Raft in Scylla

This talk will cover the characteristics and requirements of Scylla's Raft implementation, how it enables strongly consistent updates, and how it improves the reliability and safety of internal processes, such as schema changes, node membership, and range movements.

Eventually consistent databases choose to remain available under failure, allowing for conflicting data to be stored in different replicas (later repaired by background processes). Weakening the consistency guarantees improves not only availability, but also performance, as the number of replicas involved in a given operation can be minimized. There are, however, use-cases that require the opposite trade-off. Indeed, Apache Cassandra and Scylla provide Lightweight Transactions (LWT), which allow single-key linearizable updates. The mechanism underlying LWT is asynchronous consensus in the form of the Raft algorithm. In this talk, we'll describe the characteristics and requirements of Scylla's consensus implementation, and how it enables strongly consistent updates. We will also cover how consensus can be applied to other aspects of the system, such as schema changes, node membership, and range movements, in order to improve their reliability and safety. We will thus show that an eventually consistent database can leverage consensus without compromising either availability or performance.

Transcript

1. Raft in Scylla Consensus in an eventually consistent database @duarte_nunes
2. Presenter bio Duarte is a Software Engineer working on Scylla. He has a background in concurrent programming, distributed systems and low-latency software. Prior to ScyllaDB, he worked on distributed network virtualization.
3. Introduction
4. ScyllaDB ▪ Clustered NoSQL database compatible with Apache Cassandra ▪ ~10X throughput on same hardware ▪ Low latency, esp. higher percentiles ▪ Self tuning ▪ Mechanically sympathetic C++17
5. Data placement ▪ Masterless ▪ Data is replicated across a set of replicas ▪ Data is partitioned across all nodes ▪ An operation can specify a Consistency Level
6. Data model Partition Key1 Clustering Key1 Clustering Key1 Clustering Key2 Clustering Key2 ... ... ... ... ... CREATE TABLE playlists (id int, song_id int, title text, PRIMARY KEY (id, song_id)); INSERT INTO playlists (id, song_id, title) VALUES (62, 209466, 'Ænima’'); Sorted by Primary Key
7. Consistency
8. Consistency ✓ ✓
9. Consistency ✓ ✓ ✓
10. Consistency ✓ ✓ ✓
11. Consistency ✓
12. Consistency ✓ ✓ ✓
13. Concurrent Updates 1: c = ‘a’ 1: c = ‘b’
14. Seastar - http://seastar.io ▪ Thread-per-core design • No blocking, ever.
15. Seastar - http://seastar.io ▪ Thread-per-core design • No blocking, ever. ▪ Asynchronous networking, file I/O, multicore • Future/promise based APIs
16. Thread-per-core ▪ Request path is replicated per CPU ▪ Internal sharding by partition key • Like having multiple nodes on the same machine ▪ Uses middle bits to avoid aliasing a node with a shard
17. Motivation
18. Strong consistency ▪ Strong guarantees enable more use cases
19. Strong consistency ▪ Strong guarantees enable more use cases • Uniqueness constraints
20. Strong consistency ▪ Strong guarantees enable more use cases • Uniqueness constraints • Read-modify-write accesses
21. Strong consistency ▪ Strong guarantees enable more use cases • Uniqueness constraints • Read-modify-write accesses • All-or-nothing writes
22. Strong consistency ▪ Strong guarantees enable more use cases • Uniqueness constraints • Read-modify-write accesses • All-or-nothing writes ▪ Opt-in, due to inherent performance costs
23. Lightweight Transactions (LWT) ▪ Per-partition strong consistency
24. Lightweight Transactions (LWT) ▪ Per-partition strong consistency ▪ Essentially, a distributed compare-and-swap • INSERT ... IF NOT EXISTS DELETE ... IF EXISTS DELETE ... IF col_a = ? AND col_b = ? UPDATE ... IF col_a = ? AND col_b = ?
