1. Evolution of HTTP Buzzvil 2019.02.20 Brice Bang
3. ????????
4. Why I chose HTTP
5. Evolution of HTTP HTTP/0.9 (1991) HTTP/1.0 (1996) HTTP/1.1 (1997) HTTP/2 (2015) HTTP/3 (2019)
6. Evolution of HTTP HTTP/0.9 (1991) HTTP/1.0 (1996) HTTP/1.1 (1997) HTTP/2 (2015) HTTP/3 (2019) Where are we?
8. Review – TCP/IP
9. Review – TCP/IP
10. Review – TCP/IP IP
11. Review – TCP/IP IP
12. Review – TCP/IP TCP IP
13. Review – TCP/IP TCP IP
14. Review – TCP/IP TCP IP
15. Review – TCP/IP TCP IP
16. Review – UDP/IP UDP IP
17. Review – UDP/IP UDP IP
18. Review – TLS 802.11 IP TCP HTTP
19. Review – TLS 802.11 IP TCP HTTPS
20. Review – TLS TLS 1.2
21. Review – TLS TLS 1.2 TLS 1.3
22. HTTP
23. Once Upon a Time
24. Once Upon a Time
25. Once Upon a Time
26. Once Upon a Time
27. Once Upon a Time
28. Once Upon a Time
29. Once Upon a Time TCP/IP
30. Once Upon a Time TCP/IP Server
31. Once Upon a Time TCP/IP Protocol Server Client
32. Once Upon a Time TCP/IP Protocol Server Client
33. Once Upon a Time TCP/IP Protocol Server Client URI URI: Uniform Resource Identifier
34. Once Upon a Time TCP/IP Protocol Server Client URI HTML URI: Uniform Resource Identifier HTML: HyperText Markup Language
35. Once Upon a Time TCP/IP Protocol Server Client URI HTML HTTP URI: Uniform Resource Identifier HTML: Hypertext Markup Language HTTP: Hypertext Transfer Protocol
36. Once Upon a Time TCP/IP Protocol Server Client URI HTML HTTP Sir Tim Berners-Lee the father of the World Wide Web URI: Uniform Resource Identifier HTML: Hypertext Markup Language HTTP: Hypertext Transfer Protocol
37. WorldWideWeb: The First Web Browser
38. WorldWideWeb: The First Web Browser https://worldwideweb.cern.ch/browser/
39. HTTP/0.9 (1991) • The initial version of HTTP • Use 80 port • No version number (later been called 0.9) • Only one method (GET) • No HTTP headers / No error code • Response only contains the HTML file
40. HTTP/0.9 (1991) • The initial version of HTTP • Use 80 port • No version number (later been called 0.9) • Only one method (GET) • No HTTP headers / No error code • Response only contains the HTML file
41. HTTP/0.9 (1991) • The initial version of HTTP • Use 80 port • No version number (later been called 0.9) • Only one method (GET) • No HTTP headers / No error code • Response only contains the HTML file
42. HTTP/1.0 (1996) • Version information is now sent • Status code, HTTP headers, new methods (POST, HEAD) have been introduced
43. HTTP/1.0 (1996) • Version information is now sent • Status code, HTTP headers, new methods (POST, HEAD) have been introduced
44. HTTP/1.0 (1996) • Version information is now sent • Status code, HTTP headers, new methods (POST, HEAD) have been introduced
45. The Problems of HTTP/1.0
46. The Problems of HTTP/1.0
47. The Problems of HTTP/1.0
48. The Problems of HTTP/1.0
51. HTTP/1.1 (1997) • The first standard • Still in common use • Performance optimizations • A persistent connection (keep-alive) • Chunked responses • compression • Cache control • Feature enhancement • Content negotiation (lang, encoding..) • Server collocation (Host header) • New methods • PUT, DELETE, TRACE, OPTIONS
52. HTTP/1.1 (1997) • The first standard • Still in common use • Performance optimizations • A persistent connection (keep-alive) • Chunked responses • compression • Cache control • Feature enhancement • Content negotiation (lang, encoding..) • Server collocation (Host header) • New methods • PUT, DELETE, TRACE, OPTIONS
53. Persistent Connection (keep-alive)
54. Persistent Connection (keep-alive)
55. Thanks to Keep-Alive header • Pipelining • Send successive request without waiting for the answer over persistent connection • Idempotent methods only (GET, HEAD, PUT, DELETE) • Multiple Connections • Open multiple connections to same host to speed up retrieval of large numbers of objects • Maximum 6 connection for one origin to avoid DoS
