In-Memory Data Grids Essentials. Oracle Coherence

IMDG talk that has been performed at GridDynamics meetup http://www.meetup.com/Grid-Dynamics-Meetup/events/151407992/

Transcript

1. Scalable eCommerce Platform Solutions Scalable eCommerce Platform Solutions In-Memory Data Grids Essentials. Oracle Coherence Max Myslyvtsev
2. Scalable eCommerce Platform Solutions About me Max Myslyvtsev Master Degree in Computer Science Software Engineer at Grid Dynamics mmyslyvtsev@griddynamics.com
3. Scalable eCommerce Platform Solutions Scalable eCommerce Platform Solutions In-Memory Data Grids Essentials. Oracle Coherence Max Myslyvtsev
4. Scalable eCommerce Platform Solutions Different Solutions Coherence
5. Scalable eCommerce Platform Solutions Preconditions of Using IMDG • Big amounts of data (10-100 GB) • Low latency • High availability • Distributed calculations
6. Scalable eCommerce Platform Solutions Showcase Environment • Data StackOverflow.com dump (Jun 2013) 2.1M Users 14.6M Posts • Cluster 5 nodes x 7 GB = 35 GB total • Preload time 20 minutes
7. Scalable eCommerce Platform Solutions IMDG Topology
8. Scalable eCommerce Platform Solutions IMDG Topology
9. Scalable eCommerce Platform Solutions IMDG Topology
10. Scalable eCommerce Platform Solutions Architecture Layers
11. Scalable eCommerce Platform Solutions Transport Architecture Layers Transport Transport
12. Scalable eCommerce Platform Solutions Transport Architecture Layers Transport Transport Shared Data
13. Scalable eCommerce Platform Solutions Transport Local Data Architecture Layers Transport Local Data Transport Local Data Shared Data
14. Scalable eCommerce Platform Solutions CAP Theorem C A P
15. Scalable eCommerce Platform Solutions CAP Theorem C A P Coherence
16. Scalable eCommerce Platform Solutions CAP Theorem C A P Coherence
17. Scalable eCommerce Platform Solutions Scalable eCommerce Platform Solutions Transport Layer Discovery and communication
18. Scalable eCommerce Platform Solutions Discovery • Multicast • Well-known address
19. Scalable eCommerce Platform Solutions Discovery • Multicast • Well-known address New
20. Scalable eCommerce Platform Solutions Discovery • Multicast • Well-known address WKA WKA
21. Scalable eCommerce Platform Solutions Discovery • Multicast • Well-known address WKA WKA New
22. Scalable eCommerce Platform Solutions Scalable eCommerce Platform Solutions Showcase
23. Scalable eCommerce Platform Solutions Communication • Custom protocols over TCP or UDP • Senior node • Heartbeats – Cluster heartbeats – Node heartbeats Senior
24. Scalable eCommerce Platform Solutions Communication • Custom protocols over TCP or UDP • Senior node • Heartbeats – Cluster heartbeats – Node heartbeats Senior
25. Scalable eCommerce Platform Solutions Communication • Custom protocols over TCP or UDP • Senior node • Heartbeats – Cluster heartbeats – Node heartbeats Senior
26. Scalable eCommerce Platform Solutions Node Departure • Graceful shutdown • TCP Ring • Timeout
27. Scalable eCommerce Platform Solutions Node Departure • Graceful shutdown • TCP Ring • Timeouts
28. Scalable eCommerce Platform Solutions Node Departure • Graceful shutdown • TCP Ring • Timeouts
29. Scalable eCommerce Platform Solutions Node Departure • Graceful shutdown • TCP Ring • Timeouts
30. Scalable eCommerce Platform Solutions Node Departure • Graceful shutdown • TCP Ring • Timeouts
31. Scalable eCommerce Platform Solutions Node Departure • Graceful shutdown • TCP Ring • Timeout
32. Scalable eCommerce Platform Solutions Node Departure • Graceful shutdown • TCP Ring • Timeout
33. Scalable eCommerce Platform Solutions Node Departure • Graceful shutdown • TCP Ring • Timeout
34. Scalable eCommerce Platform Solutions Scalable eCommerce Platform Solutions Showcase
35. Scalable eCommerce Platform Solutions Scalable eCommerce Platform Solutions Shared Data Layer Cluster-wide data
36. Scalable eCommerce Platform Solutions Distributed Cache Cluster Client Node Cache Interface Storage Node Data Storage Cache Interface