25. Lightweight Transactions (LWT) ▪ Per-partition strong consistency ▪ Essentially, a distributed compare-and-swap • INSERT ... IF NOT EXISTS DELETE ... IF EXISTS DELETE ... IF col_a = ? AND col_b = ? UPDATE ... IF col_a = ? AND col_b = ? ▪ Fast-path operation warranting high performance and availability
26. Lightweight Transactions (LWT) ▪ Per-partition strong consistency ▪ Essentially, a distributed compare-and-swap • INSERT ... IF NOT EXISTS DELETE ... IF EXISTS DELETE ... IF col_a = ? AND col_b = ? UPDATE ... IF col_a = ? AND col_b = ? ▪ Fast-path operation warranting high performance and availability ▪ Requires internal read-before-write
27. Consensus
28. Definition “The process by which we reach agreement over system state between unreliable machines connected by asynchronous networks”
29. Consensus Protocols ▪ Strong consistency guarantees about the underlying data
30. Consensus Protocols ▪ Strong consistency guarantees about the underlying data ▪ Leveraged to implement Replicated State Machines • A set of replicas to work together as a coherent unit
31. Consensus Protocols ▪ Strong consistency guarantees about the underlying data ▪ Leveraged to implement Replicated State Machines • A set of replicas to work together as a coherent unit ▪ Tolerate non-byzantine failures • 2F + 1 nodes to tolerate F failures
32. Consensus Protocols ▪ Strong consistency guarantees about the underlying data ▪ Leveraged to implement Replicated State Machines • A set of replicas to work together as a coherent unit ▪ Tolerate non-byzantine failures • 2F + 1 nodes to tolerate F failures ▪ A consensus protocol round advances the underlying state
33. ▪ Stability • If a value is decided at a replica p, it remains decided forever ▪ Agreement • No two replicas should decide differently ▪ Validity • If a value is decided, this value must have been proposed by at least one of the replicas ▪ Termination • Eventually, a decision is reached on all correct replicas Guarantees
34. Choosing an Algorithm
35. Design Space ▪ Understandability
36. Paxos Made Live “There are significant gaps between the description of the Paxos algorithm and the needs of a real-world system. In order to build a real-world system, an expert needs to use numerous ideas scattered in the literature and make several relatively small protocol extensions. The cumulative effort will be substantial and the final system will be based on an unproven protocol.” By Google, when building Chubby using Multi-Paxos and SMR
37. Design Space ▪ Understandability ▪ Experienced & successful, well-known usages
38. Design Space ▪ Understandability ▪ Experienced & successful, well-known usages ▪ Latency, RTTs to agreement
39. Design Space ▪ Understandability ▪ Experienced & successful, well-known usages ▪ Latency, RTTs to agreement ▪ General performance (e.g., batching opportunities)
40. Leader vs RTTs ▪ Any node can decide a value • At least 2RTTs • Classical Paxos, CASPaxos
41. Leader vs RTTs ▪ Any node can decide a value • At least 2RTTs • Classical Paxos, CASPaxos ▪ Leader election • 1 RTT, but leader can limit throughput • Multi-paxos, Raft, Zab
42. Challenges ▪ Dealing with limited storage capacity ▪ Effectively handling read-only requests ▪ Dynamic membership and cluster reconfiguration ▪ Multi-key transaction support ▪ Acceptable performance over the WAN ▪ Formal and empirical validation of its safety
43. Raft ▪ Focused on understandability ▪ Widely used ▪ Amenable to nice optimizations ▪ Strong leadership ▪ For LWT, leader does read-before-write ▪ Log easily compacted in our case
44. Raft states Follower Candidate Leader
45. Raft components Consensus Module Log State Machine Client
46. Raft guarantees (1/2) ▪ Election Safety • At most one leader can be elected in a given term ▪ Leader Append-Only • A leader only appends new entries to its log ▪ Log Matching • If two logs contain an entry with the same index and term, then the logs are identical in all entries up through the given index
47. Raft guarantees (2/2) ▪ Leader Completeness • If a log entry is committed in a given term, then that entry will be present in the logs of the leaders for all higher-numbered terms ▪ State Machine Safety • If a server has applied a log entry at a given index to its state machine, no other server will ever apply a different log entry for the same index
48. Time in Raft follower/leader election Term T1 T2 T3 T4 Terms
49. Scylla Raft
50. Design Node Group Keyspace Vnode
51. Design ▪ A Scylla node participates in more than one group • A natural consequence of how data is partitioned
52. Design ▪ A Scylla node participates in more than one group • A natural consequence of how data is partitioned • Increased concurrency
53. Design ▪ A Scylla node participates in more than one group • A natural consequence of how data is partitioned • Increased concurrency • Leader failures affects only a subset of operations*
54. Design ▪ A Scylla node participates in more than one group • A natural consequence of how data is partitioned • Increased concurrency • Leader failures affects only a subset of operations* ▪ Each group on a node is itself sharded
55. Design ▪ A Scylla node participates in more than one group • A natural consequence of how data is partitioned • Increased concurrency • Leader failures affects only a subset of operations* ▪ Each group on a node is itself sharded • A shard handles a subset of the operations of the group
56. Design ▪ A Scylla node participates in more than one group • A natural consequence of how data is partitioned • Increased concurrency • Leader failures affects only a subset of operations* ▪ Each group on a node is itself sharded • A shard handles a subset of the operations of the group • Impacts how logs are organized
