Opportunities in developing for Android Wear

Wearable devices are the new frontier of personal computing and Android Wear is the easiest way for Android developers to take advantage of this new way of interacting with users and enhance how they experience your app.

In this talk we’ll explore the different ways to extend your app into Android Wear, starting by optimizing your current notification to display correctly on a smartwatch and then examining some case studies of successful apps that extended their notifications to use things like pictures, barcodes or media controls on Android Wear. We’ll also learn how to create an app that actually runs on the watch and the limitations and constraints of this new environment. Finally we’ll take a quick look at creating your own Android Wear watch face through the Watch Face API.

Transcript

1. Opportunities in developing for
   Android Wear
   Juan Gomez


   View Slide

2. Intro
   Who am I?
   • Sr. Android Engineer at Netflix
   • Previously at Eventbrite and OneLouder Apps
   • Android & Python Developer


   View Slide

3. View Slide

4. View Slide

5. View Slide

6. Design Principles


   View Slide

7. • Launched automatically
   Design Principles


   View Slide

8. • Launched automatically
   • Glanceable
   Design Principles


   View Slide

9. • Launched automatically
   • Glanceable
   • Suggest and Demand
   Design Principles


   View Slide

10. • Launched automatically
    • Glanceable
    • Suggest and Demand
    • Zero or low interaction
    Design Principles


    View Slide

11. Developing for
    Android Wear


    View Slide

12. Notifications Applications
    Watch Faces


    View Slide

13. Notifications


    View Slide

14. Simple Notifications
    Look, ma - no work required!


    View Slide

15. Intent viewIntent = new Intent(context, DummyActivity.class);



    PendingIntent viewPendingIntent = PendingIntent.getActivity(context, 0, viewIntent, 0);

    Notification notification = new NotificationCompat.Builder(context)

    .setSmallIcon(R.drawable.ic_launcher)

    .setSmallIcon(R.drawable.plane)

    .setContentTitle(String.format("Flight AW123 is ready to board", notificationId))

    .setContentText("Please proceed to gate C 17 to board. Have a nice flight!")

    .setContentIntent(viewPendingIntent)

    .build();



    NotificationManagerCompat notificationManager = NotificationManagerCompat.from(context);

    notificationManager.notify(notificationId++, notification);

    sendNotification()
    Simple Notifications


    View Slide

16. Can we do better?


    View Slide

17. BigPictureStyle
    Enhanced Notifications


    View Slide

18. Intent viewIntent = new Intent(context, DummyActivity.class);



    PendingIntent viewPendingIntent = PendingIntent.getActivity(context, 0, viewIntent, 0);

    Notification notification = new NotificationCompat.Builder(context)

    .setSmallIcon(R.drawable.ic_launcher)

    .setSmallIcon(R.drawable.plane)

    .setContentTitle(String.format("Flight AW123 is ready to board", notificationId))

    .setContentText("Please proceed to gate C 17 to board. Have a nice flight!")

    .setStyle(

    new NotificationCompat.BigPictureStyle()

    .bigPicture(BitmapFactory.decodeResource(context.getResources(),
    R.drawable.sanfrancisco))

    .setBigContentTitle("Flight AW123 is ready to board.")

    .setSummaryText("Please proceed to gate C 17 to board. Have a nice flight!"))

    .setContentIntent(viewPendingIntent)

    .build();



    NotificationManagerCompat notificationManager = NotificationManagerCompat.from(context);

    notificationManager.notify(notificationId++, notification);

    sendNotification()
    BigPictureStyle


    View Slide

19. Intent viewIntent = new Intent(context, DummyActivity.class);



    PendingIntent viewPendingIntent = PendingIntent.getActivity(context, 0, viewIntent, 0);

    Notification notification = new NotificationCompat.Builder(context)

    .setSmallIcon(R.drawable.ic_launcher)

    .setSmallIcon(R.drawable.plane)

    .setContentTitle(String.format("Flight AW123 is ready to board", notificationId))

    .setContentText("Please proceed to gate C 17 to board. Have a nice flight!")

