  1. Elastic
    February 28, 2018
    @jordansissel / @andrewvc
    What’s the Latest in Logstash
    Jordan Sissel and Andrew Cholakian

    View full-size slide

  2. Thank you to our community
    You complete the picture

    View full-size slide

  3. In the last year, 1,413 Logstashers have helped us with 9,237
    issues, comments, and pull requests to our logstash-plugins
    repository. 864 pull requests were opened.
    The Logstash Plugins Community
    3

    View full-size slide

  4. In the last year, 76 Logstashers have helped us with 1,131
    issues, comments, and pull requests to our logstash-plugins
    repository. 179 pull requests were opened.
    The Logstash Core Community
    4

    View full-size slide

  5. Triaging in Two Parts

    View full-size slide

  6. We couldn’t do it without you!

    View full-size slide

  7. queue.type: persisted # (v5.4)
    input
    input
    input
    filter
    filter
    filter
    output
    output
    Icons made by Freepik from www.flaticon.com is licensed by CC 3.0 BY
    queue
    Theme: Don’t lose data.

    View full-size slide

  8. WHAT IF WE CAN’T
    DELIVER SOMETHING?
    Theme: Don’t lose data.

    View full-size slide

  9. Simple things should be simple

    View full-size slide

  10. bin/logstash --modules netflow

    View full-size slide

  11. bin/logstash --modules arcsight

    View full-size slide

  12. bin/logstash --modules

    View full-size slide

  13. 17
    A Tale of Two* Pipelines
    *(or more)

    View full-size slide

  14. 1
    8
    input {
    beats { port => 3444 tag => apache }
    tcp { port => 4222 tag => firewall }
    }
    filter {
    if "apache" in [tags] {
    dissect { ... }
    } else if "firewall" in [tags] {
    grok { ... }
    }
    }
    output {
    if "apache" in [tags] {
    elasticsearch { ... }
    } else if "firewall" in [tags] {
    tcp { ... }
    }
    }
    TCP BEATS
    DISSECT
    GROK
    TCP ES

    View full-size slide

  15. 1
    9
    input {
    beats { port => 3444 tag => apache }
    tcp { port => 4222 tag => firewall }
    }
    filter {
    if "apache" in [tags] {
    dissect { ... }
    } else if "firewall" in [tags] {
    grok { ... }
    }
    }
    output {
    if "apache" in [tags] {
    elasticsearch { ... }
    } else if "firewall" in [tags] {
    tcp { ... }
    }
    }
    input {
    beats { port => 3444 tag => apache }
    tcp { port => 4222 tag => firewall }
    }
    filter {
    if "apache" in [tags] {
    dissect { ... }
    } else if "firewall" in [tags] {
    grok { ... }
    }
    }
    output {
    if "apache" in [tags] {
    elasticsearch { ... }
    } else if "firewall" in [tags] {
    tcp { ... }
    }
    }

    View full-size slide

  16. 2
    0
    input {
    beats { port => 3444 tag => apache }
    }
    filter {
    dissect { ... }
    }
    output {
    elasticsearch { ... }
    }
    input {
    tcp { port => 4222 tag => firewall }
    }
    filter {
    grok { ... }
    }
    output {
    tcp { ... }
    }
    Multiple Pipelines (v6.0)
    BEATS
    DISSECT
    ES
    TCP
    GROK
    TCP

    View full-size slide

  17. X-Pack Central Management (v6.0)
    -------
    -----------
    -------- - ------ ---
    ----- ---- ----
    ---
    ---
    ---
    ------------
    -- -- - -- ---- - -- ---
    -- - ----
    - --- ---
    -------
    -----------
    -------- - ------ ---
    ----- ---- ----
    ------
    ---
    ------------
    -- -- - -- ---- - -- ---
    -- - ----
    - --- ---
    -------
    -----------
    -------- - ------ ---
    ----- ---- ----
    ---
    ---
    ---
    ------------
    -- -- - -- ---- - -- ---
    -- - ----
    - --- ---
    -------
    -----------
    -------- - ------ ---
    ----- ---- ----
    ------
    ---
    ------------
    -- -- - -- ---- - -- ---
    -- - ----
    - --- ---
    -------
    -----------
    -------- - ------ ---
    ----- ---- ----
    ---
    ---
    ---
    ------------
    -- -- - -- ---- - -- ---
    -- - ----
    - --- ---
    -------
    -----------
    -------- - ------ ---
    ----- ---- ----
    ------
    ---
    ------------
    -- -- - -- ---- - -- ---
    -- - ----
    - --- ---
    Three Logstash instances.
    Doing the same thing.
    Let’s simplify this.

