SIG-Node 2020-05-12, experiences of advanced resource management in Kubernetes

Screencast used in demo:
https://asciinema.org/a/327044

Transcript

1. Alexander Kanevskiy, Krisztian Litkey, Ismo Puustinen
   2020-05-12


   View Slide

2. 2
   Agenda
   § Why?
   § Demo
   § What do we know about
   – Hardware in general
   – CPUs
   – Memory
   – UX


   View Slide

3. The stock Kubernetes + stock containerd, with some addons
   3


   View Slide

4. View Slide

5. View Slide

6. Node 1
   Node 0
   System devices topology
   Socket 0
   Core 0 Core 1 Core 6 Core 7
   Core 2 Core 3 Core 8 Core 9
   Core 4 Core 5 Core 10 Core 11
   PCIe UPI Socket 1
   Core 0 Core 1 Core 6 Core 7
   Core 2 Core 3 Core 8 Core 9
   Core 4 Core 5 Core 10 Core 11
   UPI PCIe
   Memory Controller Memory Controller


   View Slide

7. Node 5
   Node 4
   System topology in real world
   Node 0 Node 2
   Node 1 Node 3
   Package 0
   Core 0 Core 1 Core 5 Core 6
   Memory
   Controller
   Core 2 Core 7
   Memory
   Controller
   Core 3 Core 4 Core 8 Core 9
   PCIe
   UPI Package 1
   Core 0 Core 1 Core 5 Core 6
   Core 2 Core 7
   Core 3 Core 4 Core 8 Core 9
   UPI
   PCIe
   UPI UPI
   Memory
   Controller
   Memory
   Controller
   PCIe
   PCIe UPI UPI
   DMI DMI
   Chipset
   QAT x16 QAT x16
   QAT x16
   I/O Hub
   4x10G NIC


   View Slide

8. 8
   CPU
   Things to keep in mind for CPUs
   § CPU cores vs. threads
   § CPU cores frequencies: base, turbo, throttling
   § CPU usage: Shared, Exclusive, Isolated
   § Additional CPU resources: Cache, Memory Bandwidth
   § Interconnect is an expensive resource
   § “C” in “NUMA” stands for “CPU”
   – Vendors have BIOS configurable settings to redefine what means NUMA (SNC, NPS,…)
   § Workload migration cost: low to very low
   § CPUs for Kubelet might be not the same meaning inside VM based runtimes


   View Slide

9. Group …
   9
   System
   root
   Socket
   0
   Die 0
   CPU 0 CPU 1
   Die 1
   CPU 2 CPU 3
   Socket
   1
   Die 0
   CPU 4 CPU 5
   Die 1
   CPU 6 CPU 7
   For each leaf node
   § Groups of
   CPU+Memory
   § Dynamic pools
   – Shared
   – Exclusive
   – Isolated
   – “Throttled”
   – …
   Parent nodes
   § Sum of subtree
   resources
   Topology-Aware CPU policy
   physical_package_id
   die_id
   core_id


   View Slide

10. 10
    Memory
    Things to keep in mind for Memory
    § Memory types
    – DRAM
    – “Persistent”, in ”volatile, system RAM mode” (PMEM)
    – High Bandwidth (HBM)
    § Kernel’s “Normal” vs. “Movable”
    § NUMA
    – Distances
    – Have CPU
    – Have ”normal” memory
    § Workload migration costs: medium to HIGH


    View Slide

11. NUMA
    C
    11
    NUMA
    A
    NUMA
    B
    System
    root
    Socket 0
    Die 0
    IO and
    Memory
    CPUs
    Core
    Thread Thread
    Core...
    DRAM PMEM HBM
    IO and
    Memory ...
    Die ...
    Socket ...
    Each Node
    § CPU
    – CPU-less NUMA
    nodes are linked to
    nodes with CPUs
    § All memory types
    – DRAM
    – PMEM
    – HBM
    § Placement Cost
    calculated based on
    – Requested memory
    type(s) and amount of
    available memory
    – Later: BW, WSS
    MemTier Topology-Aware policy


    View Slide

12. 12
    Linux OS Memory Tiering
    Principle of operation
    § Memory pages promoted from
    PMEM to DRAM when capacity
    available
    § Cold pages in DRAM Demoted
    to PMEM
    Page Promotions
    Page Demotions
    DDR


    View Slide

13. 13
    User friendly resources controls
    § Good UX that spawns public cloud, VMs, bare metal is hard
    – Especially for non-trivial resources (block I/O, caches, …)
    § Placing workloads might lead to situations where it can’t be
    done
    – Reject?
    – Rebalance?
    § Rebalancing of the running workloads can be also hard
    – Assigned devices
    – Memory migrations
    – Priorities
    The story of jar, rocks, pebbles and sand…


    View Slide

14. 14
    What next?
    UX is the key in our opinion
    § User should expect “it just works great” by default
    § Advanced users should be able to utilize good patterns on resource groups
    – Affinity/anti-affinity pattern
    – Device pipelines
    § Solutions that we do now should be aligned with where hardware is evolving to
    § Maybe not in Kubelet…?


    View Slide

15. View Slide

16. Description of the functionality
    CRI Resource Manager
    https://github.com/intel/cri-resource-manager
    ●
    is a Container Runtime Interface proxy
    ●
    sits between CRI Clients and the CRI Runtime
    ●
    applies (hardware) resource policies to containers
    CPU, Memory, Cache, Memory Bandwidth, Block I/O, …
    ●
    policies are applied by
    ●
    modifying proxied container requests, or
    ●
    generating container update requests, or
    ●
    triggering extra policy-specific actions during request
    processing


    View Slide