57. Organization Log Core Raft Database State RPC Log Core Raft Database State RPC Group 0 Group N - 1
58. Organization Shard 0 Shard N - 1 ... Log Core Raft Database State RPC Log Core Raft Database State RPC Group 0 Group N - 1
59. Organization Heartbeats Shard 0 Shard N - 1 ... Log Core Raft Database State RPC Log Core Raft Database State RPC Group 0 Group N - 1
60. Write path (simplified) 1. lock() locked_cell[] 7. Release locks mutation mutation restrictions Log RPC ... 3. Match 4. Append if matched cell_locker 2. query() 5. Replicate to majority 6. apply() Node N, Shard S Database
61. Sharding ▪ State explosion if groups are per-shard ▪ (term, leader shard, index) tuple ▪ Heterogeneous cluster ▪ Resharding
62. ▪ All data is correctly partitioned across the cluster Homogeneous nodes RPC Leader Shard 0 RPC Follower Shard 0
63. ▪ Entries not totally ordered at the follower Heterogeneous nodes (1) RPC Leader Shard 0 RPC Shard 1 RPC Follower Shard 0
64. ▪ Follower logs will contain gaps Heterogeneous nodes (2) RPC Follower Shard 0 RPC Shard 1 RPC Leader Shard 0
65. Sharding solutions ▪ Organize logs by term and leader shard • For each term, the leader shard count is stable
66. Sharding solutions ▪ Organize logs by term and leader shard • For each term, the leader shard count is stable ▪ Leader restart ends the term
67. Sharding solutions ▪ Organize logs by term and leader shard • For each term, the leader shard count is stable ▪ Leader restart ends the term ▪ A log is stored for each leader shard • May require synchronization at followers with different shard count
68. Log compaction ▪ Log entries are applied to the state machine when committed • A log entry is committed when replicated to a majority of nodes • The commit index of an entry is per shard
69. Log compaction ▪ Log entries are applied to the state machine when committed • A log entry is committed when replicated to a majority of nodes • The commit index of an entry is per shard ▪ Committed entries can be discarded • Responsibility for a prefix of the log is transferred to the database
70. Log compaction ▪ Log entries are applied to the state machine when committed • A log entry is committed when replicated to a majority of nodes • The commit index of an entry is per shard ▪ Committed entries can be discarded • Responsibility for a prefix of the log is transferred to the database ▪ Leverage repair • Benign overlap between log entries and database state • How many committed log segments to keep around?
71. Membership changes ▪ For the set of keyspaces K, each node will be a member of ks ∈ K RF(ks) * vnodes • TL;DR: potentially many groups ▪ Raft restricts the types of changes that are allowed • Only one server can be added or removed from a group at a time • Complex changes implemented as a series of single-server changes • Unless the RF is being changed, group member count is constant
72. Adding a node A C B
73. Adding a node D A C A C B B Bootstrap D
74. Bootstrap + Raft (1) ▪ The ranges for the Raft group of which B is the primary replica have changed ▪ Node D introduces a new Raft group, of which D, B and C are members ▪ Node D joins the Raft group of which A is the primary replica ▪ Node C leaves the Raft group of which A is the primary replica
75. Bootstrap + Raft (2) ▪ Need to wait until the new node has joined all groups • Then the other nodes can exit groups ▪ Doing a single operation at a time ensures majorities overlap ▪ Configurations are special log entries ▪ New nodes become non-voting members until they are caught up
76. Transactions
77. Another LWT constraint ▪ LOCAL_SERIAL consistency level • Precludes cross-DC groups • Each DC has its own group for a token range • Need agreement between two groups ▪ More up-front work, but worth it later • Leveraged for multi-partition transactions
78. Agreement Node Group Keyspace Vnode Agreement
79. Replicated 2PC Coordinator Resource Managers Transaction Status
80. Internal Use Cases
81. Concurrent schema changes ▪ Schemas changes are carried out locally and then propagated throughout the cluster
82. Concurrent schema changes ▪ Schemas changes are carried out locally and then propagated throughout the cluster ▪ No protection against concurrent schema changes • Different IDs even if the schema is the same • Cluster-wide order of changes is not enforced
83. Distributed schema tables CREATE TABLE ks.t ( p int, x my_type PRIMARY KEY (p)); DROP TYPE ks.my_type;
84. Distributed schema tables CREATE TABLE ks.t ( p int, x my_type PRIMARY KEY (p)); DROP TYPE ks.my_type;
85. Range movements ▪ Concurrent range operations can select overlapping token ranges
86. Range movements ▪ Concurrent range operations can select overlapping token ranges ▪ Token selection is not optimal
87. Range movements ▪ Concurrent range operations can select overlapping token ranges ▪ Token selection is not optimal ▪ Can’t use a partitioning approach
88. Range movements ▪ Concurrent range operations can select overlapping token ranges ▪ Token selection is not optimal ▪ Can’t use a partitioning approach • Need to centralize token selection
89. Global Group
90. Specific Group
91. Consistent materialized views ▪ Views are updated asynchronously • Eventually consistent • Preserves base replica availability • Issues with consistency, flow control
92. Consistent materialized views ▪ Views are updated asynchronously • Eventually consistent • Preserves base replica availability • Issues with consistency, flow control ▪ Can leverage multi-key transactions • Base and view are both updated, or none are • Strongly consistent
93. Thank You Any Questions ? Please stay in touch duarte@scylladb.com @duarte_nunes