56. The Web Environment is Changed cf. Default MSS of Ethernet: 1500 bytes
57. HTTP/1.1 is Slow • Latency sensitive • Head-of-line blocking • Repetitive and redundant Http request headers • Security makes slower
58. The Internet Has Been Getting Faster
59. The Internet Has Been Getting Faster
60. The Internet Has Been Getting Faster
61. The Internet Has Been Getting Faster
62. The Key is “Latency” Bandwidth vs Latency impact on Page Load Time
63. Head-of-Line Blocking (HOL)
64. HTTP Head-of-Line Blocking (keep-alive)
65. HTTP Request Header
66. HTTP Request Header
67. HTTP Request Header
68. Security is too Slow • HTTPS (HTTP over SSL, HTTP over TLS, HTTP Secure) • Use 443 port TCP/IP HTTP Server Client
69. Security is too Slow • HTTPS (HTTP over SSL, HTTP over TLS, HTTP Secure) • Use 443 port TCP/IP TLS Server Client HTTP
70. Security is too Slow • TCP handshake + TLS handshake Exchange HTTP req/res
71. Security is too Slow • TCP handshake + TLS handshake Exchange HTTP req/res
73. Reduce the # of Request
74. Spriting
75. Spriting
76. Inlining - Data URI Scheme • Write the image resource in Base64 encoded string to reduce # of request
77. Minify and Merge CSS/Javascript • To reduce file size and # of requests
78. Minify and Merge CSS/Javascript • To reduce file size and # of requests
79. Domain Sharding • Web browser allows several parallel connections for one domain • Split resources over several domains
80. NOT A SOLUTION
81. Text Protocol’s Limitation • Ex) Detect message body length (From rfc7230)
82. Text Protocol’s Limitation • Ex) Detect message body length (From rfc7230)
83. Text Protocol’s Limitation • Ex) Detect message body length (From rfc7230)
84. Text Protocol’s Limitation • Ex) Detect message body length (From rfc7230)
85. Text Protocol’s Limitation • Ex) Detect message body length (From rfc7230)
86. Text Protocol’s Limitation • Ex) Detect message body length (From rfc7230)
87. Text Protocol’s Limitation • Ex) Detect message body length (From rfc7230)
88. Text Protocol’s Limitation • Ex) Detect message body length (From rfc7230)
89. Text Protocol’s Limitation • Ex) Detect message body length (From rfc7230)
93. Security is too Slow
94. Security is not Slow • http://www.httpvshttps.com/
95. Security is not Slow • http://www.httpvshttps.com/
96. Security is not Slow but Fast • http://www.httpvshttps.com/
97. Security is not Slow but Fast Thanks to HTTP/2 • http://www.httpvshttps.com/
98. HTTP/2
99. HTTP/2 (2015) • A protocol for low-latency transport of content over the World Wide Web • Changes • Textual protocols à binary protocols • Head-of-line blocking à multiplexed and prioritized streams • Concurrent multiple TCP connections à one TCP connection • Redundant HTTP Headers -> Header compression with HPACK • Security -> All browers support HTTP/2 only on TLS • Server Push
100. Based on the Experimental SPDY Protocol • SPDY: A deprecated network protocol developed at for transporting web content TCP/IP TLS HTTP/1.1 TCP/IP TLS SPDY HTTP HTTP/1.1 Stack SPDY Stack TCP/IP TLS HTTP/2 HTTP/2 Stack
101. Binary Framing Layer
102. Binary Framing Layer
103. Multiplexed and Prioritized Streams on single TCP con. • Frames can be interleaved • All stream(sequence of frames)s are sent over single TCP connection • Streams have dependencies and weights to calculate the priorities • DATA frames are subject to per-stream and connection flow control
104. One TCP Connection
105. One TCP Connection
106. HPACK Header Compression • Header compression
107. HTTP/2 and TLS • TLS is optional, but major implementations are force TLS • Mozilla Firefox and Google Chrome • Why? • To protect user’s privacy • To avoid the tyranny of the middleboxes • They are upgraded much slower than edges TCP/IP TLS HTTP/2 HTTP/2 Stack