    .setStyle(

    new NotificationCompat.BigPictureStyle()

    .bigPicture(BitmapFactory.decodeResource(context.getResources(),
    R.drawable.sanfrancisco))

    .setBigContentTitle("Flight AW123 is ready to board.")

    .setSummaryText("Please proceed to gate C 17 to board. Have a nice flight!"))

    .setContentIntent(viewPendingIntent)

    .build();



    NotificationManagerCompat notificationManager = NotificationManagerCompat.from(context);

    notificationManager.notify(notificationId++, notification);

    sendNotification()
    BigPictureStyle
    Create BigPictureStyle


    View Slide

20. Pages
    Enhanced Notifications


    View Slide

21. ArrayList pages = new ArrayList();

    pages.add(new NotificationCompat.Builder(context)

    .setContentTitle("Your seat")

    .setContentText("17A")

    .extend(new NotificationCompat.WearableExtender()

    .setBackground(BitmapFactory.decodeResource(context.getResources(),
    R.drawable.a380_seat)))

    .build());
    sendNotification()
    Pages


    View Slide

22. ArrayList pages = new ArrayList();

    pages.add(new NotificationCompat.Builder(context)

    .setContentTitle("Your seat")

    .setContentText("17A")

    .extend(new NotificationCompat.WearableExtender()

    .setBackground(BitmapFactory.decodeResource(context.getResources(),
    R.drawable.a380_seat)))

    .build());
    sendNotification()
    Pages
    Create page with title


    View Slide

23. ArrayList pages = new ArrayList();

    pages.add(new NotificationCompat.Builder(context)

    .setContentTitle("Your seat")

    .setContentText("17A")

    .extend(new NotificationCompat.WearableExtender()

    .setBackground(BitmapFactory.decodeResource(context.getResources(),
    R.drawable.a380_seat)))

    .build());
    sendNotification()
    Pages
    Set background image


    View Slide

24. pages.add(new NotificationCompat.Builder(context)

    .extend(new NotificationCompat.WearableExtender()

    .setHintShowBackgroundOnly(true)
    .setHintAvoidBackgroundClipping(true)

    .setHintScreenTimeout(NotificationCompat.WearableExtender.SCREEN_TIMEOUT_LONG)

    .setBackground(
    BitmapFactory.decodeResource(
    context.getResources(),
    R.drawable.qrcode)))

    .build());
    sendNotification()
    Background Only Pages


    View Slide

25. pages.add(new NotificationCompat.Builder(context)

    .extend(new NotificationCompat.WearableExtender()

    .setHintShowBackgroundOnly(true)
    .setHintAvoidBackgroundClipping(true)

    .setHintScreenTimeout(NotificationCompat.WearableExtender.SCREEN_TIMEOUT_LONG)

    .setBackground(
    BitmapFactory.decodeResource(
    context.getResources(),
    R.drawable.qrcode)))

    .build());
    sendNotification()
    Background Only Pages
    Show background only
    Don’t clip on round displays
    Extended timeout


    View Slide

26. ArrayList pages = new ArrayList();

    pages.add(new NotificationCompat.Builder(context)

    // ... (set properties)

    .build());
    Notification notification = new NotificationCompat.Builder(context)

    .setSmallIcon(R.drawable.plane)

    .setContentTitle(String.format("Flight AW123 is ready to board", notificationId))

    .setContentIntent(viewPendingIntent)

    .extend(new NotificationCompat.WearableExtender()

    .addPages(pages))

    .build();



    NotificationManagerCompat notificationManager = NotificationManagerCompat.from(context);

    notificationManager.notify(notificationId++, notification);

    sendNotification()
    Adding Pages to Notifications


    View Slide

27. ArrayList pages = new ArrayList();

    pages.add(new NotificationCompat.Builder(context)

