A Step-by-Step Guide to Kotlin Flow 手把手帶你認識 Kotlin Flow
In Android development, you might be already familiar with RxJava. Recently, Jetbrains released a reative programming library, Kotlin Flow. It is an asynchronous stream library based on top of Kotlin Coroutines. In this talk, we will show you the pros/cons of Kotlin Flow and explain how it works by analyzing its source code. Since Flow shares similarities with Rx streams, we will also talk about the comparison between Flow and Rx. Additionally, we will show the methods of testing Flow and examples of migrating from Rx to Flow.
Ivan
August 01, 2020
Transcript
91 slides
-
- 什麼是 Reactive Programming? Abstract Kotlin Flow - Flow 的基本用法
- Flow 的源碼 - Flow 與 RxJava 的比較 - 如何從 RxJava 轉到 Flow - Kotlin Flow Testing -
我們是誰? 沒看過帥哥嗎?現在你可以看清楚一點 Android Developer @ PicCollage 彥彬 RxJava experience: 4
years Community: Android Taipei, Android 讀書會 Senior Engineer @ ETtoday Ivan Wu Community: Taiwan Kotlin User Group -
Imperative Programming fun foo() { val a = 1 val
b = 2 val c = a + b } -
2 3 4 1 2 3 4 3 4 5
7 8 A B C -
Flow 的 基本用法 val numberFlow = flowOf(1, 2, 3, 4)
numberFlow.map { element -> element + 1} .collect { number -> println(number) } Producer Consumer -
Transformer val numberFlow = flowOf(1, 2, 3, 4) val anotherFlow:
Flow<Int> = numberFlow.map { element -> element + 1} anotherFlow.collect { number -> println(number) } -
- Function type Kotlin basic syntax Kotlin Flow - Lambda
- Higher order function -
Function type PRESENTATION val addOne: (Int) -> Int = {
number: Int -> number + 1 } -
Lambda PRESENTATION val addOne: (Int) -> Int = { number:
Int -> number + 1 } -
Higher order function PRESENTATION fun foo() { higherOrderFunction { text
-> println("Hello world! $text") } } fun higherOrderFunction(lambda: (String) -> Unit) { lambda.invoke("from lambda") } -
Producer in Flow PRESENTATION fun <T> flowOf(vararg elements: T): Flow<T>
= flow { for (element in elements) { emit(element) } } -
PRESENTATION fun <T> flowOf(vararg elements: T): Flow<T> = flow {
for (element in elements) { emit(element) } } fun <T> flow(block: FlowCollector<T>.() -> Unit) = SafeFlow(block) private class SafeFlow<T>( private val block: FlowCollector<T>.() -> Unit ): AbstractFlow<T>() { override fun collectSafely(collector: FlowCollector<T>) { collector.block() } } -
PRESENTATION fun <T> flowOf(vararg elements: T): Flow<T> = flow {
for (element in elements) { emit(element) } } fun <T> flow(block: FlowCollector<T>.() -> Unit) = SafeFlow(block) private class SafeFlow<T>( private val block: FlowCollector<T>.() -> Unit ): AbstractFlow<T>() { override fun collectSafely(collector: FlowCollector<T>) { collector.block() } } -
PRESENTATION fun <T> flowOf(vararg elements: T): Flow<T> = flow {
for (element in elements) { emit(element) } } fun <T> flow(block: FlowCollector<T>.() -> Unit) = SafeFlow(block) private class SafeFlow<T>( private val block: FlowCollector<T>.() -> Unit ): AbstractFlow<T>() { override fun collectSafely(collector: FlowCollector<T>) { collector.block() } } -
PRESENTATION fun <T> flowOf(vararg elements: T): Flow<T> = flow {
for (element in elements) { emit(element) } } fun <T> flow(block: FlowCollector<T>.() -> Unit) = SafeFlow(block) private class SafeFlow<T>( private val block: FlowCollector<T>.() -> Unit ): AbstractFlow<T>() { override fun collectSafely(collector: FlowCollector<T>) { collector.block() } } -
PRESENTATION fun <T> flowOf(vararg elements: T): Flow<T> = flow {
for (element in elements) { emit(element) } } fun <T> flow(block: FlowCollector<T>.() -> Unit) = SafeFlow(block) private class SafeFlow<T>( private val block: FlowCollector<T>.() -> Unit ): AbstractFlow<T>() { override fun collectSafely(collector: FlowCollector<T>) { collector.block() } } -
Produce elements 做投影片做到崩潰,讓我講個幹話 fun <T> flowOf(vararg elements: T): Flow<T> =
flow { for (element in elements) { emit(element) } } Lambda => Lazy evaluation -
fun <T> flowOf(vararg elements: T): Flow<T> = flow { for
(element in elements) { emit(element) } } fun <T> flow(block: FlowCollector<T>.() -> Unit) = SafeFlow(block) private class SafeFlow<T>( private val block: FlowCollector<T>.() -> Unit ): AbstractFlow<T>() { override fun collectSafely(collector: FlowCollector<T>) { collector.block() } } 我敢打賭你現在的頭一定是歪的 -
