How to use a JVM library in node.js

Transcript

1. Laurynas Lubys, backend developer @ Wix
   How to use a JVM library
   in node.js
   laurynasl@wix.com linkedin.com/in/laurynaslubys github.com/laurynasl-wix


   View Slide

2. AGENDA
   Interop 101
   Sync interop
   Async interop


   View Slide

3. How to use a JVM library
   in node.js


   View Slide

4. The docs
   ▪ https://github.com/graalvm/graaljs/blob/master/docs/user/JavaInterop.md
   ▪ https://www.graalvm.org/docs/reference-manual/languages/js/
   INTEROP 101


   View Slide

5. INTEROP 101
   Graal
   JVM Compiler Interface
   JVM Runtime
   Truffle
   Drop in replacement for
   node.js (mostly compatible
   with existing libs)
   TLDR;


   View Slide

6. JVM interop enabled with
   --jvm
   INTEROP 101
   Graal
   JVM Compiler Interface
   JVM Runtime
   Truffle
   Drop in replacement for
   node.js (mostly compatible
   with existing libs)
   TLDR;


   View Slide

7. TLDR;
   INTEROP 101
   Graal
   JVM Compiler Interface
   JVM Runtime
   Truffle
   Most cross language calls do
   not need conversions at
   runtime
   JVM interop enabled with
   --jvm
   Drop in replacement for
   node.js (mostly compatible
   with existing libs)


   View Slide

8. hello-world.js
   const System =
   Java.type("java.lang.System");
   System.out.println("Hello world!");
   INTEROP 101
   Java
   Graal
   global scope
   JVM


   View Slide

9. hello-world.js
   node --jvm hello-world.js
   > Hello world!
   const System =
   Java.type("java.lang.System");
   System.out.println("Hello world!");
   INTEROP 101
   run it!
   Java
   Graal
   global scope
   JVM


   View Slide

10. How to use a JVM library
    in node.js
    Use case #1
    Sync
    interop


    View Slide

11. SYNC
    INTEROP
    Use case #1
    bcrypt
    A CPU intensive hashing function


    View Slide

12. Use case #1
    The Goal
    bcrypt
    SYNC
    INTEROP
    ▪ Use the JVM bcrypt library in node.js
    ▪ Integrate it into our server to handle user logins


    View Slide

13. bcrypt
    SYNC
    INTEROP
    The Plan
    1. Tell the JVM where to find the jar
    2. Call it from node
    3. Use it in our application
    4. Go home early


    View Slide

14. SYNC
    INTEROP
    1. Tell the JVM where to find the jar
    2. Call it from node
    3. Use it in our application
    4. Go home early
    --vm.cp Java.addToClasspath(path)
    OR


    View Slide

15. SYNC
    INTEROP
    1. Tell the JVM where to find the jar
    2. Call it from node
    3. Use it in our application
    4. Go home early
    --vm.cp Java.addToClasspath(path)
    OR
    We’ll specify the classpath
    manually with --vm.cp


    View Slide

16. SYNC
    INTEROP
    1. Tell the JVM where to find the jar
    2. Call it from node
    3. Use it in our application
    4. Go home early
    const BCrypt =
    Java.type("org.mindrot.jbcrypt.BCrypt");
    const salt =
    "$2a$10$sfMWTWROyUu5JxTEwm413u";
    const hash = BCrypt.hashpw("Hello", salt);
    console.log(hash);
    bcrypt.js


    View Slide

17. SYNC
    INTEROP
    1. Tell the JVM where to find the jar
    2. Call it from node
    3. Use it in our application
    4. Go home early
    const BCrypt =
    Java.type("org.mindrot.jbcrypt.BCrypt");
    const salt =
    "$2a$10$sfMWTWROyUu5JxTEwm413u";
    const hash = BCrypt.hashpw("Hello", salt);
    console.log(hash);
    bcrypt.js
    FLAGS="\
    --jvm \
    --vm.cp=./jbcrypt-0.3m.jar"
    node $FLAGS bcrypt.js
    > $2a$1...ugoQ3u/Mjb/CYi
    run it!


    View Slide

18. SYNC
    INTEROP
    1. Tell the JVM where to find the jar
    2. Call it from node
    3. Use it in our application
    4. Go home early
    const BCrypt =
    Java.type("org.mindrot.jbcrypt.BCrypt");
    const salt =
    "$2a$10$sfMWTWROyUu5JxTEwm413u";
    app.post('/login', (req, res) => {
    const pass = req.query.password;
    res.send(BCrypt.hashpw(pass, salt));
    });
    app.js


    View Slide

19. Demo time!
    SYNC
    INTEROP


    View Slide

20. Cool, ship it!
    SYNC
    INTEROP


    View Slide

21. 1. Tell the JVM where to find the jar
    2. Call it from node
    3. Use it in our application
    4. Go home early
    We blocked the event loop
    SYNC
    INTEROP


