1. Resilient and Fast Persistent Container Storage Leveraging Linux’s Storage Functionalities Philipp Reisner, CEO LINBIT 1
2. Leading Open Source OS based SDS COMPANY OVERVIEW REFERENCES • Developer of DRBD and LINSTOR • 100% founder owned • Offices in Europe and US • Team of highly experienced Linux experts • Exclusivity Japan: SIOS • Leading Open Source Block Storage (included in Linux Kernel (v2.6.33) • Open Source DRBD supported by proprietary LINBIT products / services • OpenStack with DRBD Cinder driver • Kubernetes Driver • Install base of >2 million PRODUCT OVERVIEW SOLUTIONS LINBIT SDS Since 2016 Perfectly suited for SSD/NVMe high performance storage LINBIT HA, LINBIT DR Market leading solutions since 2001, over 600 customers Ideally suited to power HA and DR in OEM appliances (Cisco, IBM, Oracle)
3. 3 LINBIT SDS When? Why? What?
4. 4 When is LINBIT SDS a fit? Transaction Processing • Oracle DB • PostgreSQL • MariaDB • Message queuing systems Analytic Processing • DB2 Warehouse • And similar read intensive workloads PersistentVolumes ...for Containers • Kubernetes • Nomad • Docker Virtualization • OpenStack • CloudStack • OpenNebula • XCP-ng • Proxmox
5. 5 Why is LINBIT SDS so fast? Layout at volume allocation • All participating machines have full replicas, which machines participate determined when creating a volume. • Be faster at IO submission time • Saving on CPU/memory In Kernel data-path • Reduce number of context switches • Saving on CPU/memory resources • Minimal latency for block-IO operations • Optional load-balancing for READs Hyper-Converged Very well suitable for hyper-converged deployment • Reduced network load for reads • Reduces latency • LINBIT SDS’ Low resource consumption leaves most of CPU and memory for workload. About 0.5% of a single core are consumed by DRBD under heavier IO load (measured with an analytics DB) Build on existing components • DRBD, LVM, ZFS, LUKS, VDO, ... • Help day2 operations by leveraging on the opera tion teams prior knowledge • Build on the shoulders of giants
6. 6 What is LINBIT SDS doing? Storage Allocation • 3 to 1000s of nodes • Multiple tiers • Multi tenancy • Complex policies Chassis - rack - room Network • Multiple NICs per server • Multiple networks • RDMA • TCP Business continuity • Continuous data protection • Multiple sites • Backups SSD - disk - cloud Data Replication • Persistence & availability • Sync / async • 2,3 or more replicas • Consistency groups • Quorum
7. 7 Linux Storage Gems LVM, RAID, SSD cache tiers, deduplication, targets & initiators
8. 8 Linux's LVM physical volume physical volume logical volume logical volume physical volume snapshot Volume Group
9. 9 Linux's LVM • based on device mapper • original objects • PVs, VGs, LVs, snapshots • LVs can scatter over PVs in multiple segments • thinlv • thinpools = LVs • thin LVs live in thinpools • multiple snapshots became efficient!
10. 10 Linux's LVM physical volume physical volume logical volume thinpool physical volume snapshot thin-LV thin-LV thin-sLV Volume Group
11. 11 Linux's RAID • original MD code • mdadm command • Raid Levels: 0,1,4,5,6,10 • now available in LVM as well • device mapper interface for MD code • do not call it ‘dmraid’; that is software for hardware fake-raid • lvcreate --type raid6 --size 100G VG_name RAID1 A4 A3 A2 A1 A4 A3 A2 A1
12. 12 Linux’s DeDupe • Virtual Data Optimizer (VDO) since RHEL 7.5 • Red hat acquired Permabit and is GPLing VDO • Linux upstreaming is in preparation • in-line data deduplication • kernel part is a device mapper module • indexing service runs in user-space • async or synchronous writeback • recommended to be used below LVM
13. 13 SSD cache for HDD • dm-cache • device mapper module • accessible via LVM tools • bcache • generic Linux block device • slightly ahead in the performance game • dm-write-cache • for combinding PMEM & NVMe drives
14. 14 Linux’s targets & initiators • Open-ISCSI initiator • Ietd, STGT, SCST • mostly historical • LIO • iSCSI, iSER, SRP, FC, FCoE • SCSI pass through, block IO, file IO, user-specific-IO • NVMe-OF & NVMe/TCP • target & initiator Initiator Target IO-requests data/completion
15. 15 ZFS on Linux • Ubuntu eco-system only • has its own • logic volume manager (zVols) • thin provisioning • RAID (RAIDz) • caching for SSDs (ZIL, SLOG) • and a file system!
