Ingest Node: Enriching Documents within Elasticsearch

When ingesting data into Elasticsearch, sometimes only simple transforms need to be performed on the data prior to indexing. Enter Ingest Node: a new node type that will allow you to do just that! This talk will introduce you to Ingest Node and how to integrate it with the rest of the Elastic Stack.

Transcript

1. ‹#›
   @talevy
   @lucacavanna
   @mvgroningen
   Ingest Node


   View Slide

2. Indexing A Document
   2
   PUT localhost:9200/logs/mysql/1
   {
   “message”: "070917 16:29:01 21 Query select * from location"
   }


   View Slide

3. 3
   070917 16:29:01 21 Query select * from location
   Time thread_id command_type query_body


   View Slide

4. Logstash is made for this!
   4
   {
   input { … }
   filter {
   grok {
   match => {
   “message” : “^%{NUMBER:date} *%{TIME:time} *
   %{WORD:command_type} *%{DATA:command}”
   }
   mutate { remove => [“message”] }
   }
   output { … }
   }


   View Slide

5. Ingest Pipeline
   5
   just the filters
   grok remove
   Inputs outputs


   View Slide

6. Indexing [An Enriched ] Document
   6
   PUT localhost:9200/logs/mysql/1?pipeline=my_mysql_pipeline
   {
   “message”: "070917 16:29:01 21 Query select * from location"
   }
   specifying an ingest pipeline to execute before indexing


   View Slide

7. Indexing [An Enriched ] Document
   7
   PUT localhost:9200/logs/mysql/1
   {
   “timestamp”: “2007-09-17T16:29:01-08:00”,
   “thread_id”: “21”,
   “command_type”: “Query”,
   “command”: “select * from location”
   }
   document as it is being indexed


   View Slide

8. 8
   Ingest Node
   • On in Elasticsearch 5.0 by default
   • All nodes can become ingest nodes.
   • Pipelines run on any ingest node
   • Logstash Filters and Ingest Processors will be able compatible with one
   another.
   Enrich documents before indexing


   View Slide

9. Examples and Use-Cases
   9
   Beats Reindex
   • filebeat
   • no middle man, ship logs
   directory into
   elasticsearch
   • Misnamed field, bulk
   rename using reindex api
   with a pipeline defined.


   View Slide

10. The Pipeline
    10


    View Slide

11. 11
    The Pipeline
    • A description of a sequence of processors to execute against each
    document that is to be indexed.
    • defined in JSON
    • It is run before the documents are indexed into Elasticsearch
    process machine


    View Slide

12. Pipeline Management
    Create, Retrieve, Update, Delete
    12
    PUT _ingest/pipeline/pipeline-name
    GET _ingest/pipeline/pipeline-name
    GET ingest/pipeline/*
    DELETE _ingest/pipeline/pipeline-name


    View Slide

13. ‹#›
    Example Pipeline
    13
    extract mysql fields from
    `message` field and then
    remove it from the document
    {
    “description”: “mysql pipeline”,
    “processors”: [
    {
    “grok” : {
    “field” : “message”,
    “pattern” : “…”
    }
    },
    {
    “remove” : {
    “field” : “message”
    }
    }
    ]
    }


    View Slide

14. The Processors
    14
    Grok
    Rename
    Set
    Convert
    attachment
    Geoip
    Date


    View Slide

15. ‹#›
    Mutate
    Processors
    15
    set, convert, split, uppercase,
    lowercase, remove, rename,
    append, and more!
    MuTaTE
    mutate
    MUTATE
    mUTAte


    View Slide

16. ‹#› 16
    Grok Processor
    Parses new field values out of
    pattern-matched substrings
    {
    "grok": {
    "field": "field1",
    "pattern": “%{DATE:date}”
    }
    }


    View Slide

17. ‹#› 17
    Geoip Processor
    Adds information about the
    geographical location of IP
    addresses
    {
    "geoip": {
    "field": “my_ip_field”,
    }
    }


    View Slide

18. ‹#›
    Introducing new
    processors is as
    easy as writing a
    new plugin!
    18
    {
    “your_plugin_here”: {
    "field": “field1”,
    …
    }
    }


    View Slide

19. Pipeline Error Handling
    19


    View Slide

20. 20
    Handling Failure
    • Sometimes the input documents do not match what is expected. Failing is
    sometimes expected, and can handled
    • Use the on_failure parameter to define processors to run when the parent
    processor or pipeline throw an exception
    • on_failure blocks behave like little pipelines!
    Data is not clean, pipelines clean them
    Source: Gray Arial10pt


    View Slide

21. Pipeline With Failure Guards
    21
    grok date set


    View Slide

22. Pipeline With Failure Guards
    22
    grok date set


    View Slide

23. Pipeline With Failure Guards
    23
    grok date set
    set date


    View Slide

24. Pipeline With Failure Guards
    24
    grok date set
    set date


    View Slide

25. 25
    Investigating Pipelines
    • on_failure is great for allowing you to catch exceptions
    • what if you do not know what exceptions can occur?
    • what if you are unsure what a processor will do?
    • what if there was a way to test a pipeline against your documents before
    indexing?
    Peek into behavior of Pipeline
    Source: Gray Arial10pt


