Escaping The Tar Pit at Philly.rb

Escaping The Tar Pit at Philly.rb

Presentation about avoiding and escaping the tar pit.

Introduction to the `skunk` gem. Talks a little bit about `flog`; `rubycritic`; `simplecov`; `reek`; and other tools you can use to get metrics related to the codebase.

F77032adcbe77d2777bb0e0c30873159?s=128

Ernesto Tagwerker

November 05, 2019
Tweet

Transcript

  1. Escaping The Tar Pit Ernesto Tagwerker (@etagwerker) Philly.rb, November 2019

  2. ! Hi, I’m from Argentina I live in Philadelphia #

    I ❤ Open Source
  3. Founder & Software Engineer @OmbuLabs

  4. Founder & Software Engineer @fastrubyio

  5. Open Source Contributor & Maintainer database_cleaner; bundler-leak; next_rails

  6. Inspiration

  7. Chapter 1: The Tar Pit

  8. “No scene from prehistory is quite so vivid as that

    of the mortal struggles of great beasts in the tar pits. […] The fiercer the struggle, the more entangling the tar, and no beast is so strong or so skillful but that they ultimately sink.” Fred Brooks
  9. “Large-system programming has over the past decade been such a

    tar pit, and many great and powerful beasts have thrashed violently in it.” Fred Brooks
  10. We are in the tar pit; trying to avoid it;

    or trying to get out.
  11. None
  12. Tar Pit Symptoms > Projects running over budget

  13. Tar Pit Symptoms > Projects running over budget > Taking

    forever to ship small changes
  14. Tar Pit Symptoms > Projects running over budget > Taking

    forever to ship small changes > Sacrificing quality, increasing tech debt
  15. None
  16. Part 1: How to avoid the tar pit

  17. “THAT’D BE GREAT” BOSS: “IF YOU COULD COME IN ON

    THIS GREAT, LEGACY PROJECT AND MAINTAIN IT FROM NOW ON…”
  18. “THAT’D BE GREAT” CLIENT: “IF YOU COULD COME IN ON

    THIS GREAT, LEGACY PROJECT AND MAINTAIN IT FROM NOW ON…”
  19. CLIENT: “HOW LONG IS IT GOING TO TAKE?”

  20. “BECAUSE I NEED IT BY END OF DAY TODAY” CLIENT:

    “HOW LONG IS IT GOING TO TAKE?”
  21. How can we quickly assess code quality?

  22. Part 2: How to get out of the tar pit

  23. How can we gradually pay off technical debt?

  24. Part 1: Avoiding the tar pit

  25. None
  26. “It can’t be that hard. It’s a Ruby project.”

  27. How can we quickly assess code quality?

  28. Assessing Quality ✅ Paid Services ✅ Open Source Gems

  29. Assessing Quality ✅ Paid Services ➡ Open Source Gems

  30. Open Source Gems ✅ Static code analysis

  31. Open Source Gems ✅ Static code analysis ✅ Code coverage

  32. Open Source Gems ✅ Static code analysis ✅ Code coverage

    ✅ Code smells
  33. What is software quality anyway?

  34. There are hundreds of definitions.

  35. “The degree to which a system, component, or process meets

    implicit and explicit requirements.” IEEE
  36. “It works as expected.”

  37. “It works as expected and it is not a PITA

    to maintain it.”
  38. ISO 9126-1 Software Quality Model ✅ Reliability ✅ Usability ✅

    Efficiency ✅ Maintainability ✅ Portability
  39. ISO 9126-1 Software Quality Model ✅ Reliability ✅ Usability ✅

    Efficiency ➡ Maintainability ✅ Portability
  40. Maintainability

  41. Maintainability 1. Code Coverage

  42. Maintainability 1. Code Coverage 2. Code Quality

  43. Code Coverage SimpleCov (github.com/colszowka/simplecov)

  44. Code Coverage # Gemfile group :test do gem "simplecov", require:

    false end
  45. Code Coverage # spec/spec_helper.rb if ENV["COVERAGE"] == "true" require 'simplecov'

    SimpleCov.start do add_group "Models", "models" add_filter "/spec/" track_files "**/*.rb" end end
  46. Code Coverage # spec/spec_helper.rb if ENV["COVERAGE"] == "true" require 'simplecov'