16. 16 Put in simplest form
17. 17 DRBD – think of it as ... Target Initiator IO-requests data/completion RAID1 A4 A3 A2 A1 A4 A3 A2 A1
18. 18 DRBD – another way to look at it
19. 19 DRBD Roles: Primary & Secondary Primary Secondary replication
20. 20 DRBD – multiple Volumes • consistency group Primary Secondary replication
21. 21 DRBD – up to 32 replicas • each may be synchronous or async Primary Secondary Secondary
22. 22 DRBD – Diskless nodes • intentional diskless (no change tracking bitmap) • disks can fail Primary Secondary Secondary
23. 23 DRBD - more about • a node knows the version of the data is exposes • automatic partial resync after connection outage • checksum-based verify & resync • split brain detection & resolution policies • fencing • quorum • multiple resouces per node possible (1000s) • dual Primary for live migration of VMs only!
24. 24 DRBD Recent Features & ROADMAP • Recent • meta-data on PMEM/NVDIMMS • improved, fine-grained locking for parallel workloads • Eurostars grant: DRBD4Cloud • started DRBD-9.1 • ROADMAP • performance optimizations • replace „stacking” • production release of WinDRBD
25. 25 The combination is more than the sum of its parts
26. 26 LINSTOR - goals • storage build from generic Linux nodes • for SDS consumers (K8s, OpenStack, OpenNebula) • building on existing Linux storage components • multiple tenants possible • deployment architectures • distinct storage nodes • hyperconverged with hypervisors / container hosts • LVM, thin LVM or ZFS for volume management (stratis later) • Open Source, GPL
27. 27 Example
28. 28 LINSTOR - Hyperconverged storage devices hypervisor & storage VM storage devices hypervisor & storage storage devices hypervisor & storage storage devices hypervisor & storage storage devices hypervisor & storage storage devices hypervisor & storage VM
29. 29 LINSTOR - VM migrated storage devices hypervisor & storage storage devices hypervisor & storage storage devices hypervisor & storage storage devices hypervisor & storage storage devices hypervisor & storage storage devices hypervisor & storage VM VM
30. 30 LINSTOR - add local replica storage devices hypervisor & storage storage devices hypervisor & storage storage devices hypervisor & storage storage devices hypervisor & storage storage devices hypervisor & storage storage devices hypervisor & storage VM VM
31. 31 LINSTOR - remove 3rd copy storage devices hypervisor & storage storage devices hypervisor & storage storage devices hypervisor & storage storage devices hypervisor & storage storage devices hypervisor & storage storage devices hypervisor & storage VM VM
32. 32 Architecture, objects and functions
33. 33 LINSTOR Controller LINSTOR Satellite LINSTOR Satellite LINSTOR Satellite LINSTOR Controller LINSTOR Satellite LINSTOR Controller LINSTOR Satellite LINSTOR Protocol TCP/IP SSL/TLS API Library CLI
34. 34 LINSTOR Objects • Nodes • Resources  Volumes • Snapshots • Storage Pools  shared • Resource groups • Properties  Aux properties node A LVM VG node C shared LVM VG DRBD res. 2 replicas encryped volume node B ZFS pool plain volume Resource Groups Resource Groups
35. 35 LINSTOR Storage Layers LVM VG, ZFS zPool, Exos, OpenFlex, SPDK, shared LVM VG Mid (opt & multiple) Bottom (required) LUKS (encryption), caches, NVMe target & initiator Top (opt) DRBD Below (opt) Bottom (required) VDO (deduplication), software RAID
36. 36 LINSTOR data placement Example policy 3 way redundant, where two copies are in the same rack but in diffeent fire compartments (synchronous) and a 3rd replica in a different site (asynchronous) Example tags rack = number room = number site = city • arbitrary tags on nodes • require placement on equal/different/named tag values • prohibit placements with named existing volumes • different failure domains for related volumes