聽完這場大家都落枕 fun <T> flowOf(vararg elements: T): Flow<T> = flow {
for (element in elements) { emit(element) } } fun <T> flow(block: FlowCollector<T>.() -> Unit) = SafeFlow(block) private class SafeFlow<T>( private val block: FlowCollector<T>.() -> Unit ): AbstractFlow<T>() { override fun collectSafely(collector: FlowCollector<T>) { collector.block() } } -
Function with Receiver Type 這頁聽不懂很就算了,佛度有緣人 A function that can access
member functions/variables without real class instance -
PRESENTATION fun <T> flowOf(vararg elements: T): Flow<T> = flow {
for (element in elements) { emit(element) } } fun <T> flow(block: FlowCollector<T>.() -> Unit) = SafeFlow(block) private class SafeFlow<T>( private val block: FlowCollector<T>.() -> Unit ): AbstractFlow<T>() { override fun collectSafely(collector: FlowCollector<T>) { collector.block() } } -
PRESENTATION interface FlowCollector<T> { // Collect the value emitted by
the upstream. // This method is not thread-safe and should not be invoked concurrently. fun emit (value: T) } -
PRESENTATION private class SafeFlow<T>( private val block: FlowCollector<T>.() -> Unit
): AbstractFlow<T>() { override fun collectSafely(collector: FlowCollector<T>) { collector.block() } } abstract class AbstractFlow<T>: Flow<T> { override fun collect(collector: FlowCollector<T>) { val safeCollector = SafeCollector(collector, coroutineContext) try { collectSafely(collector) } finally { safeCollector.releaseInterrupted() } } } -
是不是很期待看到幹話啊? private class SafeFlow<T>( private val block: FlowCollector<T>.() -> Unit
): AbstractFlow<T>() { override fun collectSafely(collector: FlowCollector<T>) { collector.block() } } abstract class AbstractFlow<T>: Flow<T> { override fun collect(collector: FlowCollector<T>) { val safeCollector = SafeCollector(collector, coroutineContext) try { collectSafely(collector) } finally { safeCollector.releaseInterrupted() } } } -
SafeCollector 就叫你不要看了 - Just a delegate class invoke “collector.emit()” for
you - Source code: https://github.com/Kotlin/kotlinx.coroutines/blob/master/kotlinx-coroutines-core/jv m/src/flow/internal/SafeCollector.kt -
PRESENTATION interface Flow<out T> { fun collect(collect: FlowCollector<T>) } fun
<T> Flow<T>.collect(action: (value: T) -> Unit) = collect(object: FlowCollector<T> { override fun emit(value: T) = action(value) }) } -
好了拉!快結束了 interface Flow<out T> { fun collect(collect: FlowCollector<T>) } fun
<T> Flow<T>.collect(action: (value: T) -> Unit) = collect(object: FlowCollector<T> { override fun emit(value: T) = action(value) }) } Anonymous class -
Let’s lookback val numberFlow = flowOf(1, 2, 3, 4) numberFlow.map
{ element -> element + 1} .collect { number -> println(number) } -
Bonus! fun <T, R> Flow<T>.map(transform: (value: T) -> R): Flow<R>
= transform { value -> return emit(transform(value)) } fun <T, R> Flow<T>.transform( transform: FlowCollector<R>.(value: T) -> Unit ): Flow<R> = flow { collect { value -> return@collect transform(value) } } Transformer -
Bonus! fun <T, R> Flow<T>.map(trnsform: (value: T) -> R): Flow<R>
= transform { value -> return emit(transform(value)) } fun <T, R> Flow<T>.transform( transform: FlowCollector<R>.(value: T) -> Unit ): Flow<R> = flow { collect { value -> // kludge, without it Unit will be returned and TCE won't kick in, KT-28938 return@collect transform(value) } } -
Bonus! fun <T, R> Flow<T>.map(transform: (value: T) -> R): Flow<R>
= transform { value -> return emit(transform(value)) } fun <T, R> Flow<T>.transform( transform: FlowCollector<R>.(value: T) -> Unit ): Flow<R> = flow { collect { value -> transform(value) } } -
Bonus! fun <T, R> Flow<T>.map(transform: (value: T) -> R): Flow<R>
= flow { collect { value -> emit(transform(value)) } } -
真的很暈 fun <T, R> Flow<T>.map(transform: (value: T) -> R): Flow<R>
= flow { flowCollector -> collect { value -> emit(transform(value)) } } OldFlow NewFlow, NewCollector -
Comparison Stream Types • Flow ◦ Simple ◦ Kotlin language
features support ◦ Smaller lib size ◦ Less operators • RxJava ◦ Steep learning curve ◦ Additional dependencies ◦ Inflexible structure ◦ More operators -
Stream Types RxJava VS. Flow • RxJava ◦ Observable ◦
