  1. Making Grails Web Sites Fast
    Ken Liu
    GR8Conf US 2013

    View full-size slide

  2. About me
    Web development with Java since JDK 1.0.2 (applets,
    anyone?)
    Groovy and Grails since 2009
    Lead developer for IEEE Spectrum

    View full-size slide

  3. About IEEE / IEEE Spectrum
    Institute of Electrical and Electronics Engineers
    Widely known for standards - 802.3, 802.11
    World’s largest technology professional association -
    400,000 engineers in 160 countries
    Publishes nearly a third of the world’s technical
    literature in EE/CS
    IEEE Spectrum http://spectrum.ieee.org - 100% Grails

    View full-size slide

  4. Agenda
    Why focus on web performance?
    How to assess website performance
    Tools and techniques for improving performance
    Grails plugins for web performance

    View full-size slide

  5. Agenda
    Why focus on web performance?
    How to assess website performance
    Tools and techniques for improving performance
    Grails plugins for web performance

    View full-size slide

  6. Why does web performance
    matter?
    400ms delay = 5-9% drop in page traffic (Yahoo)
    100ms delay = 1% drop in revenue (Amazon)
    1s improvement = up to 2% conversion rate (Walmart)
    57% of online consumers will abandon a site after
    waiting 3 seconds for a page to load. 80% of these
    people will not return (Akamai)
    250ms delay = users will visit website less than
    competitors (Microsoft)
    Akamai http://www.akamai.com/html/about/press/releases/2010/press_061410.html
    Yahoo http://www.slideshare.net/stoyan/yslow-20-presentation
    Amazon http://sites.google.com/site/glinden/Home/StanfordDataMining.2006-11-28.ppt?attredirects=0
    Walmart http://minus.com/msM8y8nyh#2e
    http://www.nytimes.com/2012/03/01/technology/impatient-web-users-flee-slow-loading-sites.html

    View full-size slide

  7. What makes websites slow?
    Slow server performance
    Network latency
    Heavyweight/unoptimized web pages
    Third-party social network widgets and beacons
    Ad serving
    China firewall

    View full-size slide

  8. Agenda
    Why focus on web performance?
    How to assess website performance
    Tools and techniques for improving performance
    Grails plugins for web performance

    View full-size slide

  9. What is “fast” anyway?
    Industry benchmarks such as published by Keynote
    A site might be fast in NJ but slow in CA …or Asia
    User perception trumps absolute performance metrics
    You don’t know if something is fast or slow unless you
    measure it

    View full-size slide

  10. “14 Rules for Faster-Loading
    Web Sites”
    Steve Souders
    Chief Performance Yahoo!
    circa 2007

    View full-size slide

  11. The Performance Golden
    Rule
    “80-90% of the end-user
    response time is spent on the
    frontend. Start there.”
    - Steve Souders

    View full-size slide

  12. The Performance Golden
    Rule
    “backend” time is
    the time it takes
    for the initial
    HTML page to
    start downloading
    ~0.4s out of ~2.0s
    Source: http://www.stevesouders.com/blog/2012/02/10/the-performance-golden-rule/

    View full-size slide

  13. Understanding waterfall
    charts
    http://www.strangeloopnetworks.com/blog/how-to-use-a-waterfall-chart-to-interpret-web-performance-data/

    View full-size slide

  14. Understanding waterfall
    charts
    http://www.strangeloopnetworks.com/blog/how-to-use-a-waterfall-chart-to-interpret-web-performance-data/

    View full-size slide

  15. Understanding waterfall
    charts: patterns
    First line: Initial HTML page (incl. TTFB)
    Lots of lines: too many objects
    Long lines: slow downloading objects
    Wide chart: slow overall page load
    Total page weight, total page load time, response
    codes

    View full-size slide

  16. Agenda
    Why focus on web performance?
    How to measure website performance
    Tools and techniques for improving performance
    Grails plugins for web performance

    View full-size slide

  17. “14 Rules for Faster-Loading
    Web Sites”
    Rule 1 - Make Fewer HTTP Requests
    Rule 2 - Use a Content Delivery
    Network
    Rule 3 - Add an Expires Header
    Rule 4 - Gzip Components
    Rule 5 - Put Stylesheets at the Top
    Rule 6 - Put Scripts at the Bottom
    Rule 7 - Avoid CSS Expressions
    Rule 8 - Make JavaScript and CSS
    External
    Rule 9 - Reduce DNS Lookups
    Rule 10 - Minify JavaScript
    Rule 11 - Avoid Redirects
    Rule 12 - Remove Duplicate Scripts
    Rule 13 - Configure ETags
    Rule 14 - Make AJAX Cacheable