    // ... (set properties)

    .build());
    Notification notification = new NotificationCompat.Builder(context)

    .setSmallIcon(R.drawable.plane)

    .setContentTitle(String.format("Flight AW123 is ready to board", notificationId))

    .setContentIntent(viewPendingIntent)

    .extend(new NotificationCompat.WearableExtender()

    .addPages(pages))

    .build();



    NotificationManagerCompat notificationManager = NotificationManagerCompat.from(context);

    notificationManager.notify(notificationId++, notification);

    sendNotification()
    Adding Pages to Notifications
    Build pages


    View Slide

28. ArrayList pages = new ArrayList();

    pages.add(new NotificationCompat.Builder(context)

    // ... (set properties)

    .build());
    Notification notification = new NotificationCompat.Builder(context)

    .setSmallIcon(R.drawable.plane)

    .setContentTitle(String.format("Flight AW123 is ready to board", notificationId))

    .setContentIntent(viewPendingIntent)

    .extend(new NotificationCompat.WearableExtender()

    .addPages(pages))

    .build();



    NotificationManagerCompat notificationManager = NotificationManagerCompat.from(context);

    notificationManager.notify(notificationId++, notification);

    sendNotification()
    Adding Pages to Notifications
    Add pages to notification


    View Slide

29. Actions
    Enhanced Notifications


    View Slide

30. Intent mapIntent = new Intent(Intent.ACTION_VIEW);

    Uri geoUri = Uri.parse("geo:0,0?q=" + Uri.encode("London Heathrow"));

    mapIntent.setData(geoUri);

    PendingIntent mapPendingIntent = PendingIntent.getActivity(context, 0, mapIntent, 0);
    sendNotification()
    Actions


    View Slide

31. Intent mapIntent = new Intent(Intent.ACTION_VIEW);

    Uri geoUri = Uri.parse("geo:0,0?q=" + Uri.encode("London Heathrow"));

    mapIntent.setData(geoUri);

    PendingIntent mapPendingIntent = PendingIntent.getActivity(context, 0, mapIntent, 0);



    NotificationCompat.Action walkingDirectionsAction =

    new NotificationCompat.Action.Builder(
    R.drawable.ic_full_directions_walking, "Directions to gate", mapPendingIntent)

    .build();
    sendNotification()
    Actions


    View Slide

32. Intent mapIntent = new Intent(Intent.ACTION_VIEW);

    Uri geoUri = Uri.parse("geo:0,0?q=" + Uri.encode("London Heathrow"));

    mapIntent.setData(geoUri);

    PendingIntent mapPendingIntent = PendingIntent.getActivity(context, 0, mapIntent, 0);



    NotificationCompat.Action walkingDirectionsAction =

    new NotificationCompat.Action.Builder(
    R.drawable.ic_full_directions_walking, "Directions to gate", mapPendingIntent)

    .build();
    Notification notification = new NotificationCompat.Builder(context)

    .setSmallIcon(R.drawable.ic_launcher)

    .setSmallIcon(R.drawable.plane)

    .setContentTitle(String.format("Flight AW123 is ready to board", notificationId))

    .setContentText("Please proceed to gate C 17 to board. Have a nice flight!")

    .addAction(walkingDirectionsAction)

    .extend(new NotificationCompat.WearableExtender()

    .addPages(pages)

    .addAction(replyAction)

    .addAction(walkingDirectionsAction))

