1. Extending Kubernetes* with Intel® accelerator devices Alexander Kanevskiy Intel Open Source Technology Center * Other names and brands may be claimed as the property of others.
2. Agenda • Hardware accelerators: “What?” and “Why?” • How do they work in Kubernetes*? • Intel accelerators • GPU • Intel® QuickAssist Technology (Intel® QAT) • FPGA • Challenges of using hardware accelerators in Kubernetes* * Other names and brands may be claimed as the property of others.
3. Accelerators: “What?” and “Why?” • Variety of accelerator devices • SmartNIC • GPU • FPGA • Other specialized co-processors • Highly optimized hardware for specific tasks • Can provide significant performance gain • Saving CPU cycles for other workloads • Require application support
4. Hardware Accelerators in Kubernetes* Kubelet Device Plugin Device Plugin gRPC Server Device Plugin Manager gRPC Server Register ListAndWatch Allocate PreStartContainer GetDevicePluginOptions • Alpha in 1.8 • Currently: beta * Other names and brands may be claimed as the property of others.
5. Intel® Graphics Technologies • Products • Intel® Core™ processor • Intel® Xeon® processor • Intel® Visual Compute Accelerator • Variants • Intel® UHD Graphics, Intel® Iris® Graphics, Intel® Iris® Plus Graphics • GPU Acceleration use cases • Intel® Media SDK • OpenCL* containers: ... - name: demo-container-1 image: k8s.gcr.io/pause:2.0 resources: limits: gpu.intel.com/i915: 1 * Other names and brands may be claimed as the property of others. Watch Demo!
6. Intel® QuickAssist Technology • Accelerator for DPDK* applications • Security • SSL/IPSec • Symmetric Cryptography: AES, KASUMI,… • Asymmetric cryptography: DH, RSA, DSA, ECDSA,… • Digest/hash: MD5, SHA1, SHA2, SHA3,… • Compression • Deflate: LZ77 with gzip or zlib header • Stateless compression and decompression * Other names and brands may be claimed as the property of others. containers: ... - name: demo-container-2 image: k8s.gcr.io/pause:2.0 resources: limits: qat.intel.com/generic: 1 Watch Demo!
7. Field Programmable Gate Array (FPGA) • Products • PCIe* programmable acceleration cards • Intel® Arria® 10 GX FPGA • Intel® Stratix® 10 SX FPGA • Intel® Xeon® Scalable processors with integrated FPGA • Workload types • Open Programmable Acceleration Engine • OpenCL* * Other names and brands may be claimed as the property of others.
8. Using FPGAs in the Cloud • Usability aspects • Not user friendly IDs • Region (interface) ID • Accelerator Function ID • CRDs for user friendly IDs • Security aspects • User vs. Infra Programming • Bitstream access apiVersion: fpga.intel.com/v1 kind: AcceleratorFunction metadata: name: arria10-compress spec: afuId: 18b79ffa2ee54aa096ef4230dafacb5f apiVersion: fpga.intel.com/v1 kind: FpgaRegion metadata: name: arria10 spec: interfaceId: 9926ab6d6c925a68aabca7d84c545738 resources: limits: fpga.intel.com/arria10-compress: 1
9. Using FPGAs in the Cloud Different modes of operation • Pre-programmed • Orchestration programmed containers: ... - name: fpga-container-1 image: k8s.gcr.io/pause:2.0 resources: limits: fpga.intel.com/af-d8424dc4a4a383f9040b: 1 containers: ... - name: fpga-container-2 image: k8s.gcr.io/pause:2.0 resources: limits: fpga.intel.com/arria10-nlb3: 1 Watch Demo!
10. FPGA and Kubernetes*: how it works Control Plane Node Kubelet CRI-O PreStart CRI-O Hook FPGA OPAE Kernel driver FPGA Device Plugin etcd Scheduler API Server Controller Manager FPGA Admission Controller Webhook Workload Discovery Device Plugin API Programming CRI * Other names and brands may be claimed as the property of others.
11. Challenges of using accelerators in Kubernetes* … and what we should discuss as a community * Other names and brands may be claimed as the property of others.
12. Accelerator’s resources challenges Devices with internal resources • We have gaps on all levels • Kubernetes* to CRI • CRI to OCI Runtimes • Runtimes to CGroups • CGroups for accelerator drivers • “Infinite” amount of resources • Multifunctional engine units • “Compatible” resources Accelerator Engine Unit Engine Unit Engine RAM Engine RAM Kubernetes* Workload Workload Workload Workload Workload CRI Runtime CGroups Kernel Driver * Other names and brands may be claimed as the property of others.
13. Challenges with GPUs & Intel® QAT • GPUs • Several generations of compatible GPUs • Specific combinations of kernel and user space libraries • Specific to workload ABIs for user space libraries • Intel® QAT • UIO vs. kernel driver APIs • DPDK vs. “normal” applications • OpenSSL* vs. BoringSSL* • Topology aware allocation * Other names and brands may be claimed as the property of others.
14. Challenges with FPGAs • Accelerator parameters • Inability in generic way to pass parameters for programming • Allocate() • PreStartContainer() • CRI Hooks • Different parameters for several instances of accelerators • Power management and security • Deallocate() • Complex topology between accelerators, CPUs and memory
15. Device topology challenges, simplified Socket 0 Core 0 Core 1 Core 6 Core 7 Core 2 Core 3 Core 8 Core 9 Core 4 Core 5 Core 10 Core 11 PCIe UPI Socket 1 Core 0 Core 1 Core 6 Core 7 Core 2 Core 3 Core 8 Core 9 Core 4 Core 5 Core 10 Core 11 UPI PCIe Memory Controller Memory Controller Memory Controller Memory Controller $ $ $ $ $ $ $
16. Node 0 Node 2 Node 1 Node 3 Device topology challenges in real world Package 0 Core 0 Core 1 Core 6 Core 7 Memory Controller Core 3 Core 8 Memory Controller Core 4 Core 5 Core 10 Core 11 PCIe UPI Package 1 Core 0 Core 1 Core 6 Core 7 Core 3 Core 8 Core 4 Core 5 Core 10 Core 11 UPI PCIe UPI UPI Memory Controller Memory Controller PCIe PCIe UPI UPI DMI DMI Chipset QAT x16 QAT x16 QAT x16 I/O Hub 4x10G NIC
17. References Intel Device Plugins for Kubernetes* GitHub* * Other names and brands may be claimed as the property of others. GPU Demo Intel® QAT Demo FPGA Demo Intel Device Plugins for Kubernetes* Demos
