RailsConf 2016: Pat Packet visits Ruby Rails

Transcript

1. Pat Packet
   Visits
   Ruby Rails
   by: Jeremy Fairbank
   @elpapapollo | github.com/jfairbank
   illustrations: Marissa Roeper
   marissaroeper.com


   View Slide

2. We help brands excel.
   pushagency.io
   Your website, SimplyBuilt.
   simplybuilt.com


   View Slide

3. View Slide

4. ?


   View Slide

5. HTTP
   DNS
   TCP/IP
   ROUTING
   GET / HTTP/1.1


   Host: rubyonrails.org
   Accept: text/html
   Accept-Encoding: gzip, deflate, sdch
   Accept-Language: en-US,en;q=0.8
   Cache-Control: no-cache
   Connection: keep-alive


   Hello World
   The Message


   View Slide

6. HTTP
   DNS
   TCP/IP
   ROUTING
   The Destination
   rubyonrails.org
   192.30.252.153


   View Slide

7. The Transportation
   HTTP
   DNS
   TCP/IP
   ROUTING


   View Slide

8. The Directions
   HTTP
   DNS
   TCP/IP
   ROUTING


   View Slide

9. Package
   Address
   Continent
   Kingdom
   Train
   Router Station
   Network Packet
   IP Address
   Physical Device
   Software Server
   Connection
   Router/Switch
   Legend


   View Slide

10. View Slide

11. View Slide

12. View Slide

13. View Slide

14. WAN - Wide Area Network
    The Internet
    LAN - Local Area Network
    Router + computers
    Protocol
    Official rules/guidelines to follow
    HTTP - Hyper Text Transfer Protocol
    Protocol for HTML, JSON, XML


    View Slide

15. Can you send me
    your home page?
    Request
    Sure thing!
    Here you go!
    Reply


    View Slide

16. GET / HTTP/1.1
    Host: rubyonrails.org
    Accept: text/html
    Accept-Encoding: gzip, deflate, sdch
    Accept-Language: en-US,en;q=0.8
    Cache-Control: no-cache
    Connection: keep-alive


    Hello World
    Request Line
    Method Resource HTTP Version HTTP Request
    Headers
    Optional
    Message


    View Slide

17. GET
    POST
    PUT
    DELETE
    HTTP
    Methods


    View Slide

18. GET Can you send me
    your home page?
    GET / HTTP/1.1
    POST
    PUT
    DELETE
    HTTP
    Methods


    View Slide

19. GET Can you send me
    your home page?
    POST Here is my shopping
    cart for checkout.
    PUT
    DELETE
    POST /checkout HTTP/1.1
    HTTP
    Methods


    View Slide

20. GET Can you send me
    your home page?
    POST Here is my shopping
    cart for checkout.
    PUT I changed my name. Can you
    please update your records?
    DELETE
    PUT /user/info HTTP/1.1
    HTTP
    Methods


    View Slide

21. GET Can you send me
    your home page?
    POST Here is my shopping
    cart for checkout.
    PUT I changed my name. Can you
    please update your records?
    DELETE I no longer use this address.
    Can you remove it?
    DELETE /address/2 HTTP/1.1
    HTTP
    Methods


    View Slide

22. Meta data is like saying
    I’d prefer the list of
    friends in HTML.
    Data is like saying
    Please send me a list
    of my friends.
    HTTP Headers


    View Slide

23. Accept: */*
    Accept: text/html
    Content-Type: application/json
    Host: rubyonrails.org
    Content-Length: 42
    Key Value
    HTTP Headers


    View Slide

24. Send back
    whatever you have.
    Accept: */*
    Accept: text/html
    Content-Type: application/json
    Host: rubyonrails.org
    Content-Length: 42
    Key Value
    HTTP Headers


    View Slide

25. Send back HTML
    please.
    Accept: */*
    Accept: text/html
    Content-Type: application/json
    Host: rubyonrails.org
    Content-Length: 42
    Key Value
    HTTP Headers


    View Slide

26. I’m sending you
    some JSON.
    Accept: */*
    Accept: text/html
    Content-Type: application/json
    Host: rubyonrails.org
    Content-Length: 42
    Key Value
    HTTP Headers


    View Slide

27. Please give this
    message to
    rubyonrails.org.
    Accept: */*
    Accept: text/html
    Content-Type: application/json
    Host: rubyonrails.org
    Content-Length: 42
    Key Value
    HTTP Headers


    View Slide

28. Here’s how much
    information I’m
    sending.
    Accept: */*
    Accept: text/html
    Content-Type: application/json
    Host: rubyonrails.org
    Content-Length: 42
    Key Value
    HTTP Headers


