Writing NES games! with assembly!!

Talk given at !!Con 2017.

I’d like to take you on a stroll down memory lane and dig into the internals of the Nintendo Entertainment System (NES) to figure out how it works. While we’re there, we’ll see how to build a game for the NES using 6502 assembly with the help of a few modern tools. We’ll gain a new respect for ’80s developers and an appreciation for the high-level languages we have today!

Transcript

1. View Slide

2. View Slide

3. View Slide

4. View Slide

5. View Slide

6. View Slide

7. PRG ROM
   CHR ROM


   View Slide

8. chr rom


   View Slide

9. View Slide

10. View Slide

11. View Slide

12. View Slide

13. PRG ROM
    CHR ROM
    battery
    RAM


    View Slide

14. Milestone 1


    View Slide

15. NO WAY! OMG
    omg!! it works!!!
    is it normal that we are this excited about displaying a ball?


    View Slide

16. NO WAY! OMG
    omg!! it works!!!
    is it normal that we are this excited about displaying a ball?


    View Slide

17. NO WAY! OMG
    omg!! it works!!!
    is it normal that we are this excited about displaying a ball?


    View Slide

18. NO WAY! OMG
    omg!! it works!!!
    is it normal that we are this excited about displaying a ball?


    View Slide

19. NO WAY! OMG
    omg!! it works!!!
    is it normal that we are this excited about displaying a ball?


    View Slide

20. View Slide

21. 00008000: 20 8e 10 40 2c 02 20 2c 02 20 10 fb 8a 95 00 9d
    00008010: 00 01 9d 00 03 9d 00 04 9d 00 05 9d 00 06 9d 00
    00008020: 07 e8 d0 e9 a9 ff 9d 00 02 e8 d0 fa 2c 02 20 10
    00008030: fb 4c b6 80 a9 01 85 02 a9 01 85 03 a9 70 8d 03
    00008040: 02 a9 70 8d 00 02 a9 00 8d 02 02 a9 01 8d 01 02
    00008050: 60 e6 00 e6 01 a5 00 8d 03 02 a5 01 8d 00 02 60
    00008060: a9 01 8d 16 40 85 05 4a 8d 16 40 ad 16 40 29 03
    00008070: c9 01 26 04 ad 17 40 29 03 c9 01 26 05 90 ec 60
    00008080: a5 05 85 07 a5 04 85 06 20 70 80 a5 05 85 09 a5
    00008090: 04 85 08 20 70 80 a2 01 b5 04 d5 08 f0 04 b5 06
    000080a0: 95 04 ca 10 f3 60 a9 3f 8d 06 20 a9 00 8d 06 20
    000080b0: a9 0f 8d 07 20 a9 3f 8d 06 20 a9 11 8d 06 20 a9
    000080c0: 30 8d 07 20 a9 0f 8d 07 20 8d 07 20 20 44 80 a9
    000080d0: 18 8d 01 20 a9 80 8d 00 20 a9 01 85 0e 20 90 80
    000080e0: a5 04 f0 03 20 00 81 20 61 80 20 25 81 4c e9 80
    000080f0: a5 04 29 0c f0 0c a5 04 29 08 f0 03 e6 03 60 c6
    00008100: 03 60 a5 04 29 03 f0 0b a5 04 29 02 f0 03 c6 02
    00008110: 60 e6 02 60 60 e6 11 a5 11 d0 fc 60 48 8a 48 98
    00008120: 48 a5 0e f0 0a a9 00 8d 03 20 a9 02 8d 14 40 a5
    00008130: 0f f0 08 2c 02 20 20 24 81 c6 0f a5 10 f0 17 a5
    00008140: 0b 8d 01 20 a5 0a 8d 00 20 2c 02 20 a5 0c 8d 05
    00008150: 20 a5 0d 8d 05 20 a9 00 85 11 68 a8 68 aa 68 40


    View Slide

22. cc65 toolchain
    asm
    asm
    asm ca65 ld65
    asm
    asm
    obj ines


    View Slide

23. 69
    70 main:
    71 ; Set universal background color ($3F00) to black ($0F)
    72 ; Set PPU address to $3F00
    73 lda #$3F
    74 sta PPUADDR
    75 lda #$00
    76 sta PPUADDR
    77 ; Write $0F to that PPU address
    78 lda #$0F
    79 sta PPUDATA
    80
    81 ; Set sprite palette 0 ($3F11-$3F13) to white ($30), black ($0F), black ($0F)
    82 ; Set PPU address to $3F11
    83 lda #$3F
    84 sta PPUADDR
    85 lda #$11
    86 sta PPUADDR
    87 ; Write $30, $0F, $0F to PPU
    88 lda #$30
    89 sta PPUDATA ; PPUADDR will increase by 1 each time we write to it
    90 lda #$0F
    91 sta PPUDATA
    92 sta PPUDATA
    93
    94 jsr ballSetup
    95
    96 ; Enable sprite and background rendering
    97 lda #%00011000
    98 sta PPUMASK
    99
    100 ; Enable NMI
    101 lda #%10000000
    102 sta PPUCTRL
    103


    View Slide

24. 6502 assembly
    LDA STA
    memory
    ADC SBC
    INC DEC
    arithmetics
    AND ORA
    CMP
    compare
    BCC BCS BEQ
    BMI BNE BPL
    branch


    View Slide

25. 6502 assembly
    LDA STA
    memory
    ADC SBC
    INC DEC
    arithmetics
    AND ORA
    CMP
    compare
    BCC BCS BEQ
    BMI BNE BPL
    branch


