    }
    sum / xs.length
    }


    View Slide

83. def mean(xs: Array[Float]): Float = {
    val sum = {
    var it = xs.iterator
    var acc = 0
    while (it.hasNext) {
    acc = acc + it.next
    }
    acc
    }
    sum / xs.length
    }
    Iterators? For Array?
    We don’t need them!


    View Slide

84. def mean(xs: Array[Float]): Float = {
    val sum = {
    var i = 0
    val until = xs.size
    var acc = 0
    while (i < until) {
    acc = acc + a(i)
    i = i + 1
    }
    acc
    }
    sum / xs.length
    }
    Use index-based access!


    View Slide

85. def mean(xs: Array[Float]): Float = {
    val sum = {
    var i = 0
    val until = xs.size
    var acc = 0
    while (i < until) {
    acc = acc + a(i)
    i = i + 1
    }
    acc
    }
    sum / xs.length
    }
    19x speedup
    Use index-based access!
    281 ms → 15 ms


    View Slide

86. Are those optimizations parallel-collections specific?


    View Slide

87. Are those optimizations parallel-collections specific?
    No


    View Slide

88. Are those optimizations parallel-collections specific?
    No
    You can use them on sequential collections


    View Slide

89. def mean(xs: Array[Float]): Float = {
    val sum = xs.fold(0)(_ + _)
    sum / xs.length
    }


    View Slide

90. import scala.collections.optimizer._
    def mean(xs: Array[Float]): Float = optimize{
    val sum = xs.fold(0)(_ + _)
    sum / xs.length
    }


    View Slide

91. import scala.collections.optimizer._
    def mean(xs: Array[Float]): Float = optimize{
    val sum = xs.fold(0)(_ + _)
    sum / xs.length
    }
    You get 38 times speedup!


    View Slide

92. Future work


    View Slide

93. @specialized collections
    ● Maps
    ● Sets
    ● Lists
    ● Vectors
    Both faster &
    consuming less
    memory


    View Slide

94. @specialized collections
    ● Maps
    ● Sets
    ● Lists
    ● Vectors
    Both faster &
    consuming less
    memory
    Expect to get this for free inside
    optimize{} block


    View Slide

95. jdk8-style streams(parallel views)
    ● Fast
    ● Lightweight
    ● Expressive API
    ● Optimized
    Lazy data-parallel
    operations made
    easy


    View Slide

96. Future’s based asynchronous API
    val sum = future{ xs.sum }
    val normalized = sum.andThen(sum => sum/xs.size)
    Boilerplate code, ugly


    View Slide

97. Future’s based asynchronous API
    val sum = xs.toFuture.sum
    val scaled = xs.map(_ / sum)
    ● Simple to use
    ● Lightweight
    ● Expressive API
    ● Optimized
    Asynchronous dat
    parallel operations
    made easy


    View Slide

98. Current research: operation fusion
    val minMaleAge = people.filter(_.isMale)
    .map(_.age).min
    val minFemaleAge = people.filter(_.isFemale)
    .map(_.age).min


    View Slide

99. Current research: operation fusion
    val minMaleAge = people.filter(_.isMale)
    .map(_.age).min
    val minFemaleAge = people.filter(_.isFemale)
    .map(_.age).min
    ● Requires up to 3 times more memory than original collection
    ● Requires 6 traversals of collections


    View Slide

100. Current research: operation fusion
     val minMaleAge = people.filter(_.isMale)
     .map(_.age).min
     val minFemaleAge = people.filter(_.isFemale)
     .map(_.age).min
     ● Requires up to 3 times more memory than original collection
     ● Requires 6 traversals of collections
     We aim to reduce this to single traversal with no
     additional memory.
     Without you changing your code


     View Slide