    View Slide

29. Status Line
    Headers
    Message
    HTTP/1.1 200 OK
    Server: GitHub.com
    Date: Sun, 17 Apr 2016 11:19:48 GMT
    Content-Type: text/html; charset=utf-8
    Content-Length: 4127
    Last-Modified: Tue, 01 Mar 2016
    10:32:49 GMT


    Ruby on Rails!
    HTTP
    Version
    Status
    Code
    Status
    Description
    HTTP Reply


    View Slide

30. 200
    304
    404
    401
    500
    HTTP
    Statuses


    View Slide

31. HTTP/1.1 200 OK
    200 All good. Here’s
    your reply.
    304
    404
    401
    500
    HTTP
    Statuses


    View Slide

32. HTTP/1.1 304 Not Modified
    200 All good. Here’s
    your reply.
    304 Nothing changed. Keep
    what you already have.
    404
    401
    500
    HTTP
    Statuses


    View Slide

33. HTTP/1.1 404 Not Found
    200 All good. Here’s
    your reply.
    304 Nothing changed. Keep
    what you already have.
    404 Sorry, I can’t
    find that.
    401
    500
    HTTP
    Statuses


    View Slide

34. HTTP/1.1 401 Unauthorized
    200 All good. Here’s
    your reply.
    304 Nothing changed. Keep
    what you already have.
    404 Sorry, I can’t
    find that.
    401 Sorry, you’re not allowed
    to request that.
    500
    HTTP
    Statuses


    View Slide

35. HTTP/1.1 500 Internal Server Error
    200 All good. Here’s
    your reply.
    304 Nothing changed. Keep
    what you already have.
    404 Sorry, I can’t
    find that.
    401 Sorry, you’re not allowed
    to request that.
    500 Sorry, we’re having
    problems right now.
    HTTP
    Statuses


    View Slide

36. GET / HTTP/1.1
    Host: rubyonrails.org
    Accept: text/html
    Accept-Encoding: gzip, deflate, sdch
    Accept-Language: en-US,en;q=0.8
    Cache-Control: no-cache
    Connection: keep-alive


    View Slide

37. DNS - Domain Name System
    Where is
    rubyonrails.org?
    Oh, you can find it
    at 192.30.252.153.
    Translate
    domain names
    into IP addresses.
    Client DNS Server


    View Slide

38. View Slide

39. View Slide

40. View Slide

41. View Slide

42. View Slide

43. View Slide

44. View Slide

45. View Slide

46. View Slide

47. Local Resolver
    (e.g. at internet
    service provider)
    Root Kingdoms
    DNS


    View Slide

48. Local Resolver
    (e.g. at internet
    service provider)
    rubyonrails.org?
    RECURSIVE
    Root Kingdoms
    DNS


    View Slide

49. Local Resolver
    (e.g. at internet
    service provider)
    rubyonrails.org?
    RECURSIVE
    Root Kingdoms
    DNS
    ?
    ITERATIVE
    (keep trying)


    View Slide

50. Local Resolver
    (e.g. at internet
    service provider)
    rubyonrails.org?
    RECURSIVE
    Root Kingdoms
    DNS
    TLDs
    .org
    .com
    .net
    .io
    ?
    ITERATIVE
    (keep trying)


    View Slide

51. Local Resolver
    (e.g. at internet
    service provider)
    rubyonrails.org?
    RECURSIVE
    Root Kingdoms
    DNS
    TLDs
    .org
    .com
    .net
    .io
    NS
    a0.org…
    a2.org…
    ?
    Try these
    kingdoms.
    ITERATIVE
    (keep trying)


    View Slide

52. Local Resolver
    (e.g. at internet
    service provider)
    TLD Kingdoms
    DNS
    NS Kingdoms


    View Slide

53. Local Resolver
    (e.g. at internet
    service provider)
    TLD Kingdoms
    DNS
    Please associate
    rubyonrails.org with
    my IP address.
    ns1.gratisdns.dk.
    ns2.gratisdns.dk.
    NS Kingdoms
    Please associate us
    with rubyonrails.org.


    View Slide

54. Local Resolver
    (e.g. at internet
    service provider)
    TLD Kingdoms
    DNS
    ?
    NS
    ns1.gratisdns.dk.
    ns2.gratisdns.dk.
    Try these
    kingdoms.
    NS Kingdoms


    View Slide

55. Local Resolver
    (e.g. at internet
    service provider)
    DNS
    NS Kingdoms


    View Slide

56. Local Resolver
    (e.g. at internet
    service provider)
    DNS
    NS Kingdoms
    rubyonrails.org?


    View Slide

57. Local Resolver
    (e.g. at internet
    service provider)
    DNS
    NS Kingdoms
    rubyonrails.org?
    A 192.30.252.153


    View Slide

58. Local Resolver
    (e.g. at internet
    service provider)
    DNS
    NS Kingdoms
    rubyonrails.org?
    A 192.30.252.153
    rubyonrailsftw.com?