37. Scalable eCommerce Platform Solutions Cache Topology • Replicated Storage 1 A D B E C F Storage 2 A D B E C F Storage 3 A D B E C F Storage 1 A D B E Storage 2 C A D F Storage 3 E B F C • Partitioned
38. Scalable eCommerce Platform Solutions Repartitioning Storage 1 A D B E Storage 3 E B F C Storage 2 C A D F
39. Scalable eCommerce Platform Solutions Storage 3 Repartitioning Storage 1 A D B E E B F C Storage 2 C A D F
40. Scalable eCommerce Platform Solutions Storage 3 Repartitioning Storage 1 A D B E B F C E Storage 2 C A D F
41. Scalable eCommerce Platform Solutions Storage 3 Repartitioning Storage 1 A D B E B F C E Storage 2 C A D F F C E B
42. Scalable eCommerce Platform Solutions Storage 3 Repartitioning Storage 1 A D B E B F C E Storage 2 C A D F F C E B
43. Scalable eCommerce Platform Solutions Scalable eCommerce Platform Solutions Showcase
44. Scalable eCommerce Platform Solutions Cache Operations • Get/Put/Remove • Query • Event handling • Invocation • MapReduce • Indexes
45. Scalable eCommerce Platform Solutions Key hashing Cache Operations: Put Storage 1 Storage 2 Client Primary A A B C D E F • Client knows responsible storage – Key hash is used to find it • Automatic backups Backup A Backup F Primary F
46. Scalable eCommerce Platform Solutions Storage 2 Storage 1 Cache Operations: Query • Broadcast request – Unless Query is Key-Associated • All entries are evaluated – Unless Indexes are used key: field1: field2: D 70 80 key: field1: field2: C 50 60 key: field1: field2: B 30 40 key: field1: field2: A 10 20
47. Scalable eCommerce Platform Solutions Storage 2 Storage 1 Cache Operations: Query • Broadcast request – Unless Query is Key-Associated • All entries are evaluated – Unless Indexes are used field1=10 or field2>70 key: field1: field2: C 50 60 key: field1: field2: B 30 40 key: field1: field2: D 70 80 key: field1: field2: A 10 20
48. Scalable eCommerce Platform Solutions Storage 2 Storage 1 Cache Operations: Query • Broadcast request – Unless Query is Key-Associated • All entries are evaluated – Unless Indexes are used field1=10 and key=A key: field1: field2: D 70 80 key: field1: field2: C 50 60 key: field1: field2: B 30 40 key: field1: field2: A 10 20
49. Scalable eCommerce Platform Solutions Scalable eCommerce Platform Solutions Showcase
50. Scalable eCommerce Platform Solutions Cache Operations: Event handling • Subscription – Configuration-time – Runtime • Attachment – Key – Query • Flexible event data – Key, Value, Fields – Old, New Storage Client 1 key: field1: field2: A 30 40 Put Client 2 key: field1: field2: A 10 20
51. Scalable eCommerce Platform Solutions Cache Operations: Event handling • Subscription – Configuration-time – Runtime • Attachment – Key – Query • Flexible event data – Key, Value, Fields – Old, New Storage Client 1 Notify key: oldField1: newField1: A 10 30 Client 2 key: field1: field2: A 30 40
52. Scalable eCommerce Platform Solutions Cache Operations: Invocation • Task is serialized and distributed – May hold any data • Variable execution scope – Specific nodes – All nodes – Nodes bound to data Node 1 Node 2 Client Task
53. Scalable eCommerce Platform Solutions Cache Operations: Invocation • Task is serialized and distributed – May hold any data • Variable execution scope – Specific nodes – All nodes – Nodes bound to data Node 1 Node 2 Task Task Client Task
54. Scalable eCommerce Platform Solutions Cache Operations: Invocation • Task is serialized and distributed – May hold any data • Variable execution scope – Specific nodes – All nodes – Nodes bound to data Node 1 Node 2 Task Task Client Task
55. Scalable eCommerce Platform Solutions • Data-bound mapping – By keys – By Query • Parallel execution Storage 2 Storage 1 key: field1: field2: B 30 40 key: field1: field2: C 50 60 key: field1: field2: D 70 80 Cache Operations: MapReduce sum(field2) where field1>20 key: field1: field2: A 10 20
