PWA, Tools and Frameworks

GDD India Extended 2017, Pune Edition
Find Google Slides @ https://bit.ly/gddx-pune-17

1. PWA, Tools and Frameworks #GDDIndia Extended, Pune Hardik Pithva @hardikpthv
2. PWA • Web applications (actually web pages or websites) • Appear to the user like traditional applications or native mobile applications • Combines the features offered by most modern browsers • It is the best UX
3. 2) Is PWA a framework/lib. such as Angular, React or Vue? PWA Q&A 1) Is PWA a Native App or does it create? 3) Can we use PWAs within the framework/lib.? 4) Can we convert existing websites to PWAs? 5) Is it possible to use PWA features in Hybrid Apps?
4. Alright! But, why PWA?
5. Reliable Fast Engaging PWA is...
6. App Shell • An architecture which is one way to build a PWA • Download, Display and Store/Cache ◦ Minimal HTML, CSS and JavaScript (contents which don’t oftenly change) • Not loaded from the network every time the user visits • Therefore, loads only the necessary content is needed from the network • For SPAs with heavy architecture, App Shell is go-to approach
7. Technology behind PWAs
8. Service Worker • A script(JS) which runs by browser in the background • Separate from webpage, helps to boost performance • Between network and browser (lets to intercept n/w request) • Provides offline experience to the user (no downasaur) • Includes features like Push Notifications, Background Sync
9. if ("serviceWorker" in navigator) { window.addEventListener("load", () => { navigator.serviceWorker.register("./service-worker.js").then( registration => { console.log( "ServiceWorker registration successful with scope: ", registration.scope ); }, err => { console.log("ServiceWorker registration failed: ", err); } ); }); } Registration
10. Prerequisites • Browser support ◦ Chrome (v49+), Firefox (v57+), Edge (v17+) and Safari (TP) ◦ Checkout more here • HTTPS Service Worker (cont’d)
11. Manifest • Simple JSON file contains information about app • Let the browser and web know about app • Includes things like: ◦ a splash screen ◦ theme colors ◦ URL to be opened and so on • Contains unique icon and name so to distinguish • Deployed in your HTML pages using a link tag in the head of document
12. { "short_name": "MovieApp", "name": "Movies", "icons": [ { "src": "launcher-icon-1x.png", "type": "image/png", "sizes": "48x48" }, ... ], "start_url": "index.html?launcher=true" ... } manifest.json <!DOCTYPE html> <html> <head> <title>Movie App</title> <meta name="description" ..> <meta property="og:title" ..> <link rel="manifest" href="/manifest.json"> </head> <body> ... </body> </html> index.html
13. Caching Strategies • Cache only • Network only • Cache, falling back to network or vice versa • Cache & network race • Cache then network • Generic fallback
14. Migration to PWA • HTTPS (if not earlier) • Implement : ◦ Caching strategies ◦ App shell architecture • Configure Manifest • Add features such as Push Notification, Payment API, etc
15. PWA Tooling
16. Why tooling at all! • Increased efficiency in development • Ease of debugging • Code generation • Maintain standard best practices
17. • Under the Application Tab : ◦ Get all details of service worker ◦ Preview manifest ◦ Check cached assets/data ◦ Toggle network status Chrome DevTools
18. • JS libraries and build tools for PWAs • Next version of sw-precache & sw-toolbox • Applies to existing as well as new sites • Automatically generate a service worker that correctly caches resources • Currently offers… ◦ Offline caching ◦ Offline analytics ◦ Background sync
19. • Automated tool for improving : ◦ Performance ◦ Quality ◦ Correctness of web apps • Generates a report on how well the each page did. • Integrated with Chrome as well as Available as Extension • Also available as Node CLI Lighthouse
20. <demo />
21. Test @ flipkart.com
22. Lighthouse Report
23. Specific tools
25. Service Worker with Angular • JSON based declarative configuration • No need to code against low-level/traditional API • User-provided configuration a.k.a. ngsw-config.json • Service worker is generated/added by CLI • Separate dedicated package a.k.a. @angular/service-worker Prerequisites • Angular 5.0.0 or later. • Angular CLI 1.6.0 or later.
26. ngsw-config.json
27. { "index": "/index.html", "assetGroups": [{ "name": "app", "installMode": "prefetch", "resources": { "files": ["/favicon.ico", "/index.html"], "versionedFiles": ["/*.bundle.css", "/*.bundle.js", "/*.chunk.js"] } }, ], "dataGroups": [{ "name": "api-perf", "urls": [...], "cacheConfig": { "strategy": "performance" } } ] } ngsw-config.json
28. ngsw-config.json Asset groups • Name * • Install mode • Update mode • Resources ◦ File ◦ Version ◦ URL Data groups • Name * • URLs • Version • Cache configuration ◦ Max size ◦ Max age ◦ Timeout ◦ Strategy
29. Setup
30. Starting from scratch yarn global add @angular/cli Install CLI ng new ng-pwa-app --service-worker cg new ng-pwa-app Create App ng build --prod Build App
31. Existing angular app ng set apps.0.serviceWorker=true Enable SW yarn add @angular/service-worker Add SW Lib.
32. Import module import { ServiceWorkerModule } from "@angular/service-worker"; import { environment } from "environments/environment"; @NgModule({ imports: [ ServiceWorkerModule.register("/ngsw-worker.js", { enabled: environment.production }) ], .... }) app.module.ts
33. Create ngsw-config.json { "index": "/index.html", "assetGroups": [{ ... }, ], "dataGroups": [ {...} ] } src/ngsw-config.json
34. Build and Run angular app ng build --prod Production Web Server for Chrome • An open source (MIT) HTTP server for Chrome • Open Chrome App and Select dist folder • Hit the URL http://127.0.0.1:8887
35. <demo />
36. View @ bit.ly/ng-movie
37. Lighthouse Report
38. Thank You Hardik Pithva @hardikpthv
39. Get the content and stay tuned • Slides @ goo.gl/iiVUic • Repo. @ github.com/online-edu/ng-movies • Demo @ bit.ly/ng-movie • Follow @ github.com/hardikpthv
40. Extended
