Diving into Android App Bundle

Android app bundle (.aab) it's a new publishing format for android apps. This presentation handles all that is involved from dynamic delivery, split APKs, bundletool and dynamic features.

Transcript

1. Omolara Adejuwon, Brainspace VG
   @_larikraun
   Lagos
   Diving into Android
   App Bundle


   View Slide

2. What is Android App Bundle?
   Lagos


   View Slide

3. The Android App Bundle (.aab) is a new
   upload/publishing format.
   It mirrors the .apk format with a little bit of
   ‘stew’ ;)


   View Slide

4. What is the need?
   ● It makes the support of different configurations
   better - Dynamic delivery
   ● Your users have a smaller APK to download
   ● It favors modularization i.e cleaner code base
   ● Leads us to dynamic features
   ● Google Play console handles the serving for you
   Lagos


   View Slide

5. Image source
   What’s inside App Bundle?


   View Slide

6. Dynamic Delivery
   Lagos


   View Slide

7. Dynamic delivery serves only those files to the
   users which they need and this is what allows us
   to make apps smaller


   View Slide

8. ● A fundamental component of Dynamic Delivery.
   ● Available on L+.
   ● With split APKs Google Play can break up a large app
   into smaller packages that are installed on a user's
   device based on device’s configuration
   Split APKs


   View Slide

9. ● Base APK: contains all common code and resources
   ● Configuration APKs: contains resources based on
   device’s config i.e locale, architecture, screen density
   ● Dynamic Feature APKs: contains codes that can be
   downloaded at a later time. This will be discussed later in
   the presentation.
   3 Kinds of Split APKs


   View Slide

10. Image source
    Screen density
    Architecture
    Locale
    Base APK Configuration APKs


    View Slide

11. Device Configuration = en + xxhdpi + arm64
    BASE
    ARM64
    XXHDPI
    EN


    View Slide

12. 12
    android{
    ...
    bundle {
    language {
    /* This property is set to true by default.
    Specifies that the app bundle should not support
    configuration APKs for language resources. These
    resources are instead packaged with each base and
    dynamic feature APK.*/
    enableSplit = false
    }
    density {
    enableSplit = true
    }
    abi {
    enableSplit = true
    }
    }
    }
    Version 3.2+
    +
    /app/build.gradle


    View Slide

13. ● Using Bundletool
    ● Google Play console - Internal test track
    Testing App Bundles
    * App Bundles are not installable until they are signed


    View Slide

14. 14
    java -jar bundletool build-apks --bundle=PATH_TO_APP_BUNDLE \
    --output=PATH_TO_OUTPUT_APKS --ks=PATH_TO_KEYSTORE \
    --ks-pass=pass:KEYSTORE_PASSWORD --ks-key-alias=KEY_ALIAS \
    --key-pass=pass:KEY_PASSWORD --overwrite
    Bundletool -> Generate APKs
    http://github.com/google/bundletool
    https://developer.android.com/studio/command-line/bundletool


    View Slide

15. 15
    java -jar bundletool install-apks --apks=PATH_TO_OUTPUT_APKS
    Bundletool -> Install on connected device
    http://github.com/google/bundletool
    https://developer.android.com/studio/command-line/bundletool


    View Slide

16. Enroll in Google Play App Signing
    Create and manage your releases - upload app bundle
    Google Play serves APKs to devices as required
    Publishing App Bundles


    View Slide

17. Dynamic Features
    Lagos


    View Slide

18. It allows you break your app into modules/features. Your
    app handles the download and installation of each module
    when the user needs it.
    The core of this mechanism is the Play core library.
    This further helps your initial app size really small


    View Slide

19. ● How many % of your users really need that feature?
    ● How large is the feature?
    ● Can your users wait a few seconds to download that
    feature?
    When to use dynamic features


    View Slide

20. 20
    Image source


    View Slide

21. Getting started with Dynamic Feature
    Lagos


    View Slide

22. View Slide

23. View Slide

24. app/build.gradle
    dynamicFeatures = [":module_one",":module_two"]
    Generated content


    View Slide

25. module/build.gradle
    apply plugin: 'com.android.dynamic-feature'
    dependencies {
    ...
    implementation project(':app')
    }
    Generated content


    View Slide

26. 26
    module/src/AndroidManifest.xml

    : you can provide your
    feature module’s title and other
    configurations
    Generated content


    View Slide

27. 27
    module/src/AndroidManifest.xml
    dist:onDemand="true"

    dist:onDemand=”true/false”: indication
    that this module is only available to the
    user when the user requests from the
    application
    Generated content


    View Slide

28. 28
    module/src/AndroidManifest.xml
    dist:onDemand="true"
    dist:title="@string/module_name">


    dist:include=”true/false”/>: indication
    that this module should be available to Pre
    L devices at first installation
    Generated content


    View Slide

29. Installing Dynamic Feature in app
    Lagos


    View Slide

30. app/build.gradle
    api 'com.google.android.play:core:1.3.5'
    Play core library makes it possible to install and manage modules


    View Slide

31. 31
    //create splitInstallManager
    val manager = SplitInstallManagerFactory.create(this)


    View Slide

32. 32
    val manager = SplitInstallManagerFactory.create(this)
    //check if module has already been installed
    if (manager.installedModules.contains(module_name)) {
    //load the module
    }


    View Slide

33. 33
    val manager = SplitInstallManagerFactory.create(this)
    if (manager.installedModules.contains(module_name)) {
    //load the module
    }
    // Create request to install a feature module by name.
    val request = SplitInstallRequest.newBuilder()
    .addModule(module_name)
    .build()


    View Slide

34. 34
    val manager = SplitInstallManagerFactory.create(this)
    if (manager.installedModules.contains(module_name)) {
    //load the module
    }
    // Create request to install a feature module by name.
    val request = SplitInstallRequest.newBuilder()
    .addModule(module_name)
    .build()
    // Load and install the requested feature module.
    manager.startInstall(request)
    .addOnSuccessListener {}
    .addOnFailureListener {}


    View Slide

35. 35
    val listener = SplitInstallStateUpdatedListener { state ->
    state.moduleNames().forEach { name ->
    // Handle changes in state.
    when (state.status()) {
    SplitInstallSessionStatus.DOWNLOADING -> {}
    SplitInstallSessionStatus.REQUIRES_USER_CONFIRMATION -> {
    /*This may occur when attempting to download a large module like 10MB */
    startIntentSender(state.resolutionIntent()?.intentSender, null, 0, 0, 0)
    }
    SplitInstallSessionStatus.INSTALLED -> {}
    SplitInstallSessionStatus.INSTALLING -> {}
    SplitInstallSessionStatus.FAILED -> {}
    }
    }
    }


    View Slide

36. 36
    //register the listener
    manager.registerListener(listener)
    //unregister the listener
    manager.unregisterListener(listener)


    View Slide

37. 37
    //defer installation of some modules
    manager.deferredInstall(modules).addOnSuccessListener {}
    //uninstall modules that are no more needed
    val installedModules = manager.installedModules.toList()
    manager.deferredUninstall(installedModules).addOnSuccessListener {}


    View Slide

38. 38
    ● https://developer.android.com/studio/projects/dynamic-delivery
    ● https://developer.android.com/studio/command-line/bundletool
    ● https://events.google.com/io/schedule/?section=may-8&sid=b9ea
    bde0-be05-492c-bf9e-c3f772f1db7e
    ● https://codelabs.developers.google.com/codelabs/your-first-dyn
    amic-app/index.html
    Useful Resources


    View Slide

39. Lagos
    Thank you!
    Omolara Adejuwon, Brainspace VG
    @_larikraun


    View Slide