56. Scalable eCommerce Platform Solutions • Data-bound mapping – By keys – By Query • Parallel execution Storage 2 Storage 1 key: field1: field2: A 10 20 key: field1: field2: B 30 40 key: field1: field2: C 50 60 key: field1: field2: D 70 80 Cache Operations: MapReduce sum(field2) where field1>20
57. Scalable eCommerce Platform Solutions • Data-bound mapping – By keys – By Query • Parallel execution Storage 2 Storage 1 key: field1: field2: A 10 20 key: field1: field2: B 30 40 key: field1: field2: C 50 60 key: field1: field2: D 70 80 Cache Operations: MapReduce sum(field2) where field1>20 40 60 80
58. Scalable eCommerce Platform Solutions • Data-bound mapping – By keys – By Query • Parallel execution Storage 2 Storage 1 key: field1: field2: A 10 20 key: field1: field2: B 30 40 key: field1: field2: C 50 60 key: field1: field2: D 70 80 Cache Operations: MapReduce sum(field2) where field1>20 40 140
59. Scalable eCommerce Platform Solutions • Data-bound mapping – By keys – By Query • Parallel execution Storage 2 Storage 1 key: field1: field2: A 10 20 key: field1: field2: B 30 40 key: field1: field2: C 50 60 key: field1: field2: D 70 80 Cache Operations: MapReduce sum(field2) where field1>20 180
60. Scalable eCommerce Platform Solutions Scalable eCommerce Platform Solutions Showcase
61. Scalable eCommerce Platform Solutions Cache operations: Indexes • Forward and Reverse maps • Runtime addition and removal • Local to Storage nodes • Used for all applicable operations • Efficient for high-cardinality data Value Key Value Key Key Value Key Value Reverse map Forward map
62. Scalable eCommerce Platform Solutions Scalable eCommerce Platform Solutions Showcase
63. Scalable eCommerce Platform Solutions Persistence Integration • Read-through • Write-through Storage Client Durable Storage Data Grid Client Durable Storage Data Grid Storage
64. Scalable eCommerce Platform Solutions • Refresh-ahead • Write-behind Asynchronous Persistence Integration Storage Queue Client Durable Storage Data Grid Storage Queue Client Durable Storage Data Grid
65. Scalable eCommerce Platform Solutions Scalable eCommerce Platform Solutions Local Data Layer Node-specific data
66. Scalable eCommerce Platform Solutions Storage Storage Node Near Caching • Local access by primary key • Lazy population • Invalidation – On entry change – By timeout Near Cache Distributed Cache A A B
67. Scalable eCommerce Platform Solutions Scalable eCommerce Platform Solutions Showcase
68. Scalable eCommerce Platform Solutions Continuous Caching • Local access by any Query • Eager population • Near real-time data Storage Storage Node Continuous Cache Distributed Cache A B A B
69. Scalable eCommerce Platform Solutions Scalable eCommerce Platform Solutions Showcase
70. Scalable eCommerce Platform Solutions Showcase Environment: Memory Usage Cache Scope Number Size in memory Storage Indexes Total* Users per Node 420K 0.1 GB 35 MB 0.25 GB Users across Cluster 2.1M 0.5 GB 175 MB 1.25 GB Posts per Node 2.92M 1.85 GB 0.55 GB 4.4 GB Posts across Cluster 14.6M 9.25 GB 2.75 GB 22 GB * – this includes primary storage, backup storage, indexes and operational costs
71. Scalable eCommerce Platform Solutions Showcase Environment: Memory Optimization Mode Storage across Cluster Nodes Heap used No compression 24.6 GB 9 6.4/7 GB GZIP 9.75 GB 5 4.8/7 GB
72. Scalable eCommerce Platform Solutions Pros and Cons Pros: • Robust caching and processing solution • Horizontal scalability Cons: • Data should fit into memory • No durability guarantees • GC influences stability
73. Scalable eCommerce Platform Solutions Scalable eCommerce Platform Solutions Thank you! Questions & Answers
74. Scalable eCommerce Platform Solutions References • Workshop – https://github.com/mmyslyvtsev/imdg-workshop • Coherence Knowledge Base – http://coherence.oracle.com • Developers Guide – http://docs.oracle.com/cd/E18686_01/coh.37/e18677/toc.htm • Book – http://www.amazon.com/Oracle-Coherence-3-5-Aleksandar- Seovic/dp/1847196128
