Services Meshes are the new hype without any question.. But what do they really bring to the table? A service mesh adds new qualities to your container orchestration: It connects, secures, observes and controls service invocations in a language agnostic way that doesn't require any code changes. This presentation gives you a gentle intro to service mesh. Starting with the shortcomings of Docker and Kubernetes. I will show in a live demo and have a look at how a service mesh bridges to the world of chaos engineering by giving us the possibility to inject errors. To conclude I will analyze if and how a service mesh should evolve into becoming a standard component of a public cloud

643cd45dcfa73b072018046e39ed36d1?s=128

Frank Munz

April 27, 2019
Tweet

Transcript

  1. Globalcode – Open4education Service Mesh Magic in the Cloud Frank

    Munz Senior Technical Evangelist Amazon Web Services @frankmunz
  2. © 2018, Amazon Web Services, Inc. or its Affiliates. All

    rights reserved. About me • Software Architect / DevOps Engineer • Technical Evangelist @ AWS • Published an AWS book • Containers, serverless and a sprinkle of ML & big / fast data @frankmunz
  3. © 2018, Amazon Web Services, Inc. or its Affiliates. All

    rights reserved. 10+ Years Back in Time: SOA ESB = Service Virtualization Layer • Reduces complexity #cx: squared -> linear with ESB • VETO pattern = Validate, Enrich, Transform, Operate • CCC = location transparency, throttling, monitoring, security, audit
  4. © 2018, Amazon Web Services, Inc. or its Affiliates. All

    rights reserved. Splitting the Monolith – A. Cockroft @ AWS https://youtu.be/aBcG57Gw9k0
  5. © 2018, Amazon Web Services, Inc. or its Affiliates. All

    rights reserved. Enterprise SW Modernization -> Microservices Building Blocks / Technical Architecture • Containers • Serverless (AWS Lambda) • Other cloud services • Do NOT stuff everything into a container! • AWS API Gateway, Kinesis, Aurora, Dynamo DB, etc. -> Container / K8s will not make other cloud services redundant
  6. © 2018, Amazon Web Services, Inc. or its Affiliates. All

    rights reserved. Challenges of Containers at Scale • More transient • More distributed and complex • Networking • Scheduling / Resource Management • Not virtualized, but isolated: containers share Linux kernel -> Tooling and orchestration required
  7. © 2018, Amazon Web Services, Inc. or its Affiliates. All

    rights reserved. … so we built a solution for that
  8. © 2018, Amazon Web Services, Inc. or its Affiliates. All

    rights reserved. ECS Easiest way to deploy and manage containers at scale Integration with entire AWS platform ALB, Auto Scaling, Batch, Elastic Beanstalk, CloudFormation, CloudTrail, CloudWatch Events, CloudWatch Logs, CloudWatch Metrics, ECR, EC2 Spot, IAM, NLB, Parameter Store, and VPC Scales to support clusters of any size Service integrations (like ALB and NLB) are at container level 1 2 3
  9. © 2018, Amazon Web Services, Inc. or its Affiliates. All

    rights reserved. Then Kubernetes entered the stage
  10. © 2018, Amazon Web Services, Inc. or its Affiliates. All

    rights reserved. … and devOps ❤ Kubernetes
  11. © 2018, Amazon Web Services, Inc. or its Affiliates. All

    rights reserved. Open source container management platform Helps you run containers at scale Gives you primitives for building modern applications What is Kubernetes (K8s)?
  12. © 2018, Amazon Web Services, Inc. or its Affiliates. All

    rights reserved. “Run Kubernetes for me.”
  13. © 2018, Amazon Web Services, Inc. or its Affiliates. All

    rights reserved. Availability Zone 1 Availability Zone 2 Availability Zone 3 Kubectl EKS Architecture
  14. © 2018, Amazon Web Services, Inc. or its Affiliates. All

    rights reserved. Kubernetes Ressources (incomplete list) Ressource Pod Basic K8s unit, co-located containers Namespace Non-overlapping group of ressources Replica Set Keeps pod replicas running Service Exposes pod at single stable IP Deployment Rolling update of pods Ingress Expose service with static IP to external client Admission Controller Run code after API request, e.g. inject sidecar
  15. © 2018, Amazon Web Services, Inc. or its Affiliates. All

    rights reserved. OSS Hystrix library: code changes required; language specific Service Mesh: decentral, language agnostic, dumb endpoints https://www.infoq.com/articles/microservices-post-kubernetes Shift in Infrastructure Logic ESB: clustered monolith
  16. © 2018, Amazon Web Services, Inc. or its Affiliates. All

    rights reserved. Istio Service Mesh Connect, secure, and observe services • Shift in where functionality is located • Istio = control plane • Set of all Envoy proxies = data plane • Envoy proxy as sidecar in K8s pod • Automatic / manual injection of proxy
  17. © 2018, Amazon Web Services, Inc. or its Affiliates. All

