Micro Frontends with Module Federation: Beyond the Basics

# Example
https://github.com/manfredsteyer/adv-mf-examples

# Free eBook on Angular Architectures
https://www.angulararchitects.io/book

Transcript

1. @ManfredSteyer ManfredSteyer Micro Frontends with Module Federation: Beyond the Basics Manfred Steyer, ANGULARarchitects.io
2. @ManfredSteyer Booking App Booking App Check-in App Check-in App Boarding App Boarding App Luggage App Luggage App
3. @ManfredSteyer
4. @ManfredSteyer
5. @ManfredSteyer
6. @ManfredSteyer const Component = await import('other-app/cmp');
7. @ManfredSteyer #1 Version Mismatches #2 Mono vs. Multirepo #3 Dynamic Federation #4 Multiple Frameworks/ Versions
8. @ManfredSteyer #1 Version Mismatches #2 Mono vs. Multirepo #3 Dynamic Federation #4 Multiple Frameworks/ Versions #0 Module Federation 101
9. @ManfredSteyer Manfred Steyer
10. @ManfredSteyer
11. @ManfredSteyer Shell (Host) Microfrontend (Remote) // Maps Urls in // webpack config remotes: { mfe1: "http://..." } // Expose files in // webpack config exposes: { './Cmp': './my.cmp.ts' } import('mfe1/Cmp')
12. @ManfredSteyer Shell (Host) Microfrontend (Remote) shared: [ "@angular/core", "…" ] shared: [ "@angular/core", "…" ]
13. @ManfredSteyer 1) ng add @angular-architects/module-federation 2) Adjust generated configuration 3) ng serve
14. @ManfredSteyer
15. @ManfredSteyer
16. @ManfredSteyer Selecting the highest compatible version 10.0 10.1
17. @ManfredSteyer Conflict: No highest compatible version 11.0 10.1
18. @ManfredSteyer shared: { "my-lib": { singleton: true } } 11.0 10.1
19. @ManfredSteyer shared: { "my-lib": { singleton: true, strictVersion: true // Error instead of warning! } } 11.0 10.1
20. @ManfredSteyer shared: { "my-lib": { requiredVersion: ">=1.0.1 <11.1.1" } }
21. @ManfredSteyer •Several options baked-in •However, best option: avoid conflicts upfront
22. @ManfredSteyer
23. @ManfredSteyer Booking Booking Boarding Boarding Shared Shared Feature Feature Feature Feature Feature Feature Feature Feature Feature Feature … … … … … … … … … … … … … … … … … … Booking App Booking App Boarding App Boarding App Publish shared libs seperately via npm Repository n Repository 2 Repository 1 Version Mismatches? Strict Borders
24. @ManfredSteyer Booking Booking Boarding Boarding Shared Shared Feature Feature Feature Feature Feature Feature Feature Feature Feature Feature … … … … … … … … … … … … … … … … … … Booking App Booking App Boarding App Boarding App
25. @ManfredSteyer
26. @ManfredSteyer
27. @ManfredSteyer https://nrwl.io/nx
28. @ManfredSteyer
29. @ManfredSteyer Dynamic Module Federation Shell (Host) Microfrontend (Remote) remotes: { mfe1: "http://..." } exposes: { Cmp: './my.cmp.ts' } import('mfe1/Cmp')
30. @ManfredSteyer Dynamic Module Federation Shell (Host) Microfrontend (Remote) remotes: { } exposes: { Cmp: './my.cmp.ts' } import('mfe1/Cmp')
31. @ManfredSteyer Dynamic Module Federation Shell (Host) Microfrontend (Remote) remotes: { } exposes: { Cmp: './my.cmp.ts' } loadRemoteModule({ type: 'module', remoteEntry: 'http://…', exposedModule: './Cmp' })
32. @ManfredSteyer Dynamic Module Federation Shell (Host) Microfrontend (Remote) remotes: { } exposes: { Cmp: './my.cmp.ts' } loadRemoteModule({ type: 'module', remoteEntry: 'http://…', exposedModule: './Cmp' }) Helper Function using the Webpack API
33. @ManfredSteyer
34. @ManfredSteyer
35. @ManfredSteyer const Component = await import('other-app/cmp');
36. @ManfredSteyer const main = await import('other-app/main'); main.bootstrap();
37. @ManfredSteyer const main = await import('other-app/main'); main.bootstrap(); const rootElm = document.createElement('app-root') document.body.appendChild(rootElm);
38. @ManfredSteyer await import('other-app/main'); // Self-Bootstrapping const rootElm = document.createElement('app-root') document.body.appendChild(rootElm);
39. @ManfredSteyer await import('other-app/main'); const rootElm = document.createElement('app-root') document.body.appendChild(rootElm); WrapperComponent
40. @ManfredSteyer
41. @ManfredSteyer
42. @ManfredSteyer
43. @ManfredSteyer https://red-ocean-0fe4c4610.azurestaticapps.net
44. @ManfredSteyer Free eBook ANGULARarchitects.io/book Updated for Module Federation and Alternatives
45. @ManfredSteyer Conclusion Baked-in Strategies for Version Mismatches Baked-in Strategies for Version Mismatches Monorepo vs. Multirepo: Self-restriction vs. (Costly) Freedom Monorepo vs. Multirepo: Self-restriction vs. (Costly) Freedom Webpack Runtime API: Dynamic Federation Webpack Runtime API: Dynamic Federation Frankenstein: Bootstrapping Several SPAs Frankenstein: Bootstrapping Several SPAs
46. @ManfredSteyer d Slides & Examples Remote Company Workshops and Consulting http://angulararchitects.io