    View full-size slide

  18. Yahoo! 34 Rules
    Make Fewer HTTP Requests
    Use a Content Delivery Network (CDN)
    Add Expires or Cache-Control Header
    Gzip Components
    Put Stylesheets at Top
    Put Scripts at Bottom
    Avoid CSS Expressions
    Make JavaScript and CSS External
    Reduce DNS Lookups
    Minify JavaScript and CSS
    Avoid Redirects
    Remove Duplicate Scripts
    Configure ETags
    Make Ajax Cacheable
    Flush Buffer Early
    Use GET for Ajax Requests
    Postload Components
    Preload Components
    Reduce the Number of DOM Elements
    Split Components Across Domains
    Minimize Number of iframes
    Avoid 404s
    Reduce Cookie Size
    Use Cookie-Free Domains for Components
    Source: http://developer.yahoo.com/performance/

    View full-size slide

  19. Front-end performance
    analysis tools
    Browser-based tools
    Google Chrome Developer Tools + Google Page
    Speed Insight Extension
    Firefox Firebug + YSlow
    Web-based tools
    webpagetest.org
    Google Page Speed Insights

    View full-size slide

  20. demos:
    YSlow and webpagetest.org

    View full-size slide

  21. Key front end performance
    strategies
    Reduce effect of network latency
    Show content to the user as quickly as possible
    Only download what you need, when you need it
    Cache stuff so it doesn't have be loaded more than
    once

    View full-size slide

  22. Make fewer HTTP requests
    Reduce the number of objects on a page
    Many small objects slower than few larger objects
    Combine many small files into one
    Delay loading of content, especially hidden content
    More requests = more waiting
    Many of the “rules” are aimed at this goal

    View full-size slide

  23. Use a Content Distribution
    Network (CDN)
    Akamai, Amazon CloudFront, Limelight, CloudFlare
    Global network of servers - reduces network latency
    Web cache
    Be careful of changing cached content

    View full-size slide

  24. Use a Content Distribution
    Network (CDN)
    https://en.wikipedia.org/wiki/File:NCDN_-_CDN.png
    Traditional network vs. CDN

    View full-size slide

  25. Use a Content Distribution
    Network (CDN)
    Source: http://blog.letshost.ie/2012/02/letshost-launches-new-content-delivery-network-service/
    Visitors connect to “closer” servers, lower latency

    View full-size slide

  26. Gzip components
    The easiest no-brainer optimization, just do it!
    Enabled at the web server - “Accept-Encoding” header
    Gzip all text content (CSS, JS, HTML, JSON, XML)
    Don't Gzip binary content (images, PDFs, video files)

    View full-size slide

  27. Gzip components
    Compressing the following resources with gzip could reduce their transfer size by 366.2KiB (80% reduction).
    • Compressing /assets/css/site.css could save 145.8KiB (87% reduction).
    • Compressing /getGlobalNavData could save 98.3KiB (85% reduction).
    • Compressing / could save 44.8KiB (75% reduction).
    • Compressing /assets/js/script1.js could save 30.4KiB (75% reduction).
    • Compressing /.../jquery.isotope.min.js could save 10.6KiB (68% reduction).
    • Compressing /assets/js/libs/plugins.js could save 10.0KiB (66% reduction).
    • Compressing /.../modernizr-2.5.3.min.js could save 9.0KiB (60% reduction).
    • Compressing /assets/css/style.css could save 6.8KiB (68% reduction).
    • Compressing /assets/js/libs/spin.min.js could save 2.1KiB (51% reduction).
    • Compressing /.../jquery.lazyload.min.js could save 2.0KiB (64% reduction).
    • Compressing /assets/js/slimbox2.min.js could save 1.8KiB (53% reduction).
    • Compressing /assets/css/sb.css could save 1.2KiB (66% reduction).
    • Compressing /.../spec4-style-updates-1-30.css could save 970B (69% reduction).
    • Compressing /.../jquery.touchwipe.min.js could save 813B (52% reduction).
    • Compressing /.../masonry-ads-right.min.js could save 798B (58% reduction).
    • Compressing /assets/css/slimbox2.css could save 698B (56% reduction).
    Enabling gzip compression - Spectrum home page
    366.2 KiB (80%) reduction (total 1.2 MB)

    View full-size slide

  28. Optimize browser caching
    First visit (empty cache) vs. repeat visit (primed cache)
    Set cache headers in application or web server
    Cache images forever (set “expires” header)
    Rename objects when updating to facilitate caching
    Can be more complex than it seems
    Tread carefully - once objects are cached in users’
    browsers, you can’t easily remove them

    View full-size slide

  29. Optimize browser caching
    IEEE Spectrum
    First view vs. Repeat view

    View full-size slide

  30. CSS & JS minification
    Different than gzip compression
    Logical compression, some advanced smarts
    Google Closure compiler, Yahoo YUI Compressor
    Use minified versions of JS libraries (*.min.js)
    Concatenate CSS and JS files
    Use tools for bundling assets

