Using Kafka to Discover Events Hidden in your Database

Is your database the center of everything? Do you have multiple applications, batch jobs, and direct consumers hitting your database? In order to cover everywhere an event takes place would you need to update multiple legacy services? Moving to event-driven development can seem overwhelming when faced with this scenario; that’s where Kafka comes in!

Using Derivative Events, Change Data Capture (CDC) and Kafka Streams gives you access to every single event in your space—if you only know where to look.

In this talk we’ll discuss:
• The properties in a CDC message used in identifying events
• Techniques for defining high-level events and how to sniff them out using Kafka Streams
• How to define predicates for CDC events
• Recommendations on handling events that require more than one table

We’ll wrap up by discussing how to structure your event schema to handle a mix of data derived and more traditionally produced events.

Transcript

1. Anna McDonald Twitter: @jbfletch_ <- fully committed to the underscore GitHub: jbfletch 1
2. ARE YOU IN THE RIGHT TALK? Does your environment look like... Super Fancy Half Fancy help. 2 @jbfletch_
3. Event Driven Overview 3 @jbfletch_
4. Event Notification 4 @jbfletch_
5. Event Carried State Transfer 5 @jbfletch_
6. Event Sourcing Fundamental Test: Do you have the ability to blow away the current application state and rebuild from an event store? 6 @jbfletch_
7. A Tale of Two Types of Events Primary Derivative CC Image courtesy of Francoise on Flickr CC Image courtesy of OtterBox on Flickr 7 @jbfletch_
8. Primary Events Derivative Events Services are Easy to Deploy Requires 4 live chickens and a complicated interpretive dance to be granted safe passage to deploy One Service per Function, No duplication Shadow Clone Jutsu! Code changes can be modeled as: {Easy to Make, Easy to Test, Easy to push} Code changes can be modeled as: {Complicated to Make, Brutal to Test, Bureaucratic to push} 8 @jbfletch_
9. I promised you mold. 9 @jbfletch_
10. Prepare to go eventing 10 @jbfletch_
11. “To find events one must know what to look for” me talking to myself, on August 27th, 2019 Know the Events that matter 11 @jbfletch_
12. “To find events one must know what to look for” me talking to myself, on August 27th, 2019 Know your Systems Know the Events that matter 12 @jbfletch_
13. “To find events one must know what to look for” me talking to myself, on August 27th, 2019 Know your System Know the Events that matter Capture Broad Categories of Events 13 @jbfletch_
14. Derivative Events Derivative eventing is quite literally deriving events from something that has been observed. 14 @jbfletch_
15. Observe Find a Durable Event Source Define an Event Profile System Logs DB User Logs 1 2 WANTED 15 @jbfletch_
16. Flashback! mySQL Debezium FREEDOM 16 The truth is in the log based CDC @jbfletch_
17. CDC Overview MySQL inserts: op_type: I, after struct Debezium 17 @jbfletch_
18. CDC Overview MySQL inserts: op_type: I, after struct updates: op_type: U, before,after struct Debezium 18 @jbfletch_
19. CDC Overview MySQL inserts: op_type: I, after struct updates: op_type: U, before,after struct deletes: op_type: D, before struct Plus optional tombstone message Debezium 19 @jbfletch_
20. Observe Find a Durable Event Source Define an Event Profile System Logs DB User Logs 1 2 WANTED 20 @jbfletch_
21. Becoming an event profiler Trigger the event in the source system Review the CDC Messages generated during the event Find the event fingerprint that signifies completeness WANTED 21 @jbfletch_
22. Becoming an event profiler Trigger the event in the source system Review the CDC Messages generated during the event Find the event fingerprint that signifies completeness WANTED 22 @jbfletch_
23. Becoming an event profiler Trigger the event in the source system Review the CDC Messages generated during the event Find the event fingerprint that signifies completeness WANTED 23 @jbfletch_
24. Example Profiles signifying completeness Simple order placed event: • Op_type of insert, after has non null order_number 24 @jbfletch_
25. Example Profiles signifying completeness Simple order placed event: • Op_type of insert, after has non null order_number • Op_type of update, before has a null order_number, after has a non null order number 25 @jbfletch_
26. Example Profiles signifying completeness Simple order placed event: • Op_type of insert, after has non null order_number • Op_type of update, before has a null order_number, after has a non null order number • Op_type of update, before has a null crazy_random_field, after has a non null crazy_random_field and a non null order number 26 @jbfletch_
