Mental Modles of Jetpack Compose

With the raise of declarative UI, Jetpack Compose just might be the future of creating UI for Android. While the API is far from stable, there are already a lot of things that we can learn from other UI framework over the years, like React, Vue, and more recently, Flutter and SwiftUI.

Join me to learn some fundamental concepts (mental models) of this new way of building UI, and hopefully, when the time comes, you will be able to write idiomatic declarative UI with Jetpack Compose!

Transcript

1. Mental Models of Jetpack Compose @louis993546
2. Google I/O 2019 @louis993546
3. import androidx.compose.* import androidx.ui.core.* @Composable fun Greeting(name: String) { Text ("Hello $name!") } @louis993546
4. 1. Mental Model 2. Programming Paradigm 3. Inheritance 4. Composition 5. Reactive Declarative UI 6. Component 7. Functional component 8. Hindsight @louis993546
5. 1. Mental Model @louis993546
6. A mental model is an explanation of someone's thought process about how something works in the real world. -- Wikipedia @louis993546
7. 2. Programming Paradigm @louis993546
8. State Visibility Data Flags @louis993546
9. @louis993546
10. val linearLayout = LinearLayout(context).apply { orientation = LinearLayout.VERTICAL } linearLayout.addView( TextView(context).apply { text = "Hello, World" } ) linearLayout.addView( ImageView(context).apply { imageResource = R.drawable.star } ) @louis993546
11. val linearLayout = LinearLayout(context).apply { orientation = LinearLayout.VERTICAL } // a statement (instruction) linearLayout.addView( TextView(context).apply { text = "Hello, World" } ) // another statement (instruction) linearLayout.addView( ImageView(context).apply { imageResource = R.drawable.star } ) // yet another statement (instruction) @louis993546
12. Imperative programming val linearLayout = LinearLayout(context).apply { orientation = LinearLayout.VERTICAL } // a statement (instruction) linearLayout.addView( TextView(context).apply { text = "Hello, World" } ) // another statement (instruction) linearLayout.addView( ImageView(context).apply { imageResource = R.drawable.star } ) // yet another statement (instruction) @louis993546
13. <LinearLayout orientation="vertical"> <TextView android:text="Hello, World"/> <ImageView android:src="@drawable/star"/> </LinearLayout> @louis993546
14. <!-- beginning of definition --> <LinearLayout orientation="vertical"> <TextView android:text="Hello, World"/> <ImageView android:src="@drawable/star"/> </LinearLayout> <!-- end of definition --> @louis993546
15. Declarative programming <!-- beginning of definition --> <LinearLayout orientation="vertical"> <TextView android:text="Hello, World"/> <ImageView android:src="@drawable/star"/> </LinearLayout> <!-- end of definition --> @louis993546
16. Declarative programming <ConstraintLayout> <ImageView android:id="image_view" android:src="@drawable/star" app:layout_constraintBottom_toBottomOf="parent" app:layout_constraintTop_toBottomOf="@+id/text_view"/> <TextView android:id="text_view" android:text="Hello, World" app:layout_constraintTop_toTopOf="parent" app:layout_constraintBottom_toTopOf="@id/image_view"/> </ConstraintLayout> @louis993546
17. 3. Inheritance @louis993546
18. @louis993546
19. Animal @louis993546
20. Animal @louis993546
21. @louis993546
22. Commonalities Breath Walk Work Take over the world Blep Blop ✅ ✅ ✅ ✅ ✅ ✅ ✅ ✅ @louis993546
23. Commonalities Breath Walk Work Take over the world Blep Blop ✅ ✅ ✅ ✅ ✅ ✅ ✅ ✅ Animal @louis993546
24. Commonalities Breath Walk Work Take over the world Blep Blop Blup ✅ ✅ ✅ ✅ ✅ ✅ ✅ ✅ ✅ ✅ ✅ ✅ @louis993546
25. @louis993546
26. @louis993546
27. @louis993546
28. 4. Composition @louis993546
29. Commonalities Breath Walk Work Take over the world Blep Blop Blup ✅ ✅ ✅ ✅ ✅ ✅ ✅ ✅ ✅ ✅ ✅ ✅ @louis993546
30. Commonalities Breath Walk Work Take over the world Blep Blop Blup ✅ ✅ ✅ ✅ ✅ ✅ ✅ ✅ ✅ ✅ ✅ ✅ @louis993546
31. class : Breathable, Walkable, Workable, Blopable class : Breathable, Walkable, TakeOverTheWorldable, Blepable class : Walkable, Workable, TakeOverTheWorldable, Blupable @louis993546
32. class : Breathable, Walkable, Workable, Blopable class : Breathable, Walkable, TakeOverTheWorldable, Blepable class : Walkable, Workable, TakeOverTheWorldable, Blupable class : Breathable, Blupable @louis993546
33. 5. Reactive Declarative UI @louis993546
34. @louis993546 S A B C D F ? XML ? ? ? ?
35. @louis993546 S A B C D F ? XML ? ? ? ?
36. Google I/O 2015 @louis993546
37. <layout> <data> <variable name="user" type="com.example.User"/> </data> <LinearLayout android:orientation="vertical"> <TextView android:text="@{user.firstName}"/> <View android:visibility="@{user.age > 18 ? View.GONE : View.VISIBLE}" /> </LinearLayout> </layout> @louis993546
38. S A B C D F ? XML Data Binding ? ? ? @louis993546
39. JSConf US 2013 @louis993546
40. Composition Declarative Programming + @louis993546
41. React.js Move markup into logic Data Binding Move logic into markup @louis993546