108. Server Push
110. How to switch to HTTP/2?
111. Web Browsers are Ready
112. Our Server Already Supports HTTP/2 h2 h2
113. Our Server Already Supports HTTP/2 h2 h2
114. How about Our Clients? • Lockscreen: X • Feed: O • BARO: X S N I
115. How about Others?
116. OkHttp Supports HTTP/2 by Default
117. However
118. iPhone Changes the World
119. Network is Changed
120. HTTP/2 on Mobile Good Poor
121. Packet-Loss: WiFi > Wired Network 1.5% 2.0%
122. TCP is too Old • Introduced in 1974 (45 years old) • Designed to operate in wired network WaveLan (1986) Wi-Fi (1997) become popular 2010~
123. Handover: WiFi ⇄ LTE
124. Handover: From WiFi to LTE
125. TCP on Wireless Network
126. TCP Head-of-Line Blocking
129. HTTP/1.1 workarounds
130. HTTP/1.1 workarounds HTTP/2
131. HTTP/1.1 workarounds HTTP/2 HTTP/3?
132. HTTP/3
133. QUIC • An experimental transport layer network protocol introduced by in 2012 • TCP + TLS + HTTP/2 over UDP
134. QUIC • An experimental transport layer network protocol introduced by in 2012 • TCP + TLS + HTTP/2 over UDP • Flow Control • Error Control • Congestion Control • In-order delivery per stream
135. QUIC • An experimental transport layer network protocol introduced by in 2012 • TCP + TLS + HTTP/2 over UDP • Flow Control • Error Control • Congestion Control • In-order delivery per stream • To Prevent Ossification (경직화)
136. QUIC • An experimental transport layer network protocol introduced by in 2012 • TCP + TLS + HTTP/2 over UDP • Flow Control • Error Control • Congestion Control • In-order delivery per stream • HTTP • Binary Protocol • Multiplexed Streams • Prioritized Streams • One TCP Connection • Header Compression • HPACK à QPACK • Server Push • To Prevent Ossification (골화)
137. Why UDP? • Middleboxes allow TCP and UDP only • TCP has HOL • To move the transport layer from kernel mode to user mode • make development faster • make adoption and spread faster
138. Minimalized Handshake
139. Multiplexing
140. Handover: Connection Independent of IP Address Connection UUID
142. HTTP/3 (2019) HTTP/3
143. QUIC with
144. QUIC with
145. QUIC with
146. Can I use HTTP/3?
147. TLS Library Support
148. Web Browser Support
149. Server Support
150. QUICHE
151. Implementations • IETF QUIC • C • AppleQUIC, f5, lsquic, ngtcp2, ngx_quic, pandora, picoquic, quant, quicly, Winquic • C++ • ats, lsquic, mozquic, mvfst • ETC • Java: kwik, go: minq, quic-go, rust: quiche, quicr, quinn, TypeScript: QUICker • Google QUIC • goquic, libquic, lsquic, quic-go, stellite, caddyserver • https://github.com/quicwg/base-drafts/wiki/Implementations
152. HTTP/3 Challenges • 3-7% something of all QUIC attempts fail • Clients need fall back algorithms • CPU intensive (2x ~ 3x) • Lack of APIs of TLS library (OpenSSL) • ARQ limitation • Automatic Repeat Request à Forward error correction may help
153. Summary • HTTP/0.9 • the first version with one method GET in ASCII over TCP • HTTP/1.0 • Many extensions are adopted • One request per one connection • HTTP/1.1 • The first standard version • Persistent connection improved performance, but brought HTTP HOL • Many workarounds have been made over 18 years • HTTP/2 • Binary multiplexed over TCP resolves HTTP HOL ß SPDY • HTTP/3 • Binary over multiplexed QUIC resolve TCP HOL ß QUIC
154. Advertisement • #dev-news • To share news related to dev, IT, tech etc. without interrupting your works
155. Thank you