Flowable ▪ Same as Observable, but with backpressure support. ◦ Single ◦ Maybe ▪ It might complete without providing any value. ◦ Completable ▪ Without emitting values. • Flow ◦ Just... Flow. -
Example 1 Observable .just("Pikachu", "John", "Blabla") .subscribe { name ->
println(name) } flowOf("Pikachu", "John", "Blabla") .collect { name -> println(name) } -
Example 2 Single.just(6) .subscribe { number -> println(number) } flow
{ emit(6) } .collect { number -> println(number) } -
Example 3 Observable .just("Pikachu", "John", "Blabla") .map { names ->
names[5] } .subscribe( { ch -> println(ch) }, { e -> println(e) }, { println("Completed") } ) flowOf("Pikachu", "John", "Blabla") .map { names -> names[5] } .catch { e -> println(e) } .onCompletion { println("Completed") } .collect { ch -> println(ch) } -
Threading Stream Types • RxJava Schedulers ◦ io ◦ computation
◦ mainThread • Flow Dispatchers ◦ IO ◦ Default (for CPU-consuming code) ◦ Main -
Threading Operators Stream Types • RxJava ◦ subscribeOn ◦ observeOn
• Flow ◦ flowOn ◦ CoroutineScope -
Threading Operators (cont.) • In RxJava, we declare start and
modify chain below. observeSomething() .subscribeOn(io()) .observe(mainThread()) .subscribeOn(computation()) .subscribe { result -> println(result) } -
Threading Operators (cont.) • In Kotlin Flow, we have end
declared and can modify chain above. CouroutineScope(Job() + Dispatchers.Main).launch { observeSomething() .flowOn(Dispathcers.IO) .map { result -> result.length } .flowOn(Dispatchers.Default) .collect { result -> println(result) } } -
Migration From RxJava to Flow Stream Types • No need
to do the whole migration all at once. ◦ The commits will be huge. ◦ Making incremental changes might be a good idea! • Incremental migration ◦ Use kotlinx-coroutines-rx2 • Kotlinx-coroutines-rx2 ◦ Observables transformation ◦ Suspending extensions -
Observable to Flow runBlocking { Observable.just(1, 2, 3, 4, 5)
.asFlow() .flowOn(Dispatchers.IO) .collect { } } -
Flow to Observable flowOf(1, 2, 3, 4, 5) .asObservable() .subscribeOn(Schedulers.io())
.observeOn(mainThread()) .subscribe() -
Suspend Functions Stream Types • A function that can be
paused and resumed at a later time. • Executes a long running operation and wait for it to complete without blocking -
Coroutine Builders Stream Types • runBlocking ◦ Bridge between regular
and suspend functions • Launch ◦ Fire and forget • Async ◦ Expect result -
Using Mocking Libs to test Flow Stream Types • Flow
can be easily tested by using mocking libraries. • Use Mocking Libs ◦ Mockito-kotlin ◦ MockK -
Preparation Preparation data class User(val name: String, val id: Long)
interface Service { fun getUser(): User } class ApiService : Service { override fun getUser() = User("John", 1L) } -
Preparation Preparation class UserRepository(private val service: Service) { fun getUser():
Flow<User> = flow { emit(service.getUser()) } } infix fun Any?.shouldBe(expect: Any?) { Assert.assertEquals(expect, this) } -
Using Mocking Libs to test Flow Preparation @Test fun `Test
getting an user info by MockK`() = runBlocking { } val fakeUser = User("Doe", 2L) val mockApiService = mockk<ApiService>(relaxed = true) every { mockApiService.getUser() } returns fakeUser val userRepository = UserRepository(mockApiService) userRepository.getUser().collect { it shouldBe fakeUser } -
Flow Assert Stream Types • It is from SqlDelight lib
◦ There is another lib also has flow assert, called Kotlin flow test observer. • An extension function of Flow ◦ Flow<T>.test(timeout: Long, validate: suspend FlowAssert<T>.() -> Unit) • Makes expressions more specific ◦ ExpectedItem ◦ ExpectedError ◦ ExpectedComplete • Takes advantage of Channels API and Coroutines API -
Concept Concept • Under the hood, it uses Channels to
test flow. Flow Items Unlimited Buffer Channel FlowAssert expectedItem() expectedError() expectedComplete() Query the Channel Reference: https://proandroiddev.com/kotlin-flow-assert-ff45465c01c0 -
Flow Assert Flow Assert @Test fun `Test getting an user
info by Flow Assert`() = runBlocking { } val fakeUser = User("Pikachu", 3L) val fakeApiService = provideFakeService(fakeUser) val userRepository = UserRepository(fakeApiService) userRepository.getUser().test { expectItem() shouldBe fakeUser expectComplete() } -
