Microservices as an evolutionary architecture: lessons learned

Microservices as an evolutionary architecture: lessons learned

Over the years the architecture of microservices has been widely adopted, since it provides numerous advantages such as: technological heterogeneity, scalability, decoupling and so on.

In this sense the microservices architecture meets the definitions of an evolutionary architecture, that is, an architecture designed for incremental changes even changes of languages.

In this lecture, we will discuss the decisions to adopt frameworks and techniques such as: Spring, Vert.x, gRPC, Event-driven Architecture in an architecture for a payment medium solution in which throughput and response time is crucial for the survival of the business .

Ef3b48913ea26665c25b2ad78e449d16?s=128

Luram Archanjo

July 19, 2019
Tweet

Transcript

  1. Microservices as an Evolutionary Architecture: Lessons learned Claudio Eduardo de

    Oliveira & Luram Archanjo
  2. Who am I? • Software Engineer @Sensedia • MBA in

    Java projects • Java and Microservice enthusiast
  3. Who am I? • Lead Solutions Architect @Sensedia • Book

    Author • Spring, Java and Cloud Native enthusiast
  4. Agenda • Use Case & As Is • Microservices •

    Evolutionary Architecture • Domain Driven Design • Communication Patterns & Reactive Programming • Observability & Database Migration • Questions
  5. Use case

  6. Use case Token Service Provider Tokenization reduces the value of

    stored payment credentials by removing consumers’ primary account numbers (PANs) from the transaction process. It does this by replacing them with a unique identifier called a payment token. This reduces the appeal of stealing the credentials as they would be largely useless to hackers. Source: https://www.rambus.com/blogs/what-is-a-token-service-provider/
  7. Use case

  8. None
  9. None
  10. In the beginning

  11. As is • Single communication pattern • 50-60% of our

    commits during the sprint were in the same repository • Service with different workload requirements (Crypto and Business) • Traffic east-west in the API Gateway • Java & Spring everywhere • Synchronous process everywhere
  12. We were in the wrong way to adopt microservices architecture!

  13. Let's recap what is the microservices architecture!

  14. Moving to Microservices Feature A Feature B Feature C Monolith

    Microservice Microservice Microservices Microservice
  15. Technological Heterogeneity Microservice Microservice Microservice DB DB DB

  16. Evolutionary Architecture

  17. Evolutionary Architecture An evolutionary architecture supports guided, incremental change as

    a first principle across multiple dimensions. Source: https://www.thoughtworks.com/books/building-evolutionary-architectures
  18. Response time Microservices as an Evolutionary Architecture: Lessons learned Throughput

  19. Before make a architectural decision, we need to be confident!

    How?
  20. Regression Tests

  21. Regression Tests REGRESSION TEST SUITE REGRESSION SCRIPTS AUTOMATED REGRESSION TESTING

    NEW FEATURES SCRIPT UPDATES
  22. We have tests coverage and now?

  23. Domain Driven Design (DDD)

  24. Domain Driven Design(DDD) Domain-driven design (DDD) is an approach to

    developing software for complex needs by deeply connecting the implementation to an evolving model of the core business concepts. • Place the project’s primary focus on the core domain and domain logic • Base complex designs on a model • Initiate a creative collaboration between technical and domain experts to iteratively cut ever closer to the conceptual heart of the problem. Source: https://dddcommunity.org/learning-ddd/what_is_ddd/
  25. We are trying to figure out the technique to divide

    services, what part of DDD can help us?
  26. Domain Driven Design - Bounded Context Bounded Context is a

    central pattern in Domain-Driven Design. It is the focus of DDD's strategic design section which is all about dealing with large models and teams. DDD deals with large models by dividing them into different Bounded Contexts and being explicit about their interrelationships. Source: https://martinfowler.com/bliki/BoundedContext.html
  27. We separated the responsibilities and now?

