Distributed Scheduling with Apache Mesos in the Cloud

Transcript

1. Distributed Scheduling with Apache Mesos on the Cloud UberConf 2015, Denver Diptanu Gon Choudhury @diptanu
3. This Talk • Challenges of traditional Data Centre environments • Taming the complexities of running services at Scale • Cloud Native Cluster Management with Titan
4. Evolution of Data Centers Mid 90’s Early 2000
5. The Modern Data Centre VM VM VM VM VM VM VM VM VM VM VM VM SDN Network Storage
6. Data Centre of 2015 C C C C C C C C C C C C C C C C C C C C C C C C SDN Network Storage Cloud Storage Cloud Persistence
7. Internet Scale Complexities London Virginia Tokyo Distributed Across Geographies to lower latencies Highly Available within a region by distribution across buildings
8. Evolution of Applications Application Server Database Software Load Balancers API Servers Mid Tier Services Caches Caches Distributed K/V Stores
9. The Multi Core World Scale by running on more cores Scale by adding more servers Scale by running on commodity hardware
10. The Modern Internet Scale Application Is a Data Center Application
11. Data Centre Applications are essentially Distributed Systems
13. Operational Aspects of Distributed Systems • Provisioning Compute Resources • Configuration of services • Distribution of services • Supervision and Fault Tolerance • Service Discovery
14. Provisioning Resources Usually Ops folks assign servers for specific teams or applications VM1 VM2 VM3 VM4 VM5 VM6 Service Database Batch Process Statically partitions the data centre
15. Challenges of manual provisioning Node Failures - Restore services from failed nodes on specific servers Distribution of services across fault domains are harder at scale
16. Different Fault Domains • Node • Memory, Disk, CPU, Network card, etc • Rack • PDU • Switch • Data Centre • Power • Cooling
17. Maintenance • Upgrading software is harder • Choosing which machines to upgrade is more difficult VM1 VM2 VM3 VM4 VM5 VM6 Service Database Batch Process
18. Poor Utilization 90 2 5 95 API Services 2 65 55 5 Batch Processes
19. Ideal Utilization 0 25 50 75 100
20. Challenges of Manual Scheduling • Homogenous distribution of applications on a single node decreases utilization. • Static partitioning doesn’t allow sharing a group of machine’s resources across multiple applications.
21. Enter the Era of Cluster Managers • Mesos • Borg • Kubernetes • CoreOS Fleet
22. Cluster Managers C C C C C C C C C C C C C C C C C C C C C C C C SDN Network Storage Cluster Manager API Servers Batch Apps DBs
23. Mesos
24. Mesos Moves the focus from Servers to Compute Resources
25. Mesos • Two level scheduler • Provides discovery and brokerage of compute resources • Semantics for launching processes • Event driven API for monitoring life cycle of applications • Resource Isolation on a single node
26. Domain Specific Frameworks • Scheduling decisions are left to users • Allows plugging in multiple frameworks • Allows users to define their own states for processes • Pending -> Running -> Dead • Sends messages when state of a process changes • Task Dispatched -> Task Staging-> Task Running -> Task Finished
27. Node Node Node Node Node 10s of 1000s of Compute Nodes Mesos Scheduler 1 Scheduler 2 Mesos - Indirections
28. Mesos - Abstractions IAAS - Provisions Machine Mesos - Deploy and supervise processes
29. Mesos - Abstractions EC2 Mesos - Deploy and supervise processes
30. Mesos - Abstractions Mesos - Deploy and supervise processes Titan Aurora Marathon
31. Mesos - Custom Executors Linux Kernel Mesos Slave Mesos Executor Process Compute Node
32. Mesos - SDK for building Data Centre OS • SDK in Java, Python, Go • Provides interfaces for exchanging messages between schedulers and executors • Provides log replication capabilities
33. Data Centre OS Services • A highly available and consistent control plane for managing state of the cluster • An API for users and other services to submit job specifications • Custom Executors to setup processes and communicate life cycle events of processes • Containerizer for providing process isolation
34. Cloud Native Scheduling • AutoScaling • Dynamic Reservations • Automatice Node Replacements • Fail-overs across multiple Regions
35. Titan
36. Titan • A distributed compute service native to public clouds • Provides AutoScaling to clusters of Containers • Supervises containers and provides failover mechanisms to applications running in containers • Provides logging, monitoring, volume management capabilities
37. Titan
38. A Compute Node of Titan
39. Scheduling Library for Mesos
40. Dynamic Reservations • Titan allows reserving resources for specific applications • Enforces the reservations under resource contentions • Reservations are made on a priority level • P1 (Guaranteed Reservations) <-> P3 (Best Effort)
41. AutoScaling • Two Levels of AutoScaling • Scaling of underlying compute resources • Application Scaling based on business and performance metrics
42. jobs.netflix.com The Data Centre As a Computer http://www.cs.berkeley.edu/~rxin/db-papers/WarehouseScaleComputing.pdf Resource Scheduling using Fenzo http://www.slideshare.net/spodila/aws-reinvent-2014-talk-scheduling-using-apache-mesos-in-the-cloud Apache Mesos https://www.cs.berkeley.edu/~alig/papers/mesos.pdf Large Scale Cluster Management at Google http://static.googleusercontent.com/media/research.google.com/en//pubs/archive/43438.pdf