    rights reserved. Istio Service Mesh with Envoy Proxy Add a 5s delay to 10% of all requests
  18. © 2018, Amazon Web Services, Inc. or its Affiliates. All

    rights reserved. User Based Routing Traffic Shifting
  19. © 2018, Amazon Web Services, Inc. or its Affiliates. All

    rights reserved. Envoy Proxy • Level 7 proxy • HTTP, HTTP/2, gRPC, AWS Dynamo DB, MongoDB • C++11 code base , only 8 MB (statically linked) • No language or framework dependencies • No code changes • OSS started at Lyft
  20. © 2018, Amazon Web Services, Inc. or its Affiliates. All

    rights reserved. Service Mesh Cross Cutting Concerns such as retries, timeouts, circuit breaking, fault injection, client-side load balancing, service discovery, security, metrics-collection, A/B deployments, and traffic shifting / mirroring / routing
  21. © 2018, Amazon Web Services, Inc. or its Affiliates. All

    rights reserved. Service Mesh But Docker / Kubernetes can do rolling updates! Yes, but Istio sparates traffic flow from replica deployment
  22. © 2018, Amazon Web Services, Inc. or its Affiliates. All

    rights reserved. A bath tub full of cold water ? K8s rolling update 25% 1 pod at a time … or just wetten your feet? Service Mesh 3% Traffic routing ! ! ! " # ! $❄$❄$❄ Fancy a Swim in the Arctic Sea ? Blue / Green 100% All services at once Microservices Update Strategies
  23. © 2018, Amazon Web Services, Inc. or its Affiliates. All

    rights reserved.
  24. © 2018, Amazon Web Services, Inc. or its Affiliates. All

    rights reserved. Install Istio with Helm $ helm install --wait --name istio \ --namespace istio-system \ install/kubernetes/helm/istio \ --set grafana.enabled=true \ --set tracing.enabled=true \ --set servicegraph.enabled=true $ # K8s label turn on automatic sidecar injection $ kubectl label namespace default istioinjection=enabled
  25. © 2018, Amazon Web Services, Inc. or its Affiliates. All

    rights reserved. Grafana
  26. © 2018, Amazon Web Services, Inc. or its Affiliates. All

    rights reserved. Jaeger
  27. © 2018, Amazon Web Services, Inc. or its Affiliates. All

    rights reserved. Servicegraph
  28. © 2018, Amazon Web Services, Inc. or its Affiliates. All

    rights reserved. Kiali
  29. © 2018, Amazon Web Services, Inc. or its Affiliates. All

    rights reserved. Kiali
  30. © 2018, Amazon Web Services, Inc. or its Affiliates. All

    rights reserved. Customers
  31. © 2018, Amazon Web Services, Inc. or its Affiliates. All

    rights reserved. Snap @AWS Summit in New York 2018 https://youtu.be/mCVdcz01Z-g?t=2052
  32. © 2018, Amazon Web Services, Inc. or its Affiliates. All

    rights reserved. AWS App Mesh
  33. © 2018, Amazon Web Services, Inc. or its Affiliates. All

    rights reserved. App Mesh works across compute services Amazon ECS AWS Fargate Amazon EKS Amazon EC2 Kubernetes on EC2
  34. © 2018, Amazon Web Services, Inc. or its Affiliates. All

    rights reserved. Logging HTTP access logging Amazon CloudWatch Logs Available as container logs on Amazon ECS, Amazon EKS, AWS Fargate Metrics CloudWatch metrics StatsD (with tags) Prometheus Tracing AWS X-Ray Other Envoy tracing drivers Observability
  35. © 2018, Amazon Web Services, Inc. or its Affiliates. All

    rights reserved. Traffic shaping Load balancing Weight targets Service discovery (DNS + AWS Cloud Map) Health checks Retries* Timeouts* Circuit breakers* *Coming soon Traffic Management Routing controls Protocols support (HTTP, TCP, gRPC*) Path-based Header-based* Cookie-based* Host-based*
  36. © 2018, Amazon Web Services, Inc. or its Affiliates. All

    rights reserved. App Mesh Architecture
  37. © 2018, Amazon Web Services, Inc. or its Affiliates. All

    rights reserved. AWS App Mesh Roadmap is Public https://github.com/awslabs/aws-app-mesh-examples
  38. © 2018, Amazon Web Services, Inc. or its Affiliates. All

    rights reserved. Summary • Architect wisely • Running K8s is hard Use a managed K8s service in the cloud. • A Service Meshes complements K8s: It adds observability and traffic management • Istio with Envoy on EKS • AWS App Mesh
  39. © 2018, Amazon Web Services, Inc. or its Affiliates. All

    rights reserved. Open-source Istio and Enovy on AWS EKS Video https://www.youtube.com/watch?v=fDmJf9kWFws
  40. Globalcode – Open4educa0on Muito obrigado! Frank Munz Senior Technical Evangelist

    Amazon Web Services @frankmunz
