  1. INTRODUCTION TO ANDROID
    DEVELOPMENT
    Adejuwon Omolara
    Twitter: @_larikraun

    View Slide

  2. Overview
    • Android is a software stack for mobile devices that includes an
    operating system, middleware and key applications.
    • Android OS is divided into five sections
    • Applications: This is where applications to be installed are written. E.g. Games,
    Browser etc.
    • Application Framework: This layer provides many higher-level services to
    applications in the form of Java classes.
    • Android Runtime: This section provides a key component called Dalvik Virtual
    Machine. Dalvik VM enables every android application to run in its own process, with
    its own instance of the Dalvik VM. Dalvik VM is optimised to run on slow CPU, low
    RAM, low power devices. It runs .dex files and not .class nor .jar
    • Libraries: e.g. SQLite database, repository for storage and sharing of application.
    • Linux Kernel : it provides basic system functionality e.g. process management,
    device management etc.

    View Slide

  3. Platform Overview

    View Slide

  4. Android has evolved over the years :
    • Android 1.1 *Not relevant in the ecosystem*
    • Android 1.5 Cupcake *Not relevant in the ecosystem*
    • Android 1.6 Donut *Not relevant in the ecosystem*
    • Android 2.0/2.1 Eclair *Not relevant in the ecosystem*
    • Android 2.2.x Froyo *Not too relevant in the ecosystem*
    • Android 2.3.x Gingerbread *Still somewhat relevant in the ecosystem*
    • Android 3. x Honeycomb *Not relevant in the ecosystem*
    • Android 4.0.x Ice Cream Sandwich *Still quite relevant in the ecosystem*

    View Slide

  5. And now we have Lollipop…

    View Slide

  6. Tools you need to get started…
    • A fair knowledge of Java
    • Latest Java Development Kit (JDK) : Android Apps are
    developed using Java.
    http://www.oracle.com/technetwork/java/javase/downloads/inde
    x.html
    • Eclipse Integrated Development Environment (IDE)
    https://www.eclipse.org/downloads/ or any other suitable
    IDE.
    • Android SDK
    http://developer.android.com
    • ADT Tools for Eclipse (via Internet)

    View Slide

  7. Application Components
    Applications use four main components:
    • Activity
    • Service
    • Broadcast Receivers
    • Content Providers

    View Slide

  8. Activity
    Activities: A single screen that is visible to user. They dictate the UI and
    handle the user interaction to the smartphone screen.
    public class MainActivity extends Activity {
    }

    View Slide

  9. Activity Lifecycle

    View Slide

  10. Services
    Services: They handle background processes associated with an
    application. They can be used to update an application when it’s not
    active.
    public class MyService extends Service {
    }

    View Slide

  11. Service Lifecycle

    View Slide

  12. Broadcast Receiver
    Broadcast Receivers: They handle communication between Android OS
    and applications. They listen for android system events.
    public class MyReceiver extends BroadcastReceiver {
    }

    View Slide

  13. Content Providers
    Content Providers: They handle and manage data, usually stored in
    database and data access for queries.
    public class MyContentProvider extends ContentProvider {
    }

    View Slide

  14. More Components…
    • Fragments: Represents a behaviour or a portion of user
    interface.
    • Views: UI elements that are drawn onscreen. They are
    responsible for event handling e.g. ContextMenu, Menu etc.
    • Widgets: They are more advanced UI elements e.g Button,
    CheckBox, ImageView etc.
    • Layouts: View hierarchies that control screen format and
    appearance of the views.

    View Slide

  15. • Intents: Messages wiring components together. An intent
    is composed of an action it needs to perform. They are
    used to start activities and to communicate among various
    parts of the android system.
    • Resources: External elements such as strings, drawables
    and constants
    • Manifest: Configuration file for the application.

    View Slide

  16. Layout Manager
    It is responsible for the layout of itself and its child Views.
    Android supports different default layout managers. To get
    a desired layout, there are some few terms you would
    come across.
    ✔ android:layout_width defines the width of the widget.
    ✔ android:layout_heigth defines the height of the widget.
    ✔ match_parent tells the application to maximize the widget
    in its parent.
    ✔ wrap_content tells the layout to allocate the minimum
    amount so that the widget is rendered correctly.

    View Slide

  17. Image source: vogella

    View Slide

  18. Who doesn’t like easy tasks? Well, I
    do…
    Google exposes a number of functionalities in android. To
    create spectacular apps, you should make use of them.
    • Touchscreen
    • GPS
    • Accelerometer
    • Internet
    • Audio and Video support
    • Contacts
    • Security
    • Google APIs

    View Slide

  19. API levels
    This is an integer value that uniquely identifies the
    framework API revision offered by a version of the android
    platform.
    ✔ It lets the android platform describe the maximum
    framework API revision that it supports.
    ✔ It lets applications describe the framework API revision
    that they require.
    ✔ It lets the system negotiate the installation of applications
    on the user’s device such that version-incompatible are
    not installed.
    You can catch more gist on API levels here

    View Slide

  20. View Slide

  21. Image source: Android’s site

    View Slide

  22. My One-Dollar
    To write a working android application, you need to
    consider keeping it simple. Nobody likes a
    complex-for-nothing application. I encourage drawing
    mock-ups ( a visual representation of how you want the
    application to look like), flow charts ( a step-by-step
    approach to achieving your goal) as one of the first steps
    before jumping on your IDE.
    You will need to step up your UI/UX game to ‘wow’ your
    users.

    View Slide

  23. I think these will help too
    • Make Google your friend
    • Get familiar with android developers’ site
    • Read documentations before using any API
    • Join forums that will help. One of the most popular is
    stackoverflow
    • Get close to the ‘gurus’- they have a lot to offer.
    • Read books that will help.

    View Slide

  24. My ‘Hello World’ Application
    This is a dummy application that just displays ‘Hello World,
    MyFirstApp’
    ✔ MyFirstApp.java + main.xml =

    View Slide

  25. MyFirstApp.java

    View Slide

  26. The main.xml file

    View Slide

  27. AndroidManifest.xml

    View Slide

  28. ✔ package attribute defines the base package for the Java objects referred to in
    a particular file.
    ✔ android:versionCode must be an integer. You typically start from ‘1’ and
    increase the value by one if you roll-out a new version of your application.
    ✔ android:versionName is what the users see. It can be any string.
    ✔ android:minSdkVersion defines the minimum version of android your
    applicaton works on. A user cannot install your application on a device with a
    lower API level than specified in this attribute.
    ✔ android:targetSdkVersion specifies the version on which you tested and
    developed. It is a good practice to always set this to the latest Android API
    version.

    View Slide

  29. ✔ section is a container for declaring android components.
    ✔ tag defines an activity component.
    ✔ android:name="android.intent.action.MAIN" can be started and the category
    ✔ android:name="android.intent.category.LAUNCHER“ parameter tells the
    Android system to add the activity to the launcher.

    View Slide

  30. Questions???