    SimpleCov.start "rails" end
  47. Code Coverage $ COVERAGE=true rspec

  48. Code Coverage

  49. Code Quality n options

  50. Code Quality n options (flog; flay; reek; churn; RubyCritic; MetricFu;

    attractor; rubocop; fukuzatsu; turbulence; …)
  51. Code Quality RubyCritic (github.com/whitesmith/rubycritic)

  52. Churn

  53. Churn git

  54. Churn $ git log --follow --format=%h default.rb | cat 573c8f5

    2ccc5b8 b447bc3
  55. Churn $ git log --follow --format=%h default.rb | cat 573c8f5

    2ccc5b8 b447bc3 # Churn Count = 3
  56. Complexity

  57. Complexity flog

  58. Complexity $ flog foo.rb 11.2: flog total

  59. Complexity class Foo def yay # 11.2 = a =

    eval "1+1" # 1.2 + 6.0 + if a == 2 # 1.2 + 1.2 + puts "yay" # 1.2 end end end
  60. Complexity $ flog foo.rb 11.2: flog total

  61. Churn vs. Complexity

  62. Churn Complexity 50 0 1 100_000

  63. Churn Complexity 100 0 1 100_000 user.rb (changed: 2 times;

    complexity: 100_000 )
  64. Churn Complexity 100 0 1 100_000 user.rb (changed: 27 times;

    complexity: 100)
  65. Code Quality $ gem install rubycritic

  66. Code Quality $ rubycritic

  67. None
  68. GPA Pie Graph Complexity (flog) Code Smells (reek)

  69. Churn vs. Complexity Churn (SCM) Complexity (flog)

  70. 100 0 1 100_000 Complexity Churn

  71. 100 0 1 100_000 Complexity Churn

  72. 100 0 1 100_000 “Welcome to the good place.” ❤

    Complexity Churn
  73. 100 0 1 100_000 “No one understands these files but

    they work. So don’t change them.” Complexity Churn
  74. 100 0 1 100_000 “[…], if the code never changes,

    it's not costing us money.” Sandi Metz Complexity Churn
  75. 100 0 1 100_000 “Everybody understands these files but you

    need to change them often” Complexity Churn
  76. 100 0 1 100_000 Complexity Churn “These modules are complex

    and change a lot…” '
  77. 100 0 1 100_000 Complexity Churn “Sometimes a class becomes

    so complex that refactoring seems too difficult.” Michael Feathers
  78. Are you getting into a tar pit, is it a

    dumpster fire, or have you found a project which is easy to maintain?
  79. 100 0 1 100_000 “Welcome to the tar pit.” Complexity

    Churn
  80. Maintainability 1. Code Coverage (SimpleCov) 2. Code Quality (RubyCritic)

  81. Signal #1 Code Coverage

  82. Signal #2 Complexity

  83. Coverage & Complexity

  84. But what if we could calculate a new signal that

    combines both?
  85. Signal #3 StinkScore

  86. StinkScore = f(code_quality, code_coverage)

  87. StinkScore = f(code_smells, churn, code_complexity, code_coverage)

  88. code_coverage Files which lack tests should be penalized

  89. foo.rb churn: 10 complexity: 10 smells: 10 smell: 1,000 (10*10*10)

  90. bar.rb churn: 10 complexity: 10 smells: 10 smell: 1,000 (10*10*10)

  91. foo.rb churn: 10 complexity: 10 smells: 10 smell: 1,000 (10*10*10)

    bar.rb churn: 10 complexity: 10 smells: 10 smell: 1,000 (10*10*10)
  92. foo.rb is not stinkier than bar.rb

  93. foo.rb churn: 10 complexity: 10 smells: 10 code_coverage: 0 stink_score:

    100,000 (10*10*10)*100
  94. bar.rb churn: 10 complexity: 10 smells: 10 code_coverage: 100 stink_score:

    1,000 (10*10*10)*1
  95. foo.rb churn: 10 complexity: 10 smells: 10 code_coverage: 0 stink_score:

    100,000 (10*10*10)*100 bar.rb churn: 10 complexity: 10 smells: 10 code_coverage: 100 stink_score: 1,000 (10*10*10)*1
  96. foo.rb is considerably stinkier than bar.rb