    View Slide

59. Local Resolver
    (e.g. at internet
    service provider)
    DNS
    NS Kingdoms
    rubyonrails.org?
    A 192.30.252.153
    rubyonrailsftw.com?
    CNAME rubyonrails.org.


    View Slide

60. Local Resolver
    (e.g. at internet
    service provider)
    Root Kingdoms
    TLD Kingdoms
    DNS
    NS Kingdoms
    A
    Hierarchy


    View Slide

61. Local Resolver
    (e.g. at internet
    service provider)
    Root Kingdoms
    TLD Kingdoms
    DNS
    NS Kingdoms
    A
    Hierarchy


    View Slide

62. x 4 billion IP addresses
    = LOTS of storage
    Can you all update
    my address?


    View Slide

63. View Slide

64. View Slide

65. TCP/IP
    Transmission Control Protocol


    View Slide

66. TCP/IP
    Transmission Control Protocol


    View Slide

67. View Slide

68. ACKnowledging
    the package.
    Here’s your reply.
    ACK


    View Slide

69. ACKnowledging
    the package.
    Here’s your reply.
    ACK
    I’m not sure you
    got that package.
    I’ll try again!
    ?
    X


    View Slide

70. View Slide

71. X
    X
    X
    X
    X
    X
    X X
    X
    X
    X
    X
    X
    Congestion


    View Slide

72. Sliding
    Window
    (being delivered)
    Awaiting
    delivery
    1
    TCP Congestion Control


    View Slide

73. Sliding
    Window
    (being delivered)
    Awaiting
    delivery
    1
    1
    TCP Congestion Control


    View Slide

74. Sliding
    Window
    (being delivered)
    Awaiting
    delivery
    1
    ACK 1
    1
    TCP Congestion Control


    View Slide

75. ACK 1
    1
    Awaiting
    delivery
    2
    Delivered
    Sliding
    Window
    (being delivered)
    TCP Congestion Control


    View Slide

76. 2
    3
    ACK 1
    1
    Awaiting
    delivery
    2
    Delivered
    Sliding
    Window
    (being delivered)
    TCP Congestion Control


    View Slide

77. 2
    3
    ACK 1
    1
    Awaiting
    delivery
    2
    Delivered
    Sliding
    Window
    (being delivered)
    TCP Congestion Control
    X
    X


    View Slide

78. 2
    3
    ACK 1
    1
    Awaiting
    delivery
    1
    Delivered
    Sliding
    Window
    (being delivered)
    TCP Congestion Control
    X
    X


    View Slide

79. 2
    3
    ACK 1
    1
    Awaiting
    delivery
    1
    Delivered
    Sliding
    Window
    (being delivered)
    TCP Congestion Control
    X
    X
    2


    View Slide

80. View Slide

81. TCP Connections - 3 way handshake


    View Slide

82. SYN
    TCP Connections - 3 way handshake
    1. Client (requester) requests connection with SYNchronize packet.
    1


    View Slide

83. ACK-SYN
    Window = 1
    SYN
    TCP Connections - 3 way handshake
    1. Client (requester) requests connection with SYNchronize packet.
    2. Server (recipient) ACKnowledges SYN and sends its own SYN. Server
    can specify initial window size to prevent too much coming in.
    1
    2


    View Slide

84. ACK-SYN
    Window = 1
    SYN
    TCP Connections - 3 way handshake
    ACK
    1. Client (requester) requests connection with SYNchronize packet.
    2. Server (recipient) ACKnowledges SYN and sends its own SYN. Server
    can specify initial window size to prevent too much coming in.
    3. Client ACKnowledges server’s SYN and connection is established.
    1
    3
    2


    View Slide

85. View Slide

86. 1
    Sliding Window
    1
    2
    2
    1
    Sequence
    Numbers


    View Slide

87. 1
    Sliding Window
    1
    2
    2
    1
    Sequence
    Numbers
    Got #1…
    ACK 1


    View Slide

88. Sliding Window
    1
    2
    2
    1
    Sequence
    Numbers
    Got #1…
    And #2!
    2
    ACK 1
    ACK 2


    View Slide

89. View Slide

90. View Slide

91. Destination Next Hop
    23.235.44.0/24 192.168.1.1
    104.0.0.0/8 192.168.2.1
    192.30.0.0/16 192.168.3.1
    23.21.0.0/16 192.168.4.1
    Routing Tables
    Tell which location to go to next for a range of IP
    addresses.
    IP Address Range
    with CIDR
    Path to follow,
    i.e. the next router


