1. jgs
   SER 431
   Advanced Graphics
   Lecture 23: Quiz 08
   Javier Gonzalez-Sanchez
   javiergs@asu.edu
   PERALTA 230U
   Office Hours: By appointment


   View Slide

2. jgs
   Quiz 08


   View Slide

3. Javier Gonzalez-Sanchez | SER431 | Fall 2018 | 2
   jgs
   Requirements
   § 05% - Submit 3 CPP file. One file and only one per problem. No textures
   at all. Thus, no BMP. Neither OBJ, PRJ, SLN, XYZ, etc.
   § 10% - Keep the functionality of moving and zooming the scene with the
   mouse.
   § 10% - Clean code. You are Software Engineers


   View Slide

4. Javier Gonzalez-Sanchez | SER431 | Fall 2018 | 3
   jgs
   Program 1
   30% - a tree fractal as shown below.
   1) No leaves
   2) It does not uses cylinders but boxy branches
   Advice: draw one and use scale and rotate. Every level has a smaller size.


   View Slide

5. Javier Gonzalez-Sanchez | SER431 | Fall 2018 | 4
   jgs
   Program 2
   30% - a Koch snowflake with
   1) A menu that allows select diverse levels ( 0 to 7 at least). 0 is a triangle.
   2) When selecting a new level value the process begins


   View Slide

6. Javier Gonzalez-Sanchez | SER431 | Fall 2018 | 5
   jgs
   Requirements
   30% - a lightening bolt
   1) Using materials and light effects.
   2) Bright in all visible faces. And every iteration is thinner than the previous
   3) No GL_LINE_*


   View Slide

7. jgs
   SER431 Advanced Graphics
   Javier Gonzalez-Sanchez
   javiergs@asu.edu
   Fall 2018
   Disclaimer. These slides can only be used as study material for the class SER431 at ASU. They cannot be
   distributed or used for another purpose.


   View Slide