    .build();

    sendNotification()
    Actions


    View Slide

33. View Slide

34. Applications


    View Slide

35. Launching
    Wearable apps
    Using app-provided
    voice actions
    Using the start
    menu


    View Slide

36. android:icon="@drawable/greenlinelogo"

    android:label="@string/app_name"

    android:theme="@android:style/Theme.DeviceDefault" >

    android:name="de.peterfriese.weartravel.MainActivity"

    android:label="@string/app_name_voice" >















    AndroidManifest.xml
    Launching


    View Slide

37. Custom Layouts
    Wearable Apps


    View Slide

38. xmlns:android="http://schemas.android.com/apk/res/android"

    xmlns:app="http://schemas.android.com/apk/res-auto"

    android:layout_height="match_parent"

    android:layout_width="match_parent">



    android:id="@+id/frame_layout"

    android:layout_height="match_parent"

    android:layout_width="match_parent"

    app:layout_box="left|bottom|right">



    android:id="@+id/checkin_list"

    android:layout_height="match_parent"

    android:layout_width="match_parent">






    activity_checkin.xml
    Layout - List


    View Slide

39. xmlns:android="http://schemas.android.com/apk/res/android"

    xmlns:app="http://schemas.android.com/apk/res-auto"

    android:layout_height="match_parent"

    android:layout_width="match_parent">



    android:id="@+id/frame_layout"

    android:layout_height="match_parent"

    android:layout_width="match_parent"

    app:layout_box="left|bottom|right">



    android:id="@+id/checkin_list"

    android:layout_height="match_parent"

    android:layout_width="match_parent">






    activity_checkin.xml
    Layout - List


    View Slide

40.

    xmlns:app="http://schemas.android.com/apk/res-auto">



    android:id="@+id/image"

    android:alpha="0.5"

    android:layout_height="52dp"

    android:layout_marginLeft="16dp"

    android:layout_width="52dp"

    app:circle_border_color="#FFFFFFFF"

    app:circle_border_width="2dp"

    app:circle_color="#00000000"

    />



    android:id="@+id/text"

    android:alpha="0.5"

    android:fontFamily="sans-serif-condensed-light"

    android:gravity="center_vertical"

    android:layout_height="52dp"

    android:layout_marginLeft="72dp"

    checkin_listview_item.xml
    Layout - Item


    View Slide

41.

    xmlns:app="http://schemas.android.com/apk/res-auto">



    android:id="@+id/image"

    android:alpha="0.5"

    android:layout_height="52dp"

    android:layout_marginLeft="16dp"

    android:layout_width="52dp"

    app:circle_border_color="#FFFFFFFF"

    app:circle_border_width="2dp"

    app:circle_color="#00000000"

    />



    android:id="@+id/text"

    android:alpha="0.5"

    android:fontFamily="sans-serif-condensed-light"

    android:gravity="center_vertical"

    android:layout_height="52dp"

    android:layout_marginLeft="72dp"

    android:layout_marginRight="16dp"

    android:layout_width="wrap_content"

    android:textColor="@color/white"

    android:textSize="14sp"

    />


    Layout - Item
    checkin_listview_item.xml


    View Slide

42. private final class MyItemView extends FrameLayout implements
    WearableListView.OnCenterProximityListener {



    final CircledImageView image;

    final TextView text;



    public MyItemView(Context context) {

    super(context);

    View.inflate(context, R.layout.checkin_listview_item, this);

    image = (CircledImageView) findViewById(R.id.image);

    text = (TextView) findViewById(R.id.text);

    }



    @Override

    public void onCenterPosition(boolean b) {

    image.animate().scaleX(1f).scaleY(1f).alpha(1);

    text.animate().scaleX(1f).scaleY(1f).alpha(1);

    }



    @Override

    public void onNonCenterPosition(boolean b) {

    image.animate().scaleX(0.8f).scaleY(0.8f).alpha(0.6f);

    CheckInActivity.java
    MyViewItem


    View Slide

43. private final class MyItemView extends FrameLayout implements
    WearableListView.OnCenterProximityListener {



    final CircledImageView image;

    final TextView text;



    public MyItemView(Context context) {

    super(context);

    View.inflate(context, R.layout.checkin_listview_item, this);

    image = (CircledImageView) findViewById(R.id.image);

    text = (TextView) findViewById(R.id.text);