  28. Communication Patterns

  29. REST API REST API, EVERYWHERE

  30. Advanced Message Queuing Protocol (AMQP)

  31. Advanced Message Queuing Protocol (AMQP) • Introducing Message-Driven Programming with

    Low Level Events • Fire & Forget principle • Durable Messages (avoid Circuit Breakers & Retries) • Better Scale strategies & Application Decoupling • Fits well for 3rd partners integrations
  32. Advanced Message Queuing Protocol (AMQP) - Thoughts • Keep track

    of events otherwise you will have problems • We used retries to put message in the queue • Take care of the data into the message (security concerns)
  33. HTTP / gRPC

  34. HTTP / gRPC • HTTP Connections are stateful (avoid open

    & close) • Static Typed & Well Defined Contracts • Reduce serialization complexity & improve efficiency • Easy Peasy to integrate (there is code generation based in .proto) • Traffic is binary reduce bandwidth usage
  35. HTTP / gRPC - Thoughts • Load Balancing and Client

    Load Balancing • We used in the high throughput solution • By definition in general we use for internal communication (a.k.a East-West) • Not for humans, designed by machine communications
  36. HTTP / REST

  37. HTTP / REST • Well documented Style • “De-Facto” Pattern

    for Microservices Architecture • “Toolability” • Security
  38. HTTP / REST - Thoughts • Well documented Style •

    For Humans, fits very well for External APIs ( API Strategy ) • API Management provided by Sensedia offers interesting features to troubleshoot
  39. We have tests, responsibilities and communication! It is possible to

    improve more?
  40. Reactive Programming

  41. Reactive Programming Reactive programming is an asynchronous programming paradigm concerned

    with data streams and the propagation of change. • Easier to read, maintain and evolute • Low memory footprint • Scalability Source: https://en.wikipedia.org/wiki/Reactive_programming
  42. Reactive Programming Source: https://craftsmen.nl/memory-usage-6-popular-rest-server-frameworks-compared/

  43. Language

  44. Language Kotlin is fully compatible with all Java-based frameworks, which

    lets you stay on your familiar technology stack while reaping the benefits of a more modern language. • 40% less code = Easier to read, maintain and evolute • Fail fast principle = Time to Market Source: https://kotlinlang.org/docs/reference/server-overview.html
  45. Everything have been possible, because we formed a great Team

    Mindset
  46. Team Mindset In a fixed mindset, people believe their basic

    qualities, like their intelligence or talent, are simply fixed traits. Contrarily, in a growth mindset, people believe that their most basic abilities can be developed through dedication and hard work. Source: https://mindsetonline.com/whatisit/about/
  47. Team Mindset - Thoughts • Hands-on • Tech talks •

    Lightning talks • Events ◦ The Developer’s Conference (TDC) ◦ APIX ◦ Meetups
  48. We achieved the challenge! And now?

  49. None
  50. sensedia.com Monitoring & Observability

  51. Monitoring is the practice of collecting signals, telemetry, traces, etc

    and aggregating them, and matching them against some pre-defined criteria of system states we should carefully watch. When we find that one of our signals has crossed a threshold and may be heading toward a known bad state, we take action to remedy the system - Christian Posta
  52. Monitoring is a subset of Observability

  53. Observability on the other hand supposes up front that our

    systems are highly unpredictable and we cannot know all of the possible failure modes up front
  54. We need to collect much more data, even high-cardinality data

    like userIDs, requestIDs, source IPs, etc where the entire set could be exponentially large
  55. With observability, we need fine-grained data

  56. A user goes to pay for the items in their

    cart and experiences a 10s delay choosing a payment option. All of the pre-defined metric thresholds (disk usage, queue depth, machine health, etc) might be at acceptable levels
  57. sensedia.com

  58. Database Migration

  59. Database Migration SQL databases scale vertically, meaning you’ll need to

    increase the capacity of a single server (increasing CPU, RAM, or SSD) to scale your database. NoSQL databases scale horizontally, meaning you can add more servers to power your growing database. Source: https://www.thorntech.com/2019/03/sql-vs-nosql/
  60. Database Migration Microservice DB DB Synchronous, legacy Asynchronous, new Event

  61. Before & After

  62. Before

  63. After

  64. Summary 2º Place 1º Place 3º Place Last responsible moment

    • Decisions • Experience • Maturity Team mindset • Commitment • Opportunity to grow and learn • Feedbacks Technologies • Understand the technologies concepts • Business value
  65. Thanks a million! Questions? /larchanjo /luram-archanjo /claudioed /claudioed