37. 37 LINSTOR network path selection • a storage pool may preferred a NIC • express NUMA relation of NVMe devices and NICs • DRBD’s multi pathing supported • load balancing with the RDMA transport • fail-over only with the TCP transport
38. 38 LINSTOR Recent & ROADMAP • Recent • Volume, snapshot and snapshot-delta shipment • between LINSTOR clusters (disaster recovery) • to S3 buckets (backup) • K8s CRDs as LINSTOR’s database • Eliminates need for dedicated etcd • Roadmap • Public cloud, storage drivers: EBS on AWS, Azure disks, Google’s Persistent Disk
39. 39 in the Software Ecosystem
40. 40 LINSTOR connectors Kubernetes: CSI-driver, Operator, Stork, HA, YAMLs, kubectl plugin Nomad: CSI-driver OpenStack: Cinder-driver since “Stein” (April 2019) OpenNebula: Storage Driver Proxmox VE: storage plugin XCP-ng (in final beta) Apache CloudStack
41. 41 Piraeus Datastore • CSI-driver, Operator, Stork, HA, helm-chart, kubectl • Publicly available containers of all components • Joint effort of LINBIT & DaoCloud • In CNCF Sandbox https://github.com/piraeusdatastore https://piraeus.io
42. 42 LINBIT SDS & Piraeus Datastore LINBIT SDS Piraeus Datastore Container base Img Red hat UBI Debian Available drbd.io LINBIT customers only dockerhub, quay.io publicly Support ✓ Enterprise, incl 24/7 Community only OpenShift/RHCOS ✓ n.a. DRBD driver Pre-compiled for RHEL/SLES kernels Compile from source Contains LINSTOR, DRBD, operator, CSI-driver, Stork, HA, helm-chart, kubectl
43. 43 “Naming is hard” – Phil Karlton Translation Matrix LINSTOR Resource Group Resource/Volume Kubernetes storageClass + file system → persistentVolume Nomad storageClass + file system → persistentVolume OpenNebula Datastore Image OpenStack Volume Type Volume Proxmox Storage Pool Volume XCP-ng Storage Repository (SR) Virtual disk Image (VDI) CloudStack Primary storage Volume
44. 44 Summary DRBD Diskless NVMe - oF ISCSI Block transport systems Orchestrators Block Storage Features DRBD LUKS DM - Cache VDO Hardware HDD Node-level volume management LVM ZFS SSD NVMe PMEM
45. 45 Thank you https://www.linbit.com
46. 46 Appendix Slides: Example Disaggregated Architecture
47. 47 LINSTOR – disaggregated stack storage node storage node hypervisor VM VM storage node storage node hypervisor VM VM hypervisor
48. 48 LINSTOR / failed Hypervisor storage node storage node storage node storage node hypervisor VM VM hypervisor VM VM
49. 49 LINSTOR / failed storage node storage node hypervisor VM VM storage node storage node hypervisor VM VM hypervisor
50. 50 Appendix Slides: Possible Storage Stacks
51. 51 LINSTOR Storage Stacks • Disaggregated Storage • Classic enterprise workloads • Data bases • Message queues • Typical Orchestrators • OpenStack, OpenNebula • Kubernetes • Flexibly redundancy (1-n) • HDDs, SSDs, NVMe SSDs DRBD App DRBD DRBD
52. 52 LINSTOR Storage Stacks • Hyperconverged • Classic enterprise workloads • Data bases • Message queues • Typical Orchestrators • OpenStack, OpenNebula • Kubernetes • Flexibly redundancy (1-n) • HDDs, SSDs, NVMe SSDs DRBD DRBD App DRBD
53. 53 LINSTOR Storage Stacks • Disaggregated • Classic enterprise workloads • Data bases • Message queues • Typical Orchestrators • OpenStack, OpenNebula • Kubernetes • NVMe SSDs, SSDs App NVMe-oF Initiator NVMe-oF Target NVMe-oF Initiator NVMe-oF Target Raid1
54. 54 LINSTOR Storage Stacks • Disaggregated • Cloud native workload • Ephemeral storage • Typical Orchestrator • Kubernetes • Application handles redundancy • Best suited for NVMe SSDs App NVMe-oF Initiator NVMe-oF Target
55. 55 LINSTOR Storage Stacks • Hyperconverged • Cloud native workload • Ephemeral storage • PMEM optimized data base • Typical Orchestrator • Kubernetes • Application handles redundancy • PMEM, NVDIMMs App
56. 56 LINSTOR Slicing Storage • LVM or ZFS • Thick – pre allocated • Best performance • Less features • Thin – allocated on demand • Overprovisioning possible • Many snapshots possible • Optional • Encryption on top • Deduplication below