    }



    @Override

    public void onCenterPosition(boolean b) {

    image.animate().scaleX(1f).scaleY(1f).alpha(1);

    text.animate().scaleX(1f).scaleY(1f).alpha(1);

    }



    @Override

    public void onNonCenterPosition(boolean b) {

    image.animate().scaleX(0.8f).scaleY(0.8f).alpha(0.6f);

    CheckInActivity.java
    MyViewItem


    View Slide

44. private final class MyItemView extends FrameLayout implements
    WearableListView.OnCenterProximityListener {



    final CircledImageView image;

    final TextView text;



    public MyItemView(Context context) {

    super(context);

    View.inflate(context, R.layout.checkin_listview_item, this);

    image = (CircledImageView) findViewById(R.id.image);

    text = (TextView) findViewById(R.id.text);

    }



    @Override

    public void onCenterPosition(boolean b) {

    image.animate().scaleX(1f).scaleY(1f).alpha(1);

    text.animate().scaleX(1f).scaleY(1f).alpha(1);

    }



    @Override

    public void onNonCenterPosition(boolean b) {

    image.animate().scaleX(0.8f).scaleY(0.8f).alpha(0.6f);

    text.animate().scaleX(0.8f).scaleY(0.8f).alpha(0.6f);

    }

    }
    CheckInActivity.java
    MyViewItem


    View Slide

45. public class CheckInActivity extends Activity implements WearableListView.ClickListener {



    @Override

    protected void onCreate(Bundle savedInstanceState) {

    super.onCreate(savedInstanceState);

    setContentView(R.layout.activity_checkin);



    MyListAdapter adapter = new MyListAdapter();



    WearableListView listView = (WearableListView) findViewById(R.id.checkin_list);

    listView.setAdapter(adapter);

    listView.setClickListener(CheckInActivity.this);

    }



    @Override

    public void onClick(WearableListView.ViewHolder viewHolder) {

    Toast.makeText(this, String.format("You selected item #%s",
    viewHolder.getPosition()), Toast.LENGTH_SHORT).show();

    }



    @Override

    public void onTopEmptyRegionClick() {

    CheckInActivity.java
    Activity


    View Slide

46. public class CheckInActivity extends Activity implements WearableListView.ClickListener {



    @Override

    protected void onCreate(Bundle savedInstanceState) {

    super.onCreate(savedInstanceState);

    setContentView(R.layout.activity_checkin);



    MyListAdapter adapter = new MyListAdapter();



    WearableListView listView = (WearableListView) findViewById(R.id.checkin_list);

    listView.setAdapter(adapter);

    listView.setClickListener(CheckInActivity.this);

    }



    @Override

    public void onClick(WearableListView.ViewHolder viewHolder) {

    Toast.makeText(this, String.format("You selected item #%s",
    viewHolder.getPosition()), Toast.LENGTH_SHORT).show();

    }



    @Override

    public void onTopEmptyRegionClick() {

    Toast.makeText(this, "You tapped into the empty area above the list",
    Toast.LENGTH_SHORT).show();

    }

    CheckInActivity.java
    Activity


    View Slide

47. Watch Faces


    View Slide

48. View Slide

49. Design Principles


    View Slide

50. • Square vs round
    Design Principles


    View Slide

51. • Square vs round
    • Ambient mode / low-bit
    Design Principles


    View Slide

52. • Square vs round
    • Ambient mode / low-bit
    • Legibility
    Design Principles
    56° - Cloudy
    56° - Cloudy


    View Slide

53. Developing
    Watch Faces


    View Slide

54. • Start using a sample
    Developing
    Watch Faces


    View Slide

55. • Start using a sample
    • Add a new wearable module
    Developing
    Watch Faces


    View Slide

56. Architecture
    Wearable App Mobile App
    CanvasWatchFaceService
    ConfigActivity
    Engine
    ConfigActivity
    WearableListenerService