42. // a JavaScript file class HelloWorld extends React.Component { render() { // ↓ HTML ↓ JS ↓ Back to HTML return <h1>Hello, {this.props.target}!</h1> } } @louis993546
43. UI = f(state) @louis993546
44. sealed class ViewState { data class Success(val data: List<User>) : ViewState() data class Error(val error: Throwable) : ViewState() } viewStateLiveData.observe(this) { viewState -> when (viewState) { is Success -> { ... } is Error -> { ... } } } @louis993546
45. WWDC 2019 @louis993546
46. 6. Component @louis993546
47. class HelloWorld extends React.Component { render() { return ( <h1>Hello, {this.props.target}!</h1> ) } } class HelloWorld extends React.Component { constructor(props) { super(props); this.state = {target: "World"} } componentDidMount() { console.log('mounting......') } componentWillUnmount() { /* ... */ } render() { return ( <h1>Hello, {this.state.target}!</h1> ) } } @louis993546
48. @louis993546
49. 1. Notify someone when click 2. Have a background 3. Display Text 1. Notify someone when click 2. Have a background 3. Display Image @louis993546
50. 1. Notify someone when click 2. Have a background 3. Display Text 1. Notify someone when click 2. Have a background 3. Display Image @louis993546
51. 1. Notify someone when click 2. Have a background 3. Display something @louis993546
52. 1. Notify someone when click 2. Have a background 3. Display anything @louis993546
53. //... FloatingActionButton( onPressed: () { // Add your onPressed code here! }, child: Icon(Icons.navigation), backgroundColor: Colors.green, ), //... @louis993546
54. //... FloatingActionButton( onPressed: () { // Add your onPressed code here! }, child: Text('¯\_(ツ)_/¯'), backgroundColor: Colors.green, ), //... @louis993546
55. class HelloWorld extends React.Component { render() { if (this.props.isFormal) { return /* 2000 lines of very complex layout #1 */ } return /* 2000 lines very complex layout #2 */ } } @louis993546
56. class FormalHelloWorld extends React.Component { render() { return /* 2000 lines of very complex layout #1 */ } } class InformalHelloWorld extends React.Component { render() { return /* 2000 lines of very complex layout #2 */ } } @louis993546
57. Why now? • Better IDE (Autocomplete, linter, etc.) • Better performance -> Better developer ergonomics • Better languages (type inference, lambda/closure, etc.) ◦ JavaScript ◦ TypeScript/Flow ◦ Dart ◦ Swift ◦ Kotlin ◦ (Java 10+) • etc. @louis993546
58. @louis993546 S A B C D F Flutter XML Data Binding React Compose SwiftUI
59. 7. Functional component @louis993546
60. class HelloWorld extends React.Component { constructor(props) { super(props); this.state = {target: "World"} } componentDidMount() { console.log('mounting......') } componentWillUnmount() { /* ... */ } render() { return ( <h1>Hello, {this.state.target}!</h1> ) } } @louis993546
61. UI = f(state) @louis993546
62. class HelloWorld extends React.Component { constructor(props) { super(props); this.state = {target: "World"} } componentDidMount() { console.log('mounting......') } componentWillUnmount() { /* ... */ } render() { return ( <h1>Hello, {this.state.target}!</h1> ) } } @louis993546
63. function HelloWorld(props) { const [target, setTarget] = useState("World") useEffect(() => log()) return <h1>Hello, {target}!</h1> } function log() { console.log('mounting......') } @louis993546 class HelloWorld extends React.Component { constructor(props) { super(props); this.state = {target: "World"} } componentDidMount() { console.log('mounting......') } componentWillUnmount() { /* ... */ } render() { return ( <h1>Hello, {this.state.target}!</h1> ) } } →
64. function HelloWorld(props) { const [target, setTarget] = useState("World") useEffect(() => log()) return <h1>Hello, {target}!</h1> } function log() { console.log('mounting......') } function HelloWorld2(props) { // ... log() // ... } @louis993546 class HelloWorld extends React.Component { constructor(props) { super(props); this.state = {target: "World"} } componentDidMount() { console.log('mounting......') } componentWillUnmount() { /* ... */ } render() { return ( <h1>Hello, {this.state.target}!</h1> ) } } →
65. ReactConf 2018 @louis993546
66. 8. Hindsight @louis993546
67. perception of the nature of an event after it has happened -- Merriam-Webster @louis993546
68. “Read later” • ${React.js stuff} ◦ React hooks • ${Flutter stuff} ◦ Material Components widgets • Architecture-stuff ◦ “Events & Data” ◦ MVI, BLoC, etc. ◦ Redux, MobX, etc. • Kotlin extension properties • Kotlin IR • Kotlin compiler plugin • How suspend function compiles • Virtual DOM @louis993546
69. “Read later” • ${React.js stuff} ◦ React hooks • ${Flutter stuff} ◦ Material Components widgets • Architecture-stuff ◦ “Events & Data” ◦ MVI, BLoC, etc. ◦ Redux, MobX, etc. • Kotlin extension properties • Kotlin IR • Kotlin compiler plugin • How suspend function compiles • Virtual DOM @louis993546 https://bit.ly/2kVVO93
70. @louis993546