    View Slide

22. 1. Tell the JVM where to find the jar
    2. Call it from node
    3. Use it in our application
    4. Go home early
    We blocked the event loop
    fortunately...
    The node community
    knows how to deal with
    blocking workloads
    SYNC
    INTEROP


    View Slide

23. 1. Tell the JVM where to find the jar
    2. Call it from node
    3. Use it in our application
    4. Go home early
    We blocked the event loop
    fortunately...
    The node community
    knows how to deal with
    blocking workloads
    so
    We can create a pool of workers
    and do the work there
    SYNC
    INTEROP


    View Slide

24. How to use a JVM library
    in node.js
    Not so trivial,
    but it works
    Use case #2
    Sync
    interop
    Async
    interop


    View Slide

25. Use case #2
    ASYNC
    INTEROP
    rabbitmq
    The Goal
    ▪ Consume messages from rabbitmq
    ▪ We want to use the rabbitmq “push API”


    View Slide

26. ASYNC
    INTEROP
    rabbitmq
    The Plan
    1. Figure out how to do callbacks with Graal
    2. Define the Java API
    3. Handle a rabbitmq message in node


    View Slide

27. ASYNC
    INTEROP
    callback.js
    1. Figure out how to do callbacks with Graal
    3. Handle a rabbitmq message in node
    2. Define the Java API
    const Arrays = Java.type("java.util.Arrays");
    const javaList = Arrays.asList(1, 2);
    javaList.stream()
    .map(v => `In node: ${v}`)
    .forEach(console.log);


    View Slide

28. const Arrays = Java.type("java.util.Arrays");
    const javaList = Arrays.asList(1, 2);
    javaList.stream()
    .map(v => `In node: ${v}`)
    .forEach(console.log);
    callback.js
    run it!
    ASYNC
    INTEROP
    node --jvm callback.js
    > In node: 1
    > In node: 2
    1. Figure out how to do callbacks with Graal
    2. Define the Java API
    3. Handle a rabbitmq message in node


    View Slide

29. ASYNC
    INTEROP
    interface MessageQueue {
    void init();
    void addConsumer(
    String queueName,
    Handler handler
    );
    interface Handler {
    void handle(String message);
    }
    }
    1. Figure out how to do callbacks with Graal
    2. Define the Java API
    3. Handle a rabbitmq message in node


    View Slide

30. ASYNC
    INTEROP
    const RabbitMQ = Java.type("mq.RabbitMQ");
    const mq = new RabbitMQ();
    mq.init();
    const handle = console.log;
    mq.addConsumer("hello-rabbit", handle);
    1. Figure out how to do callbacks with Graal
    2. Define the Java API
    3. Handle a rabbitmq message in node


    View Slide

31. Demo time!
    ASYNC
    INTEROP


    View Slide

32. We can’t call JS from another thread
    Java
    function
    ASYNC
    INTEROP


    View Slide

33. bindCallback
    Java
    function
    ASYNC
    INTEROP


    View Slide

34. GraalJS does not provide that
    out of the box
    ASYNC
    INTEROP


    View Slide

35. Let’s see what we can do about that
    GraalJS does not provide that
    out of the box
    ASYNC
    INTEROP


    View Slide

36. InteropBus
    Async Java code
    pending
    complete( )
    ( , )
    We want to call with async results from java.
    node.js
    worker
    node.js
    Java land
    bindCallback
    on(‘message’)


    View Slide

37. 4. implement handlers that can be called from a different thread
    ASYNC
    INTEROP
    1. Figure out how to do callbacks with Graal
    2. Define the Java API
    3. Handle a rabbitmq message in node


    View Slide

38. class JSHandler implements MessageQueue.Handler {
    BoundJSCallback jsCallback;
    JSHandler(BoundJSCallback jsCallback) {
    this.jsCallback = jsCallback;
    }
    @Override
    void handle(String message) {
    jsCallback.apply(new Object[]{message});
    }
    }
    JSHandler.java
    ASYNC
    INTEROP


    View Slide

39. const RabbitMQ = Java.type("mq.RabbitMQ");
    const mq = new RabbitMQ();
    mq.init();
    const JSHandler = Java.type("mq.JSHandler");
    const {bindCallback} = require("../../interop");
    const handle =
    new JSHandler(bindCallback(console.log));
    mq.addConsumer("hello-rabbit", handle);
    Take #2
    ASYNC
    INTEROP


    View Slide

40. Demo time!
    ASYNC
    INTEROP


    View Slide

41. Not so trivial,
    but it works
    Works, not straightforward,
    mostly infrastructure
    Sync
    interop
    Async
    interop


    View Slide

42. Questions?
    laurynasl@wix.com linkedin.com/in/laurynaslubys github.com/laurynasl-wix
    github.com/laurynasl-wix/graal-jvm-interop-talk


    View Slide

43. Thank You
    laurynasl@wix.com linkedin.com/in/laurynaslubys github.com/laurynasl-wix
    github.com/laurynasl-wix/graal-jvm-interop-talk


    View Slide