    View full-size slide

  31. CSS & JS minification

    View full-size slide

  32. CSS at the top in
    JS at the bottom, before
    CSS at the top allows page to render immediately
    JS at the bottom allows JS to execute after HTML is
    loaded
    Order resources in the page

    View full-size slide

  33. Compress JPG/PNG images efficiently (lossy)
    Optimize JPG/PNG compression (losslessly)
    Don't scale down images
    Smush.it - integrated into YSlow
    PunyPNG, ImageOptim, OptiPNG, others
    Automate in your CMS / web development process
    Optimize images

    View full-size slide

  34. Image spriting
    Don’t do image slicing!
    Combine tiny icons/graphics into “sprite sheet”
    Downsides - maintenance, retina support

    View full-size slide

  35. Image lazy-loading
    Post load images using jQuery lazyload plugin
    http://www.appelsiini.net/projects/lazyload
    jQuery plugin captures onScroll events and
    loads images that are in the viewport

    View full-size slide

  36. HTML5/CSS3 techniques
    Use CSS3 rounded corners, drop shadows, gradients,
    not images
    Old browsers get degraded, but functional, appearance

    View full-size slide

  37. Async loading and AJAX
    Use AJAX to refresh parts of page or load parts after
    document ready
    Cache AJAX responses
    Beware of impacts to analytics, ad serving, page
    history, etc.
    Can add significant application complexity
    May break searchability

    View full-size slide

  38. Agenda
    Why focus on web performance?
    How to measure website performance
    Tools and techniques for improving performance
    Grails plugins for web performance

    View full-size slide

  39. UiPerformance plugin
    Granddaddy of all web performance plugins
    “Swiss Army knife” approach
    No longer maintained, replaced with Resources plugin
    family

    View full-size slide

  40. Grails resources plugin
    family
    Powerful plugin framework for web performance
    concerns
    Many additional plugins that collaborate with grails-
    resources processing pipeline
    Does some processing at runtime instead of build time
    Stores generated files locally?

    View full-size slide

  41. Grails resources usage
    Declare “modules” (groupings of resources) in
    ApplicationResources.groovy (by convention)
    Declare GSP dependencies on modules using

    insert on pages to include
    declared resources

    View full-size slide

  42. Resources plugin:
    Using a CDN
    Example CloudFront domain:
    d1209ystrpttii.cloudfront.net
    set grails.resources.mappers.baseurl.default =
    "d1209ystrpttii.cloudfront.net"
    mapped resources will now point to CDN domain

    View full-size slide

  43. Resources plugin:
    Dispositions
    Implements rules for resource ordering
    By default, CSS is placed in and JS at the end
    of the document (“defer”)
    Can override defaults for special cases

    View full-size slide

  44. Resources plugin:
    Compressing/minifying CSS
    Google closure compiler plugin
    set options for compilation level: WHITESPACE_ONLY,
    SIMPLE_OPTIMIZATIONS,
    ADVANCED_OPTIMIZATIONS
    YUI compiler plugin is abandoned!

    View full-size slide

  45. Cached-resources plugin
    Takes care of object versioning problem, facilitates
    caching resources “forever”
    Facilitates CDN caching and browser caching
    No need for manual object versioning - generates file
    names based on SHA of file contents

    View full-size slide

  46. Resources plugin:
    Concatenating JS/CSS
    Can declare bundle property on resource declaration
    Eases maintenance of code - use smaller files during
    development without performance hit
    Changing one of the resources in the bundle will trigger
    a rebuild of the bundle

    View full-size slide

  47. Zipped resources plugin
    Automatically gzips static resources and caches in
    server
    May be better/easier just to set gzip at web server

    View full-size slide

  48. Cache Headers plugin

    View full-size slide

  49. The server side
    The first 10-20%
    TTFB (time-to-first-byte) means blank screen
    Don't confuse server load with front end performance -
    test separately
    Database query performance
    Server-side caching (cache plugin family)
    Server memory, thread contention, disk performance

    View full-size slide

  50. The server side: cache
    plugins
    Springcache plugin: deprecated in favor of cache
    plugin family
    Cache-ehcache, Cache-redis, Cache-gemfire
    extensions
    Cache GSPs: @Cacheable annotation on controller
    methods
    Cache Services: @Cacheable on services
    Be careful to set cache key correctly for services

    View full-size slide

  51. Automated WPO
    Trade off money for performance/developer time
    Reverse proxy to automatically apply performance
    optimizations on-the-fly
    Akamai Blaze, Strangeloop, Google PageSpeed
    Service, many others
    mod_pagespeed - many experimental optimizations
    available
    https://developers.google.com/speed/pagespeed/

    View full-size slide

  52. Summary
    Slow web performance impacts your business
    Use performance tools to assess performance
    Start optimizing front end performance first
    34 best practices for optimizing web sites

    View full-size slide

  53. Thank you!
    Ken Liu
    @kenliu (Twitter)
    [email protected]

    View full-size slide