    View full-size slide

  18. X-Pack Central Management (v6.0)
    -------
    -----------
    -------- - ------ ---
    ----- ---- ----
    ------
    ---
    ------------
    -- -- - -- ---- - -- ---
    -- - ----
    - --- ---
    -------
    -----------
    -------- - ------ ---
    ----- ---- ----
    ------
    ---
    ------------
    -- -- - -- ---- - -- ---
    -- - ----
    - --- ---
    -------
    -----------
    -------- - ------ ---
    ----- ---- ----
    ------
    ---
    ------------
    -- -- - -- ---- - -- ---
    -- - ----
    - --- ---
    -------
    -----------
    -------- - ------ ---
    ----- ---- ----
    ------
    ---
    ------------
    -- -- - -- ---- - -- ---
    -- - ----
    - --- ---
    One configuration source.

    View full-size slide

  19. WITH GREAT POWER
    COMES GREAT

    View full-size slide

  20. --experimental-java-execution (v6.1)
    27
    0: new #121
    3: dup
    4: iconst_2
    5: fconst_1
    6: invokespecial #122
    9: astore_1
    10: aload_1
    11: ldc #47
    13: aload_0
    14: getfield #6
    17: invokeinterface #52, 3
    filter {
    if “debug” in [tags] {
    drop { }
    }
    grok {
    match => { … }
    }
    }
    if event.getField(“tags”)... {
    drop.execute(event);
    if event.isCancelled() {
    return;
    }
    }
    grok.execute(event);
    Compile bytecode
    Load Configuration Transform to Java

    View full-size slide

  21. --experimental-java-execution (v6.1)
    28
    “Compile”
    code = config.compile()
    pipeline = eval(code)
    loop do
    batch = queue.pop()
    pipeline.execute(batch)
    end
    Load Configuration
    filter {
    if “debug” in [tags] {
    drop { }
    }
    grok {
    match => { … }
    }
    }
    Transform to Ruby
    if event.get(“tags”).include?(
    drop.execute(event)
    return if event.cancelled?
    end
    grok.execute(event)
    Ruby

    View full-size slide

  22. Logstash 6.2: Protect credentials with the keystore
    logstash-keystore (Logstash 6.2)
    % logstash-keystore create
    % logstash-keystore add es_password
    # use es_password in the pipeline:
    output {
    elasticsearch {
    hosts => …
    user => “elastic”
    password => “${es_password}”
    }
    }

    View full-size slide

  23. Upcoming Features

    View full-size slide

  24. Visual Pipeline Builder

    View full-size slide

  25. More Security Modules
    (SIEM, IDS, Firewalls, etc.)

    View full-size slide

  26. SNMP Poller
    (It’s not a trap!)

    View full-size slide

  27. Centralized Management
    Improvements

    View full-size slide

  28. How we do it today
    3
    7
    xpack.management.enabled: true
    xpack.management.pipeline.id: ["apache", "cloudwatch_logs"]
    LS1 LS2 LS3
    apache
    cloudwatch
    logs

    View full-size slide

  29. Where we Want to Go
    3
    8
    xpack.management.enabled: true
    xpack.management.pipeline.node_groups: ["webserver_logs”, “security_logs”]
    LS1 LS2 LS3
    apache
    logs
    cloudwatch
    logs
    webserver_logs security_logs
    nginx
    logs
    azure
    activity logs

    View full-size slide

  30. Pipeline Settings Will Also Be
    Supported!

    View full-size slide

  31. Ancillary Files in Config
    Management

    View full-size slide

  32. Config
    File
    Grok
    Patterns
    GeoIP
    Database
    Without Config Management

    View full-size slide

  33. Config
    File
    Grok
    Patterns
    GeoIP
    Database
    Config Management Today

    View full-size slide

  34. Config
    File
    Grok
    Patterns
    GeoIP
    Database
    Config Management in the Future

    View full-size slide

  35. Java Plugin API

    View full-size slide

  36. • Allow people to use additional JVM languages to develop plugins
    • Enable performance optimization where required
    Java Plugin API Goals
    4
    5

    View full-size slide

  37. • We’re starting with a low level API, optimized for performance
    • Will add sugar on top
    • We plan to support the current plugin API indefinitely
    • Some esoteric APIs, like flush, may go away
    Java Plugin API Plan
    4
    6

    View full-size slide

  38. Logstash -> Logstash:
    Making it a better story

    View full-size slide

  39. Currently, things are a little ugly

    View full-size slide

  40. How we do it today
    4
    9
    output {
    lumbjerjack { … }
    }
    input {
    beats { … }
    }
    ?
    ?
    ?