    View Slide

26. Simulation
    26


    View Slide

27. 27
    _simulate
    • The Simulate API can be used to run pipelines against input documents
    • These input documents are not indexed
    • Use verbose flag to see output of each processor within a pipeline, not just
    the end result
    • Used to debug output of specific processors within a pipeline
    running pipelines without indexing


    View Slide

28. Simulate Endpoints
    28
    POST _ingest/pipeline/pipeline-name/_simulate
    POST _ingest/pipeline/_simulate
    POST _ingest/pipeline/_simulate?verbose


    View Slide

29. 29
    _simulate
    request response
    POST _ingest/pipeline/_simulate
    {
    “pipeline” : { … },
    “docs” : [
    {“message”: “transform!”},
    {“message”: “me too!”}
    ]
    }
    {
    “docs” : [
    {…},
    {…}
    ]
    }


    View Slide

30. Ingest node internals
    30


    View Slide

31. 31
    Ingest node internals
    • Ingest node is part of core Elasticsearch
    • The infrastructure
    • Many processors
    • Some processors are available as plugins


    View Slide

32. 32
    Ingest node internals - the infrastructure
    • Ingest needs to intercept documents before it gets indexed for and
    preprocess it.
    • But where should intercept the documents?
    • The cost of preprocessing and the ability to isolate that are important


    View Slide

33. cluster
    33
    Ingest node internals - the infrastructure
    node
    index1
    1P
    node
    index1
    1R
    node
    index2
    1P
    node
    index2
    1R
    index1
    2R
    index1
    2P
    index2
    2R
    index2
    2P


    View Slide

34. Cluster
    Node
    34
    Ingest node internals - the infrastructure
    index1
    1P
    index1
    2R


    View Slide

35. Cluster
    Node
    35
    Ingest node internals - the infrastructure
    index1
    1P
    index1
    2R


    View Slide

36. Cluster
    Node
    36
    Ingest node internals - the infrastructure
    ? ?
    CS


    View Slide

37. cluster
    node CS
    37
    Ingest node internals - the infrastructure
    node
    index1
    1P
    index1
    1R
    node
    index2
    1P
    node
    index2
    1R
    index1
    2R
    index1
    2P
    index2
    2R
    index2
    2P
    CS
    CS CS


    View Slide

38. 38
    Ingest node internals - other details
    node
    Ingest
    processing


    View Slide

39. Ingest node in production
    39


    View Slide

40. 40
    Ingest node in production - performance
    • The type of operations your pipelines are going to perform
    • The number of processors in your pipelines
    • The amount of fields your pipelines add or remove.
    • The number of nodes ingest can run on.
    • So it depends!


    View Slide

41. 41
    Ingest node in production - default architecture
    cluster
    node
    index1
    1P
    node
    index1
    1R
    node
    index2
    1P
    node
    index2
    1R
    index1
    2R
    index1
    2P
    index2
    2R
    index2
    2P


    View Slide

42. 42
    Ingest node in production - dedicated ingest nodes
    cluster
    d+m node
    index1
    1P
    d+m node
    index1
    1R
    d+m node
    index2
    1P
    d+m node
    index2
    1R
    index1
    2R
    index1
    2P
    index2
    2R
    index2
    2P
    ingest

    node
    ingest

    node
    ingest

    node
    ingest

    node


    View Slide

43. 43
    Dedicated ingest node in production - benchmark
    • Indexing apache logs
    • Bulk indexing with 5 concurrent threads
    • 2 node cluster
    • Data+master node
    • Ingest only node


    View Slide

44. Dedicated ingest node in production - benchmark
    44
    0%
    20%
    40%
    60%
    80%
    100%
    0.3M 0.6M 1.2M 2.4M 4.8M 9.6M
    empty
    set
    grok
    grok + geoip
    grok + remove


    View Slide

45. ‹#›
    Pipeline Construction Demo
    experiment with pipeline creation
    from within Kibana


    View Slide

46. View Slide

47. View Slide

48. View Slide

49. ‹#›
    Filebeat Demo
    Shipping Logs to Ingest from Beats


    View Slide

50. View Slide

51. Filebeat demo
    Grok processor
    51
    {
    "grok": {
    "field": "message",
    "pattern": "%{COMBINEDAPACHELOG}"
    }
    }


    View Slide

52. Filebeat demo
    Date processor
    52
    {
    "date": {
    "match_field" : "timestamp",
    "target_field" : "timestamp",
    "match_formats" : ["dd/MMM/YYYY:HH:mm:ss Z"]
    }
    }


    View Slide

53. Filebeat demo
    Convert processor
    53
    {
    "convert": {
    "field" : "response",
    "type" : "integer"
    }
    }


    View Slide

54. Filebeat demo
    Convert processor with on_failure
    54
    {
    "convert": {
    "field" : "bytes",
    "type" : "integer",
    "on_failure" : [
    {
    "set" : {
    "field" : "bytes",
    "value" : 0
    }
    }
    ]
    }
    }


    View Slide

55. View Slide

56. See you at AMA
    56


    View Slide

57. ‹#›
    Please attribute Elastic with a link to elastic.co
    Except where otherwise noted, this work is licensed under
    http://creativecommons.org/licenses/by-nd/4.0/
    Creative Commons and the double C in a circle are
    registered trademarks of Creative Commons in the United States and other countries.
    Third party marks and brands are the property of their respective holders.
    57


    View Slide