27. Complex Events Multiple Tables Multiple Sources MySQL Oracle What constitutes event completeness? 27 @jbfletch_
28. Order and Items example Order # 42 Total # Items 3 28 @jbfletch_
29. 29 Flow Diagram @jbfletch_
30. Plan of attack 30 We need both of these things to be true before we fire the event: Order # 42 Total # Items 3 Order Event Aggregate @jbfletch_
31. How do we wait for all items to arrive? 31 @jbfletch_
32. What is the minimum information we need to know to be able to determine event completeness for items? 32 @jbfletch_ Total Number of items per order
33. 33 Flow Diagram @jbfletch_
34. Basic Central Event Service Setup Filter using the event profile: op_type = “I” to create: KTable<OrderId, Order> orderTableKeyOrderId <- Orders that match our order created event profile KStream<ItemId,Items> itemsKeyedByItemIdStream <- Items that match our order created event profile KTable<OrderId,NumberOfItems> totalNumberofItemsTable <- Number of items in each order 34 1 2 3
35. groupBy + aggregate + join + filter KTable<OrderId, ArrayList<Items>> preItemsTable = itemsKeyedByItemIdStream(ItemId,Items) .groupBy(ORDER_ID) ← OrderId: 42 .aggregate(ArrayList::new, add(Items), return null for TS) .join(totalNumberofItemsTable) <- itemCount: 3 Optional join allows for the propagation of total order items to each item 35 1 2 3 @jbfletch_
36. groupBy + aggregate + join + filter KTable<OrderId, ArrayList<Items>> preItemsTable = itemsKeyedByItemIdStream<ItemId,Items> .groupBy(ORDER_ID) ← OrderId: 42 .aggregate(ArrayList::new, add(Items), return null for TS) .join(totalNumberofItemsTable) <- itemCount: 3 Optional join allows for the propagation of total order items to each item 36 1 2 3 @jbfletch_
37. groupBy + aggregate + join + filter KTable<OrderId, ArrayList<Items>> preItemsTable = itemsKeyedByItemIdStream(ItemId,Items) .groupBy(ORDER_ID) ← OrderId: 42 .aggregate(ArrayList::new, add(Items), return null for TS) .join(totalNumberofItemsTable) <- itemCount: 3 Optional join allows for the propagation of total order items to each item 37 1 2 3 @jbfletch_
38. groupBy + aggregate + join + filter KTable<OrderId, ArrayList<Items>> fullItemsTable = preItemsTable .filter((k,v)-> v.size() == v.get(0).get(“itemCount”).asInt()) <- This filter will block until all 3 item lines are in the array 38 4 @jbfletch_
39. Part Deux 39 How can we be sure the order message has arrived? Order # 42 Total # Items 3 Order Event Aggregate @jbfletch_
40. Thou shall not pass!!! Using inner joins 40 KTable fullOrderTable = orderTableKeyOrderId .join(fullItemsTable, <- only contains orders with all items arrived (orderNode, itemNodes) -> { construct and return order placed event aggregate }) @jbfletch_
41. Step 2 41 @jbfletch_
42. Event Schemas What do I want to tell others and what information do I need to do it? 42 @jbfletch_
43. Example Event Schema Properties Event Name - “order placed” 43 @jbfletch_
44. Example Event Schema Properties Event Name - “order placed” Event Production Time - 2019-10-16 17:37:20.000534 44 @jbfletch_
45. Example Event Schema Properties Event Name - “order placed” Event Production Time - 2019-10-16 17:37:20.000534 Database Operation Time - 2019-10-16 17:34:20.000534 45 @jbfletch_
46. Example Event Schema Properties Event Name - “order placed” Event Production Time - 2019-10-16 17:37:20.000534 Database Operation Time - 2019-10-16 17:34:20.000534 Source System - “old evil application” 46 @jbfletch_
47. Example Event Schema Properties Event Name - “order placed” Event Production Time - 2019-10-16 17:37:20.000534 Database Operation Time - 2019-10-16 17:34:20.000534 Source System - “old evil application” Event Creation System - “central order event service” 47 @jbfletch_
48. Example Event Schema Properties Event Name - “order placed” Event Production Time - 2019-10-16 17:37:20.000534 Database Operation Time - 2019-10-16 17:34:20.000534 Source System - “old evil application” Event Creation System - “central order event service” Details Block - Specific to event, area for event-carried state transfer, information needed for event store. 48 @jbfletch_
49. Step 3 49 @jbfletch_
50. Emit Go big you can always filter or branch later 50 @jbfletch_
51. Demo Code https://github.com/jbfletch/kstreams -des-demo 51 @jbfletch_
52. Presenter Info Anna McDonald @jbfletch_ Principal Software Developer, SAS Straight up Math, Event Sourcing, Apache Kafka, Integration Architecture 52
