Work Log - 11/30
Liang Bo Wang
November 30, 2012
Transcript
11 slides
-
Bioinformatics and Biostatistics Core, NTU Center of Genomic Medicine 1
Ve r i f i c a t i o n w o r k f l o w, P a r a l l e l c o m p u t i n g , Ve r i f i c a t i o n r e s u l t , A u t o m a t i o n Work Progress – 11/30 -
Bioinformatics and Biostatistics Core, NTU Center of Genomic Medicine 2
• Not collapsing for disk usage and BLAST function • Summarize results by myself • Quality control will be added in near future • NGS QC Toolkit (建樂學長) may be used • Automation & Parallelization NCBI SRA-Toolkit dump to fasta/q format Original datasets on GEO SRRxxx.sra, SRRyyy.sra, ... Fastq format with QC and sequencing details SRRxxx.fastq, SRRyyy.fastq, ... FastX Toolkit clip off 3' adapter Only clipped sequences left SRRxxx_clipped.fastq, SRRyyy_clipped.fastq, ... Quality Control discard low score reads Fasta Converter file format conversion Simpler file format: fasta SRRxxx_clipped.fasta, SRRyyy_clipped.fasta, ... BLAST+ make blast database Original datasets on GEO SRRxxx.sra, SRRyyy.sra, ... BLAST+ blastn query for every candidates on every dataset novel miRNA candidates candidate01.fa, candidate02.fa, ... Handmade Script summary all queries BLAST detail results for every query candidate01_xxx.csv, candidate02_xxx.csv, … candidate01_yyy.csv, candidate02_yyy.csv, … …, …, … Summarized read count for all candidates candidate01-10_xxx-zzz.csv Excel table output Script Automation -
Parallel Computing Bioinformatics and Biostatistics Core, NTU Center of Genomic
Medicine 3 CPU 1 CPU 2 Task A Task B CPU 3 Task C … … run run run run run run run run run run CPU 1 CPU 2 Task A 01.file Task A 02.file CPU 3 Task A 03.file … … run run run run run run run run run run -
Tasks with heavy I/O may not be benefited from parallel
computing Bioinformatics and Biostatistics Core, NTU Center of Genomic Medicine 4 CPU 2 Task A 02.file CPU 3 Task A 03.file … … run run run run run run run run run I/O system call run run run I/O I/O run I/O run I/O run I/O CPU 2 Task A 02.file CPU 3 Task A 03.file … … run run run run run run run run run I/O system call run run run I/O I/O run I/O run I/O run I/O CPU Bound Task I/O Bound Task -
Parallelization Result (Heavy CPU) Bioinformatics and Biostatistics Core, NTU Center
of Genomic Medicine 5 -
Parallelization Result (Heavy I/O) Bioinformatics and Biostatistics Core, NTU Center
of Genomic Medicine 6 -
Heavy I/O Bioinformatics and Biostatistics Core, NTU Center of Genomic
Medicine 7 57MB/s -
Parallel Computing + Automation • NGS computing takes extra long
time • use script to perform tasks • Python script is used here • Ex. 60 (total 1800) tasks are pooled for blasting • General input • task performed can be changed easily • code usability Bioinformatics and Biostatistics Core, NTU Center of Genomic Medicine 8 -
in silico verification • GSE33858 lung cancer small RNA-seq
• platform: Illumina Genome Analyzer IIx • tissue type: NT + T for same patient • 62 samples in total • about 1,500,000,000 reads(after clipped) per sample • originally 2,000,000,000 reads per sample • With new code being used, whole workflow can complete within 8 hours • about 4x faster ! • auto Bioinformatics and Biostatistics Core, NTU Center of Genomic Medicine 9 -
Bioinformatics and Biostatistics Core, NTU Center of Genomic Medicine 10
ID score normal tumor total total in previous verification original chr7_8791 32.8 104 49 153 5 69 chr11_13342 30.6 76 164 240 9 49 chr22_20736 17.5 240 152 392 4 32 chr13_14817 15.7 4 4 8 9 18 chr17_17828 14 2 0 2 10 26 chr20_19494 13.9 32 29 61 2 22 chr20_19450 12.6 40 17 57 1 20 chr18_18769 12.5 0 0 0 9 21 chr11_13709 12 1 0 1 0 15 chr2_2356 9.8 412 266 678 4 6 chr4_5692 9 95 75 170 2 11 chr11_12760 8.6 6 31 37 0 14 chr3_3910 7.5 0 0 0 131 19 chr1_692 6.8 0 4 4 1 9 chr10_12452 6.4 10 17 27 1 6 chr6_7548 6 58 206 264 2 24 chr1_944 6 1 2 3 1 3 chr6_8151 6 58 206 264 2 18 chr11_13239 5.8 150 152 302 0 1 chr7_8991 5.6 39 37 76 1 14 chr7_8849 5.4 17 25 42 4 26 chr22_20809 5.4 2115 1846 3961 2392 13 chr2_3487 5.4 1 1 2 170 19 chr7_8673 5.3 0 3 3 0 15 chr14_15459 5.3 180 206 386 16 11 chr20_19463 5.2 10 21 31 0 11 chr6_8250 5.2 0 5 5 211 199 chr19_19992 5.1 7 3519 3526 4531 15 chr1_689 5.1 1 0 1 1 17 chr17_17785 5 0 22 22 2326 483 lung breast breast • expression should be normalized in RKPM • low expression • threshold for blast was set too high • E Value < 0.001 • previous verification will be performed again to follow same criteria • find novel candidates from other datasets? -
To do • Automation for miRDeep • continue verification •
study Galaxy extension • Version control – GIT Bioinformatics and Biostatistics Core, NTU Center of Genomic Medicine 11