    View Slide

57. Architecture
    Wearable App
    CanvasWatchFaceService
    ConfigActivity
    Engine
    WearableListenerService


    View Slide

58. Engine
    onCreate
    onPropertiesChanged
    onDraw
    onTimeTick
    onAmbientModeChanged
    onVisibilityChanged


    View Slide

59. @Override

    public void onCreate(SurfaceHolder holder) {

    super.onCreate(holder);



    setWatchFaceStyle(new WatchFaceStyle.Builder(AnalogWatchFaceService.this)

    .setCardPeekMode(WatchFaceStyle.PEEK_MODE_SHORT)

    .setBackgroundVisibility(WatchFaceStyle.BACKGROUND_VISIBILITY_INTERRUPTIVE)

    .setShowSystemUiTime(false)

    .build());



    Resources resources = AnalogWatchFaceService.this.getResources();

    Drawable backgroundDrawable = resources.getDrawable(R.drawable.bg);

    mBackgroundBitmap = ((BitmapDrawable) backgroundDrawable).getBitmap();



    mHourPaint = new Paint();

    mHourPaint.setARGB(255, 200, 200, 200);

    mHourPaint.setStrokeWidth(5.f);

    mHourPaint.setAntiAlias(true);

    mHourPaint.setStrokeCap(Paint.Cap.ROUND);
    onCreate
    Lifecycle - initialise watch face elements


    View Slide

60. @Override

    public void onCreate(SurfaceHolder holder) {

    super.onCreate(holder);



    setWatchFaceStyle(new WatchFaceStyle.Builder(AnalogWatchFaceService.this)

    .setCardPeekMode(WatchFaceStyle.PEEK_MODE_SHORT)

    .setBackgroundVisibility(WatchFaceStyle.BACKGROUND_VISIBILITY_INTERRUPTIVE)

    .setShowSystemUiTime(false)

    .build());



    Resources resources = AnalogWatchFaceService.this.getResources();

    Drawable backgroundDrawable = resources.getDrawable(R.drawable.bg);

    mBackgroundBitmap = ((BitmapDrawable) backgroundDrawable).getBitmap();



    mHourPaint = new Paint();

    mHourPaint.setARGB(255, 200, 200, 200);

    mHourPaint.setStrokeWidth(5.f);

    mHourPaint.setAntiAlias(true);

    mHourPaint.setStrokeCap(Paint.Cap.ROUND);
    onCreate
    Lifecycle - initialise watch face elements
    Single-line peek card
    Do not show system time
    Show background briefly for
    interruptive cards


    View Slide

61. @Override

    public void onCreate(SurfaceHolder holder) {

    super.onCreate(holder);



    setWatchFaceStyle(new WatchFaceStyle.Builder(AnalogWatchFaceService.this)

    .setCardPeekMode(WatchFaceStyle.PEEK_MODE_SHORT)

    .setBackgroundVisibility(WatchFaceStyle.BACKGROUND_VISIBILITY_INTERRUPTIVE)

    .setShowSystemUiTime(false)

    .build());



    Resources resources = AnalogWatchFaceService.this.getResources();

    Drawable backgroundDrawable = resources.getDrawable(R.drawable.bg);

    mBackgroundBitmap = ((BitmapDrawable) backgroundDrawable).getBitmap();



    mHourPaint = new Paint();

    mHourPaint.setARGB(255, 200, 200, 200);

    mHourPaint.setStrokeWidth(5.f);

    mHourPaint.setAntiAlias(true);

    mHourPaint.setStrokeCap(Paint.Cap.ROUND);
    onCreate
    Lifecycle - initialise watch face elements
    Load background image


    View Slide

62. @Override

    public void onCreate(SurfaceHolder holder) {

    super.onCreate(holder);



    setWatchFaceStyle(new WatchFaceStyle.Builder(AnalogWatchFaceService.this)

    .setCardPeekMode(WatchFaceStyle.PEEK_MODE_SHORT)

    .setBackgroundVisibility(WatchFaceStyle.BACKGROUND_VISIBILITY_INTERRUPTIVE)