    View full-size slide

  41. Interpipeline Communications

    View full-size slide

  42. - pipeline.id: senderone
    config.string: "input { generator { message => huhx } } output { internal { send_to => [foo] } }"
    - pipeline.id: sendertwo
    config.string: "input { generator { message => whutx } } output { internal { send_to => [foo] } }"
    - pipeline.id: out
    config.string: " input { internal { address => foo } } output { stdout { codec => json_lines } }"
    What it looks like
    5
    1
    senderone
    sendertwo
    out

    View full-size slide

  43. Share a Port
    5
    2
    Beats
    Ingest +
    Routing
    Enrich
    Weblogs +
    Output
    Enrich ETL
    Logs +
    Output
    Enrich
    Metrics +
    Output

    View full-size slide

  44. Buffer as Needed
    5
    3
    PQ
    PQ
    Logs Ingest
    Output to
    Elasticsearch
    Output to S3

    View full-size slide

  45. Put it Together
    5
    4
    PQ
    PQ
    PQ
    Beats
    Ingest and
    Route
    Enrich
    Weblogs
    Enrich ETL
    Logs
    Enrich
    Metrics +
    Output to
    Metrics ES
    Cluster
    Output to
    Logging ES
    Cluster

    View full-size slide

  46. Language Improvements on the
    Horizons

    View full-size slide

  47. • Is not null checks
    • Array/field reference conflation (is [foo] an array, or a field reference?)
    • What else does the lang need?
    • Can we experiment with new languages?
    The Language Can Move Forward
    5
    6

    View full-size slide

  48. An Ephemeral World
    Or, how I learned to stop worrying about my disk and
    embrace ephemeral storage

    View full-size slide

  49. An Ephemeral World
    Part 1: End to End ACKs

    View full-size slide

  50. Resiliency today isn’t as easy as
    it could be

    View full-size slide

  51. 60
    You need to think
    about disks if you
    use the PQ

    View full-size slide

  52. 61
    You need to be able
    to tolerate data loss
    if you use the in-
    memory queue

    View full-size slide

  53. What if we could give you the
    best of both worlds?

    View full-size slide

  54. End-to-End (E2E) ACKs solve
    this problem

    View full-size slide

  55. We currently buffer at each stage

    View full-size slide

  56. Each event must be persisted, then acknowledged

    View full-size slide

  57. With E2E ACKs, Nodes Can Fully Fail

    View full-size slide

  58. Where we can replay or delay asynchronously
    acknowledge, we can skip persistence
    6
    7

    View full-size slide

  59. • TCP, UDP, and Syslog protocol offer no facility to replay
    • The best strategy here is to store ASAP on Logstash, and then try to get it elsewhere ASAP
    Where we can’t replay, the PQ is still best
    6
    8

    View full-size slide

  60. • Currently in progress
    • Will likely require rewrites to input plugins to be efficient
    • Only works for things that are replayable
    • Luckily, a lot of things are replayable
    E2E ACK Summary
    6
    9

    View full-size slide

  61. An Ephemeral World
    Part 2: Distributed Plugin State/Execution

    View full-size slide

  62. Problem 1:
    Plugins store metadata on disk

    View full-size slide

  63. This all must be backed up

    View full-size slide

  64. Problem 2:
    Inputs cannot share work

    View full-size slide

  65. Today, Logstashes cannot coordinate their access to a service like S3
    Active
    Failover

    View full-size slide

  66. • Users must implement backups of metadata
    • Scaling past one box requires manual partitioning, or is not possible
    • Failover is tricky, and involves restoring backed up metadata
    Why Local State is Irritating
    7
    5

    View full-size slide

  67. Solution: Centralized
    State/Distributed Exec

    View full-size slide

  68. Local File Metadata Will Still Work!
    Active
    Failover

    View full-size slide

  69. But This is Way Cooler
    Indexing cluster
    Management Cluster
    Management Data

    View full-size slide

  70. • Plugin state kept in ES
    • Leader election through ES
    • Task assignment through ES
    • Still in design phase, we have a PoC in progress
    How it Works
    7
    9

    View full-size slide

  71. Problem 3:
    The DLQ is Local

    View full-size slide

  72. Solution: Create an ES DLQ

    View full-size slide

  73. • Pitch in on PRs
    • Report bugs
    • Review PRs
    We Need Your Help!
    8
    2

    View full-size slide
