Dispelling the Dark Magic: Inside a Ruby Debugger

Presentation by Daniel Azuma at RubyConf 2017. Covers how to implement a basic debugger for Ruby programs, and discusses some techniques behind the Stackdriver Debugger for Ruby. See also the live coding artifact at https://github.com/dazuma/google-snippets/blob/master/mini-debug

Transcript

1. Dispelling the dark magic:
   inside a Ruby debugger
   Daniel Azuma
   November 16, 2017


   View Slide

2. photo by Daniel Azuma


   View Slide

3. https://eclipse2017.nasa.gov/eclipse-who-what-where-when-and-how


   View Slide

4. https://tenderlovemaking.com/2016/02/05/i-am-a-puts-debuggerer.html


   View Slide

5. Live coding!? OMG!!



   View Slide

6. Live coding!? OMG!!



   View Slide

7. Daniel Azuma
   http:/
   /daniel-azuma.com/


   View Slide

8. View Slide

9. Lawyercat says:
   Code samples are:
   Copyright 2017 Google Inc.
   Licensed under the Apache License, Version 2.0 (the "License"); you may not
   use this code except in compliance with the License. You may obtain a copy of
   the License at:
   https://www.apache.org/licenses/LICENSE-2.0
   Unless required by applicable law or agreed to in writing, software distributed
   under the License is distributed on an "AS IS" BASIS, WITHOUT WARRANTIES
   OR CONDITIONS OF ANY KIND, either express or implied. See the License for
   the specific language governing permissions and limitations under the License.


   View Slide

10. Breakpoints by file/line
    Command shell
    Step in/out/over
    Debugger features


    View Slide

11. ( Live coding session )


    View Slide

12. TracePoint


    View Slide

13. TracePoint.trace :call do |tp|
    puts "Called method #{tp.method_id}"
    end


    View Slide

14. line
    class
    end
    call
    return
    c_call
    c_return
    raise
    b_call
    b_return
    thread_begin
    thread_end
    fiber_switch
    TracePoint event types


    View Slide

15. line
    class
    end
    call
    return
    c_call
    c_return
    raise
    b_call
    b_return
    thread_begin
    thread_end
    fiber_switch
    TracePoint event types


    View Slide

16. ( Live coding session )


    View Slide

17. Inception (2010) © Warner Bros.
    https://commons.wikimedia.org/wiki/File:Solar_eclipse_1878Jul29-Corona_Pikes_peak_Langley.png


    View Slide

18. Stackdriver
    Debugger


    View Slide

19. https://commons.wikimedia.org/wiki/File:Lunar_eclipse_al-Biruni.jpg
    Threads


    View Slide

20. TracePoint.trace :call do |tp|
    puts "Called method #{tp.method_id}"
    end


    View Slide

21. void rb_thread_add_event_hook(VALUE thval,
    rb_event_hook_func_t func,
    rb_event_flag_t events,
    VALUE data);
    int rb_thread_remove_event_hook(VALUE thval,
    rb_event_hook_func_t func);


    View Slide

22. Ruby interface to
    thread-scoped
    TracePoint call?


    View Slide

23. https://commons.wikimedia.org/wiki/File:Astronomy;_a_view_of_London_in_1748,_with_diagrams_of_an_ecl_Wellcome_V0024734.jpg
    Speed


    View Slide

24. file_events = [:call, :b_call, :return,
    :b_return, :fiber_switch]
    TracePoint.trace *file_events do |tp|
    if @breakpoint_files.include? tp.path
    @line_trace.enable
    else
    @line_trace.disable
    end
    end


    View Slide

25. View Slide

26. Native
    breakpoint API?


    View Slide

27. https://commons.wikimedia.org/wiki/File:Macrobius,_lunar_and_solar_eclipse.jpg
    Side effects


    View Slide

28. Object state changes
    External side effects
    Side effects


    View Slide

29. BYTE_CODE_BLACKLIST = %w(
    setinstancevariable
    setclassvariable
    setconstant
    setglobal
    defineclass
    opt_ltlt
    opt_aset
    opt_aset_with
    ).freeze


    View Slide

30. C_METHOD_WHITELIST = %w(
    Array#+
    Array#-
    Array#==
    Array#any?
    Array#assoc
    Array#at
    Array#bsearch
    # etc...


    View Slide

31. View Slide

32. Immutability?


    View Slide

33. Immutability?
    Code jails?


    View Slide

34. Immutability?
    Code jails?
    Guilds??


    View Slide

35. View Slide

36. Debuggers (the basics)
    are straightforward!


    View Slide

37. Ruby has partial
    support for debuggers


    View Slide

38. Try out a debugger!
    Byebug: interactive debugger shell
    https://github.com/deivid-rodriguez/byebug
    Stackdriver debugger: for live web applications
    https://cloud.google.com/debugger
    https://github.com/GoogleCloudPlatform/google-cloud-ruby/tree/
    master/google-cloud-debugger


    View Slide

39. It's just Ruby


    View Slide

40. Thanks for viewing!
    Daniel Azuma
    dazuma@gmail.com
    @danielazuma


    View Slide