    .setShowSystemUiTime(false)

    .build());



    Resources resources = AnalogWatchFaceService.this.getResources();

    Drawable backgroundDrawable = resources.getDrawable(R.drawable.bg);

    mBackgroundBitmap = ((BitmapDrawable) backgroundDrawable).getBitmap();



    mHourPaint = new Paint();

    mHourPaint.setARGB(255, 200, 200, 200);

    mHourPaint.setStrokeWidth(5.f);

    mHourPaint.setAntiAlias(true);

    mHourPaint.setStrokeCap(Paint.Cap.ROUND);
    onCreate
    Lifecycle - initialise watch face elements
    Create styles for graphic objects


    View Slide

63. @Override

    public void onDraw(Canvas canvas, Rect bounds) {

    mTime.setToNow();



    canvas.drawBitmap(mBackgroundScaledBitmap, 0, 0, null);
    float centerX = width / 2f;

    float centerY = height / 2f;



    float innerTickRadius = centerX - 10;

    float outerTickRadius = centerX;

    for (int tickIndex = 0; tickIndex < 12; tickIndex++) {

    float tickRot = (float) (tickIndex * Math.PI * 2 / 12);

    float innerX = (float) Math.sin(tickRot) * innerTickRadius;

    float innerY = (float) -Math.cos(tickRot) * innerTickRadius;

    float outerX = (float) Math.sin(tickRot) * outerTickRadius;

    float outerY = (float) -Math.cos(tickRot) * outerTickRadius;

    canvas.drawLine(centerX + innerX, centerY + innerY,

    centerX + outerX, centerY + outerY, mTickPaint);

    }



    float secRot = mTime.second / 30f * (float) Math.PI;

    onDraw
    Lifecycle - draw the watch face


    View Slide

64. @Override

    public void onDraw(Canvas canvas, Rect bounds) {

    mTime.setToNow();



    canvas.drawBitmap(mBackgroundScaledBitmap, 0, 0, null);
    float centerX = width / 2f;

    float centerY = height / 2f;



    float innerTickRadius = centerX - 10;

    float outerTickRadius = centerX;

    for (int tickIndex = 0; tickIndex < 12; tickIndex++) {

    float tickRot = (float) (tickIndex * Math.PI * 2 / 12);

    float innerX = (float) Math.sin(tickRot) * innerTickRadius;

    float innerY = (float) -Math.cos(tickRot) * innerTickRadius;

    float outerX = (float) Math.sin(tickRot) * outerTickRadius;

    float outerY = (float) -Math.cos(tickRot) * outerTickRadius;

    canvas.drawLine(centerX + innerX, centerY + innerY,

    centerX + outerX, centerY + outerY, mTickPaint);

    }



    float secRot = mTime.second / 30f * (float) Math.PI;

    onDraw
    Lifecycle - draw the watch face
    Update time
    Draw background image


    View Slide

65. @Override

    public void onDraw(Canvas canvas, Rect bounds) {

    mTime.setToNow();



    canvas.drawBitmap(mBackgroundScaledBitmap, 0, 0, null);
    float centerX = width / 2f;

    float centerY = height / 2f;



    float innerTickRadius = centerX - 10;

    float outerTickRadius = centerX;

    for (int tickIndex = 0; tickIndex < 12; tickIndex++) {

    float tickRot = (float) (tickIndex * Math.PI * 2 / 12);

    float innerX = (float) Math.sin(tickRot) * innerTickRadius;

    float innerY = (float) -Math.cos(tickRot) * innerTickRadius;

    float outerX = (float) Math.sin(tickRot) * outerTickRadius;

    float outerY = (float) -Math.cos(tickRot) * outerTickRadius;

    canvas.drawLine(centerX + innerX, centerY + innerY,

    centerX + outerX, centerY + outerY, mTickPaint);