    View Slide

92. CIDR — Classless Inter-domain Routing
    192.30.0.0/16


    View Slide

93. 192.30.252.153
    8 bits = 2^8 = 256 numbers => 0-255
    4 of 2^8 => 0-255.0-255.0-255.0-255
    IPV4 Addresses - Dotted Quads
    0—255
    1st quad
    0—255
    2nd quad
    0—255
    3rd quad
    0—255
    4th quad


    View Slide

94. CIDR — Classless Inter-domain Routing
    192.30.0.0/16
    192.30.0.0/8
    1. Use the first /8 bits
    to mask the first
    quad. Masks “lock”
    a number in.
    2. Use the next /8 bits
    to mask the second
    quad.
    3. This leaves a range
    of possible IP
    addresses to find a
    match in.
    192.30.0.0/0
    192.30.0-255.0-255
    -or-
    192.30.0.0 - 192.30.255.255


    View Slide

95. Destination Next Hop
    23.235.44.0/24 192.168.1.1
    192.30.0.0/16 192.168.3.1
    23.21.0.0/16 192.168.4.1
    Destination Next Hop
    107.20.0.0/16 192.168.5.1
    192.30.252.0/24 192.168.6.1
    Destination Next Hop
    192.30.252.50.144/28 192.168.7.1
    192.30.0.0/16 192.168.8.1
    192.30.252.153?
    Routing
    Range grows smaller and more specific (mask grows larger).


    View Slide

96. View Slide

97. View Slide

98. Router Buffer
    (hold unprocessed
    packets)


    View Slide

99. Router Buffer
    (hold unprocessed
    packets)


    View Slide

100. Router Buffer
     (hold unprocessed
     packets)
     No room for packets.
     They must be dropped.
     Requester must try again and
     potentially slow down sending
     rate.


     View Slide

101. Router Buffer
     (hold unprocessed
     packets)
     No room for packets.
     They must be dropped.
     Requester must try again and
     potentially slow down sending
     rate.
     Slow down
     please!
     X X


     View Slide

102. Router Buffer
     (hold unprocessed
     packets)
     No room for packets.
     They must be dropped.
     Requester must try again and
     potentially slow down sending
     rate.
     Slow down
     please!
     X X


     View Slide

103. View Slide

104. View Slide

105. View Slide

106. View Slide

107. GET / HTTP/1.1
     Host: rubyonrails.org
     Accept: text/html
     Accept-Encoding: gzip, deflate, sdch
     Accept-Language: en-US,en;q=0.8
     Cache-Control: no-cache
     Connection: keep-alive


     View Slide

108. View Slide

109. View Slide

110. DNS
     Destination Next Hop
     192.30.0.0/16 192.168.3.1
     Routing
     TCP/IP
     ACK
     Recap


     View Slide

111. DNS
     Destination Next Hop
     192.30.0.0/16 192.168.3.1
     Routing
     TCP/IP
     ACK
     Recap


     View Slide

112. • Physical distance and latency unavoidable
     • Persistent/shared TCP connections
     • Caching DNS queries
     • Caching HTML, scripts, images, etc.
     • Content distribution networks (CDNs) and mirrors
     • HTTP 2
     Performance Matters!


     View Slide

113. • https://commons.wikimedia.org/wiki/File:Cartoon_cloud.svg
     • https://commons.wikimedia.org/wiki/File:Checkmark_green.svg
     • https://commons.wikimedia.org/wiki/File:Computer.svg
     • https://commons.wikimedia.org/wiki/File:Gnome-web-browser.svg
     • https://commons.wikimedia.org/wiki/File:Modern_clock_chris_kemps_01.svg
     • https://commons.wikimedia.org/wiki/File:Network-server.svg
     • https://commons.wikimedia.org/wiki/File:Server-web.svg
     • https://commons.wikimedia.org/wiki/File:Server.svg
     • https://commons.wikimedia.org/wiki/File:Simple_crown_icon.svg
     • https://pixabay.com/en/metro-subway-tramway-159004/
     • https://pixabay.com/en/postal-parcel-post-package-32383/
     • https://pixabay.com/en/subway-map-transportation-metro-576776/
     • https://upload.wikimedia.org/wikipedia/commons/3/3e/I-80_Eastshore_Fwy.jpg
     • https://commons.wikimedia.org/wiki/File:Osa_device-wireless-router.svg
     Sources


     View Slide

114. Acknowledgement
     Illustrations by Marissa Roeper
     marissaroeper.com


     View Slide

115. Thanks!
     by: Jeremy Fairbank
     @elpapapollo | github.com/jfairbank
     illustrations: Marissa Roeper
     marissaroeper.com


     View Slide