    View Slide

26. 6502 assembly
    LDA STA
    memory
    ADC SBC
    INC DEC
    arithmetics
    AND ORA
    CMP
    compare
    BCC BCS BEQ
    BMI BNE BPL
    branch


    View Slide

27. 6502 assembly
    LDA STA
    memory
    ADC SBC
    INC DEC
    arithmetics
    AND ORA
    CMP
    compare
    BCC BCS BEQ
    BMI BNE BPL
    branch


    View Slide

28. 6502 assembly
    LDA STA
    memory
    ADC SBC
    INC DEC
    arithmetics
    AND ORA
    CMP
    compare
    BCC BCS BEQ
    BMI BNE BPL
    branch


    View Slide

29. $0600: LDA $05
    $0602: CMP #$08
    $0604: BEQ $060b
    $0606: INC $05
    $0608: JMP $0600
    $060b: RTS
    PC


    View Slide

30. Milestone 2
    !


    View Slide

31. Milestone 2
    !


    View Slide

32. picture processing unit


    View Slide

33. 256px
    240px


    View Slide

34. View Slide

35. 00 01 02 03 04 05 06 07 08 09 0A 0B 0C 0D 0E 0F
    10 11 12 13 14 15 16 17 18 19 1A 1B 1C 1D 1E 1F
    20 21 22 23 24 25 26 27 28 29 2A 2B 2C 2D 2E 2F
    30 31 32 33 34 35 36 37 38 39 3A 3B 3C 3D 3E 3F
    nes palette


    View Slide

36. View Slide

37. View Slide

38. View Slide

39. y tile attrs x
    23 01 00 01
    64 x


    View Slide

40. PPU registers
    $2000-$2007


    View Slide

41. !
    Milestone 3
    "
    "
    "


    View Slide

42. OMG! Wait... Is that real?
    yeah!!!
    NO WAY!!
    yeah!!!


    View Slide

43. OMG! Wait... Is that real?
    yeah!!!
    NO WAY!!
    yeah!!!


    View Slide

44. OMG! Wait... Is that real?
    yeah!!!
    NO WAY!!
    yeah!!!


    View Slide

45. OMG! Wait... Is that real?
    yeah!!!
    NO WAY!!
    yeah!!!


    View Slide

46. OMG! Wait... Is that real?
    yeah!!!
    NO WAY!!
    yeah!!!


    View Slide

47. OMG! Wait... Is that real?
    yeah!!!
    NO WAY!!
    yeah!!!


    View Slide

48. video frame
    vertical blank


    View Slide

49. video frame
    vertical blank


    View Slide

50. nmi interrupt


    View Slide

51. loop:
    INC $05
    JMP loop
    nmi:
    ; Do stuff
    RTI
    PC


    View Slide

52. loop:
    INC $05
    JMP loop
    nmi:
    ; Do stuff
    RTI
    PC


    View Slide

53. loop:
    INC $05
    JMP loop
    nmi:
    ; Do stuff
    RTI
    PC


    View Slide

54. loop:
    INC $05
    JMP loop
    nmi:
    ; Do stuff
    RTI
    PC


    View Slide

55. loop:
    INC $05
    JMP loop
    nmi:
    ; Do stuff
    RTI
    PC


    View Slide

56. loop:
    INC $05
    JMP loop
    nmi:
    ; Do stuff
    RTI
    PC


    View Slide

57. loop:
    INC $05
    JMP loop
    nmi:
    ; Do stuff
    RTI
    PC


    View Slide

58. loop:
    INC $05
    JMP loop
    nmi:
    ; Do stuff
    RTI
    PC


    View Slide

59. loop:
    INC $05
    JMP loop
    nmi:
    ; Do stuff
    RTI
    PC


    View Slide

60. Milestone 4
    #
    #
    "


    View Slide

61. controllers
    $4016-$4017


    View Slide

62. View Slide

63. 0 0 0 0 0 0 0 0
    a B se st


    View Slide

64. $
    1 0 0 0 0 0 0 0
    a B se st


    View Slide

65. $
    $
    1 0 0 0 0 0 0 1
    a B se st


    View Slide

66. LDA controller1
    AND #%10000000
    BEQ notPressed

    ; A is pressed
    notPressed:
    RTS


    View Slide

67. LDA controller1
    AND #%10000000
    BEQ notPressed

    ; A is pressed
    notPressed:
    RTS
    1 0 0 0 0 0 0 0
    a B se st


    View Slide

68. Milestone 5
    # #
    "
    %
    &
    "


    View Slide

69. wine + fceux


    View Slide

70. View Slide

71. lua scripting


    View Slide

72. emu.frameadvance()
    memory.readbyte(0x0000)
    memory.writebyte(0x0001, 0x30)


    View Slide

73. emu.registerafter(function()
    ballX = memory.readbyte(0x0000)
    ballY = memory.readbyte(0x0001)
    gui.text(
    10,
    30,
    string.format('Ball: %02x,%02x', ballX, ballY)
    )
    end)


    View Slide

74. View Slide

75. '


    View Slide

76. '
    (
    lua


    View Slide

77. !
    )


    View Slide

78. function TestBall:test_ball_moves_down()
    memory.writebyte(ballYAddress, 0x30)
    memory.writebyte(ballYDirection, 0x01)
    emu.frameadvance()
    ballY = memory.readbyte(ballYAddress)
    luaunit.assertEquals(ballY, 0x31)
    end


    View Slide

79. View Slide

80. View Slide

81. View Slide

82. Read the source code
    when in doubt


    View Slide

83. View Slide

84. NExt steps


    View Slide

85. @cjoudrey