    }



    float secRot = mTime.second / 30f * (float) Math.PI;

    onDraw
    Lifecycle - draw the watch face
    Draw the ticks


    View Slide

66. float centerX = width / 2f;

    float centerY = height / 2f;



    float innerTickRadius = centerX - 10;

    float outerTickRadius = centerX;

    for (int tickIndex = 0; tickIndex < 12; tickIndex++) {

    float tickRot = (float) (tickIndex * Math.PI * 2 / 12);

    float innerX = (float) Math.sin(tickRot) * innerTickRadius;

    float innerY = (float) -Math.cos(tickRot) * innerTickRadius;

    float outerX = (float) Math.sin(tickRot) * outerTickRadius;

    float outerY = (float) -Math.cos(tickRot) * outerTickRadius;

    canvas.drawLine(centerX + innerX, centerY + innerY,

    centerX + outerX, centerY + outerY, mTickPaint);

    }



    float secRot = mTime.second / 30f * (float) Math.PI;

    int minutes = mTime.minute;

    float minRot = minutes / 30f * (float) Math.PI;

    float hrRot = ((mTime.hour + (minutes / 60f)) / 6f ) * (float) Math.PI;



    float secLength = centerX - 20;

    float minLength = centerX - 40;

    float hrLength = centerX - 80;

    if (!isInAmbientMode()) {

    float secX = (float) Math.sin(secRot) * secLength;

    float secY = (float) -Math.cos(secRot) * secLength;

    canvas.drawLine(centerX, centerY, centerX + secX, centerY + secY, mSecondPaint);

    }



    onDraw
    Lifecycle - draw the watch face
    Determine hands geometry


    View Slide

67. float outerX = (float) Math.sin(tickRot) * outerTickRadius;

    float outerY = (float) -Math.cos(tickRot) * outerTickRadius;

    canvas.drawLine(centerX + innerX, centerY + innerY,

    centerX + outerX, centerY + outerY, mTickPaint);

    }



    float secRot = mTime.second / 30f * (float) Math.PI;

    int minutes = mTime.minute;

    float minRot = minutes / 30f * (float) Math.PI;

    float hrRot = ((mTime.hour + (minutes / 60f)) / 6f ) * (float) Math.PI;



    float secLength = centerX - 20;

    float minLength = centerX - 40;

    float hrLength = centerX - 80;

    if (!isInAmbientMode()) {

    float secX = (float) Math.sin(secRot) * secLength;

    float secY = (float) -Math.cos(secRot) * secLength;

    canvas.drawLine(centerX, centerY, centerX + secX, centerY + secY, mSecondPaint);

    }



    float minX = (float) Math.sin(minRot) * minLength;

    float minY = (float) -Math.cos(minRot) * minLength;

    canvas.drawLine(centerX, centerY, centerX + minX, centerY + minY, mMinutePaint);



    float hrX = (float) Math.sin(hrRot) * hrLength;

    float hrY = (float) -Math.cos(hrRot) * hrLength;

    canvas.drawLine(centerX, centerY, centerX + hrX, centerY + hrY, mHourPaint);

    }
    onDraw
    Lifecycle - draw the watch face
    Don’t draw seconds when in
    ambient mode
    Draw minutes hand
    Draw hours hand


    View Slide

68. View Slide

69. Summary
    • Extending your app’s notifications is the easiest way to offer
    an Android Wear experience.
    • Watch apps and Watch faces are a great way to offer new
    functionality to you users.
    • Make sure you follow the Android Wear design principles to
    maintain platform consistency.


    View Slide

70. Useful links
    • http://developer.android.com/training/building-wearables.html
    • https://www.youtube.com/playlist?list=PLWz5rJ2EKKc-
    kIrPiq098QH9dOle-fLef
    • http://developer.android.com/design/wear/index.html


    View Slide

71. Thank You!
    Twitter: @_juandg
    Email: jgomez@netflix.com
    Lanyrd: lanyrd.com/profile/juandg/


    View Slide