  97. Stink Score Calculator Skunk (github.com/fastruby/skunk)

  98. Skunk $ gem install skunk

  99. Skunk $ skunk

  100. None
  101. None
  102. Skunk $ skunk ... StinkScore Total: 13220.859999999997 Modules Analysed: 71

    StinkScore Average: 0.1862092957746 Worst StinkScore: 2401.75 (lib/rubycritic/source_control_systems/git.rb)
  103. RubyCritic module RubyCritic class AnalysedModule def cost smells.map(&:cost).inject(0.0, :+) +

    # From Reek (complexity / COMPLEXITY_FACTOR) # From Flog end end end
  104. Skunk module RubyCritic class AnalysedModule def stink_score return churn_times_cost if

    perfect_coverage? (churn_times_cost * (PERFECT_COVERAGE - coverage.to_i)) end def churn_times_cost safe_churn = churn > 0 ? churn : 1 safe_churn * cost end end end
  105. Skunk module RubyCritic class AnalysedModule def stink_score return churn_times_cost if

    perfect_coverage? (churn_times_cost * (PERFECT_COVERAGE - coverage.to_i)) end def churn_times_cost safe_churn = churn > 0 ? churn : 1 safe_churn * cost end end end
  106. Skunk Warning > skunk-v0.2.0 > feedback wanted

  107. Maintainability 1. Code Coverage (SimpleCov) 2. Code Quality (RubyCritic) 3.

    StinkScore (Skunk)
  108. You are here:

  109. Part 2: Getting out of the tar pit

  110. So, where do we begin?

  111. removing files will decrease our stink_score

  112. Find Dead Code Coverband (github.com/danmayer/coverband)

  113. None
  114. refactoring complex files will decrease our stink_score

  115. 100 0 1 100_000 Complexity Churn “Here be dragons. These

    modules are complex and change a lot…” '
  116. 100 0% 1 100_000 Complexity Churn “Great candidates for refactoring

    (paying technical debt!)” #
  117. Churn vs. Complexity is not enough to prioritize

  118. Stink Score Table

  119. Refactor These Files:

  120. Refactor These Files:

  121. 100 0 1 100_000 Complexity Churn git.rb

  122. 100 0 1 100_000 Complexity Churn git_calculator.rb git_fetcher.rb refactor! git.rb

  123. 100 0 1 100_000 Complexity Churn git_calculator.rb git_fetcher.rb

  124. Skunk $ skunk ... StinkScore Total: 13220.859999999997 11220 Modules Analysed:

    71 StinkScore Average: 0.1862092957746 0.157
  125. writing tests for our app will decrease our stink_score

  126. Stink Score Table

  127. Write Tests Here:

  128. Skunk $ skunk ... StinkScore Total: 13220.859999999997 11220 Modules Analysed:

    71 StinkScore Average: 0.1862092957746 0.157
  129. Time StinkScore Average 100 (days) 0 1 100

  130. stink_score your compass to get out of the tar pit

  131. stink_score Code Coverage; Complexity; and Smells

  132. Thank you! @etagwerker 132

  133. Resources 1. https://github.com/whitesmith/rubycritic 2.https://github.com/colszowka/simplecov 3.https://github.com/metricfu/metric_fu 4.https://github.com/julianrubisch/attractor 5.https://www.fastruby.io/blog/ruby/quality/code-quality-ruby-gems.html 6.https://www.reddit.com/r/ruby/comments/2bq092/rubycritic/ 7.http://jakescruggs.blogspot.com/2008/08/whats-good-flog-score.html 8.http://ruby.sadi.st/Flog.html

    9.http://ruby.sadi.st/Flay.html 10.https://github.com/makaroni4/sandi_meter
  134. Resources 1.https://codeclimate.com/blog/deciphering-ruby-code-metrics/ 2.https://www.stickyminds.com/article/getting-empirical-about-refactoring 3.https://www.sandimetz.com/blog/2017/9/13/breaking-up-the-behemoth 4.https://github.com/troessner/reek 5.https://github.com/seattlerb/flay 6.https://github.com/seattlerb/flog 7.http://www.sqa.net/iso9126.html 8.https://www.slideshare.net/mscottford/important-metrics-for-measuring- code-health

    9.https://dilbert.com/strip/2006-12-08
  135. Questions?
